M74PRONTOPRONTO

Each button on the one or six button PRONTO can be programmed to send a unique message to separate pagers or group of pagers. Both the six-button and one-button models can also send a specific message for an external switch or sensor. Installation To put the PRONTO in operation: Note:If your Pronto is not already programmed, refer to the programming guide first. 1. Install the 2-batteries in the Pronto (note the positive and negative end) 2. Locate and install the mounting bracket where it is to be used. (use screws, straps or velcro) 3. Position the unit into the notches in the mounting bracket and press until latch engages. 4. Turn on the pager (refer to the pager booklet). 5. Press the button(s) on the PRONTO to test that the pager is receiving the messages. Normal Operation 1. Press a button the pager will receive the message. Optional Power Supply The PRONTO may also be powered by an optional external power supply. Please contact Long Range Systems for more information. WARNING: Connection of an incorrect power supply will void the warranty. Long Range Systems 1 PRONTO Quick Guide PRONTO ™ Six and One Button Paging System QUICK SETUP & OPERATION Programming Your Pronto 1. Locate the 4-pin connector. 2. Connect the USB probe with special 4-pin connectors. 3. Plug into the PRONTO with 4-hole location. 4. Connect the USB plug to the PC. 5. Execute the PC program named “LRS Programmer”. 6. Click “New Table” to edit the messages associated with each button. Long Range Systems2PRONTO Quick Guide 7. Click “Edit” in the corresponding entry for message re-definition. 8. Click “Global Configuration” for configuration setting. Long Range Systems3PRONTO Quick Guide Long Range Systems4PRONTO Quick Guide Six Button Front Six Button Back O One Button Front One Button Back FCC Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the inter- ference by one of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. FCC Caution: Any changes or modifications not expressly approved by the party responsible for com- pliance could void the user's authority to operate this equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two condi- tions: (1) This device may not cause harmful interference, and (2) this device must accept any interfer- ence received, including interference that may cause undesired operation. Long Range Systems5PRONTO Quick Guide WARRANTY Long Range Systems LLC warrants this product against any defects that are due to faulty material or workmanship for a one year period after the original date of consumer purchase. The warranty does not include damage to the product resulting from accident, misuse, improper electrical connection, or failure to charge the product within 30 days of receipt. Recharge- a ble pagers are required to stay on charge while not in use. Rechargeable pagers that are left off of charge for longer than 30 days will have a negative impact on the life of the batteries requiring them to be replaced thus voiding the war- ranty.If this product should become defective within the warranty period, we will repair or replace it with an equivalent prod- uct, free of charge. LRS will return your product via UPS ground shipping. All warranty claims must be initiated through our customer service department: Long Range Systems, LLC | 4550 Excel Pkwy, Suite 200 | Addison, TX 75001 | 800-437-4996 | www.pager.net No return or replacement can be received without prior authorization and the proper RMA Number posted to the outside of the shipping container. This warranty gives you specific legal rights and you may also have rights that vary from state to state. Copyright © 2012, Long Range Systems, LLC All Rights Reserved. This document contains proprietary information of Long Range Systems, LLC. (LRS) and is intended for use only by it’s em- ployees or customers. None of the material contained herein may be copied, reproduced, republished, downloaded, displayed, posted, or transmitted in any form or by any means, including but not limited to, electronic, mechanical, photocopying, record- ing, or otherwise without the prior written permission of LRS. Additional copies of this manual may be obtained by contacting LRS. Screen displays, keyboard layouts, hardware descriptions, or software are proprietary to LRS and are subject to copyright and other intellectual property rights of LRS and shall be treated in accordance with the previous paragraph. All attempts have been made to make the information in this document complete and accurate. LRS is not responsible for any direct or indirect damages or loss of business resulting from inaccuracies or omissions. Specifications and other information contained within this document are subject to change without notice. Long Range Systems, LLC reserves the right to make changes without further notice to any products herein. Long Range Sys- tems, LLC makes no warranty, representation or guarantee regarding the suitability of its products for any part…

Text truncated - open the document above for the full version.

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 2.0 2206 Ringwood Avenue San Jose, CA 95131 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (current) 1.0 1.0 Nov-14-2006 Revised wording (current) 1.0 2.0 Sept–25-2007 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 2.0 Long Range Systems Inc 2012.2.1 To: SIEMIC, INC. 2206 Ringwood Avenue, San Jose, CA 95131 USA Dear Sir/Madam, Re: Project and Product Certification Representative Authorization Letter We, __Long Range Systems Inc __hereby authorize SIEMIC, INC. to act as a Certification Body for certifying for the following project(s): PRONTO TX-PRONTO-6-PS We affirm that between SIEMIC and _ Long Range Systems Inc __, any difference in understanding, including test plan, measurement methods, applicable standards and relevant procedures and processes have been resolved prior to commencement of testing activities. Sincerely, Client’s signature: Client’s name / title: kenneth.Lovegreen/President Contact information / address: 4550 Excel Pkwy, Suite 200 Addison, TX 75001

SCS-F19: Confidentiality Request Letter Page 1 of 2 Rev 2.0 2206 Ringwood Avenue San Jose, CA 95131 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (current) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 1.0 2.0 August – 11 - 2008 SCS-F19: Confidentiality Request Letter Page 2 of 2 Rev 2.0 Long Range Systems Inc 2012.2.1 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Confidentiality Request regarding application for certification of FCC ID:M74PRONTO We hereby request confidential treatment of information accompanying this application as outlined below: - Schematics - Block Diagram - Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Client’s signature: Client’s name / title: Kenneth.Lovegreen/President Contact information / address: 4550 Excel Pkwy, Suite 200 Addison, TX 75001

FCC ID: M74PRONTO EST Technology Co.,Ltd Report No. ESTE-R1202001 Page 23 of 24 7. PHOTOGRAPHS OF THE EUT Figure 1 General Appearance of the EUT Figure 2 General Appearance of the EUT

Note: 1. White letters with black background. 2. The rear with adhesive. PRONTO Model No.:TX-PRONTO-6-PS Rating:DC 5V 300mA or AAA battery x 2 FCC ID:M74PRONTO Made in China www.pager.net Date:16/12/11 Page: 1 of 1 Approved by: Checked by: Title: TX-PRONTO-6-PS FCC CE CTLINK LABEL Drawn by: Neil Zhang Quantity: Finish: Model: Color: Material: Revision Description Date Drawn 1 PRONTO Black 80G Art Paper Scale: 4:1 PN: 2917862400 DN:M86244710 13 Dec.2011 The First Draft 01 CW Lau 02 Modify text 16 Dec.2011 Neil Zhang Neil Zhang unless otherwise specified dimensions are in mm, tolerance are ±0.1 / for angle ±0.5°, break sharp edegs,do not scale drawing. 03 Modify text 04 Jan.2012 Neil Zhang 04 Modify text 12 Jan.2012 Neil Zhang Neil Zhang 13 Jan.2012 05 Modify text

FCC ID: M74PRONTO EST Technology Co.,Ltd Report No. ESTE-R1202001 Page 23 of 24 7. PHOTOGRAPHS OF THE EUT Figure 1 General Appearance of the EUT Figure 2 General Appearance of the EUT Label Location

FCC ID: M74PRONTO EST Technology Co.,Ltd Report No. ESTE-R1202001 Page 24 of 24 Figure 3 General Appearance of the EUT Figure 4 General Appearance of the PCB

FCC ID: M74PRONTO EST Technology Co.,Ltd Report No. ESTE-R1202001 Page 1 of 23 APPLICATION FOR CERTIFICATION On Behalf of Long Range Systems, Inc PRONTO Model Number: TX-PRONTO-6-PS;TX-PRONTO-1-PS; TX-PRONTO-6; TX-PRONTO-1 FCC ID: M74PRONTO Prepared for : Long Range Syatem, Inc Address : 4550 Excel Pkwy, Suite 200 Addison, TX 75001 Prepared By : EST Technology Co., Ltd. Address : Santun(guantai Road), Houjie Town, DongGuan City,GuangDong, China Tel: +86-769-83081888 Fax: +86-769-83081878 Report Number : ESTE-R1202001 Date of Test : Jan.1~Jan.17, 2012 Date of Report : Feb.1, 2012 FCC ID: M74PRONTO EST Technology Co.,Ltd Report No. ESTE-R1202001 Page 2 of 23 TABLE OF CONTENTS Test Report Declaration Page 1. GENERAL PRODUCT INFORMATION ...................................................................................4 1.1. Product Function ................................................................................................................................... 4 1.2. Description of Device (EUT) ................................................................................................................ 4 1.3. Difference between Model Numbers .................................................................................................... 4 1.4. Independent Operation Modes .............................................................................................................. 4 2. TEST SITES....................................................................................................................................5 2.1. Description of Standards and Results.................................................................................................... 5 2.2. List of Test and Measurement Instruments ........................................................................................... 6 3. TEST SET-UP AND OPERATION MODES ..............................................................................7 3.1. Principle of Configuration Selection..................................................................................................... 7 3.2. Block Diagram of Test Set-up............................................................................................................... 7 3.3. Test Operation Mode and Test Software............................................................................................... 7 3.4. Special Accessories and Auxiliary Equipment .....................................................................................7 3.5. Countermeasures to Achieve EMC Compliance ................................................................................... 7 4. EMISSION TEST RESULTS........................................................................................................8 4.1. Conducted Emissions ............................................................................................................................ 8 4.2. Radiated emissions ................................................................................................................................ 9 4.3. 20dB Occupied Bandwidth ................................................................................................................. 16 4.4. Deactivation time ................................................................................................................................ 18 5. DUTY CYCLE CORRECTION FACTOR................................................................................20 6. PHOTOGRAPHS OF TEST SET-UP ........................................................................................21 7. PHOTOGRAPHS OF THE EUT ................................................................................................22 FCC ID: M74PRONTO EST Technology Co.,Ltd Report No. ESTE-R1202001 Page 3 of 23 EST Technology Co., Ltd. Applicant: Address: Long Range System, Inc 4550 Excel Pkwy, Suite 200 Addison, TX 75001 Manufacturer: Address: Seveco Global Limited 1 Jianxiang Street, Hanxishui, Chashan Town, Dongguan, Guangdong, China E.U.T: PRONTO Model Number: TX-PRONTO-6-PS;TX-PRONTO-1-PS; TX-PRONTO-6; TX-PRONTO-1 Note: The products different is that have 1 button or 6 button, with or without DC jack. But the PCB boards inside are identical. Power Supply: DC 3V or DC 5V For Supply Test Voltage: DC 3V Trade Name: ----- Operating Frequency: 467.75MHz Date of Receipt: Jan.1, 2012 Date of Test: Jan.1 ~Jan.17, 2012 Test Specification: FCC Part 15 Subpart C: July. 10, 2008 ANSI C63.4:2009 Test Result: The equipment under test was found to be compliance with the requirements of the standards applied. Issue Date: Feb. 1, 2012 Tested by: Reviewed by: Approved by: Ada / Assistant Tony / Engineer Iceman Hu / Manager Other Aspects: None. Abbreviations: OK/P=passed fail/F=failed n.a/N=not applicable E.U.T=equipment under tested This test report is based on a single evaluation of one sample of above mentioned products ,It is not permitted to be duplicated in extracts without written approval of EST Technology Co., Ltd. FCC ID: M74PRONTO EST Technology Co.,Ltd Report No. ESTE-R1202001 Page 4 of 23 1. GENERAL PRODUCT INFORMATION 1.1. Product Function The EUT is used to transmit control command only. The operation frequency is 315MHz. Press the button on remote transmitter. Please refer to the user’s manual for the details. 1.2. Description of Device (EUT) E.U.T. : PRONTO Model No. : TX-PRONTO-6-PS Operating Frequency : 467.75 MHz Number of Channels : 1 Channels Type of Modulation : FSK Antenna and Gain :Loop antenna, 0 dBi Gain. System Input Voltage : Nominal Voltage: DC 3V(Battery) Temperature Range(Operating) : -0 ~+ 55°C 1.3. Difference between Model Numbers None 1.4. Independent Operation Modes The basic operation modes are: TX mode FCC ID: M74PRONTO EST Technology Co.,Ltd Report No. ESTE-R1202001 Page 5 of 23 2. TEST SITES 2.1. Description of Standards and Results The EUT have been tested according to the applicable standards as ref…

Text truncated - open the document above for the full version.

FCC ID: M74PRONTO EST Technology Co.,Ltd Report No. ESTE-R1202001 Page 22 of 24 6. PHOTOGRAPHS OF TEST SET-UP Figure 1 Set-up for radiated measurements (30MHz to 1000MHz) Figure 2 Set-up for radiated measurements (1000MHz to 5000MHz)
