M4Y-04-580802.11b/g Wireless Station Adapter / Access Point

000 1 FCC Information This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received; including interference that may cause undesired operation. Federal Communications Commission (FCC) Statement This Equipment has been tested and found to comply with the limits for a Class B and C digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. FCC RF Radiation Exposure Statement: 1. This Transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. 2. This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with a minimum distance of 20 centimeters between the radiator and your body. 2 CONTENTS Before You Start You must have the following items ................................................3 Checklist ...................................................................................3 Character ..................................................................................3 Hardware Installation Connect the station adapter to your Ethernet-enabled device............4 Mechanical Description ................................................................5 Connecting One Ethernet-Device (as Station) .................................6 Connecting Multiple Ethernet-Devices (as Bridge) ...........................6 Configuring Your Adapter with a web browser Information ...............................................................................9 Configuration .............................................................................10 TCP/IP ......................................................................................16 Statistics...................................................................................17 Firmware Upgrade ......................................................................18 Appendix...................................................................................19 Limited Warranty 3 You must have the following items An Ethernet-enabled device, such as a game console, PC, or network printer will connect to the station adapter. Checklist If you discover damaged or missing items, please contact your local reseller. 9 802.11g Wireless LAN Station Adapter x 1 9 Power Adapter x 1 9 CDx1 9 User’s Manual x 1 Character Ethernet Connector: 10/100BaseTR-45 LAN port with Auto-MDIX Power Supply: DC 5V/2A Configuration: WEB-Based utility Antenna: One External dipole antenna, gain 2dBi, with diversity function Operation: Station Adapter Supported Operating systems: Win98SE/ME/2000/XP/Mac OS Security: WEP/WPA with PSK 4 Connect the station adapter to your Ethernet-enabled device A. Connect the power adapter to the 802.11g Wireless LAN Station Adapter. B. Connect one end of an Ethernet cable to the 802.11g Wireless LAN Station Adapter and connect the other end to the Ethernet LAN port located on the device (e.g., a gaming console, laptop, desktop computer, or network printer). C. Combine the antenna with the station adapter to wirelessly connect to the 802.11g networks. A. Power Ada pter B.LAN P o r t C. Ant e nna 5 Mechanical Description The following table provides an overview of each LED activity: LED Definition Activity Description PWR Green Power enabled Off: No Wireless LAN traffic activity WLAN Green On: Associated to the Wireless AP and Wireless LAN traffic activity. Off: No Ethernet traffic activity Flashing: Wired LAN traffic activityLAN Green On: Connect to the Ethernet. Power Socket Using the power adapter supplied with the Wireless LAN Station will prevent damage to the station adapter and personal injury. We cannot assume the responsibility for the damage from using with the other power adapter supplier. LAN Ports Connect the Wireless LAN Station Adapter to a hub or a PC with Ethernet cable. Please note that, use the Ethernet cable when you directly connect the Wireless LAN Station Adapter to a PC. Antenna Notice that you connect tightly the External dipole antenna on the antenna connector of your station adapter. A loosen antenna will reduce the radiant energy or even lose it. In order to improve the RF signal radiation of your antenna, proper antenna placement is necessary. We recommend you mount the antenna attached to access point in the position that can be best covered by its BSS. Try to place the antenna as high as possible to increase the coverage area. If you have further question, please contact your wireless network administrator. Default Press the “default” button for about 3 seconds until the LEDs go off. This action will restore to the factory default settings of the wireless station adapter and enable you to configure the station adapter via web again. Besides, this is also used when you forget the password. ! 6 Connecting One Ethernet-Device (as Station) The station can be implemented on allowing only one client to access the wireless net…

Text truncated - open the document above for the full version.

Company: Z-Com, Inc. Page: 1 of 5 Product : 802.11b/g Wireless Station Adapter / Access Point Model: XG-580 XG-580 plus Company: Z-Com, Inc. Page: 2 of 5 Product : 802.11b/g Wireless Station Adapter / Access Point Model: XG-580 XG-580 plus Company: Z-Com, Inc. Page: 3 of 5 Product : 802.11b/g Wireless Station Adapter / Access Point Model: XG-580 XG-580 plus Company: Z-Com, Inc. Page: 4 of 5 Product : 802.11b/g Wireless Station Adapter / Access Point Model: XG-580 XG-580 plus Company: Z-Com, Inc. Page: 5 of 5 Product : 802.11b/g Wireless Station Adapter / Access Point Model: XG-580 XG-580 plus Company: Bothhand Enterprise Inc. Page: 1 of 10 Product : Adapter Model: M1-10S05 Company: Bothhand Enterprise Inc. Page: 2 of 10 Product : Adapter Model: M1-10S05 Company: Bothhand Enterprise Inc. Page: 3 of 10 Product : Adapter Model: M1-10S05 Company: Bothhand Enterprise Inc. Page: 4 of 10 Product : Adapter Model: M1-10S05 Company: Bothhand Enterprise Inc. Page: 5 of 10 Product : Adapter Model: M1-10S05 Company: Bothhand Enterprise Inc. Page: 6 of 10 Product : Adapter Model: M1-10S05 Company: Bothhand Enterprise Inc. Page: 7 of 10 Product : Adapter Model: M1-10S05 Company : AIPTEK Internaitonal Inc. Page : 8 of 10 Product : PenCam Trio Plus Model : CRX-D31 Company : AIPTEK Internaitonal Inc. Page : 9 of 10 Product : PenCam Trio Plus Model : CRX-D31 Company: Bothhand Enterprise Inc. Page: 10 of 10 Product : Adapter Model: M1-10S05

Company: Z-Com, Inc. Product : 802.11b/g Wireless Station Adapter / Access Point Model: XG-580 XG-580 plus Z-Com, Inc. FCC IDM4Y-04-580 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: [1] this device may not cause harmful interference and [2] this device must accept any interference received, including interference that may cause undesired operation. S/N Made in Taiwan

Company: Z-Com, Inc. Page: 1 of 7 Product : 802.11b/g Wireless Station Adapter / Access Point Model: XG-580 XG-580 plus Company: Z-Com, Inc. Page: 2 of 7 Product : 802.11b/g Wireless Station Adapter / Access Point Model: XG-580 XG-580 plus Company: Z-Com, Inc. Page: 3 of 7 Product : 802.11b/g Wireless Station Adapter / Access Point Model: XG-580 XG-580 plus Company: Z-Com, Inc. Page: 4 of 7 Product : 802.11b/g Wireless Station Adapter / Access Point Model: XG-580 XG-580 plus Company: Z-Com, Inc. Page: 5 of 7 Product : 802.11b/g Wireless Station Adapter / Access Point Model: XG-580 XG-580 plus Company: Z-Com, Inc. Page: 6 of 7 Product : 802.11b/g Wireless Station Adapter / Access Point Model: XG-580 XG-580 plus Company: Z-Com, Inc. Page: 7 of 7 Product : 802.11b/g Wireless Station Adapter / Access Point Model: XG-580 XG-580 plus

Description of Operation EUT is a 802.11b/g Wireless Station Adapter / Access Point with 11 channels. This device provided four kind of transmitting speed 1,2,5.5 and 11Mbps. The device of RF carrier is DQPSK,DB PSK and CCK. The device adapts direct sequence spread spectrum modulation. The Connector antenna was scolded on DIPOLE provided diversity function to improve the receiving function. This 802.11b/g Wireless Station Adapter / Access Point is an IEEE 802.11b&g Wireless LAN adapter. It allows your computer to connect to a wireless network and to share resources, such as files or printers without being bound to the network wires. Operation in 2.4GHz Direct Sequence Spread Spectrum (DSSS) or Orthogonal Frequency Division Multiplex (OFDM) radio transmission, the 802.11b/g Wireless Station Adapter / Access Point transfers data at speeds up to 64/128-bit Wired Equivalent Protection(WEP) algorithm is used. In addition, its standard compliance ensures that it can communicate with any 802.11b&g network.

Ecom Sertech Corp. Rm. 258, Bldg. 17, NO.195, Sec. 4 Chung Hsing Rd.,Chu -Tung Chen, Hsinchu, Taiwan 310, R.O.C TEL:886 - 3 - 5918012 FAX : 886 - 3 - 5825720 FCC ID M4Y-04-580 Report No.EC04-05-048FRF Page 1 of 2 9. RF EXPOSURE EVALUATION According to FCC 1.1310 : The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency (RF) radiation as specified in 1.1307(b) LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Average Time (A) Limits for Occupational / Control Exposures 300-1,500 -- -- F/300 6 1,500-100,000 -- -- 5 6 (B) Limits for General Population / Uncontrol Exposures 300-1,500 -- -- F/1500 6 1,500-100,000 -- -- 1 30 9.1 Friis Formula Friis transmission formula : Pd = (Pout*G)/(4*pi*r 2 ) Where Pd = power density in mW/cm 2 Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm Pd id the limit of MPE, 1 mW/cm2. If we know the maximum gain of the antenna and the total power input to the antenna, through the calculation, we will know the distance r where the MPE limit is reached. 9.2 EUT Operating Condition A software provided by client enabled the EUT to transmit and receive data at lowest, middle and highest channel individually. Ecom Sertech Corp. Rm. 258, Bldg. 17, NO.195, Sec. 4 Chung Hsing Rd.,Chu -Tung Chen, Hsinchu, Taiwan 310, R.O.C TEL:886 - 3 - 5918012 FAX : 886 - 3 - 5825720 FCC ID M4Y-04-580 Report No.EC04-05-048FRF Page 2 of 2 9.3 Test Result of RF Exposure Evaluation Test Item RF Exposure Evaluation Data Test Mode Normal Operation 9.3.1 Antenna Gain Antenna GainThe maximum Gain measured in fully anechoic chamber is 2dBi linear scale. 9.3.2 Output Power into Antenna & RF Exposure Evaluation Distance Channel Channel Frequency (MHz) Output Power to Antenna (dBm) Power Density at 20cm (mW/cm 2 ) LIMITS (mW/cm 2 ) CH1 2412.00 23.24 0.066486 1 CH6 2437.00 23.65 0.073068 1 CH11 2462.00 23.48 0.070264 1 Note : 1. For 802.11b Mode (11Mbps) 2. The power density Pd (4 th column) at a distance of 20cm calculated from the Friis transmission formula is far below the limit of 1 mW/cm 2 . The EUT is classified as mobile product. So, RF exposure limit warning or SAR test are not required. Channel Channel Frequency (MHz) Output Power to Antenna (dBm) Power Density at 20cm (mW/cm 2 ) LIMITS (mW/cm 2 ) CH1 2412.00 19.27 0.026652 1 CH6 2437.00 18.12 0.020452 1 CH11 2462.00 17.84 0.019175 1 Note : 1. For 802.11g Mode (6Mbps). 2. The power density Pd (4 th column) at a distance of 20cm calculated from the Friis transmission formula is far below the limit of 1 mW/cm 2 . The EUT is classified as mobile product. So, RF exposure limit warning or SAR test are not required.

Ecom Sertech Corp. Rm. 258, Bldg. 17, NO.195, Sec. 4 Chung Hsing Rd.,Chu -Tung Chen, Hsinchu, Taiwan 310, R.O.C TEL:886 - 3 - 5918012 FAX : 886 - 3 - 5825720 FCC ID ：M4Y-04-580 Report No.：EC04-05-048FRF Page 1 of 65 RF TEST REPORT Product Name ： 802.11b/g Wireless Station Adapter / Access Point Model Number ： XG-580 ； XG-580 plus FCC ID ： M4Y-04-580 Applicant ： Z-Com, Inc. Address ： 7F-2, No. 9, Prosperity Rd. I, Science-Based Industrial Park, Hsin-chu, Taiwan, R.O.C. Received Date ： May 20, 2004 Tested Date ： May 20 ~ June 10, 2004 Notes ： 1. This report will be invalid if duplicated or photocopied in part. 2. This report refers only to the specimen(s) submitted to testing, and be invalid as seperately used. 3. This report is invalid without examination stamp and signature of this institute. 4. The tested specimen(s) will be preserved for thirty days from the data issued. 5. The report must not be used to claim product certification, approval, or endorsement by NVLAP, NIST, or any agency of the federal government. Ecom Sertech Corp. Rm. 258, Bldg. 17, NO.195, Sec. 4 Chung Hsing Rd.,Chu -Tung Chen, Hsinchu, Taiwan 310, R.O.C TEL:886 - 3 - 5918012 FAX : 886 - 3 - 5825720 FCC ID ：M4Y-04-580 Report No.：EC04-05-048FRF Page 2 of 65 Test Report Certification Product Name ： 802.11b/g Wireless Station Adapter / Access Point Model Number ： XG-580 ； XG-580 plus FCC ID ： M4Y-04-580 Applicant ： Z-Com, Inc. Measurement Standard : FCC 47 C.F.R. Part 15, Subpart B and Subpart C (Section 15.247), ANSI C63.4-2001 WE HEREBY CERTIFY THAT: The measurements shown in the attachment were made in accordance with the procedures indicated, and the energy emitted by the equipment was found to be within the limits applicable. We assume full responsibility for the accuracy and completeness of these measurements and vouch for the qualifications of all persons taking them. Ecom Sertech Corp. Rm. 258, Bldg. 17, NO.195, Sec. 4 Chung Hsing Rd.,Chu -Tung Chen, Hsinchu, Taiwan 310, R.O.C TEL:886 - 3 - 5918012 FAX : 886 - 3 - 5825720 FCC ID ：M4Y-04-580 Report No.：EC04-05-048FRF Page 3 of 65 TABLE OF CONTENTS TITLE PAGE NO. 1. GENERAL INFORMATION ................................................................................................... 5 1.1 General Statement ...............................................................................................................................5 1.2 General Description of EUT & Power ................................................................................................5 1.3 Description of Test Modes ..................................................................................................................6 1.4 Description of Peripherals...................................................................................................................6 1.5 EUT & Peripherals Setup Diagram.....................................................................................................6 1.6 EUT Operating Condition ...................................................................................................................7 1.7 Description of Test Site.......................................................................................................................7 1.8 Summary of Test Results ....................................................................................................................8 2. CONDUCTED POWERLINE TEST....................................................................................... 9 2.1 Test Equipments..................................................................................................................................9 2.2 Test Setup............................................................................................................................................9 2.3 Conducted Power Line Emission Limit ..............................................................................................10 2.4 Test Procedure.....................................................................................................................................10 2.5 Uncertainty of Conducted Emission ...................................................................................................10 2.6 Conducted RF Voltage Measurement .................................................................................................11-14 2.7 Photos of Conduction Test ..................................................................................................................15 3. RADIATED EMISSION TEST ................................................................................................ 16 3.1 Test Equipments..................................................................................................................................16 3.2 Test Setup............................................................................................................................................16 3.3 Radiation Limit ...................................................................................................................................17 3.4 Test Procedures ...................................................................................................................................18 3.5 Uncertainty of Radiated Emission ......................................................................................................18 3.6 Radiated RF Noise Measurement........................................................................................................19-44 3.7 Photos of Open Site.............................................................................................................................45-46 4. 6dB BANDWIDTH MEASUREMENT ................................................................................... 47 4.1 Test Equipments..................................................................................................................................47 …

Text truncated - open the document above for the full version.

Ecom Sertech Corp. Rm. 258, Bldg. 17, NO.195, Sec. 4 Chung Hsing Rd.,Chu -Tung Chen, Hsinchu, Taiwan 310, R.O.C TEL:886 - 3 - 5918012 FAX : 886 - 3 - 5825720 FCC ID M4Y-04-580 Report No.EC04-05-048FRF Page 1 of 3 2.7 Photos of Conduction Test Ecom Sertech Corp. Rm. 258, Bldg. 17, NO.195, Sec. 4 Chung Hsing Rd.,Chu -Tung Chen, Hsinchu, Taiwan 310, R.O.C TEL:886 - 3 - 5918012 FAX : 886 - 3 - 5825720 FCC ID M4Y-04-580 Report No.EC04-05-048FRF Page 2 of 3 33.7 Photos of Open Site Ecom Sertech Corp. Rm. 258, Bldg. 17, NO.195, Sec. 4 Chung Hsing Rd.,Chu -Tung Chen, Hsinchu, Taiwan 310, R.O.C TEL:886 - 3 - 5918012 FAX : 886 - 3 - 5825720 FCC ID M4Y-04-580 Report No.EC04-05-048FRF Page 3 of 3
