Vodafone Simply Sagem VS2 The book for your Vodafone Simplymobile phone A reassuringly brief guide to using your new mobile phone user_man_cover_VS2_UK 18/4/05 12:35 pm Page 1 The phone with common sense as a feature Vodafone Simply user_man_cover_VS2_UK 18/4/05 12:35 pm Page 2 2.How to insert the SIM card 4.How to charge the battery 6.So what do all these buttons do? 8.How to use the buttons on the phone 10.What does everything on my Home screen mean? 12.How do I add people to my Phone Book? 14.How to make and receive calls 16.How to send a text message 17.How to receive a text message 18.How do I set reminders? 19.How do I ask for help? 20.How do I adjust the clock and other settings? 21.What is my Phone Book Manager? 22.How do I use my Phone Book Manager? 24.How do I create new contacts and transfer them to my phone? 25.How are my contacts saved? 26.The importance of regularly ‘Backing Up’ 27.How do I restore my contacts? 28.How do I close my Phone Book Manager safely 29.What’s in the box 30.A closer look at the detail Contents user_manual_Black_UK 18/4/05 12:45 pm Page 1 You wanted a mobile phone that’s sophisticated yet easy to use and here it is in your hands! Naturally you’re eager to start using it, but first you need to insert the SIM card. Page 2 How to insert the SIM card The SIM card lives under the battery. Here’s how to insert it: •Ensure that the phone is switched off and the charger is disconnected from the bottom of the phone. •Turn the phone over and push the lock button upwards. •Remove the back cover by lifting the bottom end first. •If the battery is already inside remove it. •Hold your SIM card with the cut corner oriented as shown and then slide it into the card holder face down. •Replace the battery first. •Replace the back cover clicking in the top edge then the lower end and push the catch downwards into the locked position. user_manual_Black_UK 18/4/05 12:45 pm Page 2 Page 3 Lock What is a SIM card? Every mobile phone has a SIM card. (Subscriber Identity Module). This is a microchip that holds your personal information such as your phone number, and the names and numbers of your friends and family. Your phone won’t work without it. If you already have contacts on your SIM card these can be transferred across in most cases. user_manual_Black_UK 18/4/05 12:45 pm Page 3 Your phone is powered by a rechargeable battery. This needs to be chargedfor at least 4 hoursbefore you can make your first call. Ready? Charge! Page 4 Charging the battery •Plug the charger into the mains and the phone. •The phone is now charging. The battery icon moves from left to right. •When the icon stops moving and the percentage of charge shows 100% the battery is fully charged. •Disconnect the charger. How to charge the battery user_manual_Black_UK 18/4/05 12:45 pm Page 4 Page 5 When you are at home, just sit the phone in the charging cradle and plug it into the mains. That way your phone will always be charged when you need it and you will always be able to find it. You can always check the battery icon to see how much power you have left. When it’s red you know it’s time to recharge. You will also see a message on the screen when you need to recharge it. Recharge for at least 15 minutes before making another call so your phone doesn’t cut out in the middle of a call! (Your battery has a standby time of up to 12 days or you can make calls of up to 4 hours before recharging again). Charging cradle user_manual_Black_UK 18/4/05 12:45 pm Page 5 • On/off –Turns the phone on and off, just press and hold down the button on the top. • Home –Returns you to the ‘Home Screen’, the original screen that you see when you switch on the phone. • Contacts –Opens your phone book where you keep your family and friends’ details. • Log –Where you can find all your messages in one place. Just press this button and you can access your voice and text messages, missed calls, and reminders. Page 6 At the top of the phone you’ll see three special buttons, each of which has a dedicated function. Basically this means less searching through menus. So what do all these buttons do? user_manual_Black_UK 18/4/05 12:45 pm Page 6 Home On/off Contacts Log Page 7 user_manual_Black_UK 18/4/05 12:45 pm Page 7 On the side of the phone you’ll see three more buttons: • Ringer Setting (right side) –Easily set the ringer to loud,normal, vibrate or silent. • Volume Key (left side) –While you are in a call you can use this button to adjust the volume. • Button Lock (right side) –Lock the keypad to avoid making accidental calls! Below the screen you’ll find the main function keys: • Hello –Answer incoming calls with this key. • Goodbye –Hang up with this key. When not in a call button may be pressed to return to previous screen. • Up/Down –To navigate through menus and phone book entries. • Menu Keys –Press these buttons to select the command written above them on the screen. Page 8 How to use the buttons on the phone user_manual_Black_UK 18/4/05 12:45 pm Page 8 Volume Up/down Menu key Hello Goodbye Button lock Menu key Ringer setting Page 9 user_manual_Black_UK 18/4/05 12:45 pm Page 9 On the ‘Home’ screenyou will see the following settings: Clock –Displays the time. Ringer Setting –Loud,normal, vibrate or silent as set by the button on the side of the phone. Battery Indicator –Shows the amount of power left. Network Signal –Shows the strength of your connection to the mobile phone network. Your Number –Handy when someone asks you for your phone number and you go, “It’s... oh, wait a minute, what is it again?” Page 10 What does everything on my Home screen mean? user_manual_Black_UK 18/4/05 12:45 pm Page 10 Page 11 Home user_manual_Black_UK 18/4/05 12:45 pm Page 11 •Press the ‘Contacts’button (the one with people on it). •Select‘ADD NEW CONTACT’. •Enter a name using the number keys and confirm by clicking ‘OK’. •Enter the contacts’ phone number. •Choose‘SAVE’. You can also save a number right after you’ve made or received a phone call,…
