M82-TREK-510COMPUTER

TREK‐510 User manual 1 User Manual TREK‐510 In‐Vehicle Computing Box Smart Display User manual TREK‐510 User manual 2 Copyright The documentation and the software included with this product are copyrighted 2010 by Advantech Co., Ltd. All rights are reserved. Advantech Co., Ltd. reserves the right to make improvements in the products described in this manual at any time without notice. No part of this manual may be reproduced, copied, translated or transmitted in any form or by any means without the prior written permission of Advantech Co., Ltd. Information provided in this manual is intended to be accurate and reliable. How‐ ever, Advantech Co., Ltd. assumes no responsibility for its use, nor for any infringements of the rights of third parties, which may result from its use. Acknowledgements Intel and Atom are trademarks of Intel Corporation. Microsoft Windows and MS‐DOS are registered trademarks of Microsoft Corp. All other product names or trademarks are properties of their respective owners. Product Warranty (2 years) Advantech warrants to you, the original purchaser, that each of its products will be free from defects in materials and workmanship for two years from the date of purchase. This warranty does not apply to any products which have been repaired or altered by persons other than repair personnel authorized by Advantech, or which have been subject to misuse, abuse, accident or improper installation. Advantech assumes no liability under the terms of this warranty as a consequence of such events. Because of Advantech’s high quality‐control standards and rigorous testing, most of our customers never need to use our repair service. If an Advantech product is defective, it will be repaired or replaced at no charge during the warranty period. For out‐ of‐warranty repairs, you will be billed according to the cost of replacement materials, service time and freight. Please consult your dealer for more details. If you think you have a defective product, follow these steps: 1. Collect all the information about the problem encountered. (For example, CPU speed, Advantech products used, other hardware and software used, etc.) Note anything abnormal and list any onscreen messages you get when the problem occurs. 2. Call your dealer and describe the problem. Please have your manual, product, and any helpful information readily available. 3. If your product is diagnosed as defective, obtain an RMA (return merchandise authorization) number from your dealer. This allows us to process your return more quickly. 4. Carefully pack the defective product, a fully‐completed Repair and Replacement Order Card and a photocopy proof of purchase date (such as your sales receipt) in a shippable container. A product returned without proof of the purchase date is not eligible for warranty service. 5. Write the RMA number visibly on the outside of the package and ship it prepaid to your dealer. Part No. 2010051001 Edition 1 Printed in Ta i w a n Jan 2011 TREK‐510 User manual 3 Declaration of Conformity This product has passed the CE test for environmental specifications. Te s t conditions for passing included the equipment being operated within an industrial enclosure. In order to protect the product from being damaged by ESD (Electrostatic Discharge) and EMI leakage, we strongly recommend the use of CE‐compliant industrial enclosure products. FCC Class B Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: z Reorient or relocate the receiving antenna. z Increase the separation between the equipment and receiver. z Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. z Consult the dealer or an experienced radio/TV technician for help. Technical Support and Assistance 1. Visit the Advantech web site at www.advantech.com/support for the latest information about the product. 2. Contact the distributor, sales representative, or Advantech's customer service center for technical support if you need additional assistance. Please have the following information ready before you call: – Product name and serial number – Description of your peripheral attachments – Description of your software (operating system, version, application software, etc.) – A complete description of the problem – The exact wording of any error messages TREK‐510 User manual 4 Warnings, Cautions and Notes Warning! Warnings indicate conditions, which if not observed, can cause personal Caution! Cautions are included to help you avoid damaging hardware or losing data. e.g. Note! Notes provide optional additional information. Document Feedback To assist us in making improvements to this manual, we would welcome comments and constructive criticism. Send all such in writing to: [email protected] Packing List Before setting up, check that the items listed below are included, in good condition. If any item does not accord with the table, please contact your dealer immediately. z TREK‐510 series In‐Vehicle Computing Box z USB/Audio Cable clip z Warranty card z Power cord: DC power inlet cable (180 cm ‐ for TREK‐510 only) z “Drivers, Utilities and User Manual" CD‐ROM z End User License Agreement (WinCE model), please download driver and related document from www.advantech.c…

Text truncated - open the document above for the full version.

2011/7/24 Federal Communications Commission Authorization and Evaluation Division FCC IDM82-TREK-510 Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the applicant hereby requests confidential treatment of information applied this application as outlined below: 1. Block Diagram 2. Circuit Diagram 3. Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application Sincerely, Name/Title: Lily Huang / Supervisor Company Name: Advantech Co., Ltd. Address: No.1, Alley 20, Lane 26, Rueiguang Road, Neihu District, Taipei 114, Taiwan, R.O.C. TEL: 886-2-2792-7818#1412 FAX: 886-2-2794-7334 Email: [email protected]

Compliance Certification Services Inc. Report No.: T110422103 Date of Issue: July 8, 2011 A1 - 1 / 29 APPENDIX 1 - PHOTOGRAPHS OF EUT EXTERNAL PHOTOGRAPHS OF EUT Compliance Certification Services Inc. Report No.: T110422103 Date of Issue: July 8, 2011 A1 - 2

Compliance Certification Services Inc. Report No.: T110422103 Date of Issue: July 8, 2011 A1 - 3 INTERNAL PHOTOGRAPHS OF EUT Compliance Certification Services Inc. Report No.: T110422103 Date of Issue: July 8, 2011 A1 - 4 Compliance Certification Services Inc. Report No.: T110422103 Date of Issue: July 8, 2011 A1 - 5 Compliance Certification Services Inc. Report No.: T110422103 Date of Issue: July 8, 2011 A1 - 6 Compliance Certification Services Inc. Report No.: T110422103 Date of Issue: July 8, 2011 A1 - 7 Compliance Certification Services Inc. Report No.: T110422103 Date of Issue: July 8, 2011 A1 - 8 Compliance Certification Services Inc. Report No.: T110422103 Date of Issue: July 8, 2011 A1 - 9 Compliance Certification Services Inc. Report No.: T110422103 Date of Issue: July 8, 2011 A1 - 10 Compliance Certification Services Inc. Report No.: T110422103 Date of Issue: July 8, 2011 A1 - 11 Compliance Certification Services Inc. Report No.: T110422103 Date of Issue: July 8, 2011 A1 - 12 Compliance Certification Services Inc. Report No.: T110422103 Date of Issue: July 8, 2011 A1 - 13 Compliance Certification Services Inc. Report No.: T110422103 Date of Issue: July 8, 2011 A1 - 14 Compliance Certification Services Inc. Report No.: T110422103 Date of Issue: July 8, 2011 A1 - 15

Compliance Certification Services Inc. Report No.: T110422103 Date of Issue: July 8, 2011 A1 - 16 Compliance Certification Services Inc. Report No.: T110422103 Date of Issue: July 8, 2011 A1 - 17 Compliance Certification Services Inc. Report No.: T110422103 Date of Issue: July 8, 2011 A1 - 18 Compliance Certification Services Inc. Report No.: T110422103 Date of Issue: July 8, 2011 A1 - 19 Compliance Certification Services Inc. Report No.: T110422103 Date of Issue: July 8, 2011 A1 - 20 Compliance Certification Services Inc. Report No.: T110422103 Date of Issue: July 8, 2011 A1 - 21 Compliance Certification Services Inc. Report No.: T110422103 Date of Issue: July 8, 2011 A1 - 22 Compliance Certification Services Inc. Report No.: T110422103 Date of Issue: July 8, 2011 A1 - 23 Compliance Certification Services Inc. Report No.: T110422103 Date of Issue: July 8, 2011 A1 - 24 Compliance Certification Services Inc. Report No.: T110422103 Date of Issue: July 8, 2011 A1 - 25 Compliance Certification Services Inc. Report No.: T110422103 Date of Issue: July 8, 2011 A1 - 26 Compliance Certification Services Inc. Report No.: T110422103 Date of Issue: July 8, 2011 A1 - 27 Compliance Certification Services Inc. Report No.: T110422103 Date of Issue: July 8, 2011 A1 - 28 Compliance Certification Services Inc. Report No.: T110422103 Date of Issue: July 8, 2011 A1 - 29

豪 岑 電 子 金 屬 股 份 有 限 公 司 HOW TSEN INTL. ELECTRONICS METAL CO., LTD. P. T H O W S A N I N D O I N D U S T R Y ( I N D O N E S I A ) 桃園縣 327 新屋鄉中山東路 2 段 130 巷 12 號 TAIWAN : NO.12 LANE 130. SEC, 2, CHUNG-SAN EAST RD., SHIN WU HSIANG TAOYUAN HSIEN, TAIWAN, R.O.C TEL : 886-3-4777517 hunting FAX : 886-3-4777520 INDONESIA : JL PANGKALAN 1-B BANTAR GEBANG, BEKASI 17310 INDONESIA TEL : 62-21-8250470 hunting FAX :62-21-8250473 SPECIFICATION FOR APPROVAL Parts Name : 2G/3G Antenna Type No : C-911 Rev. : E Customer P/N : 1750006083 Date : Sep. 27 th ,2011 CUSTOMER APPROVAL & COMMENT FULL NAME POSITION SIGNATURE COMPANY STAMP COMMENT DATE : RECOGNIZED ENGINEERING QC CHECK Sep. 27 th , 2011 HOW TSEN Intl. ELECTRONICS METAL CO., LTD. ANTENNA SPECIFICATIONS FOR APPROVAL 1. General Description 1.1 Type No : C-911 1.2 Customer P/N : 1750006083 2. A DESCRIPTION & APPLICATION This antenna assembly is designed for use in portable。 Communications equipment over a temperature range。 Of -20°C to +70°C in an indoor / outdoor environment。 3. Structure Dimensions and material are be in conformity with the requirement of an approved drawing number。 4. Surface Appearance Surface condition should not have scratch，pin hole，blistering (If necessary take sample for consideration) 5. ENVIRONMENTAL CHARACTERISTICS 5.1 Operating temperature range -20°C to +65°C。 5.2 Humidity range : 10 % RH to 80 % RH。 6. Electrical Characteristics 6.1 Testing Equipment : ADVANTEST R3767CG Network Analyzer 6.2 Frequency Band : GSM850/GSM900 / DCS1800 / PCS1900 / WCDMA2100 MHz 6.3 Frequency Marker : 880 / 960 / 1710 / 1880 / 1990 / 2170 MHz 6.4 Return Loss : ≦-10.0 dB Maximum 6.5 V.S.W.R : 3.0:1.0 or less 6.6 Connector : SMA Male 6.7 Impedance : 50Ω Nominal Value 6.8 Radiation Pattern : Near omni-directional in the horizontal plane 6.9 Admitted Power : 2W 7. Mechanical Capability 7.1 Qualification testing，all product shall be able to withstand the following testing。 7.2 Physical dimensions identified within this specification。 7.3 Pull Test : Tube has the capability of load 3 kgf-cm in a vertical position within30 seconds。 7.4 Torque Test : 3 kgf-cm no damage happened。 7.5 Testing Conditions 7.5.1 Precondition at -20°C for 1 hour then expose to +80°C taking final measurements for 120 hours。 7.5.2 90%~95% relative humidity for 120 hours, finally allow to dry at room ambient for 4 hour。 8. Inspection Standard 8.1：For Dimension to use the special inspection level of S-4，AQL 1.0。 8.2：For Appearance to use MIL-STD-105DII AQL1.0。 8.3：For Mechanical Capability : Per lot Sampling, n=5，Ac 0，Re 1。 8.4：For Environmental test : Per lot Sampling n=3，Ac 0，Re 1。 9. Packing Style According to the specified packing method。 10. Others Any changes in this specification should be agreed by both parties。 2G/3G Antenna For : GSM850 / GSM900 / DCS1800 / PCS1900 / WCDMA2100 MHz Type No. : C-911 Electrical Specification Testing Equipment ADVANTEST R3767CG Network Analyzer Frequency Range GSM850 / GSM900 / DCS1800 / GSM1900 / WCDMA2100 MHz Frequency Marker 850/880/960/1710/1880 / 1990/2170 MHz Return Loss ≦-10.0 dB Maximum V.S.W.R 2.0:1.0 or less Connector SMA Male Impedance 50Ω Nominal Value Radiation Pattern Near Omni-directional in the horizontal plane Admitted Power 2W Environmental & Mechanical Characters Temperature -20°C to +65°C Weight G Dimensions Ø HOW TSEN Intl. Electronics Metal Co., Ltd. http://www.howtsen.com.tw HOW SANE industries Co., Ltd E-mail:[email protected] HOW TSEN INTL. ELECTRONICS METAL CO.,LTD. TEST REPORT 1.Model : C-911 2.Quantity : 5 Pcs 3.Date Of Testing : March.10,2011 4.Testing Item : Pull Test 5.Testing Equipment : B-016 (Push-Pull Scale Fb30K) 6.Testing Conditions : Antenna Must Withstand a (3.0 Kgf-Cm) Tensile Load Applied To Over Mold For 10 Seconds. No Part Of The Antenna May Be Pulled Out Of The Assembly Or From The Housing. 7.Testing Result : Sample 1 2 3 4 5 6 7 8 9 10 OK or NG ok ok ok ok ok - - - - - Approved : Tester : HOW TSEN INTL. ELECTRONICS METAL CO.,LTD. TEST REPORT 1.Model : C-911 2.Quantity : 5 Pcs 3.Date Of Testing : March.10,2011 4.Testing Item : Torque Test 5.Testing Equipment : B-001 (Mechanical Torque Meter 2-TM30) 6.Testing Conditions : (3.0 Kgf-Cm) No Damage Happened. 7.Testing Result : Sample 1 2 3 4 5 6 7 8 9 10 OK or NG ok ok ok ok ok - - - - - Approved : Tester : Testing Equipment Log Magnitude Smith Chart V.S.W.R 2D Pattern E plane 820MHz 835MHz 850MHz E1 Max Gain (dBi) -3.2 Max Gain@Angle (degree) 309 Min Gain (dBi) -13.12 Min Gain@Angle (degree) 227 Average Gain (dBi) -5.06 -3dB Angle L (degree) 11.95 -3db Angle R (degree) 265.6 HPB (degree) 106.35 FBR (dB) 1.8 E1 Max Gain (dBi) -3.28 Max Gain@Angle (degree) 316 Min Gain (dBi) -13.69 Min Gain@Angle (degree) 230 Average Gain (dBi) -4.96 -3dB Angle L (degree) 20.1 -3db Angle R (degree) 270 HPB (degree) 110.1 FBR (dB) 1.84 E1 Max Gain (dBi) -2.5 Max Gain@Angle (degree) 315 Min Gain (dBi) -17.48 Min Gain@Angle (degree) 225 Average Gain (dBi) -6.08 -3dB Angle L (degree) 14.1 -3db Angle R (degree) 267.15 HPB (degree) 106.95 FBR (dB) 1.4 2D Pattern E Plane 870MHz 880MHz 890MHz E1 Max Gain (dBi) -2.99 Max Gain@Angle (degree) 48 Min Gain (dBi) -29.59 Min Gain@Angle (degree) 99 Average Gain (dBi) -6.72 -3dB Angle L (degree) 71.1 -3db Angle R (degree) 23.4 HPB (degree) 47.7 FBR (dB) 1.49 E1 Max Gain (dBi) -3.28 Max Gain@Angle (degree) 51 Min Gain (dBi) -32.09 Min Gain@Angle (degree) 99 Average Gain (dBi) -6.96 -3dB Angle L (degree) 71.8 -3db Angle R (degree) 25.55 HPB (degree) 46.25 FBR (dB) 1.14 E1 Max Gain (dBi) -1.75 Max Gain@Angle (degree) 43 Min Gain (dBi) -36.95 Min Gain@Angle (degree) 94 Average Gain (dBi) -5.34 -3dB Angle L (degree) 65.23 -3db Angle R (degree) 20.95 HPB (degree) 44.28 FBR (dB) 0.93 2D Pattern E plane 950MHz 960MHz 970MHz E1 Max Gain (dBi) 1.69 Max Gain@Angle (degree) 50 Min Gain (dBi) -27.65 Min Gain@Angle (degree) 282 Average Gain (dBi) -2.51 -3dB Angle L (degree) 75.8 -3db Angle R (degree) 29.47 HPB (degree) 46.33 FBR (dB) 1.26 E1 Ma…

Text truncated - open the document above for the full version.

Create Material Cost Estimate with Quantity Structure1 03/05/2012 Quantit yResource Vehicle computin g system HSxPA STA2062,1,000 PCTWH1 TREK-510-HCEA0E Vehicle computin g system HSxPA STA2062,1,000 PCTWM3 TREK-510-HCEA0E A Cable SMA/MMCX 27CM C=G1,000 PCTWM3 1700004434 A Cable 2*6P-3.0/fuse 180cm TREK1,000 PCTWM3 1700018306 A cable 2*15P-1.25/2*15P-1.25 20cm for1,000 PCTWM3 1700018790 GPS antenna N12G0002 5.5V 22mA 40.5x381,000 PCTWM3 1750001380 Antenna L=10.9cm 50Ohm AN8921F-5701SM1,000 PCTWM3 1750005865 Antenna Cable R/P SMA (F) to MHF 1.32 21,000 PCTWM3 1750006009 Post F=M2.6x4L M=M2.6x6L B=4.7 H=4.8 Cu2,000 PCTWM3 1910001818 POST F=M3x5L M=M3x4L B=5 H=5 Cu NK6,000 PCTWM3 1910001820 1/4R/S D=6.9 H=1.95 + M3*5L ST Ni N ylok16,000 PCTWM3 1930001066 F/S D=3 H=0.5 + M=1.6 L=4 ST Ni NK2,000 PCTWM3 1930002101 Antenna dustproof cap (PVC), RYBBER-00022,000 PCTWM3 1990000608 plastic-ba g 170Wx240Hx0.04t mm PE-ZP CL1,000 PCTWM3 2162417000 PE BAG #2 85*60mm*0.04mm1,000 PCTWM3 2190508560 S/S D=5.0 H=1.2 + M3*5L ST BZn NK9,000 PCTWM3 19310305C0 POST F=#4-40*4L M=#4-40*7L B=4.7 H=4.98,000 PCTWM3 193A200001 Cover Top TREK-5111,000 PCTWM3 1960046824T000 Cover Panel TREK-5101,000 PCTWM3 1960046825N001 Cover Bottom TREK-5101,000 PCTWM3 1960046826N001 Door SD-Card TREK-5101,000 PCTWM3 1960050742N000 Cover Side TREK-5112,000 PCTWM3 1990018547T000 Clamp Cable SWPL-3 FOR TREK-5504,000 PCTWM3 1990018848T000 WIRE MOUNT FW-2MQ-NQW1,000 PCTWM3 1990018855N000 Cap for Hole-Clamp SWPL-34,000 PCTWM3 1990018886T000 Carton 425Lx245Wx185H (I)mm ADV A1,000 PCTWM3 2100000316N000 BOX Partition Pad 179(L)x39W)x40(L)mm 1,000 PCTWM3 2100012202N000 Spon ge Side TREK-5102,000 PCTWM3 2130011790N000 EPE Foam FOR TREK-5102,000 PCTWM3 2130011954T000 Cellular 1900MHZ Sierra Wireless MC87901,000 PCTWM3 968EMC0026 TREK-510 SYSTEM BOARD A101-31,000 PCTWM3 9698051002E TREK-510 SYSTEM BOARD A101-31,000 PCTWM4 9698051002E Shieldin g Bag ANTI-STATIC 190X240+60mm1,000 PCTWM4 2163102000 Carton 511Lx463Wx195H mm ADV A50 PCTWM4 2115247210T000 TREK-510 SYSTEM BOARD A101-31,000 PCTWM4 9598051002E EC 100uF 20% 50V 8x11.5mm EKY-500ELL1012,000 PCTWM4 1100003604 Coil 10.8uH 20% 12A DIP LG-110M56X011,000 PCTWM4 1211004140 LED B/G/R/G DIP 3PHI 8P MT-34 (BWC)GRG-4D1,000 PCTWM4 1304001567 PUSH SW ELTSA-63N-H DIP 4P 7.4x6.65x8.51,000 PCTWM4 1600002384 Phone Jack 9P 2ports 90D (F) DIP JA2333L1,000 PCTWM4 1652509210 TERMINAL BLOCK 1P 180D (F) C=M3 DIP JH-81,000 PCTWM4 1652601200 PIN HEADER 2*1P 180D (M)SQUARE 2.0mm DIP1,000 PCTWM4 1653002101 PIN HEADER 3x1P 2.0mm 180D (M) DIP 2000-1,000 PCTWM4 1653003101 PIN HEADER 5x1P 2.0mm 180D (M) DIP 1140-2,000 PCTWM4 1653005101 PIN HEADER 5x2P 2.0mm 180D (M) DIP 21N221,000 PCTWM4 1653005201 MINI JUMPER 2P 2.0mm 180D (F) DIP MJ-2B3,000 PCTWM4 1653302122 D-SUB Conn. 36P 90D (F) DIP 10236-55G3PC1,000 PCTWM4 1654004667 Antenna Conn. 5P 1.27mm 180D (F) DIP 25-1,000 PCTWM4 1654008805 D-SUB Conn. 18P 90D (M) DIP DM10151-H5312,000 PCTWM4 1654009494 (DEL)USB CONN. 4P 90D(F) DIP UB3112C-K11,000 PCTWM4 1654904900 WAFER BOX 2x5P 2.00mm 180D (M) DIP 24W211,000 PCTWM4 1655000197 WAFER BOX 6P 1.25mm 180D (M) DIP A1251-W1,000 PCTWM4 1655000205 WAFER BOX 2x6P 3.0mm 90D (F) DIP 04304511,000 PCTWM4 1655003423 BUZZER 9*4mm for SNMP-1000 BU-UGCM0905 Q1,000 PCTWM4 1750002860 BATTERY 3V/190 mAh W/CABLE BR2032L/DBE1,000 PCTWM4 1760000897 TREK-510 SYSTEM BOARD A101-31,000 PCTWM4 9498051002E CR 280K 1% 1/10W SMD 0603 RM06FTN28031,015 PCTWM4 1000000008 CR 20K 1% 1/16W SMD 0402 RM04FTN20023,045 PCTWM4 1000000177 CR 2.2K 1% 1/16W SMD 0402 RM04FTN22011,015 PCTWM4 1000000642 CR 71.5K 1% 1/10W SMD 0603 2322 704 6711,015 PCTWM4 1000000883 CR 4.99K 1% 1/16W SMD 0402 RM04FTN49912,030 PCTWM4 1000001949 CR 10 5% 1/2W SMD 2010 RM20JEN1002,030 PCTWM4 1000004492 CR 54.9K 1% 1/16W SMD 0402 RM04FTN54922,030 PCTWM4 1000004856 CR 12K 1% 1/16W SMD 0402 RM04FTN12022,030 PCTWM4 1000006038 CR 82.5K 1% 1/16W SMD 0402 RM04FTN82521,015 PCTWM4 1000006558 CR 0.05 1% 1W SMD 2512 LCR2512LF-01-CR02,010 PCTWM4 1053500579 CR 120 5% 1/8W SMD 0805 RM10JTN1211,015 PCTWM4 1059712000 CR 47K 5% 1/8W SMD 0805 232273061473L3,045 PCTWM4 1059747020 MLCC X7R 0.1uF 10% 100V 1206 222260111,015 PCTWM4 1100000040 SC 47uF 20% 16V SMD 7.3x4.3x1.9mm 16TQC2,010 PCTWM4 1100000127 MLCC X7R 4.7uF 10% 10V SMD 0805 C0805X417,255 PCTWM4 1100000184 MLCC X7R 1uF 10% 10V SMD 0603 C0603X10518,270 PCTWM4 1100000185 MCC X7R 4.7uF 10% 16V SMD 1206 C1206X472,030 PCTWM4 1100000186 MLCC X5R 4.7uF 10% 6.3V SMD 0603 GRM18811,165 PCTWM4 1100000213 MLCC X7R 0.1uF 10% 50V SMD 0603 C1608X79,135 PCTWM4 1100000214 MLCC X7R 4.7uF 10% 50V SMD 1812 C4532X76,030 PCTWM4 1100000216 MLCC X5R 22uF 20% 6.3V SMD 0805 C0805B21,015 PCTWM4 1100000254 MLCC X7R 1uF 10% 50V SMD 1206 C3216X7R13,045 PCTWM4 1100000300 SC 220uF 20% 6.3V SMD 7.3x4.3x1.8mm 6TP1,005 PCTWM4 1100000310 MLCC NPO 4.7pF 0.25pF 50V SMD 0402 22381,015 PCTWM4 1100000330 MLCC X7R 0.1uF 10% 16V SMD 0402 2238 7159,355 PCTWM4 1100000332 MLCC 1uF 10% 25V SMD 0603 GRM188R61E10 55,075 PCTWM4 1100000405 MLCC X7R 15nF 10% 16V SMD 0402 223878712,030 PCTWM4 1100000414 SC 180uF 20% 16V SMD 10.3x7.9mm 16SVP182,010 PCTWM4 1100000450 MLCC X7R 0.22uF 10% 16V SMD 0603 2238784,060 PCTWM4 1100003845 MLCC NPO 1000pF 5% 50V SMD 0603 2238 863,045 PCTWM4 1100003984 MLCC X5R 10uF 10% 10V SMD 0805 CC0805KK10,050 PCTWM4 1100004004 MLCC X5R 10uF 20% 6.3V SMD 0603 C1608X51,015 PCTWM4 1100004184 MLCC X7R 0.022uF 10% 16V SMD 04021,015 PCTWM4 1100004344 MLCC X7R 0.1uF 10% 1000V SMD 22201,005 PCTWM4 1100004664 MLCC X7R 0.22uF 10% 630V SMD 22204,020 PCTWM4 1100004684 MLCC X7R 3300pF 10% 50V SMD 0402 CC04023,045 PCTWM4 1100005727 MLCC X7R 0.22uF 10% 25V 0603 C0603X224K1,015 PCTWM4 1100005876 MLCC NPO 2.7PF 0.25pF 50V SMD 0603 MURA1,015 PCTWM4 1100006591 MLCC X7R 0.1uF 10% 16V SMD 0603 22387864,060 PCTWM4 1121510490 MLCC X7R 0.01uF 10% 16V SMD 0402 2238 723,345 PCTWM4 1121610790 MLCC NPO 10pF 5% 50V SMD 0402 2238 8696,090 PCTWM4 1124410091 MLCC NPO 100pF 5% 50V SMD 0402 223886916,090 PCTWM4 11…

Text truncated - open the document above for the full version.

Functional Description Tune-up procedure During manufacturing each phone is individually calibrated. Measurement is performed in a fully calibrated setup using an CMU 200 base station simulator (system tester). Measurement procedure is outlined below: Measurement Procedure: 1. Set the phone to operational voltage and on a predefined band class and channel. 2. The maximum output power is measured when the power control bit is set as all UP bits. 3. Output power is adjusted individually for no higher than maximum compliance power shown in the relevant test reports. The user has no possibility to change these settings. EUT Test Cable Power Meter Attenuator CMU200 Splitter

Compliance Certification Services Inc. FCC ID: M82-TREK-510 Report No.: T110422103-RP Note: This report shall not be reproduced except in full, without the written approval of Compliance Certification Services Inc. This document may be altered or revised by Compliance Certification Services Inc. personnel only, and shall be noted in the revision section of the document. Page 1 / 73 FCC 47 CFR PART 22 SUBPART H AND PART 24 SUBPART E TEST REPORT For Computer Trade Name: ADVANTECH Model: TREK-510XXXXXXXXXXXX(X = 0 ~ 9 or A ~ Z or blank) Issued to Advantech Co., Ltd. No.1, Alley 20, Lane 26, Rueiguang Road, Neihu District, Taipei 114, Taiwan, R.O.C. Issued by Compliance Certification Services Inc. No.11, Wu-Gong 6th Rd., Wugu Industrial Park, New Taipei City 248, Taiwan (R.O.C.) http://www.ccsrf.com [email protected] Issued Date: July 8, 2011 Compliance Certification Services Inc. FCC ID: M82-TREK-510 Report No.: T110422103-RP Page 2 Revision History Rev. Issue Date Revisions Effect Page Revised By 00 July 8, 2011 Initial Issue ALL Angel Cheng Compliance Certification Services Inc. FCC ID: M82-TREK-510 Report No.: T110422103-RP Page 3 TABLE OF CONTENTS 1. TEST RESULT CERTIFICATION............................................................................................. 4 2. EUT DESCRIPTION .................................................................................................................... 5 3. TEST METHODOLOGY ............................................................................................................. 6 3.1 EUT CONFIGURATION.............................................................................................................. 6 3.2 EUT EXERCISE......................................................................................................................... 6 3.3 GENERAL TEST PROCEDURES.................................................................................................. 6 3.4 DESCRIPTION OF TEST MODES................................................................................................. 7 4. INSTRUMENT CALIBRATION................................................................................................. 8 4.1 MEASURING INSTRUMENT CALIBRATION........................................................................... 8 4.2 MEASUREMENT EQUIPMENT USED .............................................................................. 9 4.3 MEASUREMENT UNCERTAINTY .................................................................................. 10 5. FACILITIES AND ACCREDITATIONS ................................................................................. 11 5.1 FACILITIES............................................................................................................................ 11 5.2 EQUIPMENT........................................................................................................................... 11 5.3 TABLE OF ACCREDITATIONS AND LISTINGS.......................................................................... 12 6. SETUP OF EQUIPMENT UNDER TEST ................................................................................ 13 6.1 SETUP CONFIGURATION OF EUT............................................................................................ 13 6.2 SUPPORT EQUIPMENT..................................................................................................... 13 7. FCC PART 22 & 24 REQUIREMENTS ................................................................................... 14 7.1 TRANSMIT POWER................................................................................................................. 14 7.2 ERP & EIRP MEASUREMENT .......................................................................................... 16 7.3 OCCUPIED BANDWIDTH MEASUREMENT ................................................................. 19 7.4 OUT OF BAND EMISSION AT ANTENNA TERMINALS .............................................. 27 7.5 FIELD STRENGTH OF SPURIOUS RADIATION MEASUREMENT ............................. 39 7.6 FREQUENCY STABILITY V.S. TEMPERATURE MEASUREMENT............................ 65 7.7 FREQUENCY STABILITY V.S. VOLTAGE MEASUREMENT ...................................... 68 APPENDIX I PHOTOGRAPHS OF TEST SETUP........................................................................ 71 APPENDIX 1 - PHOTOGRAPHS OF EUT Compliance Certification Services Inc. FCC ID: M82-TREK-510 Report No.: T110422103-RP Page 4 1. TEST RESULT CERTIFICATION Applicant: Advantech Co., Ltd. No.1, Alley 20, Lane 26, Rueiguang Road, Neihu District, Taipei 114, Taiwan, R.O.C. Equipment Under Test: Computer Tr a d e N a m e : ADVANTECH Model: TREK-510XXXXXXXXXXXX(X = 0 ~ 9 or A ~ Z or blank) Date of Test: June 14 ~ 22, 2011 APPLICABLE STANDARDS STANDARD TEST RESULT FCC 47 CFR Part 22 Subpart H & Part 24 Subpart E No non-compliance noted We hereby certify that: The above equipment was tested by Compliance Certification Services Inc. The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in TIA/EIA-603-C: 2004 and the energy emitted by the sample EUT tested as described in this report is in compliance with conducted and radiated emission limits of FCC Rule FCC PART 22 Subpart H and PART 24 Subpart E. The test results of this report relate only to the tested sample identified in this report. Approved by: Reviewed by: Jason Lin Gina Lo Section Manager Section Manager Compliance Certification Services Inc. Compliance Certification Services Inc. Compliance Certification Services Inc. FCC ID: M82-TREK-510 Report No.: T110422103-RP Page 5 2. EUT DESCRIPTION Product Computer Trade Name ADVANTECH Model Number TREK-510XXXXXXXXXXXX(X = 0 ~ 9 or A ~ Z or blank) Model Discrepancy All the specification and layout are identical except they come with different model numbers. The suffix of (X= a-z / 0-9 or blank) o…

Text truncated - open the document above for the full version.

Compliance Certification Services Inc. FCC ID: M82-TREK-510 Report No.: T110422103-RP Page 71 APPENDIX I PHOTOGRAPHS OF TEST SETUP CONDUCTED EMISSION SET UP PHOTO Compliance Certification Services Inc. FCC ID: M82-TREK-510 Report No.: T110422103-RP Page 72 RADIATED EMISSION SET UP PHOTOS Compliance Certification Services Inc. FCC ID: M82-TREK-510 Report No.: T110422103-RP Page 73 POWERLINE CONDUCTED EMISSIONS SETUP PHOTOS
