M4Y-XG110054Mbps 802.11g Wireless Access Point

FEB/25th/2002 1 54Mbps 802.11g Wireless Access Point Version 1.0 -- September 2003 FEB/25th/2002 2 Table of Contents Quick Start Guide Version 1.0 3 1. Package Content 3 2. Installing the 54Mbps 802.11g Wireless Access Point 3 3. Configuring the 54bps 802.11g Wireless Access Point 4 3.1 How to access the Web-based configuration Utility 4 3.2 Configuration: 4 3.2.1 Local Area Network settings: 5 3.2.2 Wireless settings 5 3.2.3 WDS links 6 3.2.4 Wireless Security 7 3.2.4.1 ACL 7 3.2.4.2 WEP 7 3.2.4.3 RADIUS 8 3.2.4.4 802.1x 8 3.2.4.5 WPA 9 3.3 Install Wizard 9 3.4 Status: 10 Technical Support 10 FCC Information 11 FEB/25th/2002 3 Introduction The next-generation wireless LAN device – 54Mbps 802.11g Wireless Access Point, brings an extremely high performance to the wireless realm. Fully compliant with IEEE802.11g standard, the 54Mbps 802.11g Wireless Access Point also provides powerful features such as the WDS, WPA security, SNMP and more. Maximize network efficiency while minimizing your network investment and maintenance costs. 1. Package Content 54Mbps Wireless LAN Access Point x 1 DC Power Adapter x 1 Quick Start Guide x 1 Note: If any of the above items are missing or damaged, contact your local dealer for support. 2. Installing the 54Mbps 802.11g Wireless Access Point „ Connect the 54Mbps 802.11g Wireless Access Point to a hub (in Bridge mode) or a PC with its UTP Ethernet cable. Please note that, use the cross-over cable when you directly connect the Access Point to a PC. „ Connect the power adapter to the power socket on the 54Mbps 802.11g Wireless Access Point, and plug the other end of the power pack into an electrical outlet. Note 1: ONLY use the power adapter supplied with the 54Mbps 802.11g Wireless Access Point. Otherwise, the product may be damaged. Note 2: The button labeled “DEFAULT” enables you to restore the 54Mbps Wireless LAN Access Point’s default setting. This is used when you forget the password. Please press the “DEFAULT” button on the side panel of the Wireless Access Point at least for 10 seconds then release the button and wait for a reboot. Usually it will take you another 30 seconds. Afterward, you will have the 54Mbps 802.11g Wireless Access Point’s default settings and can configure the Access Point via Web again. FEB/25th/2002 4 3. Configuring the 54bps 802.11g Wireless Access Point The 54Mbps 802.11g Wireless Access Point allows configuration only via Web. 3.1 How to access the Web-based configuration Utility The following gives instructions guiding you through the installations of the Wireless Access Point. 1. Connect your computer to the Access Point either through wireless or wired connection. Please set a fixed IP address, within the range of 192.168.1.X (X can’t be 254), to your computer. If you attempt to use a wireless connection, you must also set a configuration in your computer in advance as below. SSID: default WEP: disable 2. Activate your web browser and type in the IP address of your AP in the Address or location field and press Enter. The default value of Access Point is 192.168.1.254. 3. Follow the on-screen instructions to enter the system password then press Enter. The default value of password is “private”. The Web-based configuration Utility provides 3 items for you to monitor and configure the Wireless Access Point: Configuration, Install Wizard and Status. 3.2 Configuration: These core options are essential to enable the AP to work properly. FEB/25th/2002 5 3.2.1 Local Area Network settings: Three selections are provided. If you plan to use any external DHCP server, select Dynamic. Otherwise set the LAN address to Static. Under the Static IP, you have the third choice to turn on the internal DHCP server. First enter the setting on the DHCP server page and enable the default DHCP server. Once DHCP is enabled, you have to make sure the IP address at the Static IP settings is in the range of the DHCP server in which the default DHCP server is usually enabled. 3.2.2 Wireless settings Your wireless settings will impact the coverage and the performance of your wireless LAN. AP can be operated in three different bandwidth scenarios: high rate 54Mbps, low rate 11Mbps and a mix of both below 54M and 11Mbps. To deliver the throughput FEB/25th/2002 6 enhancement in both mixed and g-only networks, you can also enable Prism Nitro mode by using Intersil’s packet bursting technology. The burst size is adjustable, usually the bigger burst packet, the more sharing of 11g transmission while a mixed network is introduced. You can also do something to logically hide the Access Point. By unclicking the broadcase SSID, your Access Point will refuse the connection request from whom is not aware the Network ID. But certainly the Access Point can be easily connected well when you realize the Network ID. 3.2.3 WDS links Extend the range of your network without having to use cables to link the Access Points by using the Wireless Distribution System (WDS): Put simply, you can link the Access Points wirelessly. Under WDS, your Access Points are still functioning as a regular Access Point, which can provide the link services to wireless clients. Enter the MAC address of another AP you wirelessly want to connect to into the appropriate field either by clicking Add WDS link or selecting the peer Access Point that your Access Point finds out. The implementation can be done as below. FEB/25th/2002 7 3.2.4 Wireless Security To protect your wireless intellectual property, it is important to secure your wireless connection. This Access Point is equipped a sophisticated security algorithm to protect against intruders entering your system or listening to the conversation over your network. 3.2.4.1 ACL You can assign different access rules for different users by adding the MAC address and the access rights which is to either accept or reject the connection. 3.2.4.2 WEP The basic security settings is to enable WEP algorithm by assigning 64 or 128 bits encryption key. You have…

Text truncated - open the document above for the full version.

Company : Z-COM, INC. Page : 1 of 16 Product : 54Mbps 802.11g Wireless Access Point Model : XG-1100 Company : Z-COM, INC. Page : 2 of 16 Product : 54Mbps 802.11g Wireless Access Point Model : XG-1100 Company : Z-COM, INC. Page : 3 of 16 Product : 54Mbps 802.11g Wireless Access Point Model : XG-1100 Company : Z-COM, INC. Page : 4 of 16 Product : 54Mbps 802.11g Wireless Access Point Model : XG-1100 Company : Z-COM, INC. Page : 5 of 16 Product : 54Mbps 802.11g Wireless Access Point Model : XG-1100 Company : Z-COM, INC. Page : 6 of 16 Product : 54Mbps 802.11g Wireless Access Point Model : XG-1100 Company : AC ADAPTOR Page : 7 of 16 Product : 54Mbps 802.11g Wireless Access Point-Adapter Model : SP48-121000 Company : AC ADAPTOR Page : 8 of 16 Product : 54Mbps 802.11g Wireless Access Point-Adapter Model : SP48-121000 Company : AC ADAPTOR Page : 9 of 16 Product : 54Mbps 802.11g Wireless Access Point-Adapter Model : SP48-121000 Company : AC ADAPTOR Page : 10 of 16 Product : 54Mbps 802.11g Wireless Access Point-Adapter Model : SP48-121000 Company : AC ADAPTOR Page : 11 of 16 Product : 54Mbps 802.11g Wireless Access Point-Adapter Model : SP48-121000 Company : AC ADAPTOR Page : 12 of 16 Product : 54Mbps 802.11g Wireless Access Point-Adapter Model : SP48-121000 Company : AC ADAPTOR Page : 13 of 16 Product : 54Mbps 802.11g Wireless Access Point-Adapter Model : SP48-121000 Company : AC ADAPTOR Page : 14 of 16 Product : 54Mbps 802.11g Wireless Access Point-Adapter Model : SP48-121000 Company : AC ADAPTOR Page : 15 of 16 Product : 54Mbps 802.11g Wireless Access Point-Adapter Model : SP48-121000 Company : AC ADAPTOR Page : 16 of 16 Product : 54Mbps 802.11g Wireless Access Point-Adapter Model : SP48-121000

Company: Z-COM, INC Model: XG-1100 Product : 54Mbps 802.11g Wireless Access Point 54Mbps 802.11g Wireless Access Point Model No: XG-1100 FCC IDM4Y-XG1100 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: [1] this device may not cause harmful interference and [2] this device must accept any interference received, including interference that may cause undesired operation. S/N Made in Taiwan

Company : Z-COM, INC. Page : 1 of 7 Product : 54Mbps 802.11g Wireless Access Point Model : XG-1100 Company : Z-COM, INC. Page : 2 of 7 Product : 54Mbps 802.11g Wireless Access Point Model : XG-1100 Company : Z-COM, INC. Page : 3 of 7 Product : 54Mbps 802.11g Wireless Access Point Model : XG-1100 Company : Z-COM, INC. Page : 4 of 7 Product : 54Mbps 802.11g Wireless Access Point Model : XG-1100 Company : Z-COM, INC. Page : 5 of 7 Product : 54Mbps 802.11g Wireless Access Point Model : XG-1100 Company : Z-COM, INC. Page : 6 of 7 Product : 54Mbps 802.11g Wireless Access Point Model : XG-1100 Company : AC ADAPTOR Page : 7 of 7 Product : 54Mbps 802.11g Wireless Access Point Model : SP48-121000

Description of Operation EUT is a 54Mbps 802.11g Wireless Access Point with 11 channels. This device provided four kind of transmitting speed 1,2,5.5 and 11Mbps. The device of RF carrier is DQPSK,DB PSK and CCK. The device adapts direct sequence spread spectrum modulation. The Connector antenna was scolded on PCB provided diversity function to improve the receiving function. This 54Mbps 802.11g Wireless Access Point is an IEEE 802.11b Wireless LAN adapter. It allows your computer to connect to a wireless network and to share resources, such as files or printers without being bound to the network wires. Operation in 2.4GHz Direct Sequence Spread Spectrum (D.S.S.S) or Orthogonal Frequency division Multiplex (O.F.D.M) radio transmission, the 54Mbps 802.11g Wireless Access Point transfers data at speeds up to 64/128-bit Wired Equivalent Protection(WEP) algorithm is used. In addition, its standard compliance ensures that it can communicate with any 802.11b/g network.

Ecom Sertech Corp. Rm. 258, Bldg. 17, NO.195, Sec. 4 Chung Hsing Rd.,Chu -Tung Chen, Hsinchu, Taiwan 310, R.O.C TEL:886 - 3 - 5918012 FAX : 886 - 3 - 5825720 FCC ID ：M4Y-XG1100 Report No.：ER03-10-033FRF Page 1 of 2 RF EXPOSURE EVALUATION According to FCC 1.1310 : The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency (RF) radiation as specified in 1.1307(b) LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Average Time (A) Limits for Occupational / Control Exposures 300-1,500 -- -- F/300 6 1,500-100,000 -- -- 5 6 (B) Limits for General Population / Uncontrol Exposures 300-1,500 -- -- F/1500 6 1,500-100,000 -- -- 1 30 Friis Formula Friis transmission formula : Pd = (Pout*G)/(4*pi*r 2 ) Where Pd = power density in mW/cm 2 Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm Pd id the limit of MPE, 1 mW/cm2. If we know the maximum gain of the antenna and the total power input to the antenna, through the calculation, we will know the distance r where the MPE limit is reached. EUT Operating Condition A software provided by client enabled the EUT to transmit and receive data at lowest, middle and highest channel individually. Ecom Sertech Corp. Rm. 258, Bldg. 17, NO.195, Sec. 4 Chung Hsing Rd.,Chu -Tung Chen, Hsinchu, Taiwan 310, R.O.C TEL:886 - 3 - 5918012 FAX : 886 - 3 - 5825720 FCC ID ：M4Y-XG1100 Report No.：ER03-10-033FRF Page 2 of 2 Test Result of RF Exposure Evaluation Test Item ： RF Exposure Evaluation Data Test Mode ： Normal Operation Antenna Gain Antenna Gain：The maximum Gain measured in fully anechoic chamber is 2dBi linear scale. Output Power into Antenna & RF Exposure Evaluation Distance Channel Channel Frequency (MHz) Output Power to Antenna (dBm) Power Density at 20cm (mW/cm 2 ) LIMITS (mW/cm 2 ) CH1 2412.00 18.95 0.247590 1 CH6 2437.00 18.04 0.020078 1 CH11 2462.00 17.12 0.016245 1 Note : 1. For 802.11b Mode (11Mbps). 2. The power density Pd (4th column) at a distance of 20cm calculated from the Friis transmission formula is far below the limit of 1 mW/cm 2 . The EUT is classified as mobile product. So, RF exposure limit warning or SAR test are not required. Channel Channel Frequency (MHz) Output Power to Antenna (dBm) Power Density at 20cm (mW/cm 2 ) LIMITS (mW/cm 2 ) CH1 2412.00 16.55 0.014247 1 CH6 2437.00 15.79 0.011960 1 CH11 2462.00 14.99 0.009948 1 Note : 1. For 802.11g Mode (6Mbps). 2. The power density Pd (4th column) at a distance of 20cm calculated from the Friis transmission formula is far below the limit of 1 mW/cm 2 . The EUT is classified as mobile product. So, RF exposure limit warning or SAR test are not required.

Ecom Sertech Corp. Rm. 258, Bldg. 17, NO.195, Sec. 4 Chung Hsing Rd.,Chu -Tung Chen, Hsinchu, Taiwan 310, R.O.C TEL:886 - 3 - 5918012 FAX : 886 - 3 - 5825720 FCC ID ：M4Y-XG1100 Report No.：ER03-10-033FRF Page 1 of 61 TEST REPORT Product Name ： 54Mbps 802.11g Wireless Access Point Model Number ： XG-1100 Applicant ： Z-Com, Inc. Address ： 7F-2 No. 9 Prosperity RD. 1, HSIP, Hsinchu 300, Taiwan R.O.C. Received Date ： Oct. 17, 2003 Tested Date ： Oct. 07~Nov. 05, 2003 Notes ： 1. This report will be invalid if duplicated or photocopied in part. 2. This report refers only to the specimen(s) submitted to testing, and be invalid as seperately used. 3. This report is invalid without examination stamp and signature of this institute. 4. The tested specimen(s) will be preserved for thirty days from the data issued. 5. The report must not be used to claim product certification, approval, or endorsement by NVLAP, NIST, or any agency of the federal government. Ecom Sertech Corp. Rm. 258, Bldg. 17, NO.195, Sec. 4 Chung Hsing Rd.,Chu -Tung Chen, Hsinchu, Taiwan 310, R.O.C TEL:886 - 3 - 5918012 FAX : 886 - 3 - 5825720 FCC ID ：M4Y-XG1100 Report No.：ER03-10-033FRF Page 2 of 61 Test Report Certification Product Name : 54Mbps 802.11g Wireless Access Point Model Number : XG-1100 Applicant : Z-Com, Inc. Measurement Standard : 47 CFR Part 15, Subpart B and Subpart C (Section 15.247), ANSI C63.4-2001 WE HEREBY CERTIFY THAT: The measurements shown in the attachment were made in accordance with the procedures indicated, and the energy emitted by the equipment was found to be within the limits applicable. We assume full responsibility for the accuracy and completeness of these measurements and vouch for the qualifications of all persons taking them. Ecom Sertech Corp. Rm. 258, Bldg. 17, NO.195, Sec. 4 Chung Hsing Rd.,Chu -Tung Chen, Hsinchu, Taiwan 310, R.O.C TEL:886 - 3 - 5918012 FAX : 886 - 3 - 5825720 FCC ID ：M4Y-XG1100 Report No.：ER03-10-033FRF Page 3 of 61 TABLE OF CONTENTS TITLE PAGE NO. 1. GENERAL INFORMATION .........................................................................................................5 1.1 General Statement ......................................................................................................................5 1.2 General Description of EUT & Power .......................................................................................5 1.3 Description of Peripherals..........................................................................................................6 1.4 EUT & Peripherals Setup Diagram............................................................................................7 1.5 EUT Operating Condition..........................................................................................................8 1.6 Description of Test Site .............................................................................................................8 1.7 Summary of Test Results ...........................................................................................................9 2. CONDUCTED POWERLINE TEST ..............................................................................................10 2.1 Test Equipments ........................................................................................................................10 2.2 Test Setup ..................................................................................................................................10 2.3 Conducted Power Line Emission Limit .....................................................................................11 2.4 Test Procedure ...........................................................................................................................11 2.5 Uncertainty of Conducted Emission ..........................................................................................11 2.6 Conducted RF Voltage Measurement ........................................................................................12 2.7 Photos of Conduction Test.........................................................................................................13 3. RADIATED EMISSION TEST ......................................................................................................14 3.1 Test Equipments ........................................................................................................................14 3.2 Test Setup ..................................................................................................................................14 3.3 Radiation Limit ..........................................................................................................................15 3.4 Test Procedures..........................................................................................................................16 3.5 Uncertainty of Radiated Emission .............................................................................................16 3.6 Radiated RF Noise Measurement ..............................................................................................17-41 3.7 Photos of Open Site ...................................................................................................................42-43 4. 6dB BANDWIDTH MEASUREMENT .........................................................................................44 4.1 Test Equipments ........................................................................................................................44 4.2 Test Setup ..................................................................................................................................44 4.3 Limits of 6dB Bandwidth Measurement ....................................................................................44 4.4 Test Procedure ...........................................................................................................................44 4.5 Uncertainty of Conducted Emi…

Text truncated - open the document above for the full version.

Ecom Sertech Corp. Rm. 258, Bldg. 17, NO.195, Sec. 4 Chung Hsing Rd.,Chu -Tung Chen, Hsinchu, Taiwan 310, R.O.C TEL:886 - 3 - 5918012 FAX : 886 - 3 - 5825720 FCC ID ：M4Y-XG1100 Report No.：ER03-10-033FRF Page 13 of 61 2.7 Photos of Conduction Test Ecom Sertech Corp. Rm. 258, Bldg. 17, NO.195, Sec. 4 Chung Hsing Rd.,Chu -Tung Chen, Hsinchu, Taiwan 310, R.O.C TEL:886 - 3 - 5918012 FAX : 886 - 3 - 5825720 FCC ID ：M4Y-XG1100 Report No.：ER03-10-033FRF Page 42 of 61 3.7 Photos of Open Site Ecom Sertech Corp. Rm. 258, Bldg. 17, NO.195, Sec. 4 Chung Hsing Rd.,Chu -Tung Chen, Hsinchu, Taiwan 310, R.O.C TEL:886 - 3 - 5918012 FAX : 886 - 3 - 5825720 FCC ID ：M4Y-XG1100 Report No.：ER03-10-033FRF Page 43 of 61
