ARK-3384 Wireless Enabled, Audio and Three USB Port Fanless Embedded Box Computer User Manual ARK-3384 User Manualii Copyright The documentation and the software included with this product are copy- righted 2006 by Advantech Co., Ltd. All rights are reserved. Advantech Co., Ltd. reserves the right to make improvements in the products described in this manual at any time without notice. No part of this man- ual may be reproduced, copied, translated or transmitted in any form or by any means without the prior written permission of Advantech Co., Ltd. Information provided in this manual is intended to be accurate and reli- able. However, Advantech Co., Ltd. assumes no responsibility for its use, nor for any infringements of the rights of third parties, which may result from its use. Acknowledgements Award is a trademark of Award Software International, Inc. IBM, PC/AT, PS/2 and VGA are trademarks of International Business Machines Corporation. Intel and Pentium are trademarks of Intel Corporation. Microsoft Windows and MS-DOS are registered trademarks of Microsoft Corp. RTL is a trademark of Realtek Semi-Conductor Co., Ltd. All other product names or trademarks are properties of their respective owners. For more information on this and other Advantech products, please visit our websites at: http://www.advantech.com http://www.advantech.com.tw/products/ sub_category.asp?category_id=1-23A2QN&BU=ACG For technical support and service, please visit our support website at: http://support.advantech.com This manual is for the ARK-3384-1S0A2E, and ARK-3384-1S4A2E. Part No. 2006338400Edition 1 Printed in TaiwanApril 2007 iii Product Warranty (2 years) Advantech warrants to you, the original purchaser, that each of its prod- ucts will be free from defects in materials and workmanship for two years from the date of purchase. This warranty does not apply to any products which have been repaired or altered by persons other than repair personnel authorized by Advantech, or which have been subject to misuse, abuse, accident or improper instal- lation. Advantech assumes no liability under the terms of this warranty as a consequence of such events. Because of Advantechís high quality-control standards and rigorous test- ing, most of our customers never need to use our repair service. If an Advantech product is defective, it will be repaired or replaced at no charge during the warranty period. For out-of-warranty repairs, you will be billed according to the cost of replacement materials, service time and freight. Please consult your dealer for more details. If you think you have a defective product, follow these steps: 1.Collect all the information about the problem encountered. (For example, CPU speed, Advantech products used, other hardware and software used, etc.) Note anything abnormal and list any onscreen messages you get when the problem occurs. 2.Call your dealer and describe the problem. Please have your man- ual, product, and any helpful information readily available. 3.If your product is diagnosed as defective, obtain an RMA (return merchandize authorization) number from your dealer. This allows us to process your return more quickly. 4.Carefully pack the defective product, a fully-completed Repair and Replacement Order Card and a photocopy proof of purchase date (such as your sales receipt) in a shippable container. A product returned without proof of the purchase date is not eligible for war- ranty service. 5.Write the RMA number visibly on the outside of the package and ship it prepaid to your dealer. ARK-3384 User Manualiv Declaration of Conformity CE This product has passed the CE test for environmental specifications when shielded cables are used for external wiring. We recommend the use of shielded cables. This kind of cable is available from Advantech. Please contact your local supplier for ordering information. FCC Class A Note: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environ- ment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Opera- tion of this equipment in a residential area is likely to cause harmful inter- ference in which case the user will be required to correct the interference at his own expense. Technical Support and Assistance 1.Visit the Advantech web site at www.advantech.com/support where you can find the latest information about the product. 2.Contact your distributor, sales representative, or Advantech's cus- tomer service center for technical support if you need additional assistance. Please have the following information ready before you call: ñ Product name and serial number ñ Description of your peripheral attachments ñ Description of your software (operating system, version, appli- cation software, etc.) ñ A complete description of the problem ñ The exact wording of any error messages v Document Feedback To assist us in making improvements to this manual, we would welcome comments and constructive criticism. Please send all such - in writing to: [email protected] Packing List ARK-3384 Series Model There are two sub-models in ARK-3384 series listed below: Table 1.1 ARK-3384 Model List Before setting up the system, check that the items listed below are included and in good condition. If any item does not accord with the table, please contact your dealer immediately. Packing list ï1 x ARK-3384 Unit ï1 x DIN-Rail Mounting Kit ï1 x PS2 Keyboard/Mouse Cable (P/N: 1700060202) ï1 x Driver and Utility CD (P/N: 2066338400) ï1 x Flat Cable Supports RS-485/RS-422 Mode for COM2 Serial Port (P/N: 1700001967) ï1 x 2-P Phoenix to DC-Jack Power Cable (P/N: 1700001394) ï1 x 2.4GHz External Antenna (P/N: …

Text truncated - open the document above for the full version.

39Chapter 4 4.5.15 On-Chip Frame Buffer Size The default setting is 32MB. The options available include 1MB, 4MB, 8MB and 16MB. 4.5.16 Boot Display The default setting is VBIOS Default to allow system to detect the con- nected display device automatically. The options available include VBIOS-Default, CRT, LVDS, CRT+LVDS. Figure 4.5: Boot Display 4.5.17 Panel Scaling The default setting is Auto. The options available include On and Off. 4.5.18 Panel Type These fields allow you to select the resolution of LCD Panel type. The resolution values for these ports are: 640 x 480 800 x 600 1024 x 768 1280 x 1024 1600 x 1200 The default setting is 1280x1024 ARK-3384 User Manual40 4.6 Integrated Peripherals This section sets configurations for your hard disk and other integrated peripherals. The first screen shows three main items for user to select. Once an item selected, a submenu appears, as below. Figure 4.6: Integrated Peripherals 4.6.1IDE Cable Detect Some UDMA cables use a hole in the ribbon cable as a cable detect mechanism to determine if a UDMA IDE or standard IDE cable is installed. The default setting is ìEnabledî. 4.6.2On Chip IDE Device Move the cursor to this field and press <Enter>. The following screen will appear. 41Chapter 4 Figure 4.7: OnChip IDE Device 4.6.2.1 On-Chip Primary PCI IDE and On-Chip Secondary PCI IDE These fields allow you to enable or disable the primary and secondary IDE controller. The default is Enabled. Select Disabled if you want to add a different hard drive controller. 4.6.2.2 IDE Primary Master/Slave PIO and IDE Secondary Mas- ter PIO PIO means Programmed Input/Output. Rather than have the BIOS issue a series of commands to affect a transfer to or from the disk drive, PIO allows the BIOS to tell the controller what it wants and then lets the con- troller and the CPU perform the complete task by itself. Your system sup- ports five modes, 0 (default) to 4, which primarily differ in timing. When Auto is selected, the BIOS will select the best available mode after check- ing your drive. Auto: The BIOS will automatically set the system according to your hard disk driveís timing. Mode 0-4 You can select a mode that matches your hard disk. Mode 0-4:You can select a mode that matches your hard disk driveís tim- ing. Caution Do not use the wrong setting or you will have drive errors. ARK-3384 User Manual42 4.6.2.3 IDE Primary Master/Slave UDMA and IDE Secondary Master UDMA These fields allow you to set the Ultra DMA in use. When Auto is selected, the BIOS will select the best available option after checking your hard drive or CD-ROM. Auto: The BIOS will automatically detect the settings for you. Disabled:The BIOS will not detect these categories. 4.6.2.4 On-Chip IDE HDD Block Mode Enabled: The IDE HDD uses the block mode. The system BIOS will check the hard disk drive for the maximum block size the system can transfer. The block size will depend on the type of hard disk drive. Disabled: The IDE HDD uses the standard mode. 4.6.3Onboard Device Move the cursor to this field and press <Enter>. The following screen will appear. Figure 4.8: On Board Device 4.6.3.1 LAN Controller (82551 Only) This field is used to enable or disable the Intel 82551 LAN controller. 43Chapter 4 4.6.3.2 USB Controller Select Enabled if your system contains a Universal Serial Bus (USB) controller and you have USB peripherals. The choices: Enabled, Dis- abled. 4.6.3.3 USB 2.0 Controller If you are using USB 2.0, this field must be set to Enabled. 4.6.3.4 USB Keyboard Support Select Enabled if user plan to use an USB keyboard under DOS. The choices: Enabled, Disable. 4.6.3.5 AC97 Audio Select Disable if you do not want to use AC-97 audio. Option are Auto, Disable. 4.6.3.6 Init Display First This item allows you to choose which one to activate first, PCI Slot or on- chip VGA. The choices: PCI Slot, Onboard/AGP. 4.6.4Super IO Device Move the cursor to this field and press <Enter>. The following screen will appear. Figure 4.9: Super IO Device ARK-3384 User Manual44 The screen shown above, which list all the fields available in the Super IO Device submenu for ease of reference in this manual. In the actual CMOS setup, you have to use the scroll bar to view the fields. The settings on the screen are for reference only. Your version may not be identical to this one. 4.6.4.1 Onboard FDC Controller When enabled, this field allows you to connect your floppy disk drives to the onboard floppy disk drive connector instead of a separate controller card. If you want to use a different controller card to connect the floppy disk drives, set this field to Disabled. Note: ARK-3384 series embedded box computer does not support interface connection. 4.6.4.2 Onboard Serial Port 1 You can disable the COM1 serial port by selecting ìDisabledî, select the ìAutoî to allow the BIOS to arrange a suitable resource value for your COM1 device connection automatically, or you can select the resource of IRQ/IO Address combination for your COM 1 serial port device connec- tion. The setup value options are: Disabled 3F8/IRQ4 2FB/IRQ3 3E8/IRQ4 2E8/IRQ3 Auto The default setup value of COM1 (Onboard Serial Port 1) is ì3F8/IRQ4î. 4.6.4.3 Onboard Serial Port 2 You can disable the COM2 serial port by selecting ìDisabledî, select the ìAutoî to allow BIOS arrange a suitable resource value for your COM2 device connection automatically, or you can select the resource of IRQ/ IO Address combination for your COM 1 serial port device connection. The setup value options are: Disabled 3F8/IRQ4 2FB/IRQ3 3E8/IRQ4 2E8/IRQ3 Auto 45Chapter 4 The default setup value of COM2 (Onboard Serial Port 2) is ì2F8/IRQ3î. 4.6.5Watchdog Timer Select This field allows you to set the timing duration when any unexpected pro- gram cause a halt, the Watch-Dog Timer will automatically reset the CPU or generate an interrupt. The Watch-Dog is designed with hardware only and doesnít need any arithmetical functions of a real-time clock chip, this ensures the reliability …

Text truncated - open the document above for the full version.
