ZC-3635-5-23 Broadband Wireless Access ODU Quick Installation Guide Copyright Copyright © 2008 all rights reserved. No part of this publication may be reproduced, adapted, stored in a retrieval system, translated into any language, or transmitted in any form or by any means without the written permission of the supplier. About the Installation Guide This Installation Guide is intended to guide professional installer to install the wireless bridge. It includes procedures assisting you in avoiding unforeseen problems. Conventions This indicates a warning or caution that you have to abide to avoid hazards. This indicates an important note that you must pay attention to. Note: Warning: Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. IMPORTANT NOTE: FCC Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 100cm between the radiator & your body. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. The availability of some specific channels and/or operational frequency bands are country dependent and are firmware programmed at the factory to match the intended destination. The firmware setting is not accessible by the end user. Professional Installation Required 1. Please seek assistance from a professional installer who is well trained in the RF installation and knowledgeable in the local regulations. 2. The ZC-36 35-5-23 is distributed through distributor and system installer with professional technicians and will not be sold directly through retail store. 3. Product is for Point to Point operation only and cannot be use for Point to Multipoint operation. TABLE OF CONTENT Professional Installation Required ................................................................................................... 2 CHAPTER 1 INTRODUCTION........................................................................................................... 5 INTRODUCTION...................................................................................................................................... 5 PRODUCT SPECIFICATION...................................................................................................................... 6 TYPICAL APPLICATIONS......................................................................................................................... 8 Tele-medical Broadband Wireless Application ................................................................................. 8 Campus Broadband Wireless Application......................................................................................... 9 CHAPTER 2 PREPARATION BEFORE INSTALLATION............................................................ 10 SAFETY PRECAUTIONS........................................................................................................................ 10 PRODUCT PACKETS.............................................................................................................................. 10 Mounting Kit................................................................................................................................... 11 Waterproof RJ-45 Connector Kit .................................................................................................... 11 SITE PLANNING................................................................................................................................... 12 Choosing a Mounting Location ...................................................................................................... 12 Antenna Polarization...................................................................................................................... 13 CHAPTER 3 HARDWARE INSTALLATION .................................................................................. 14 ASSEMBLE THE MOUNTING BRACKET................................................................................................. 14 POLE MOUNTING................................................................................................................................. 15 INTERFACE DEFINITION....................................................................................................................... 16 RS-232 .......................................................................................…

Text truncated - open the document above for the full version.

Z-COM, INC. 7F-2, No.9. Prosperity RD. I , Science-Based Industrial Park Hsinchu, 300 Taiwan Professional Installation Attestation Date:11/2/2009 To Whom It May Concern: Please be advised that due to the Market and function targeted by this product, this product will need special trained professional in configuring and installing the product. We hereby declare that the product will be distributed through controlled distribution channel which has special trained professional to install this product and will not be sold directly to the general public through retail store. This authorization is limited to the following products： FCC ID: M4Y-ZC3635-5V02 If you have any questions regarding the authorization, please don’t hesitate to contact us. Thank you! Sincerely yours, ------------------------------------- Ann Su Z-COM, INC. TEL：886-3-577-7364*167 FAX：886-3-577-3583 [email protected]

Z-COM, INC. 7F-2, No.9. Prosperity RD. I , Science-Based Industrial Park Hsinchu, 300 Taiwan Date: 2009/11/2 GENERAL DECLARATION We, Z-COM, INC. declares that device does not have “Ad Hoc on non-US frequencies” and/or “on DFS frequencies” while applying for the follow product. FCC ID: M4Y-ZC3635-5V02 If you have any questions regarding the authorization, please don’t hesitate to contact us. Thank you! --------------------------------------------- Ann Su Z-COM, INC. TEL：886-3-577-7364*167 FAX：886-3-577-3583 [email protected]

Z-COM, INC. 7F-2, No.9. Prosperity RD. I , Science-Based Industrial Park Hsinchu, 300 Taiwan 2009/11/2 Federal Communications Commission Authorization and Evaluation Division Confidentiality Request FCC ID: M4Y-ZC3635-5V02 Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying this Application as outlined below: Block Diagram Schematics Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely yours, ------------------------------------- Ann Su Z-COM, INC. TEL：886-3-577-7364*167 FAX：886-3-577-3583 [email protected]

Z-COM, INC. 7F-2, No.9. Prosperity RD. I , Science-Based Industrial Park Hsinchu, 300 Taiwan Power of Attorney 2009/11/2 To whom it may concern: We, the undersigned Z-COM, INC. hereby authorize Bureau Veritas Consumer Product Service (Hong Kong) Limited, Taoyuan Branch of Taiwan to act on our behalf in all matters relating to all processes required in the FCC Part 15C approval and any communication needed with the national authority. Any and all acts carried out by Bureau Veritas Consumer Product Service (Hong Kong) Limited, Taoyuan Branch on our behalf shall have the same effects as acts of our own. This authorization is limited to the following products： FCC ID: M4Y-ZC3635-5V02 If you have any questions regarding the authorization, please don’t hesitate to contact us. Thank you! Sincerely yours, -------------------------------- Ann Su Z-COM, INC. TEL：886-3-577-7364*167 FAX：886-3-577-3583 [email protected]

Page 1 CONSTRUCTION PHOTOS OF EUT Page 2

SCALE ECO NO.REVISIONAPP . DES. DATE TOLERANCE GRADE ( ) GRADE AB C LENGTH 60.050.080.20 0.080.100.30 0.100.150.40 0.200.300.80 66 18 18 50 50 18 0 ~ ~ ~ ~ DRW.DES.CKD. RECKD. APP . MODELSHEET DWG NO. V A 1 1 Z-Com ,Inc. NAME PAR T NO. 1 UNITS GRADEANGLE M.M. TOLERANCE 1 1 JULIE 10/28/2009 : 1.: 50# 2.: 3. 4. 5.():0.12mm+/-0.05mm 6.:+0.1/-0.2mm 7. 3.0 ZC-3635-5-23 IXP-3635 Pro LABEL 白色特多龍 貼紙黏處-示意圖 需捲狀入料 打字亮模 55-000040-IZN Size : 70x30 mm 4R-1.5 Model : ZC-3635-5-23 MAC : XXXXXX-XXXXXX SN : XXXXXXXXXXXXXX Power Rating : See the label on the PoE Injector ZC-3625 Default Settings : IP Address : 192.168.1.1 Password : password Domain : FCC ID : M4Y-ZC3635-5V02 廠商製作 廠內打印CODE示意圖--正確請依照BARCODE 對照表 Model : ZC-3635-5-23 MAC : XXXXXX-XXXXXX SN : XXXXXXXXXXXXXX Power Rating : See the label on the PoE Injector ZC-3635 Default Settings : IP Address : 192.168.1.1 Password : password Domain : FCC ID : M4Y-ZC3635-5V02

Page 3 Page 4 Page 5 Page 6 Page 7 Page 8 Page 9 Page 10 Page 11

Report No.: SA971126H03A Reference No.: 981026H09 1 RF EXPOSURE REPORT REPORT NO.: SA971126H03A MODEL NO.: ZC-3635-5-23 ACCORDING: FCC Guidelines for Human Exposure IEEE C95.1 APPLICANT: Z-COM, INC. ADDRESS: 7F-2, No.9. Prosperity RD. I , Science-Based Industrial Park Hsinchu, 300 Taiwan ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch LAB LOCATION: No. 81-1, Lu Liao Keng, 9th Ling, Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan Report No.: SA971126H03A Reference No.: 981026H09 2 RF Exposure Measurement 1. Introduction In this document, we try to prove the safety of radiation harmfulness to the human body for our product. The limit for Maximum Permissible Exposure (MPE) specified in FCC 1.1310 is followed. The Gain of the antenna used in this product is measured in a Fully Anechoic Chamber (FAC) calibrated for antenna measurement in our lab, and also the maximum total power input to the antenna is measured. Through the Friis transmission formula and the maximum gain of the antenna, we can calculate the distance, away from the product, where the limit of MPE is reached. Although the Friis transmission formula is a far field assumption, the calculated result of that is an over-prediction for near field power density. We will take that as the worst case to specify the safety range. 2. RF Exposure Limit According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environmental impact of human exposure to radio-frequency (RF) radiation as specified in 1.1307(b) LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Average Time (minutes) (A)Limits For Occupational / Control Exposures 300-1500 ... ... F/300 6 1500-100,000 ... ... 5 6 (B)Limits For General Population / Uncontrolled Exposure 300-1500 ... ... F/1500 30 1500-100,000 ... ... 1.0 30 F = Frequency in MHz Report No.: SA971126H03A Reference No.: 981026H09 3 3. Friis Formula Friis transmission formula : Pd = (Pout*G) / (4*pi*r 2 ) where Pd = power density in mW/cm 2 Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm Pd is the limit of MPE, 1 mW/cm 2 . If we know the maximum Gain of the antenna and the total power input to the antenna, through the calculation, we will know the MPE value at distance 100cm. Ref. : David K. Cheng, Field and Wave Electromagnetics, Second Edition, Page 640, Eq. (11-133). 4. EUT Operating condition The software provided by Manufacturer enabled the EUT to transmit and receive data at lowest, middle and highest channel individually. 5. Classification The antenna of this product, under normal use condition, is at least 100cm away from the body of the user. Warning statement to the user for keeping at least 100cm or more separation distance with the antenna should be included in users manual. So, this device is classified as Mobile Device Report No.: SA971126H03A Reference No.: 981026H09 4 6. Test Results 6.1 Antenna Gain There is one antenna provided to this EUT, please refer to the following table: No Antenna Gain Antenna Type Connector 1 23 dBi Patch Arry SMA 6.2 Output Power Into Antenna & RF Exposure value at distance 100cm: For Part 802.11a: Channel Channel Frequency (MHz) Output Power to Antenna (mW) Power Density (mW/cm 2 ) Limit of Power Density (mW/cm 2 ) 149 5745 549.5 0.872 1.0 157 5785 575.4 0.914 1.0 165 5825 562.3 0.893 1.0
