LLM0102WA3001A11Mbps WLAN Access Point

Quick Installation Guide of WLAN 11Mbps Access Point WA3001A Eumitcom Eumticom Technlolgy Inc. 2 Federal Communications Commission Statement This device complies with FCC Rules Part 15. Operation is subject to the following two conditions: This device may not cause harmful interference. This device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy. If this equipment is not installed and used in accordance with the manufacturer's instructions, it may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by during the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: ! Reorient or relocate the receiving antenna. ! Increase the separation between the equipment and receiver. ! Connect the equipment to an outlet on a circuit different from that to which the receiver is connected. ! Consult the dealer or an experienced radio/TV technician for help. The use of shielded cables for connection of the monitor to the graphics card is required to assure compliance with FCC regulations. Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. FCC Radiation Exposure Statement This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator and your body. Manufacturer's Disclaimer Statement The information in this document is subject to change without notice and does not represent a commitment on the part of the vendor. No warranty or representation, either expressed or implied, is made with respect to the quality, accuracy or fitness for any particular purpose of this document. The manufacturer reserves the right to make changes to the content of this document and/or the products associated with it at any time without obligation to notify any person or organization of such changes. In no event will 3 the manufacturer be liable for direct, indirect, special, incidental or consequential damages arising out of the use or inability to use this product or documentation, even if advised of the possibility of such damages. This document contains materials protected by copyright. All rights are reserved. No part of this manual may be reproduced or transmitted in any form, by any means or for any purpose without expressed written consent of its authors. Product names appearing in this document are mentioned for identification purchases only. All trademarks, product names or brand names appearing in this document are registered property of their respective owners. This device requires a radio license, unless it (including antenna ) is installed totally inside a building. (User must obtain this license from Industry Canada ). “To reduce potential radio interference to other users, the antenna type and its gain should be so chosen that the equivalent isotropically radiated power (EIRP) is not more than that required for successful communication.” Printed in Taiwan 1 Introduction WA3001A is an 11Mbps Access Point that bridges between wired Local Area Network and one or more wireless mobile PC based stations. Connected to the Ethernet backbone through RJ-45 connector, the single Access Point wirelessly provides multiple data access with verity of mobile desktop or laptop PC in covered propagation range. The Serial of Wireless LAN products offer a fast, reliable, cost-effective solution. I. Release package 1. One Access Point 2. One Power Adapter (9V/1.11A) 3. One Floppy Diskette 2 II. Hardware Installation 1. Connect the AP RJ45 port to a Ethernet 10BaseT Hub. 2. Connect the power adapter to power source and plug it into power hole of AP. III. Software Installation Following descriptions describe the steps to install the AP Utility 1. Power on the PC and boot it to the windows system 2. Insert the floppy diskette to the floppy driver. 3. Type the “A:\Utility\setup.exe” to start the Installation. 4. Follow the setup wizard to complete the setup process. IV. Access Point Setup and Configure After AP Utility is installed, you may start to setup and configure the AP. You could choose to configure the AP through the Ethernet or WLAN. If you want to configure the AP by WLAN, you should have a WLAN PC or PCI adapter installed and associate with the AP in advance. The default SSID of AP is “WLAN”. 1. Lunch the WLAN AP Utility program from “ Access Point Utility” Folder. 2. Click item “Scan” under the menu item “AP” in the utility program to search the AP in network. 3 3. If an AP is detected, the utility program will show the AP information . 4. Double click the found AP from the list table. 5. Input the IP Address, subnet mask and default gateway correctly, click the “OK” button, you MUST assign the AP IP address with the value that is located within the same subnet of the configured PC. V. Hardware Specification Radio: Complies with IEEE 802.11 Frequency Band: 2400 ~ 2483.5MHz ( for US, Canada, and ETSI) 2400 ~ 2497MHz (for Japan) Modulation TYPE: CCK,BPSK,QPSK Operating Channels: IEEE 802.11 compliant 11 channels (US, Canada) 13 channels (ETSI) 14 channels (Japan) Radio Technology: Direct Sequence Spread Spectrum Data Rate: 1 / 2 / 5.5 / 11 Mbps Output Power: > +15dBm Receive sensitivity: Min. -78dBm for 11Mbps; Min. -82dBm for 5.5/2/1 Mbps ;(@BER 10E-5) Eth…

Text truncated - open the document above for the full version.

Eumitcom Technology Inc. WA3001A AP BLOCK DIAGRAM RF/IF Converter HFA3683A Quad IF HFA3783A DSSS Baseband Processor HFA3861A Ethernet to Wireless Bridge AT76C510 BPF BPFBPF BPF 44 MHz OSC. RF PA MA02303 BPF FL15 1st LO DMP-VCX2074S6 2nd LO DMP-VCX748S6 T/R SW I Q I Q TX RX Flash 512Kx8 AT29LV040A SRAM 512Kx8 AS7C3409 LDO MIC5205-2.8BM5 O/P: 2.8V RFSW UPG-152TA-E3 LDO AME1117ACCT ANT SWITCH ANT ANT Ethernet physical chip SEEQ 8225 RJ-45 CONNCTER 25 MHz OSC. 33 MHz OSC. 5V DC JACK

Report No.: RF900215051Issued: February 26, 2001 ANNEX 3 PHOTOGRAPHS OF EUT Report No.: RF900215052Issued: February 26, 2001 Report No.: RF900215059Issued: February 26, 2001 Report No.: RF9002150510Issued: February 26, 2001

WA3001A FCC ID label: 1. The FCC ID label will paste in the bottom side of the product.( See figure below) MODEL : WA3001A FCC ID: LLM0102WA3001A Canada ID: XXXXXXXXXXXXXX THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES.OPERATIONS IS SUBJECT TO THE FOLLOWING TWO CONDITIONS (1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE AND(2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION. Complies with CANADA RSS-210" Eumitcom Technology Inc. Made in Taiwan 4 CM BOTTOM SIDE 6 CM

Report No.: RF900215053Issued: February 26, 2001 Report No.: RF900215054Issued: February 26, 2001 Report No.: RF900215055Issued: February 26, 2001 Report No.: RF900215056Issued: February 26, 2001 Report No.: RF900215057Issued: February 26, 2001 Report No.: RF900215058Issued: February 26, 2001

FCC ID: LLM0102WA3001A ADT No.90021505 Operational Description The transmitter of the EUT (11Mbps WLAN Access Point) is powered by power adapter and connected with notebook through USB port. The antenna is Dual Monopole Antenna, there is no antenna connector . Under normal use condition, the user has to keep at least 20cm separation distance between radiator and the body of the user. The other instruction, please have a look at the users manual.

FCC ID: LLM0102WA3001A Report No.: RF900215051Issued: Feb. 26, 2001 ANNEX 2 DSSS INFORMATION This device is Direct Sequence Spread Spectrum, the data is mixed by pseudorandom code which is an orthogonal code. The mixed data is digital modulated by BPSK and QPSK technique depends on the data rates. The CCK coding is applied for increasing the data rate, and also the processing gain will be increased. The bit rates are 1,2,5.5,11Mbps, the symbol rates are 1,1,1.375,1.375Mbps, the chip rates are always 11Mbps. So, the Chip/symbol is 11,11,8 and 8 respectively. Although is higher bit rate, the processing gain is lower than 10, but the CCK coding used in higher bit rate will provide 2.2dB coding gain.

FCC ID: LLM0102WA3001A Report No.: RF90021505 1 Issued: Feb. 26, 2001 FCC TEST REPORT REPORT NO.: RF90021505 MODEL NO.: WA3001A RECEIVED: February 15, 2001 TESTED: February 26, 2001 APPLICANT: Eumitcom Technology Inc. ADDRESS: 2F, No.2, Li Hsin Rd., Science-Based Industrial Park, Hsinchu, Taiwan, R.O.C. ISSUED BY: Advance Data Technology Corporation LAB LOCATION: 13-1, Lane 19, Wen Shan 3 rd St., Kweishan, Taoyuan Hsien, Taiwan, R.O.C. This test report consists of 48 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by NVLAP or any U.S. government agencies. The test results in the report only apply to the tested sample. Accredited Laboratory FCC ID: LLM0102WA3001A Report No.: RF90021505 2 Issued: Feb. 26, 2001 Table of Contents 1CERTIFICATION ...................................................................................................... 4 2SUMMARY OF TEST RESULTS............................................................................. 5 3GENERAL INFORMATION .................................................................................... 6 3.1GENERAL DESCRIPTION OF EUT .....................................................................................6 3.2DESCRIPTION OF TEST MODES ........................................................................................6 3.3GENERAL DESCRIPTION OF APPLIED STANDARDS ....................................................7 3.4DESCRIPTION OF SUPPORT UNITS...................................................................................7 4TEST PROCEDURES AND RESULTS ................................................................... 8 4.1CONDUCTED EMISSION MEASUREMENT......................................................................8 4.1.1LIMITS OF CONDUCTED EMISSION MEASUREMENT ................................................................8 4.1.2TEST INSTRUMENTS .........................................................................................................................8 4.1.3TEST PROCEDURES ...........................................................................................................................9 4.1.4TEST SETUP .......................................................................................................................................10 4.1.5TEST RESULTS ..................................................................................................................................11 4.2RADIATED EMISSION MEASUREMENT ........................................................................17 4.2.1LIMITS OF RADIATED EMISSION MEASUREMENT ..................................................................17 4.2.2TEST INSTRUMENTS .......................................................................................................................18 4.2.3TEST PROCEDURES .........................................................................................................................19 4.2.4TEST SETUP .......................................................................................................................................20 4.2.5TEST RESULTS ..................................................................................................................................21 4.36dB BANDWIDTH MEASUREMENT ................................................................................25 4.3.1LIMITS OF 6 D B BANDWIDTH MEASUREMENT..........................................................................25 4.3.2TEST INSTRUMENTS .......................................................................................................................25 4.3.3TEST PROCEDURE............................................................................................................................26 4.3.4TEST SETUP .......................................................................................................................................26 4.3.5EUT OPERATING CONDITION........................................................................................................26 4.3.6TEST RESULTS ..................................................................................................................................27 4.4MAXIMUM PEAK OUTPUT POWER................................................................................31 4.4.1LIMITS OF MAXIMUM PEAK OUTPUT POWER MEASUREMENT...........................................31 4.4.2INSTRUMENTS..................................................................................................................................31 4.4.3TEST PROCEDURES .........................................................................................................................32 4.4.4TEST SETUP .......................................................................................................................................32 4.4.5EUT OPERATING CONDITION........................................................................................................32 4.4.6TEST RESULTS ..................................................................................................................................33 4.5POWER SPECTRAL DENSITY MEASUREMENT ...........................................................34 4.5.1LIMITS OF POWER SPECTRAL DENSITY MEASUREMENT .....................................................34 4.5.2TEST INSTRUMENTS .......................................................................................................................34 FCC ID: LLM0102WA3001A Report No.: RF90021505 3 Issued: Feb. 26, 2001 4.5.3TEST PROCEDURE............................................................................................................................35 4.5.4TEST SETUP ....................................................................…

Text truncated - open the document above for the full version.

FCC ID: LLM0102WA3001A Report No.: RF90021505 31 Issued: Feb. 26, 2001 4.4 MAXIMUM PEAK OUTPUT POWER 4.4.1 LIMITS OF MAXIMUM PEAK OUTPUT POWER MEASUREMENT The Limit of Maximum Peak Output Power Measurement is 30dBm. 4.4.2 INSTRUMENTS Description & ManufacturerModel No.Serial No.Calibrated Until HP SPECTRUM ANALYZER8593E3926A04191Mar. 03, 2001 HP ATTENUATOR8496B3247A18505Cal. on use HP PLOTTER7475A2641V27755N/A Notes: 1.The measurement uncertainty is less than +/- 2.6dB, which is calculated as per the NAMAS document NIS81. 2.The calibration interval of the above test instruments is 12 months. And the calibrations are traceable to NML/ROC and NIST/USA. FCC ID: LLM0102WA3001A Report No.: RF90021505 32 Issued: Feb. 26, 2001 4.4.3 TEST PROCEDURES 1. The transmitter output was connected to the spectrum analyzer through an attenuator. 2. The center frequency of the spectrum analyzer is set to the fundamental frequency and using 3 MHz RBW and 3 MHz VBW. 3. The span of the spectrum analyzer should be larger than 6dB BandWidth plus 10MHz. 4. Use Peak Search to read the peak power after Maximum Hold function is activated. 5. Shift the marker to +/- 3MHz and +/-6MHz, and record the reading. 6. The Maximum Peak Output Power is the linear summation of the 5 readings in (4) and (5). Note: This measurement is the total power of 15MHz bandwidth which is far more wider than 6dB bandwidth. 4.4.4 TEST SETUP For the actual test configuration, please refer to the related Item – Photographs of the Test Configuration. 4.4.5 EUT OPERATING CONDITION The software provided by client enabled the EUT to transmit and receive data at lowest, middle and highest channel frequencies individually. EUT SPECTRUM ANALYZER Attenuator FCC ID: LLM0102WA3001A Report No.: RF90021505 33 Issued: Feb. 26, 2001 4.4.6 TEST RESULTS Output Power Into Antenna: EUT11Mbps WLAN Access PointModelWA3001A Environmental Conditions 20°C, 70%RHTe s t e d B ySteven Lu CHANNEL CHANNEL FREQUENCY (MHz) PEAK POWER OUTPUT (dBm) PEAK POWER LIMIT (dBm) PASS/FAI L 1241217.2130PASS 6243717.7430PASS 11246217.5430PASS FCC ID: LLM0102WA3001A Report No.: RF90021505 34 Issued: Feb. 26, 2001 4.5 POWER SPECTRAL DENSITY MEASUREMENT 4.5.1 LIMITS OF POWER SPECTRAL DENSITY MEASUREMENT The Limit of Power Spectral Density Measurement is 8dBm. 4.5.2 TEST INSTRUMENTS Description & ManufacturerModel No.Serial No.Calibrated Until ROHDE & SCHWARZ TEST RECEIVER ESMI 846839/018 848926/005 Mar. 03, 2001 HP ATTENUATOR8496B3247A18505Cal. on use HP PLOTTER7475A2641V27755N/A Notes: 1.The measurement uncertainty is less than +/- 2.6dB, which is calculated as per the NAMAS document NIS81. 2.The calibration interval of the above test instruments is 12 months. And the calibrations are traceable to NML/ROC and NIST/USA. FCC ID: LLM0102WA3001A Report No.: RF90021505 35 Issued: Feb. 26, 2001 4.5.3 TEST PROCEDURE The transmitter output was connected to the spectrum analyzer through an attenuator, the bandwidth of the fundamental frequency was measured with the spectrum analyzer using 3 kHz RBW and 30 kHz VBW, set sweep time=span/3kHz. The power spectral density was measured and recorded. The sweep time is allowed to be longer than span/3KHz for a full response of the mixer in the spectrum analyzer. 4.5.4 TEST SETUP For the actual test configuration, please refer to the related Item – Photographs of the Test Configuration. 4.5.5 EUT OPERATING CONDITION The software provided by client enabled the EUT to transmit and receive data at lowest, middle and highest channel frequencies individually. EUT SPECTRUM ANALYZER Attenuator FCC ID: LLM0102WA3001A Report No.: RF90021505 36 Issued: Feb. 26, 2001 4.5.6 TEST RESULTS EUT11Mbps WLAN Access PointModelWA3001A Environmental Conditions 20°C, 70%RHTe s t e d B ySteven Lu CHANNEL NUMBER CHANNEL FREQUENCY (MHz ) RF POWER LEVEL IN 3 KHz BW (dBm) MAXIMUM LIMIT (dBm) PASS/FAI L 12412-10.918PASS 62437-9.598PASS 112462-10.698PASS FCC ID: LLM0102WA3001A Report No.: RF90021505 37 Issued: Feb. 26, 2001 CH1 FCC ID: LLM0102WA3001A Report No.: RF90021505 38 Issued: Feb. 26, 2001 CH6 FCC ID: LLM0102WA3001A Report No.: RF90021505 39 Issued: Feb. 26, 2001 CH11 FCC ID: LLM0102WA3001A Report No.: RF90021505 40 Issued: Feb. 26, 2001 4.6 BAND EDGES MEASUREMENT 4.6.1 LIMITS OF BAND EDGES MEASUREMENT Below –20dB of the highest emission level of operating band (in 100KHz RB). 4.6.2 TEST INSTRUMENTS Description & ManufacturerModel No.Serial No.Calibrated Until ROHDE & SCHWARZ TEST RECEIVER ESMI 848926/005 846839/018 Dec 03, 2001 HP ATTENUATOR8496B3247A18505Cal. on use HP PLOTTER7475A2641V27755N/A Notes: 1.The measurement uncertainty is less than +/- 2.6dB, which is calculated as per the NAMAS document NIS81. 2.The calibration interval of the above test instruments is 12 months. And the calibrations are traceable to NML/ROC and NIST/USA. 4.6.3 TEST PROCEDURE The transmitter output was connected to the spectrum analyzer via a low lose cable. Set both RBW and VBW of spectrum analyzer to 100 kHz with suitable frequency span including 100 kHz bandwidth from band edge. The band edges was measured and recorded. FCC ID: LLM0102WA3001A Report No.: RF90021505 41 Issued: Feb. 26, 2001 4.6.4 EUT OPERATING CONDITION The software provided by client enabled the EUT to transmit and receive data at lowest, middle and highest channel frequencies individually. 4.6.5 TEST RESULTS The spectrum plots are attached below. D2 line indicates the highest level, D1 line indicates the 20dB offset below D2. It shows compliance with the requirement in part 15.247(C). FCC ID: LLM0102WA3001A Report No.: RF90021505 42 Issued: Feb. 26, 2001 4.6.6 NOTE ON BAND EDGE EMISSION The band edge emission plot on page 43 shows 49.44dB delta between carrier maximum power and local maximum emission in restrict band (2.4835GHz). The emission of carrier strength list in table of page 24 is 95.2dBμV/m, so the maximum field strength in restrict band is 95.2- 49.44 = 45.76dBμV/m which is under 54 dBμV/m limit. FCC ID: LLM0102W…

Text truncated - open the document above for the full version.

FCC ID: LLM0102WA3001A Report No.: RF90021505 1 Issued: Feb. 26, 2001 ANNEX 1 PROCESSING GAIN OF DIRECT SEQUENCE SPREAD SPECTRUM MEASUREMENT 1. 1.1. 1. LIMITS OF PROCESSING GAIN OF A DIRECT SEQUENCE SPREAD SPECTRUM MEASUREMENT The limit of processing gain is 10dB 1.1 TEST INSTRUMENTS & SUPPORT UNIT Description & ManufacturerModel No.Serial No. Anritsu Spectrum Analyzer, 9kHz to 30GHz MS2667CM10281 Anritsu Signal Generator, 10kHz to 20GHz 68247B984703 Hewlett Packard Power Meter,HP438A2743A04416 Hewlett Packard Power Sensor, -30 to 20dBm 8485A2942A08387 Hewlett Packard Step Attenuator, 10dB steps HP8496B3247A18505 Mini-Circuits Power SplitterZN2PD-9GNA DELL Laptop ComputerInspiron 5000eNA Campaq Laptop ComputerPPX99125 FCC ID: LLM0102WA3001A Report No.: RF90021505 2 Issued: Feb. 26, 2001 1.2 METHOD OF MEASUREMENT The processing gain may be measured using the CW jamming margin method. Section 4.7.4 shows the test configuration. The test consists of stepping a signal generator in 50 kHz increments across the passband of the system. At each point, the generator level required to produce the recommended Bit Error Rate (BER) is recorded. This level is jammer level. The output power of the transmitting unit is measured at the same point. The jammer to Signal (J/S) ratio is then calculated. Discard the worst 20% of the J/S data points. The lowest remaining J/S ratio is used when calculating the Process Gain. The reference PER is specified as 8%. The corresponding Es/No (signal to noise ratio per symbol) is 16.4 dB. The curve is attached as below. This value and the measured J/S ratio are used in the following equation to calculate the Process Gain (Gp) of the system. Where: (S/N) o : Signal to noise ratio for the chosen BER. Gp = (S/N) o +Mj+Lsys FCC ID: LLM0102WA3001A Report No.: RF90021505 3 Issued: Feb. 26, 2001 Mj : Maximum jammer to Signal Ratio recorded at the detected BER. Lsys : System losses . For the purpose of this processing gain calculation, we assume Lsys at its minimum value of 2 dB. TEST SETUP 7 NOTEBOOK EUT ANRITSU SIGNAL GENERATOR EUT NOTEBOOK PWR SENSOR 8485A Power meter HP 438A Mini-Circuits 15542 ZNZPD-9G HP8496D STEP ATTN 110dB (10dB steps) Matched Cables RECEIVER Transmitter FCC ID: LLM0102WA3001A Report No.: RF90021505 4 Issued: Feb. 26, 2001 1.3 TEST PROCEDURES Obtain the simplex link shown. Perform all independent instrumentation calibrations prior to this procedure. Set operating power levels using fixed and variable attenuators in system to meet the following objectives: Signal Power at receiver approximately –55dBm (above thermal sensitivity such that thermal noise does not cause bit errors. Signal Power at power meter between –20 and –30dBm for optimal linearity. Use spectrum analyzer to monitor test. Ensure that CW Jammer generator RF output is disabled and measure the power at the power meter port using the power meter. This is the relative signal power, Sr. Disable Transmitter, and set CW Jammer generator RF output frequency equal to the carrier frequency and enable generator output. Set reference CW Jammer power level at power meter port 8.4dB below Sr (minimum J/S, or 10dB processing gain reference level). Note the power level setting on the generator, this is the reference CW Jammer power setting, Jr. Disable CW Jammer, re-establish link. PER test should be operating essentially error -free. Enable CW Jammer at the reference power level and verify that the PER test indicates a PER of less than 8%. Alternatively, adjust the CW Jammer level to that which causes 8% PER and verify that the S/J is less than 8.4dB. Repeat step 7 for uniform steps in frequency increments of 50 kHz across the receiver passband with the CW Jammer. In this case the receiver passband is +/- 8.5 MHz. The numerical data associated with the following radio channel is tabulated and presented for Channel 1,6, and 11. Note:Since the jamming signal will be blocked by the IF filter if the jamming frequency is far form the center of the carrier frequency. So, only those frequencies around carrier frequency are shown here. FCC ID: LLM0102WA3001A Report No.: RF90021505 5 Issued: Feb. 26, 2001 1.4 EUT OPERATING CONDITION The software provided by client to set the EUT to transmit at lowest, middle and highest channel. 1.5 TEST RESULTS EUT11Mbps WLAN Access PointModelWA3001A Environmental Conditions20°C, 70%RHTe s t e d B ySteven Lu Although the theoretical processing gain is lower than 10 dB, but the CCK coding provides an extra coding gain of 2.2dB. 11Mbps CHANNEL 1 Processing Gain FrequencyGp(S/N)。Mj = J/SLsys (GHz)(dB)(dB)(dB)(dB) 2.408 13.3 16.4 -5.1 2 2.40805 13.5 16.4 -4.9 2 2.4081 13.2 16.4 -5.2 2 2.40815 13.5 16.4 -4.9 2 2.4082 13.6 16.4 -4.8 2 2.40825 13.1 16.4 -5.3 2 2.4083 13.1 16.4 -5.3 2 2.40835 12.8 16.4 -5.6 2 2.4084 12.8 16.4 -5.6 2 2.40845 12.9 16.4 -5.5 2 2.4085 12.6 16.4 -5.8 2 2.40855 12.7 16.4 -5.7 2 2.4086 12.4 16.4 -6 2 2.40865 12.6 16.4 -5.8 2 2.4087 12.7 16.4 -5.7 2 2.40875 12.5 16.4 -5.9 2 2.4088 12.6 16.4 -5.8 2 2.40885 12.3 16.4 -6 2 2.4089 12.3 16.4 -6.1 2 2.40895 12.4 16.4 -6 2 FCC ID: LLM0102WA3001A Report No.: RF90021505 6 Issued: Feb. 26, 2001 11Mbps CHANNEL 1 Processing Gain FrequencyGp(S/N)。Mj = J/SLsys (GHz)(dB)(dB)(dB)(dB) 2.409 11.9 16.4 -6.5 2 2.4095 11.7 16.4 -6.7 2 2.40955 11.5 16.4 -6.9 2 2.4096 11.7 16.4 -6.7 2 2.40965 11.9 16.4 -6.5 2 2.4097 11.5 16.4 -6.9 2 2.40975 11.7 16.4 -6.7 2 2.4098 11.2 16.4 -7.2 2 2.40985 11.4 16.4 -7 2 2.4099 11.5 16.4 -6.9 2 2.40995 11.2 16.4 -7.2 2 2.41 11.3 16.4 -7.1 2 2.41005 11.1 16.4 -7.3 2 2.4101 11.3 16.4 -7.1 2 2.41015 11.6 16.4 -6.8 2 2.4102 11.4 16.4 -7 2 2.41025 11.7 16.4 -6.7 2 2.4103 11.4 16.4 -7 2 2.41035 11.7 16.4 -6.7 2 2.4104 11.8 16.4 -6.6 2 2.41045 11.5 16.4 -6.9 2 2.4105 11.7 16.4 -6.7 2 2.41055 11.3 16.4 -7.1 2 2.4106 11.5 16.4 -6.9 2 2.41065 11.8 16.4 -6.6 2 2.4107 11.5 16.4 -6.9 2 2.41075 11.7 16.4 -6.7 2 2.4108 11.5 16.4 -6.9 2 2.41085 11.8 16.4 -6.6 2 2.4109 12.1 16.4 -6.3 2 2.41095 11.8 16.4 -6.6 2 2.411…

Text truncated - open the document above for the full version.

FCC ID: LLM0102WA3001A Report No.: RF90021505 46 Issued: Feb. 26, 2001 5 PHOTOGRAPHS OF THE TEST CONFIGURATION CONDUCTED EMISSION TEST FCC ID: LLM0102WA3001A Report No.: RF90021505 47 Issued: Feb. 26, 2001 RADIATED EMISSION TEST
