M3N5WY7078Immobilizer

Re: Certification for Siemens 5WY7078 Immobilizer Model: 5WY7078 FCC ID: M3N5WY7078 IC: 267F-5WY7078 USER'S MANUAL INFORMATION (PRELIMINARY) The User's Manual is in preparation. The following material will be contained in the manual: FCC ID: M3N5WY7078 IC: 267F-5WY7078 This device complies with Part 15 of the FCC Rules and with RSS-210 of Industry Canada. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. WARNING: Changes or modifications not expressively approved by the party responsible for compliance could void the user's authority to operate the equipment.

Re: Certification for Siemens 5WY7078 Immobilizer Model: 5WY7078 FCC ID: M3N5WY7078 IC: 267F-5WY7078 POWER OF ATTORNEY A letter granting Valdis V. Liepa the Power of Attorney is on file and can be provided when so requested. Re: Certification for Siemens 5WY7078 Immobilizer Model: 5WY7078 FCC ID: M3N5WY7078 IC: 267F-5WY7078 REQUEST FOR CONFIDENTIALITY Pursuant to 47 CRF 0.459, Siemens requests that a part of the subject application be held confidential. This comprises Exhibits (5) Schematics (10) Parts List (Part of Exhibit only) Siemens has spent substantial effort in developing this product and it is one of the first of its kind in industry. Having the subject information easily available to "competition" would negate the advantage they have achieved by developing this product. Not protecting the details of the design will result in financial hardship. If there are any questions regarding this request, please contact me at the above address or call 734-483-4211, fax 734-647-2106 or e-mail [email protected]. Sincerely, Valdis V. Liepa Research Scientist University of Michigan June 18, 2002 Re: Certification for Siemens 5WY7078 Immobilizer Model: 5WY7078 FCC ID: M3N5WY7078 IC: 267F-5WY7078 STATEMENT OF MODIFICATIONS There were no modifications made to the DUT by this test laboratory. (Also see Section 3.1 of the attached Test Report). _____________________ Valdis V. Liepa Research Scientist Re: Certification for Siemens 5WY7078 Immobilizer Model: 5WY7078 FCC ID: M3N5WY7078 IC: 267F-5WY7078 GENERAL PRODUCT INFORMATION The device, for which certification is pursued, has been designed by: Siemens Automotive Corporation 2400 Executive Hills Drive Auburn Hills, MI 48326-2980 Kevin Cotton Tel: (248) 764-6771 Fax: (248) 764-7171 It will be manufactured by: Siemens Automotive Corporation 2400 Executive Hills Drive Auburn Hills, MI 48326-2980 Kevin Cotton Tel: (248) 764-6771 Fax: (248) 764-7171

18 June 2002 Filename: SKREES_IMM RKE TX FCC_IC Homolagation1.doc Department: AT BE AS Page 4 of 11 Copyright © by Siemens Automotive Corp. All rights reserved DaimlerChrysler SKREES SYSTEM Block Diagram: EMS EEPROM Microcontroller - Secret Key -Transponder id(s) Bus Controller BatteryGround Ignition Switch J1850 BUS Sentry Key Remote Entry Key SKREEM Diagnostic Tool -VIN -PIN -Secret Key -VIN -RollingCode Algorithm -Rolling Code Algorithm -Crypto Algorithm -Vin Compare Algorithm LF Base Station BCM RF Board RF Link EEPROM LF Link Figure 1. System Block Diagram

Re: Certification for Siemens 5WY7078 Immobilizer Model: 5WY7078 FCC ID: M3N5WY7078 IC: 267F-5WY7078 REQUEST FOR CONFIDENTIALITY Pursuant to 47 CRF 0.459, Siemens requests that a part of the subject application be held confidential. This comprises Exhibits (5) Schematics (10) Parts List (Part of Exhibit only) Siemens has spent substantial effort in developing this product and it is one of the first of its kind in industry. Having the subject information easily available to "competition" would negate the advantage they have achieved by developing this product. Not protecting the details of the design will result in financial hardship. If there are any questions regarding this request, please contact me at the above address or call 734-483-4211, fax 734-647-2106 or e-mail [email protected]. Sincerely, Valdis V. Liepa Research Scientist University of Michigan

Re: Certification for Siemens 5WY7078 Immobilizer Model: 5WY7078 FCC ID: M3N5WY7078 IC: 267F-5WY7078 POWER OF ATTORNEY A letter granting Valdis V. Liepa the Power of Attorney is on file and can be provided when so requested.

American Telecommunications Certification Body Inc. 6731 Whittier Ave, McLean, VA 22101 June 19, 2002 RE: FCC ID: M3N5WY7078 Attention: Valdis V Liepa I have a few comments on this Application. 1 The limits in the table of emissions on page 6 of the report are incorrect. While the device appears compliant when compared to the proper limits, the report needs to reflect the appropriate limits. 125kHz limit at 300 meters is 25.6dBuV as shown, and while 1250kHz at 30 meters is also approximately 25.6dBuV as shown, all other limits listed are incorrect. Please use the formula provided in 15.209 for the proper limits. Please provide a report with the corrected limits. 2 Also, 15.31 allows either a multiple measurement method or a 40dB/decade roll off for extrapolating data. This means that each frequency may be measured at multiple distances and a ‘best fit’ straight line drawn between the results to the limit distance may be done, or the FCC’s stated 40dB/ decade value in 15.31 must be used. This means the calculations in the table are incorrect. While correcting the data to reflect the proper readings show the device compliant, the report must still reflect the proper data as related to the limit. Please correct the data and refer to the proper limit. Dennis Ward mailto:[email protected] The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information may result in application termination. Correspondence should be considered part of the permanent submission and may be viewed from the Internet after a Grant of Equipment Authorization is issued. Please do not respond to this correspondence using the email reply button. In order for your response to be processed expeditiously, you must submit your documents through the AmericanTCB.com website. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the sender.

5WY7078 Immobilizer– DUT with Harness 5WY7078 Immobilizer– Front 5WY7078 Immobilizer– Back

18 June 2002 Filename: SKREES_IMM RKE TX FCC_IC Homolagation1.doc Department: AT BE AS Page 9 of 11 Copyright © by Siemens Automotive Corp. All rights reserved SKREEM Schematic: See Attached SKREEM PCB Assembly: See Attached SKREEM Marking Information: NOTES: 1. DAIMLERCHRYSLER SPECIFICATION PS 8800 FORMAT C 2. PRINTED WITH THERMOTRANSFER PRINTER ABRASION RESISTANCE TO DIN 54021 3. NO ABRASION AFTER 100 CROCKET METER THRUST 4. BAR CODE A - CPI 8.47, TEXT HEIGHT 1.82, WIDTH 14.53 (DCX PART NUMBER) 5. BAR CODE B - CPI 8.73, TEXT HEIGHT 1.82, WIDTH 20.11 (TRACEABILITY CODE) 6. TRACEABILITY CODE: 4 5 P04727408AA TCCDDDY?XXXX 60.0 mm 35.0 mm 5WY7078 Immobilizer– DUT with Harness 5WY7078 Immobilizer– Front

5WY7078 Immobilizer– Case Open Top 5WY7078 Immobilizer– Case Open Bottom 5WY7078 Immobilizer – PCB Top 5WY7078 Immobilizer – PCB Top w/o Shield 5WY7078 Immobilizer – PCB Bottom

18 June 2002 Filename: SKREES_IMM RKE TX FCC_IC Homolagation1.doc Department: AT BE AS Page 1 of 11 Copyright © by Siemens Automotive Corp. All rights reserved Re: Confidential Certification of Siemens VDO Automotive SKREES (Sentry Key REmote Entry System) SKREEM FCC ID: “FCC ID: M3N5WY7078” SKREEM Canada ID: “IC: 267F-5WY7078” SKREEK FCC ID: “FCC ID: M3N5WY72XX” SKREEK Canada ID: “IC: 267F-5WY72XX” GENERAL PRODUCT INFORMATION: DaimlerChrysler SKREES The SKREES (Sentry Key REmote Entry System) being certified for the DaimlerChrysler Corporation has been designed by: Siemens VDO Automotive 4685 Investment Drive Troy, MI 48098 FCC Grantee Code: M3N The SKREES will be manufactured by: Siemens VDO S.A. de C.V. Camino a la Tijera # 3 Km 3.5 Carretera Guadalajara-Morelia C.P. 45640 Mpio. Tlajomulco de Zúñiga, Jalisco Mexico The SKREES will be distributed by the DaimlerChrysler Corporation and will be serviced by its authorized automobile dealers and service shops in the United States of America, Canada and other countries. 18 June 2002 Filename: SKREES_IMM RKE TX FCC_IC Homolagation1.doc Department: AT BE AS Page 2 of 11 Copyright © by Siemens Automotive Corp. All rights reserved FUNCTIONAL DESCRIPTION OF THE DaimlerChrysler SKREES System Components The DaimlerChrysler SKREES (Sentry Key REmote Entry System) is a vehicle immobilization and Remote Keyless Entry (RKE) system. This system consists of a module or base station called the SKREEM (Sentry Key REmote Entry Module) and the fob or combi-key called a SKREEK (Sentry Key REmote Entry Key). The SKREEM is located near the vehicle’s ignition cylinder. The Transponder is located within the SKREEK which is attached to the ignition key. This Transponder is energized via low frequency magnetic coupling with the SKREEM. The SKREEM (control module or base station) is connected via a wire harness to vehicle power, vehicle ground, vehicle ignition, and the vehicle communications bus. The communications bus is a single line digital interface. This bus allows communications between the SKREEM and other vehicle controllers such as the Engine Control Module and Body Controller. System Operation The DaimlerChrysler Sentry Key Remote Entry System (SKREES) combines an Immobilizer Module and a Remote Keyless Entry Module into one system that performs functions of both modules. Therefore, SKREES can be in fact divided into two major sub-systems: a Sentry Key Immobilizer and a Remote Keyless Entry. Immobilizer: SKREEM Transmits VPWM encoded 125kHz ASK data to the SKREEK SKREEM Receives Manchester encoded 125kHz ISK data from SKREEK Philips HITAG2+ protocol and encryption algorithm Remote keyless Entry: SKREEK transmits 315 MHz ASK Manchester data to the SKREEM Philips HITAG2+ protocol and encryption algorithm The Sentry Key Immobilizer sub-system authenticates an electronically coded Sentry Key Remote Entry Key (SKREEK) placed into the ignition and sends a valid/invalid key message to the engine controller based on the results. The authentication of the SKREEK is performed using Philips HITAG2 protoco and Philips HITAG2 encryption algorithm. The “valid/invalid key” message communication is performed using a DaimlerChrysler proprietary rolling code algorithm via a J1850 bus. A “valid key” message must be sent to the engine controller within 2 seconds of ignition ON to free the engine from immobilization. The Sentry Key Remote Keyless Entry sub-system of SKREEM receives an encrypted RF signal from a SKREEK. SKREEM then decrypts the signal and broadcasts the requested remote commands to the appropriate control modules in the vehicle through J1850 bus. The RF data is encrypted using Philips HITAG2 encryption algorithm. A valid SKREEK ID must be incorporated into the RF signal in order for the SKREEM to pass the message to the control modules. 18 June 2002 Filename: SKREES_IMM RKE TX FCC_IC Homolagation1.doc Department: AT BE AS Page 3 of 11 Copyright © by Siemens Automotive Corp. All rights reserved Automatic SKREEK synchronization is done by SKREEM if valid SKREEK is detected when it is inserted into the ignition cylinder and ignition is turned on. This provides a maximum operation window for RKE functions. Each DaimlerChrysler SKREES consists of a SKREEM and a SKREEK. Each system has a secret key code unique to that system. The secret key is electronically coded in the SKREEM and in all programmed SKREEKs. It is used for immobilizer and RKE functions for data security. In addition, each SKREEK will have a unique identification (IDE). A system block diagram is given in Figure 1. RKE Receiver The purpose of the RF link is to provide remote vehicle access. The RF link is comprised of the base station’s (SKREEM) RF receiver and the fob’s (SKREEK) RF transmitter. The SKREEM contains a stand-alone, daughter board, superheterodyne 315 MHz receiver for remote keyless entry operation. This device has been tested to comply with FCC standards for automotive use and is certified in Canada under 267 1032 336A.

5WY7078 Immobilizer Close-up on OATS 5WY7078 Immobilizer on OATS
