M5ZEPX1Engine Parameter Transmitter

FCC ID: M5ZEPX1 Installation and Operation Instructions for the Engine Parameter Transmitter Model EPX-1. Point Six, Inc. Wireless Engine Parameter Transmitter Model WOW-EPX1 Installation and Operation Instructions The WOW-EPX1 wireless engine parameter transmitter transmits engine temperature, air pressure, oil pressure, RPM, Runtime in hours and a unique serial number to a 418 MHz receiver. The EPX1 is enclosed in a 4X4X2 PVC enclosure for direct attachment to the firewall of the engine compartment. A 12-pin screw connector provides connection to 12V dc power, air and oil pressure sensors, engine temperature sensor and RPM sensor. A backup battery provides means to transmit status when primary power is lost. Application: Attach the PVC enclosure to the engine compartment firewall with bolts placed through the four-flange holes on the sides of the PVC junction box. Attach the engine sensors as is indicated on the enclosure lid drawing. The EPX-1 operates on 12 Volts DC . All sensors are provided power on the 12-pin quick disconnect screw connector on the bottom face of the PVC enclosure. . Battery: A 3.0-3.6 Volt lithium battery powers the WOWEPX1 wireless engine parameter transmitter whenever primary power is lost. The battery will last for more than 10 years in the idle state (primary power applied). The WOWEXP1 will provide backup function for as long as 2 years at a rate of once each minute once placed in backup transmission mode. The user cannot replace the battery. The EPX-1 may be placed in a quiescent state (battery life greater than 10 years and no transmissions) by removing the runtime backup iButton from the socket on the top surface of the PCB electronics. THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES, OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS: (1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE AND (2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE UNDESERED OPERATION FCC ID: M5ZEPX1 MADE IN USA Wireless Temperature Sensor Data Format The Point Six, Inc. 418 MHz wireless transmitters require a compatible receiver with the ability to receive, error check and provide RS232 and RS422/485 interface. This document describes the data format provided by the HA8-WOW, HA9-WOW or HA10- WOW 418 MHz. Receivers. The transmit packet from a receiver is approximately 15 milliseconds in duration and consists of 13 bytes of data: 1-byte ID/Mode field 8-byte serial number 2-byte temperature data 2-byte CRC-16 error check The WOW receivers process this packet. The receivers perform a CRC-16 error check on the packet. If the data is not accurate it is discarded. When a packet is received that is error free it is converted to a 29-character packet and transmitted out the serial port at 19,200 Baud. The data is transmitted serially in ASCII Hex format and terminated with a CR character. This format requires two bytes for each byte of data; 14 data bytes x 2=28 plus the CR is 29 characters The resulting binary data format of the packet is: 1-byte ID field this field will contain a byte whose LSBit indicates the service state of the transmitter, 0=normal, 1=service mode. 8-byte serial# this field contains the serial number of the 1-Wire sensor. 2-byte temperature this field contains the temperature data stored MSB first in two's compliment 16-bit form of 1/16 deg. C units. 2-byte CRC-16 this is the originally received data packet CRC as described above. 1-byte checksum the checksum is a mod 256 sum of all the ASCII character values in the response but does not include the CR Example: “EPX” Engine Parameter Transmitter C5 F1D61300050000070000BD2DE1<CR> string from an HA8 45 F1D61300050000070000BD2DE1<CR> string from an HA9 The device type field: LSX has device type C5/45 hex. A C4/44 hex when in service mode. C5F1D61300 050000070000BD2DE1<CR> string from an HA8 45F1D61300050000070000BD2DE1<CR> string from an HA9 The MS-30 bits of these 4-bytes are the Serial number of the EPX. The LS-2 bits are the status flags for the dc POWERSUPPLY. The LS bit (bit-0) is the is set to 1 when the 12 Volt DC power supply is present and 0 when it is not present. C1F1D613000500 00070000BD2DE1<CR> string from an HA8 41F1D61300050000070000BD2DE1<CR> string from an HA9 This 16-bit field stored LCByte first is the Runtime in hours (0-65535), this value accumulates based on engine RPM activity. The display value indicates 5 hours. C1F1D61300050010070000BD2DE1<CR> string from an HA8 41F1D61300050010070000BD2DE1<CR> string from an HA9 THIS 8-BIT FIELD IS THE ENGINE RPM DIVIDED BY 60, THE DISPLAYED VALUE INDICATES AN RPM OF 960-1020 RPM, (60*16-60*17) C1F1D61300050010560000BD2DE1<CR> string from an HA8 41F1D61300050010560000BD2DE1<CR> string from an HA9 This 8-bit field indicates Air Pressure in the compressed air system. The reading is in PSIG units; the displayed value is 88 PSIG. C1F1D613000500105684 00BD2DE1<CR> string from an HA8 41F1D61300050010568400BD2DE1<CR> string from an HA9 this 8-bit field is the Engine Temperature in degrees C. The displayed value is 84 degrees C. C1F1D6130005001056843CBD2DE1<CR> string from an HA8 41F1D6130005001056843CBD2DE1<CR> string from an HA9 this 8-bit field is the engine Oil Pressure in PSIG, the indicated value is 60 PSIG. C1F1D6130005001056843CBD2DE1<CR> string from an HA8 This field is the CRC-16 error check as was originally received and checked. This CRC is over the first 11 bytes of the packet starting with the device type and ending with inclusion of the temperature data. C1F1D61300050010560000BD2DE1 <CR> string from an HA8 This field is the mod 256 sum of all the ASCII character values in the response but does not include the <CR>. 91F1D61300050000070000BD2DE1<CR > string from an HA8 This is the CR terminator, 0Dhex. FCC Radio Frequency Interference Statement Wireless Engine Parameter Transmitter FCC ID: M5ZEPX1 NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant …

Text truncated - open the document above for the full version.

Dear Mr. Compton, We have a few issues to resolve on this application. 1. Please provide data responsive to 15.31(e) voltage variation requirements. Unlike your previous transmitters, this unit is primarily powered by an external 12VDC source. We need measurements made of the fundamental at 85% and 115% of nominal supply voltage. New data provided and placed in test report. 2. Please provide details on the cables attached to the unit during radiated emissions testing. Details include shielding status, length, and use of ferrite, if applicable. New data provided and placed in test report. Best regards Barry C. Quinlan Certification & Telecom Manager

dBi Corporation Point Six, Inc. 391 Codell Drive Lexington, KY. 40509, USA July 6, 2001 Federal Communications Commission Equipment Approval Services re: FCC ID: M5ZEPX1 Gentlemen: Enclosed please find the Point Six, Inc. application for FCC Certification of the Point Six Engine Parameter Transmitter, Model EPX-1. The test data submitted as part of this application were prepared by the dBi Corporation located at 131 French Ave, Winchester, KY. dBi Corporation has A2LA accreditation for EMC testing. Certificate number 1012.01 is valid to October 31, 2001. The facility used for radiated measurements is owned by Lexmark International, Inc. and was recognized by the Commission as meeting the requirements of section 2.948 of the Rules via a letter dated August 20, 1998. We submit the information in this application pursuant to the requirements of section 2.1033 and Part 15 of the Federal Communications Commission Rules and Regulations. We request that the Commission grant equipment authorization as soon as it is determined that the attached Application for Equipment Authorization is acceptable. We further request that the schematics and block diagrams of the Point Six Engine Parameter Transmitter be treated as confidential information as provided for in 47 CFR Section 0.459 (d) (2). Point Six considers this information to be a trade secret. The schematics and block diagrams are in Word files (included with this application) and are listed as 01dBi019(Schematics) and 01dBi019(Block-Diag) respectively. Thank you in advance for your assistance. If further information is required concerning this application, please do not hesitate to contact me. Sincerely John I. Compton President, Point Six, Inc. dBi Corporation FCC ID: M5ZEPX1 List of Exhibits 1. Cover Letter, Word file 01dBi019(Cover-Ltr) 2. FCC 731 Form, Word file 01dBi019(731) 3. Test Report, Word file 01dBi019(Test-Report) 4. Timing Information, Word file 01dBi019(Timing) 5. FCC Label Information, Word file 01dBi019(FCC-Label) 6. Operational Description, Word file 01dBi019(Op-Discrp) 7. Functional Block Diagram (Confidential), Word file 01dBi019(Block-Diag) 8. Schematics (Confidential), Word file 01dBi019(Schematics) 9. Transmitted Bandwidth Measurements, Word file 01dBi019(BW-Meas) 10. Users Manual, Word file 01dBi019(User's Man) 11. External Pictures, Word file 01dBi019(External-Pics) 12. Internal Pictures, Word file 01dBi019(Internal-pics) 13. Setup Pictures, Word file 01dBi019(Setup-pics)

FCC ID: M5ZEPX1 Overall view of the Point Six Engine Parameter Transmitter Model EPX-1

FCC ID: M5ZEPX1 FCC label and location of the label on the product. FCC ID Label shown on the Engine Parameter Transmitter, Model EPX-1

FCC ID: M5ZEPX1 Top and Bottom View of the Point Six Engine Parameter Transmitter Circuit Board, Model EPX-1

Test Report FCC ID: M5ZEPX1 EUT: Point Six Limit Engine Parameter Transmitter, Model EPX-1 Manufactured by: Point Six, Inc. 391 Codell Drive Lexington, KY. 40509 Measurements According to: ANSI C63.4 (1992) Measurement Date: May 30, 2001 Testing Performed at: Lexmark International, Inc. Registered Open Field Test Site Development Lab. 740 New Circle Road, NW. Lexington, KY. 40511-1876 Accreditation Status of Test Facility: The Lexmark site was recognized by the Commission as meeting the requirements of section 2.948 of the FCC Rules via a letter dated August 20, 1998 and is presently on file with the Commission. Test Report FCC ID: M5ZEPX1 Testing Results: (S/N 2D00000001048B97) Harmonic Freq. (MHz) Meter Peak dB Meter Average dB Ant & Cable Factors dB/uV/m Total Peak dB/uV/m Limit Peak dB/uV/m Total Average dB/uV/m Limit Average dB/uV/m 1 418(V) 69.50* - 19.28 88.78 92.78 - 72.30 2 836(V) 10.00 QP - 25.16 35.16 QP 46.00 QP - - 3 1254(V) 15.67 -2.19 24.60 40.27 74.00 22.41 54.00 4 1672(V) 14.19 -1.72 26.50 40.69 74.00 24.78 54.00 5 2090(V) 23.97 -1.26 28.10 52.07 74.00 26.84 54.00 6 2508(V) 11.85 -2.18 29.80 41.65 74.00 27.62 54.00 7 2926(V) 12.03 -1.60 31.50 43.53 74.00 29.90 54.00 8 3344(V) 12.06 -1.69 31.90 43.96 74.00 30.21 54.00 9 3762(H) 14.30 -2.13 32.40 46.70 74.00 30.27 54.00 10 4180(V) 11.10 -1.91 32.90 44.00 74.00 30.99 54.00 * Indicates max. radiation orientation; the product was measured at three different orientations. Sample Calculation: From FCC Rules, Paragraph 15.231(e) Frequency: 260-470 MHz. Amplitude: 1500-5000 uV/m For 418 MHz. L(limit)=((418-260)/(470-260))(5000-1500)+1500 L = 4133 uV/m L(dB/uV/m) = 20 Log (4133) L = 72.3 dB/uV/m (AVG) L(Peak) = Avg. + 20 dB L(Peak) = 72.3 + 20 = 92.3 dB/uV/m Signed:________________________________Date:_____________ D.R. Bush, PE, NCE, President dBi Corporation FCC ID: M5ZEPX1 The photo below indicates that the 20 dB transmitted bandwidth of the Point Six Engine Parameter Transmitter is 46 kHz. This is well within the maximum bandwidth specified by 47CFR15.233(c). Point Six Inc. 391 Codell Drive Lexington KY 40509 Gentlemen: On Thursday, August 2, Jim Factor of Point Six and I performed the measurements required in 47CFR15.31(e) on the Point Six EPX, Engine Parameter Transmitter. The instrumentation used included a Hewlett-Packard model 8568B spectrum analyzer, an EMCO loop antenna model 7405-902, and a Hewlett-Packard model 6114A precision adjustable power supply. The loop antenna was securely fixed near the EPX and the following relative measurements of the 418 MHz output power were taken: 12.0 volts 7.00 dBm (ref) 10.2 volts 7.00 dBm 13.8 volts 6.80 dBm As can be seen from these measurements, the 418 MHz output power varies insignificantly with power supply voltage variation. Please feel free to contact me if there are any questions concerning these measurements. Very truly yours, Donald R. Bush, PE, NCE The cable assembly used to test the EPX-1 was made up of three sets of four conductor cat 5 cable , and one three conductor 24 gauge cable . All cables were 3 meters long and were in one meter bundles . the board has ferrites on all inputs. Point Six, Inc. 391 Codell Drive Lexington, KY 40509 859-266-3606 Fax 266-0702 Signed:______________________ ________Date:_________ D. R. Bush, PE, NCE, President dBi Corporation FCC ID: M5ZEPX1 To Whom It May Concern: The Point Six, Inc. wireless engine parameter transmitter (model EPX-1) transmits a 15-16 millisecond packet once each 600-10 seconds. This is identical to the data packet timing of a previously certified “M5ZWOW”. I will restate this timing below. The packet consists of transmitter-on/transmitter-off timing that represents the serial number and humidity/temperature data. The duty cycle is approximately 50%. The packet time can vary with serial number between 14-16 milliseconds. The packet data is controlled by a microprocessor whose timing is based on a ceramic resonator that is very stable. The packet below (figure #2) illustrates a typical data packet, the worst case, 16 milliseconds, cannot be shown because serial number would have to be forced to make this so. Figure #1 illustrates the overall timing; a packet is sent each 10 seconds in this worst case. The battery used during the tests was new and was a standard 3.6 Volt Lithium cell. The battery is a 3.6 Volt Lithium chemistry, which has a flat discharge curve from new to about 90% used. In this application the battery requires about 5 years to discharge to the point that it cannot be used. The battery was used for no other purpose and had operated in the test unit for only a short time when the test was performed. The label will be Flexcon 2 mil PM200S mylar with a Flexcon 1 mil PM100C Polyester laminate. John I. Compton President, Point Six, inc. Point Six , Inc. 391 Codell Drive Lexington, Ky. 40509 606-266-3606 Fax 271-0702 FCC ID: M5ZEPX1 Figure #1 Overall timing Figure #2 Packet Timing

FCC ID: M5ZLSX1 Radiated Test Setup Picture of the Point Six Engine Parameter Transmitter, Model EPX-1
