February 11, 2010 Shawn Li Continental 4685 Investment Dr. Troy, MI 48098 Phone: 248-764-6712 Fax: 248-764-7226 RE: Certification for Continental Transmitter Model/PN(s): BT4T-15604-Cx BA1T-15604-Ax BB5T-15604-Bx BB5T-15604-Cx FCC ID: M3N5WY8434 IC: 7812A-5WY8434 USERS MANUAL & COMPLIANCE STATEMENT The Continental Transmitter is sold only as part of a vehicle by retail automobile dealers and as such has no separate manual. The exhibit is provided electronically to the vehicle manufacturer after submission. The compliance statement for Continental Transmitter will be integrated by the OEM into the vehicles owner's manual. It will read: This device complies with part 15 of the FCC rules and with RSS-210 of industry Canada. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received , including interference that may cause undesired operation. WARNING: Changes or modifications not expressively approved by Continental could void the user's authority to operate the equipment.

March 15, 2010 Certification and Engineering Bureau Industry Canada 3701 Carling Avenue, Bldg. 94 Ottawa, Ontario K2H 8S2 Re: Certification for Continental Transmitter Model/PN(s): 5WY8604, 5WY8606 5WY8678, 5WY8679 FCC ID: M3N5WY8434 IC: 7812A-5WY8434 Please find enclosed application materials for certification of Continental Transmitter. We tested the device and found it to comply with RSS-GEN/102/210. The product is identified by: IC: 7812A-5WY8434 If there are any questions, suggestions, etc., regarding the application or testing performed, please contact me at the above address or call 734-483-4211, fax 734-647- 2106; e-mail: [email protected]. Sincerely, Valdis V. Liepa Research Scientist March 15, 2010 Federal Communications Commission Equipment Approval Services P.O. Box 358315 Pittsburgh, PA 15251-5315 Re: Certification for Continental Transmitter Model/PN(s): 5WY8604, 5WY8606 5WY8678, 5WY8679 FCC ID: M3N5WY8434 IC: 7812A-5WY8434 Please find enclosed application materials for certification of Continental Transmitter. We tested it and found it to comply with FCC Part 15. If there are any questions regarding the application or testing performed, please contact me at the above address or call 734-483-4211, fax 734-647-2106, or e-mail [email protected]. Sincerely, Valdis V. Liepa Research Scientist

March 15, 2010 American Telecommunications Certification Body, Inc. 6731 Whittier Avenue Suite C110 McLean, VA 22101 RE: Certification Application FCC ID: M3N5WY8434 IC: 7812A-5WY8434 Model/PN(s): 5WY8604, 5WY8606, 5WY8678, 5WY8679 Please find enclosed application materials for certification of Continental LF Transmitter Note: 1) Portions of this submittal are filed Confidential. 2) A list of the modifications made is provided in Attestations. If there are any questions regarding the application or testing performed, please contact me at the above address or call 734-483-4211, fax 734-647-2106, or e-mail [email protected]. Sincerely, Valdis V. Liepa Research Scientist

(gotioeotille Attn:DirectorofCertification AuthoritytoActasAgent I appointValdisV.Liepatoactasouragentin thepreparationofthisapplication forequipmentcertification.I certifythatsubmitteddocumentsproperlydescribe thedevice orsystemforwhichequipmentcertificationissought.I alsocertifythat eachunitmanufactured,importedormarketed,asdefinedinIndustryCanada's regulationswillhaveaffixedtoit a labelidenticaltothatsubmittedforapproval withthisapplication. Forinstanceswhereourauthorizedagentsignstheapplication forcertificationon ourbehalf,I acknowledgethatallresponsibilityforcomplyingwiththetermsand conditionsforCertification,asspecifiedbyAmericanTCB,stillresideswith ContinentalAutomotiveSystemsUS Inc.~ Datedthisi h dayofMarch,2008. By:~<::::-._-·-I-&--1.~~~ ReimusI (Signature) (Printname) Title: email: N.A.RFDomainManager [email protected] Onbehalfof:ContinentalAutomotiveSystemsUSInc (CompanyName) Telephone: +1(248)764-6522 (gotioeotalG) Interior FederalCommunicationsCommission ApplicationsProcessingBranch 7435OaklandMillsRoad Colombia,MD21046 Re:LetterofAgencyforFCCComplianceTesting PleasebeadvisedthatContinentalAutomotiveSystemsUSInc.authorizes ProfessorValdis V.LiepaoftheUniversityofMichigan,DepartmentofElectrical EngineeringandComputerScience,AnnArbor,Michigan,toact onourbehalfin frontof theFederalCommunicationsCommissionwithrespecttoallmatters relatingtocertification. Anti-DrugAbuseCertification: I furthercertifythatnoparty(asdefined in1.2002ofCFR47,1992)tothis application,includingmyself, issubjecttoa denialof federalbenefits,that includesFCCbenefits,pursuanttoSection5301oftheAntiDrugAbuseActof 1988,21U.S.C.853(a). Datedthis t h dayofMarch,2008. (Printname) (Signature) I~~- By: Reimus Title: N.A.RFDomainManager email: [email protected] Onbehalfof:ContinentalAutomotiveSystemsUSInc (CompanyName) Telephone: +1(248)764-6522

Re: Certification for Continental Transmitter Model/PN(s): 5WY8604, 5WY8606 5WY8678, 5WY8679 FCC ID: M3N5WY8434 IC: 7812A-5WY8434 POWER OF ATTORNEY A letter granting Valdis V. Liepa the Power of Attorney is on file and can be provided when so requested. March 15, 2010 Re: Certification for Continental Transmitter Model/PN(s): 5WY8604, 5WY8606 5WY8678, 5WY8679 FCC ID: M3N5WY8434 IC: 7812A-5WY8434 STATEMENT OF MODIFICATIONS There were no modifications made to the DUT by this test laboratory. (Also see Section 3.1 of the attached Test Report). _____________________ Valdis V. Liepa Research Scientist Re: Certification for Continental Transmitter Model/PN(s): 5WY8604, 5WY8606 5WY8678, 5WY8679 FCC ID: M3N5WY8434 IC: 7812A-5WY8434 GENERAL PRODUCT INFORMATION The device, for which certification is pursued, has been designed by: Continental Automotive Systems US Inc. 2400 Executive Hills Drive Auburn Hills Michigan 48326-2980 Contact: Shawn Li [email protected] Tel: 248-764-6712 Fax: 248 764 7183 It will be manufactured by: Continental Automotive Guadalajara Mexico S.A. de C.V. Camino a la Tijera # 3 Km 3.5 Carretera Guadalajara-Morelia C.P. 45640 Mpio. Tlajomulco de Zúñiga, Jalisco Mexico Contact: Shawn Li [email protected] Tel: 248-764-6712 Fax: 248 764 7183 Canadian Contact: Continental Automotive Canada, Inc. 700 Park Ave. E., P.O. Box 2014 Chatham, Ontario N7M 5M7 Contact: Gary Fell [email protected] Tel: 519-852-4855 Fax:248-209-7824

Re: Certification for Continental Transmitter FCC ID: M3N5WY8434 IC: 7812A-5WY8434 REQUEST FOR CONFIDENTIALITY Pursuant to FCC 47 CRF 0.457(d) and 0.459 and IC RSP-100, Section 10, Continental requests that a part of the subject application be held confidential. Continental has spent substantial effort in developing this product and it is one of the first of its kind in industry. Having the subject information easily available to "competition" would negate the advantage they have achieved by developing this product. Not protecting the details of the design will result in financial hardship. Type of Confidentiality Requested Exhibit Short Term Permanent (1) ID Label & Location Short Term Permanent (3) External Photos Short Term Permanent 1 (4) Block Diagram Short Term Permanent (5) Schematics Short Term Permanent (7) Test Setup Photos Short Term Permanent (8) User’s Manual Short Term Permanent (9) Internal Photos Short Term Permanent (10) Parts List & Placement Short Term Permanent (11) RF Exposure Short Term Permanent (12) Description of Operation 1. Block Diagram includes internal oscillator frequency information that the manufacturer considers to be proprietary. Permanent Confidentiality: Continental requests the exhibits listed above as permanently confidential be permanently withheld from public review. Short-Term Confidentiality (FCC Only): Continental requests the exhibits selected above as short term confidential be withheld from public view for a period of 45 days from the date of the Grant of Equipment Authorization and prior to marketing. If there are any questions regarding this request, please contact me at the above address or call 734-483-4211, fax 734-647-2106 or e-mail [email protected]. Sincerely, Valdis V. Liepa, Research Scientist University of Michigan

Date: 22-Oct-08 Title: Editor: Y. Tambat MY11 PEPS ECU 1.Check Karthik Narayan ECU Module Label Print AG VUT012595 06-Dec-09 Y. Tambat 2.Check Neil Garbacik A2C53324539 Rev 05 AF VUT012541 10-Nov-09 Y. Tambat Page AE VUT012495 26-Oct-09 Y. Tambat State Revision number Date Name 40275384 1 Pg 40275384_DRW_000_AG Draft.doc Notes: 1. Data Matrix (size: 10 x 10mm) defined as: XXX ZZ L YDDD S1 S2 S3 S4 T Where: XXX = 3 last MLFB digits (see chart) ZZ = Ford part number suffix (see chart) L= 1 digit (Identification of Laser Equipment; 1= Laser #1 or 2=Laser #2) Y= 1 last digit of the year DDD= Julian date S1 S2 S3 S4 = Correspond to a consecutive serial T = type code, M = module / K= Kit 2. Ford Part Number (See Chart) 3. MLFB Number (See Chart) 4. Part Description 5. Homologation Information a. FCC and IC IDs; FCC ID: M3N5WYXXXX, IC: 7812A-5WYXXXX b. Statement of compliance 6. Company Name 7. Made in Mexico stamp 8. Site Code ID 9. Customer Logo 10. Label to be printed on the blank label, part number A2C00018512 per drawing 6598621401 11. Mfg Serial Number, Data Matrix Information (Human readable) 12. EOL test step date code (see Date Code chart) Date Code Year Month Day 2011 - 1 Jan. - A 01 13 25 2012 - 2 Feb. - B 02 14 26 2013 - 3 Mar. - C 03 15 27 2014 - 4 Apr. - D 04 16 28 2015 - 5 May - E 05 17 29 2016 - 6 Jun. - F 06 18 30 2017 - 7 Jul. - G 07 19 31 2018 - 8 Aug. - H 08 20 2019 - 9 Sep. - J 09 21 2020 - 0 Oct. - K 10 22 Nov. - L 11 23 Dec. - M 12 24 Variant Ford Part No. MLFB MY11 U387 PEPS ECU Kit BT4T-15604-CK 5WY8604 MY11 U388 PEPS ECU Kit BA1T-15604-AK 5WY8606 MY11 U502 PEPS ECU Kit BB5T-15604-BH 5WY8678 MY11 U502 PEPS ECU Kit BB5T-15604-CH 5WY8679 2. 1. 4. 3. 5. 6. 7. 8. 9. 11. 12.

The Passive Entry Passive Start (PEPS) controls vehicle functions. This consists of a PK (Passive Key), an ECU (Electronic Control Unit) with passive ferrite antennas. The ECU transmits information to the PK through a 125kHz ASK carrier and the PK transmits information to the ECU through an RF FSK carrier (315MHz). The passive antennae are used to transmit the 125kHz. The system allows for Passive Start and Entry as well as control of other in vehicle operations. Passive entry is initiated by lifting a door handle. The ECU will then generate a 125kHz field, which the PK will read and respond back to the ECU via an RF response (315MHz).
