M9H95H03R3Triple Band GSM/PCS Mobile Phone 900/1800/1900 MHz

Mobile Phones Division Tel. +33 1 40 70 88 44 - Fax +33 1 40 70 66 40 - www.sagem.com Le Ponant de Paris - 27, rue Leblanc - 75512 PARIS CEDEX 15 - FRANCE SAGEM SA - Société anonyme à directoire et conseil de surveillance capital : 36 405 229 € - 562 082 909 RCS PARIS SAGEM SA ENGLISH *251437828* 251437828-Couv-myX-7-LU-en.qxd 30/01/04 14:28 Page 1 You have just purchased a SAGEM phone, we congratulate you; it is recommended that you read this handbook carefully in order to use your phone efficiently and in the best conditions. Your phone can be used internationally in the various networks (GSM 900 MHz and DCS 1800 MHz or PCS 1900 MHz, depending on model) depending on the roaming arrangements with your operator. We remind you that this phone is approved to meet European standards. WARNING Depending on the model, network configuration and associated subscription cards, certain functions may not be available. Ensure that your SIM card is a 3 V SIM type that is compatible with your phone. Inserting an incompatible card will be indicated by a message when your phone is switched on. Contact your operator. Your phone is identified by its IMEI number. Write this number down, and do not keep it with your phone, because you may be asked for it in the event of your phone being stolen, in order to prevent it from being used, even with a different SIM card. In order to display the IMEI on your phone's screen, type: *#06#. SAGEM is a trademark of SAGEM SA. AT is a registered trademark of Hayes Microcomputer Products Inc. Hayes is a registered trademark of Hayes Microcomputer Products Inc. T9 is protected by one or more of the following US patents: 5,818,437, 5,953,541, 5,187,480, 5,945,928, 6,011,554 and other patents are being applied for worldwide. Java and all Java based trademarks and logos are trademarks or registered trademarks of Sun Microsystems, Inc. in the U.S. and other countries. The WAP navigator is the exclusive property of Openwave. For this reason, it is forbidden to modify, translate, disassemble or even decompile all or part of the software that makes up the navigator. © 2003 GAMELOFT - All rights reserved - GAMELOFT is a registered trademark of GAMELOFT S.A. - All rights reserved. Wellphone™ and SmartCom™ are registered trademarks owned by SmartCom SARL France. 251437828_myX-7_lu_2e-3ecouv_en.fm Page 1 Vendredi, 30. janvier 2004 9:55 09 Weight: 106 g Size: 110 x 46 x 22 mm Original battery: Lithium ion 1000 mAh Battery life calls/standby: up to 4 h 40 mn/310 h (see page 16 how to increase the efficiency of your myX-7) Multimedia objects supported: Audio formats: iMelody, Midi, wave Graphic formats: wbmp, bmp, png, gif, animated gif, jpeg, .3gp Size of memory available for messages: 100 SMS 300 Kb for MMS (inbox, outbox and drafts together; MMS depending on option) Size of memory available for the phonenook and the multimedia objects: 4 MB Maximum size of each message: SMS < 160 characters MMS < 100 Kb for outgoing, 100 Kb for incoming messages (depends on the phone configuration and on the operator reservations) Using temperature: from - 10°C to + 55°C 251437828_myX-7_lu_2e-3ecouv_en.fm Page 2 Vendredi, 30. janvier 2004 9:55 09 1 Conformance Document 251437828_myX-7_lu_en.book Page 1 Lundi, 2. février 2004 1:58 13 2 FCC Conformance Document FCC Part 24 Network NAPRD03.ver 2.9.1 HealthDraft IEEE Std 1528-200x Exposure to Radio Frequency Signals - Your wireless handheld portable phone is a low power radio transmitter and receiver. When it is ON, it receives and also sends out frequency (RF) signals. - In August, 1996, the Federal Communications Commissions (FCC) adopted RF exposure guidelines with safety levels for handheld wireless phones. Those guidelines are consistent with the safety standards previously set by both U.S. and international standards bodies: ANSI C95.1 (1992)* NCPR Report 86 (1986)* ICNIRP (1996)* (*) American National Standards Institute; National Council on Radiation Protection and Measurements; International Commission and Non-Ionizing Radiation Protection. - Those standards were based on comprehensive and periodic evaluations of the relevant scientific literature. For example, over 120 scientists, engineers, and physicians from universities, government health agencies, and industry reviewed the available body of research to develop the ANSI Standard (C95.1). - The design of your phone complies with the FCC guidelines (and those standards). - For body worn operation, this phone has been tested and meets FCC RF exposure guidelines when used with an accessory that contains no metal and that positions the handset a minimum of 1.5 cm from the body. Use of other accessories may not ensure compliance with FCC RF exposure guidelines. 251437828_myX-7_lu_en.book Page 2 Lundi, 2. février 2004 1:58 13 3 Menus Games WAP Applications Delete all ToDo Calculator Converter Alarm Timer Settings About Messages Compose Inbox Outbox Drafts Options Memory Local info. Call Voice Mail Camera Photo Camera Video Camera Multimedia Mes Videos Mes Pictures Mes Sounds Memory Organiser Calendar menu See month See week See today See date Phonebook Contacts menu Settings Sounds Display Camera Languages Calls Security Networks Others Short cuts Date/Time Connectivity Menu Hot-line 251437828_myX-7_lu_en.book Page 3 Lundi, 2. février 2004 1:58 13 4 Contents Page 3MENUS Page 9YOUR PHONE PACKAGE - ACCESSORIES Page 10DESCRIPTION Programmable keys and Short cut keys Strap attachment Page 12NAVIGATION PRINCIPLES Page 13INITIAL SCREEN Page 14ACTIVATING YOUR PHONE Information on the SIM card Installing the SIM card and the battery Page 16USING YOUR PHONE Don't obstruct the antenna with your fingers Increase the efficiency of your phone Charging the battery Page 18PHONEBOOK Using the phonebook Contacts menu Options from a contact saved Sending a vCard Receiving a vCard Page 25MESSAGES Compose SMS Compose MMS Receiving messages 251437828_myX-7_lu_en.book Page 4 Lundi, 2. février 2004 1:58 13 5 Contents In…
