M4Y-0835C11Mbps Wireless LAN CF Card

1 User’s Manual CF Card XI-835C 2 11Mbps Wireless LAN CF Card Quick Start Guide I. Network Configuration 11Mbps Wireless LAN CF Card is an IEEE802.11/802.11b compliant CF Type I DSSS wireless LAN adapter. It fully supports wireless networking under Windows 2000/XP/CE. ® 11Mbps Wireless CF Card can be operated in Ad-Hoc or Infrastructure network configurations. Ad-Hoc mode allows 11Mbps Wireless LAN CF Card users to join a Basic Service Set (i.e., peer-to-peer mode, without access point). Infrastructure mode allows 11Mbps Wireless LAN CF Card users to join an Extended Basic Service Set (i.e., connect to access point) II. Package Content 11Mbps Wireless LAN CF Card x 1 Quick Installation Guide x 1 Product CD-ROM x 1 III. Wireless LAN CF Card and Utility Installation under Pocket PC/Handheld PC Installation of the 11Mbps Wireless LAN CF Card under CE 3.0/Pocket PC 2002 1. Establish a connection between host PC and PDA (only for hand-held) device by Microsoft Active Sync program. 2. Insert and run SanDisk AutoRun Program Source CD-ROM/Pocket PC 2002 to install the driver and utility. 3. Once SanDisk ConnectPlus Front Page appears, click on ‘Installation’ 4. Following the necessary prompts. Once SanDisk ConnectPlus Front Page re-appears, click ‘Exit’ 5. Click ‘OK’ and reset your Pocket PC accordingly. 6. Insert the 11Mbps Wireless LAN Compact Flash Card into the compact flash slot of your PDA (only for hand-held). The PDA (only for hand-held) will auto-detect the Wireless LAN Compact Flash Card and automatically install the corresponding driver. Infrastructure Network Ad-hoc Network Wired Network Wireless Network Access Point 3 7. Assign an IP address to your Wireless LAN Compact Flash Card. You may either choose to give a fixed IP address or have the Wireless LAN Compact Flash Card automatically obtain an IP address from your DHCP server. Set the Proxy server, DNS, WINS if needed (Most of IP addresses are automatically assigned.) 8. Reset your PDA (only for hand-held) to complete the installation. ÿ Caveat n When the Pocket PC is idle (not in use) without A/C power being present, it is highly advised to remove the 11Mbps Wireless LAN CF Card in order to prevent from complete battery drain. n Due to WinCE's nature of the first application at power-on resuming to that at power-off, if you are stuck at the utility program, you may use the PDA's (only for hand-held) reset bottom to terminate it. And activate it again when needed. n Sometimes, your wireless connection to AP may disconnect for any reason. You can reset and force a connection request by going to utility program, then select " Configuration ", check parameters, then select " Apply " to force a re-scan. n If your device roams to a new AP which is in a different subnet, you may need the following two actions: (1) Unplug and re-insert the Wireless LAN Compact Flash Card, or (2) Hard reset your device to force an execution of "release and renew" of an re-assignment of IP address in a DHCP Access Point environment. IV. Wireless LAN CF Card and Utility Installation under Windows XP/2000/NT/98/ME Installation of the11Mbps Wireless LAN CF Card under Windows XP 1. If your PC has a compact flash type I slot, simply insert the Wireless LAN CF Card into the CF slot. If not, use a CF/PCMCIA Adapter as described in the next procedure. 2. Firmly insert the 11Mbps Wireless LAN CF Card into the CF/PCMCIA Adapter, figured as below. Then insert the 11Mbps Wireless LAN CF Card into the PCMCIA slot and start Windows. CF/PCMCIA Adapter CF Card 4 3. Windows will auto-detect the Wireless LAN CF Card and a “ Found New Hardware Wizard ” window will show up. 4. Select “ Install from a list or specific (Advanced) ” and insert the SanDisk AutoRun Program CD-ROM into the CD-ROM drive. Check the CD-ROM drive item and click on Next to install the driver. 5. Once SanDisk Connect Plus Front Page appears, click on Installation 6. Select Windows/92/ME/2000/XP 7. Select the necessary prompts, especially click ‘Yes’ to proceed to insert Microsoft Hotfix for Windows XP 8. The windows will find “ IEEE 802.11 Wireless LAN/CF Card ”. Click on Next to continue. 9. Click Finish to complete the installation. After installing the Wireless LAN CF Card, the Windows XP will display a “Wireless Network Connection # ” message. Click on the message and the “Automatic Wireless Network Configuration” will then appear automatically and allow users to connect a wireless infrastructure network (Access Point), shown as follows: You may click the Advanced button to make advanced configuration for the 11Mbp Wireless LAN CF Card, shown as below. 5 For more information on using the automatic wireless network configuration please refer to Windows XP Help file. However, the WLAN Utility, which comes with the Wireless LAN CF Card, provides you more tools to configure the 11Mbps Wireless LAN CF Card and monitor the wireless connection. For more information on installing and using the WLAN utility, please refer to the following sections “Installation of the Wireless LAN Utility” and “Usage of the WLAN Utility”. Note: To use the WLAN utility under Windows XP, you need to disable the Automatic Wireless Network Configuration first. Steps are described as follows: n Right click the Network Connections icon. Select Properties . n Go to the Wireless Networks tab. n Uncheck the “ Use Windows to configure my wireless network settings ” check box and click the OK button ( see the above picture). 6 FCC Information This device, CF Card (model no.: XI-835C), complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received; including interference that may cause undesired operation. Federal Communications Commission (FCC) Statement This Equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC rules. These limit…

Text truncated - open the document above for the full version.

Z-Com, Inc. 7F-2, No.9, Prosperity 1St RD., Science-Based Industrial Park, Hsinchu, Taiwan R.O.C. TEL: (886)-3-3577364 ext.147 FAX: (886)-3-5639241 Company Z-Com, Inc. Address 7F-2, No. 9, Prosperity RD. 1, Science-Based Industrial Park, Hsinchu, 300 Taiwan. Country Taiwan Telephone number +886-3-577-7364 Fax number +886-3-577-3359 Internet [email protected] Federal Communications Commission Authorization and Evaluation Division Confidentiality Request RE: FCC ID: M4Y-0835C Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying this Application as outlined below: Schematics Block Diagram Technical Specification The above materials contain trade secrets and proprietary information not customarily release to the public. The public disclosure of these matters might be harmful to the Applicant and Provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the data of the Grant for this application.

American Telecommunications Certification Body Inc. 6731 Whittier Ave, McLean, VA 22101 April 8, 2003 RE: FCC ID: M4Y-0835C_ATCB000362 Attention: Elton Chen I have a few comments on this Application. 1. Your report states that the antenna is an internal/integral antenna. The internal photos show an antenna connector but not what kind (photo is not clear). It is not clear if the ‘cover’ that is removed for internal photos contains the antenna. Please describe the antenna and how it is internal/integral. Please provide a photo of the cover/antenna for this device showing how it connect to the antenna terminal. 2. The band edge plots appear to show that the peaks of the transmitted signals are being compressed. This will affect all of the parameters of the plot and produce erroneous readings. Please show band edge compliance without signal compression. 3. The manual specifically states that this device can be used in a PDA. The SAR report only addresses this device as used in a laptop. Please provide test data showing compliance of this device as it is intended to be used as described in the manual (i.e. in a laptop and in a PDA). 4. You have not listed the Crest Factor on the data graphs/plots. Please verify these factors. 5. I found the probe calibration data, but I could not find the dipole calibration data. Please provide. Dennis Ward mailto:[email protected] The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information may result in application termination. Correspondence should be considered part of the permanent submission and may be viewed from the Internet after a Grant of Equipment Authorization is issued. Please do not respond to this correspondence using the email reply button. In order for your response to be processed expeditiously, you must submit your documents through the AmericanTCB.com website. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the sender.

dward From: Julia Chu [[email protected]] Sent: Thursday, April 17, 2003 5:01 AM To: Dennis Ward Cc: Sammy Wu ITS/LAB-TPE Subject: Re: FCC ID: M4Y-0835C (ATCB000362) Importance: High Page 1 of 1 4/17/2003 Dear Dennis, Thanks for your kindly advise. As per your review comments, please see the explanation below: 1) The antenna of this device is a PIFA antenna, and the connector is a testing port. I have marked it on the internal photo and have it attached for your reference. 2) We have remeasured the Band-edge test. Please find the attached file as file name " revised-band edge plot" for your review. 3) Please find the revised manual provided by our client as attachment for your reference. 4) Due to the crest factors of DSSS and CW signals are the same (equals to 1), We chose the CW factor of probe calibration, which showed on the plots. We will add the crest factor on the plots. 5) We modified the SAR report regarding to your requirement. Please find the revised SAR report attached. I hope the supplementary satisfy all your requirements for reviewing this project, if you have further question, please feel free to let me know. Best Regards, Julia Chu Intertek Testing Services Taiwan Ltd. ETL SEMKO Tel: (+886-3) 519-1411 ex 304 Fax: (+886-3) 519-1410 [email protected] www.etlsemko.com








FCC ID Label Location 36 mm 36 mm

Photo 1: Inner view XI-835C XI-835C PIFA antenna Testing port Photo 2: Inner view XI-835C XI-835C











   !

    "  #$ %






  %&' ()!*)   +,%&'       +,

-
                                                                          !    "   #



































  . / 0
1   " /

21 #$             3 4 5%+!5 %671 ,+)%!! %!,8)5  ! 5!$% %. 4()9:)5 ;%
2
2</$,  5%=$:+! !'>!),/  . +) % 5!5'5"7: :  ,)%/ 5 5 '%,& ? 5  55!= ,/ )!' +)   =: +)+$% +!)& 2$)5%&% '5 & ± /@/  %+!,%5?5)5 )) ,%!%&'3 4   )55'5?5)5=: +) 5%+!+$% +2$, )%  &
  55!=& ? 5 , A%   %  & =# , A%!)   5255 /
/225*B$/  ! !) %:5%+!, )% &! 5!,8)5% % 4()9:)5 ;%
2
2< & %'!  $) /


































  . / 0
1   " /

21 #$    !"    2/2  5   71 &%8)   #$%
& ' ( ) *#+*$  "&+&+!+, ,-*. */0&-1      2/  8)5)%;A<  *,-&"+&*#%


2-#+
3(4 *,  *,+ +  3 4
,+. %  71
"


+*$
  5#-*+  A!  %+ 5
*+2-+&$!,  2 C 9  >D
$+  :::

6 +"+&*#
$#+
7-*  .?%
"+


8  $ %(
&
6+7 *,-&%  *+.+"-&
-7&-*+*%  3 4   *,-&#.+,%E7F0EF"   6*+&+9+,+%  /2

  6*+&+9+,&,% G % $! %   '/  +*,+%  !

  ++,,+%  !




































  . / 0
1   " /

21 #$   2/  !   .  )# /2
. H4()9:)5 ;%
2
2<   2/ :'5!  $)    2//2 :'5& !=%$5I:) 8)5  -##* 2-#+ +: 2-#+,+.   2 !   5)7
*

91                   2 %% ,# : , 5!.%; ,<


































  . / 0
1   " /

21 #$   -*+(% 6#+*#+,&-.*#1,&+;  2//  #
                     !5  '
  %  -*+%!   !"! #$%!& $"'#&$%      !5   %   ' 255


































  . / 0
1   " /

21 #$9   2//  %   )$, !%;5? .! )$<,%5%,  ,$! %   6+ 4,  & ! 5) "&+4+1++ +5+< ,+.2-,-*7&+%   )!$# 5 &  5  $255 %!)   -. -0+, !,$0, ( %' 6!+*$ +! ,%  5  ! 5) )$&'/ +. *+2-+&$ 0= !+7*+  + >? 7+*  + >?  , 2 2 29/29/ % 9 29/2929/29 ,-&+, -#- 1+* >$ 22 9 2/92/9   =: +),%  ,5%%%$ $!% %&' 5) !)/  ! %)!% )) ,,5)%& % )$+$ ,5/ , 5%%B,% .55 '8)!%)$5$5 %/  2/ % ! 8)% ! 5!  =$:+!55% 5 % ! /   2/9 %% %+ %?!)   5%%   55 '%,& ? 5  55!=+!,/


































  . / 0
1   " /

21 #$   (   @ 6    /2 : 5
  ,$. 5 : ' %+! G# ) BA!  % ? )+ 5
A 6  >8++*. #-.6&*..+, 5#-*++9*+?    >/?
+$ +, & %'

/
1
:#=;2$<
2/9

:#= %, %=;2
$<
/

































…

Text truncated - open the document above for the full version.

Intertek Testing Services ETL SEMKO FCC ID. : M4Y-0835C Report No.: EME-030310 Page 1 of 23 EMC TEST REPORT Report No. : EME-030310 Model No. : XI-835C Issued Date : Mar. 24, 2003 Applicant : Z-COM, Inc. 7F-2, No. 9, Prosperity 1 St RD., Science-Based Industrial Park, Hsinchu, Taiwan Test By : Intertek Testing Services Taiwan Ltd. No. 11, Lane 275, Ko-Nan 1 Street, Chia-Tung Li, Shiang-Shan District, Hsinchu City, Taiwan This test report consists of 23 pages in total. It may be duplicated completely for legal use with the allowance of the applicant. It shall not be reproduced except in full, without the written approval of ITS Laboratory. The test result in this report only applies to the tested sample. Jerry Liu Project Engineer Reviewed By Elton Chen Intertek Testing Services ETL SEMKO FCC ID. : M4Y-0835C Report No.: EME-030310 Page 2 of 23 Table of Contents Summary of Tests ............................................................................................................. 3 1. General information...................................................................................................... 4 1.1 Identification of the EUT........................................................................................ 4 1.2 Additional information about the EUT................................................................... 4 1.3 Antenna description ................................................................................................ 5 1.4 Peripherals equipment ............................................................................................ 5 2. Test specifications.........................................................................................................6 2.1 Test standard ........................................................................................................... 6 2.2 Operation mode ...................................................................................................... 6 2.3 Test equipment........................................................................................................ 7 3. Minimum 6dB Bandwidth test ..................................................................................... 8 3.1 Operating environment ........................................................................................... 8 3.2 Test setup & procedure ........................................................................................... 8 3.3 Measured data of Minimum 6dB Bandwidth test results ....................................... 8 4. Maximum Output Power test........................................................................................ 9 4.1 Operating environment ........................................................................................... 9 4.2 Test setup & procedure ........................................................................................... 9 4.3 Measured data of Maximum Output Power test results ......................................... 9 5. Radiated Emission test ............................................................................................... 10 5.1 Operating environment ......................................................................................... 10 5.2 Test setup & procedure ......................................................................................... 10 5.3 Emission limits ..................................................................................................... 11 5.4 Radiated spurious emission test data .................................................................... 12 5.4.1 Measurement results: frequencies equal to or less than 1 GHz ......................... 12 5.4.2 Measurement results: frequency above 1GHz................................................... 15 6. Power Spectrum Density test...................................................................................... 18 6.1 Operating environment ......................................................................................... 18 6.2 Test setup & procedure ......................................................................................... 18 6.3 Measured data of Power Spectrum Density test results ....................................... 18 7. Emission on the band edge §FCC 15.247(C) ............................................................. 19 8. Power Line Conducted Emission test §FCC 15.207 .................................................. 20 8.1 Operating environment ......................................................................................... 20 8.2 Test setup & procedure ......................................................................................... 20 8.3 Power Line Conducted Emission test data ........................................................... 21 Intertek Testing Services ETL SEMKO FCC ID. : M4Y-0835C Report No.: EME-030310 Page 3 of 23 Summary of Tests CF Card-Model: XI-835C FCC ID: M4Y-0835C Test Reference Results Minimum 6dB Bandwidth test 15.247(a)(2) Complies Maximum Output Power test 15.247(b) Complies Radiated Spurious Emission test 15.205, 15.209 Complies Power Spectrum Density test 15.247(d) Complies Power Line Conducted Emission test 15.207 Complies Intertek Testing Services ETL SEMKO FCC ID. : M4Y-0835C Report No.: EME-030310 Page 4 of 23 1. General information 1.1 Identification of the EUT Applicant : Z-COM, Inc. Product : CF Card Model No. : XI-835C FCC ID. : M4Y-0835C Frequency Range : 2412~2462 MHz Channel Number : 11 Channels Frequency of Each Channel : 2412MHz, 2417MHz, 2422MHz, 2427MHz, 2432MHz, 2437MHz, 2442MHz, 2447MHz, 2452MHz, 2457MHz, 2462MHz Type of Modulation : CCK (11Mps, 5.5Mbps), DQPSK (2Mbps), DBPSK (1Mbps) Power Supply : 3.3Vdc from notebook Power Cord : N/A Sample Received : Mar. 4, 2003 Test Date(s) : Mar. 5, 2003 to Mar. 18, 2003 A FCC DoC report has been generated for the client. 1.2 Additional information about the EUT The EUT can be operated in A…
