MMA1001LWXAMOBILE CB TRANSCEIVER

www.midlandradio.com 1001LWX |CB 1001LWX |CB Radio with Weather Scan Radio with Weather Scan Technology Technology Owner’s Manual Owner’s Manual Model 1001LWX Owner’s Manual Page 2www.midlandradio.com T T able of Contents able of Contents Welcome to the World of Midland Electronics Major 1001LWX Features How to install your Midland mobile CB What’s in the Box Where to Locate your CB Transceiver Mechanical Mounting Power Wiring (negative ground only) Installation of Microphone Hanger Antenna: How to select, position install and tune the right one for you Antenna Installation Tuning your Antenna Factors affecting CB and Weather Scan Range Noise 1001LWX Front Panel Features and Operation Back Panel Features and Operation Transceiver Operation Technical Specifications Service Limited Warranty 2 3 3 3 4 4 4 5 5 5 6 6 6 6 7 8 8 9 10 11 The Citizens Band Radio Service is under the jurisdiction of the Federal Communications Commission (FCC). Any adjust- ments or alterations which would alter the performance of the transceiver’s original FCC certification, or which would change the frequency determining method, are strictly prohibited. Replacement or substitution of crystal, transistors, ICs, regulator diodes, or any other part of a unique nature, with parts other than those recommend by Midland, may cause violations of the technical regulations in Part 95 of the FCC Rules or in violation of cer- tification requirements in Part 2 of the rules. Model 1001LWX Owner’s Manual Page 3www.midlandradio.com Welcome to the World of Midland Electronics Welcome to the World of Midland Electronics Congratulations on your purchase of the Midland 1001LWX CB radio. In the years ahead, you can expect to find time and again why Midland holds the front running position among CB users. You will also find that American Original is not just a slogan, but the heading of a long list of hearable, seeable benefits. As your Midland CB experience unfolds and grows we hope you will remember that CB radios are only one kind of electronic excellence avail- able under the Midland name. The 40 channel 1001LWX CB radio represents the state of the art in high tech engineering. The first in the industry with Weather Scan technology, it is able to receive up to the minute National Weather broadcasts any where you go- keeping you up to date on severe weather events. The 1001LWX also includes all the important CB features- RF Gain, Automatic Noise Limiter and a Large Backlit LCD for easy night time viewing. Skillfully con- structed with the finest components, this radio is designed for reliable and trouble-free per- formance for years to come. Enjoy! Major 1001LWX Features Major 1001LWX Features • 40 CB Channels • 4 Watt Output Power • Large, Backlit LCD • Exclusive Weather Scan Technology • 4- Pin Front Panel Mic Connector • Squelch • PA Function • Automatic Noise Limiter (ANL) • RF Gain • Push to talk ergonomically designed microphone • Includes mounting bracket/hardware and fused DC power cord How to Install your Midland Mobile CB: How to Install your Midland Mobile CB: This transceiver may be installed in any 12-volt negative ground-system car or truck. Most current U.S. and foreign vehicles use a negative system, but some older models and some newer large trucks may have a positive ground. Check the requirements for your vehicle before you begin installation. Generally, you have a negative-ground system if the minus ( - ) battery terminal is connected to the motor block. Contact your dealer in the event you are unable to determine your vehicle’s polarity system. Model 1001LWX Owner’s Manual Page 4www.midlandradio.com 1. Easy removal mounting bracket system. 2. Microphone bracket system. 3. All main-unit and microphone mounting hardware needed for normal installation. 4. Plug-in microphone with coil cord. 5. FCC part 95, Subpart D. 6. Owner’s Manual. What’s in the Box: What’s in the Box: Where to Locate your CB Transceiver: Where to Locate your CB Transceiver: Your new Midland CB is designed to be installed under the dash or vertically on a console of your vehicle. Safety and convenience are the primary considerations in deciding exactly where to locate your radio. Caution:Be sure that the unit is located so that it does not interfere with the driver, supplemental restraint systems (air bags) or impair access to any controls. Connecting cables must be routed and secured in such a manner as not to interfere with the opera- tion of the brake, accelerator or other controls. Interference from either the unit or con- necting cables may contribute to the loss of control of the vehicle. Mechanical Mounting: Mechanical Mounting: Step 1: Heeding the caution, use the mounting bracket as a template for marking the loca- tion of screw holes under the dash. Use an awl, nail or other sharp pointed object to mark the hole locations. Step 2: Drill a 1/8” hole for each screw hole in the mounting bracket. Attach the bracket to the dash with the Phillips head sheet metal screws provided. Extreme care should be exercised when drilling into the dash to avoid damage to under-dash electronic ignition, cruise control, instrument and / or accessory wiring. Step 3: Position the main unit between the bracket arms in line with the retention knobs. Set the angle for optimum operating comfort and accessibility. Step 4: Tighten the retention knobs. Model 1001LWX Owner’s Manual Page 5www.midlandradio.com Power Wiring (negative ground only): Power Wiring (negative ground only): Step 1: If you have not determined whether your vehicle has a negative or positive ground, do so now. Then disconnect the negative lead from the battery to prevent short circuits that can occur during wiring. Do not connect this transceiver to posi- tive ground electrical systems. Step 2: With negative ground A. Connect the positive (RED WIRE) the one with in-line fuse holder to either the (a) fuse block, (b) cigarette lighter, or (c) directly to the positive post on your battery. Usually,…

Text truncated - open the document above for the full version.

5900 Parretta Drive ● KANSAS CITY, MISSOURI ● 64120 TELEPHONE: (816) 241-8500 ● FAX: (816) 241-5713 EMAIL: [email protected] WEBSITE: www.midlandradio.com Confidentiality Letter Date: _April 19, 2013__ Subject: Confidentiality Request for IC ID: 3690A-1001LWXA Pursuant to FCC 47 CRF 0.457(d) and 0.459 and IC RSP-100, Section 10, the applicant requests that a part of the subject FCC/IC application be held confidential. Type of Confidentiality Requested Exhibit Short Term Permanent Block Diagrams Short Term Permanent Schematics Short Term Permanent Operation Description/Theory of Operation Short Term Permanent External Photos Short Term Permanent Internal Photos Short Term Permanent User’s Manual Short Term Permanent Test Setup Photos Midland Radio Corporation ___ has spent substantial effort in developing this product and it is one of the first of its kind in industry. Having the subject information easily available to "competition" would negate the advantage they have achieved by developing this product. Not protecting the details of the design will result in financial hardship. Permanent Confidentiality: The applicant requests the exhibits listed above as permanently confidential be permanently withheld from public review due to materials that contain trade secrets and proprietary information not customarily released to the public. Short-Term Confidentiality: The applicant requests the exhibits selected above as short term confidential be withheld from public view for a period of ___180 ___ days from the date of the Grant of Equipment Authorization and prior to marketing. This is to avoid premature release of sensitive information prior to marketing or release of the product to the public. Applicant is also aware that they are responsible to notify TIMCO Engineering Inc. in the event information regarding the product or the product is made available to the public. TIMCO Engineering Inc will then release the documents listed above for public disclosure pursuant to FCC Public Notice DA 04-1705. Sincerely, By: ____________Project Manager__ Kim Free_________ (Signature/Tittle) (Print name)

日期 : 12/04/13 [16:39] MULTI-LEVEL PRODUCTION BOMS (WINKLER GP) 页面 : 1 Winkler Industrial Co., Ltd. （包括 工艺流程） GREEN Product 公司 : 301 制造物料 : G102+6100100+002 1001L-WX SI4707 MIDLAND REV:2 库存单位: pcs修订号 : 0 虚拟件 : 否 BOM 单位 : 1 层 位置 物料 说明 Reference (BOM Text) 长度 [mm ] No. of Unit 净数量 单位 废品 % 物料类型 虚拟件 1 10/ 1 G200+6101600+002 Bare Unit For 1001L-WX SI4707 0.00 0 1.0000 pcs 0 制造 否 .2 10/ 1 G200+6101300+002 MaIn PCB Assembly For 1001L-WX 0.00 0 1.0000 pcs 0 制造 否 ..3 10/ 1 G200+6101200+002 MaIn Inserted Assembly For 100 0.00 0 1.0000 pcs 0 制造 否 ...4 10/ 1 G200+6101100+002 MaIn SMT For 1001L-WX SI4707 M 0.00 0 1.0000 pcs 0 制造 否 ....5 20/ 1 G305+0GP214D+100 IC, GP214D TSSOP-16 "GAINTECH" U3 0.00 0 1.0000 pcs 0 采购 否 物料文本 : IC, GP214D TSSOP-16 "GAINTECH" GP ....5 30/ 1 G305+17AL36D+000 IC LD1117AL36 TN3-A-R TO-252"U U5 0.00 0 1.0000 pcs 0 采购 否 物料文本 : IC LD1117AL36 TN3-A-R TO-252"U TC" GP 0.4g/pcs ....5 40/ 1 G300Y0602711+023 Chip Res, 0805, 270 Ohm, 1/8W, R130 0.00 0 1.0000 pcs 0 采购 否 物料文本 : Chip Res, 0805, 270 Ohm, 1/8W, +/-5%, Tape pack "YAGEO" G P ....5 50/ 1 G300Y1400001+003 Chip Res,R0402,0 Ohm,1/16w,+/- R17 0.00 0 1.0000 pcs 0 采购 否 物料文本 : Chip Res,R0402,0 Ohm,1/16w,+/- 5%,Green Product ....5 60/ 1 G300Y1401091+003 Chip Res,0402 1 Ohm 1/16W +/-5 R78 0.00 0 1.0000 pcs 0 采购 否 物料文本 : Chip Res,0402 1 Ohm 1/16W +/-5% "YAGEO" GP....5 70/ 1 G300+1401001+003 Chip Res,0402 10 Ohm 1/16W +/- R120 0.00 0 1.0000 pcs 0 采购 否 物料文本 : Chip Res,0402 10 Ohm 1/16W +/-5% Tape Pack Green Prod uct ....5 80/ 1 G300+1401011+003 Chip Res,0402 100 Ohm 1/16W +/ R66,R69,R83,R25,R107,R203,R6 0.00 0 7.0000 pcs 0 采购 否 物料文本 : Chip Res,0402 100 Ohm 1/16W +/-5% Tape Pack Green Prod uct ....5 90/ 1 G300+1401021+003 Chip Res,0402 1K 1/16W +/-5% R14,R51,R52,R68,R134,R209 0.00 0 6.0000 pcs 0 采购 否 物料文本 : Chip Res,0402 1K1/16W +/-5% Tape Pack Green Product....5 100/ 1 G300Y1401821+003 Chip Res, 0402, 1.8K,1/16W,+/- R67 0.00 0 1.0000 pcs 0 采购 否 物料文本 : Chip Res, 0402, 1.8K,1/16W, +/-5% "YAGEO" GP....5 110/ 1 G300+1401521+003 Chip Res, 0402, 1.5K,1/16W,+/- R7,R34 0.00 0 2.0000 pcs 0 采购 否 物料文本 : Chip Res, 0402, 1.5K,1/16W, +/-5% Tape Pack GP....5 120/ 1 G300+1401031+003 Chip Res,0402 10K 1/16W +/-5% R33,R41,R61,R29,R62,R207,R606,R607 0.00 0 8.0000 pcs 0 采购 否 物料文本 : Chip Res,0402 10K1/16W +/-5% 日期 : 12/04/13 [16:39] MULTI-LEVEL PRODUCTION BOMS (WINKLER GP) 页面 : 2 Winkler Industrial Co., Ltd. （包括 工艺流程） GREEN Product 公司 : 301 制造物料 : G102+6100100+002 1001L-WX SI4707 MIDLAND REV:2 库存单位: pcs修订号 : 0 虚拟件 : 否 BOM 单位 : 0 层 位置 物料 说明 Reference (BOM Text) 长度 [mm ] No. of Unit 净数量 单位 废品 % 物料类型 虚拟件 Tape Pack Green Product....5 130/ 1 G300+1401231+003 Chip Res,0402 12K 1/16W +/-5% R211 0.00 0 1.0000 pcs 0 采购 否 物料文本 : Chip Res,0402 12K1/16W +/-5% Tape Pack Green Product....5 140/ 1 G300Y1401531+003 CHIP RES,R0402,15KOhm 1/16w,+/ R82,R36,R49,R218,R75 0.00 0 5.0000 pcs 0 采购 否 物料文本 : CHIP RES,R0402,15KOhm 1/16w, +/-5%,"YAGEO",GP(XHA002)....5 150/ 1 G300+1401041+003 Chip Res,0402 100K 1/16W +/-5% R133,R21 0.00 0 2.0000 pcs 0 采购 否 物料文本 : Chip Res,0402 100K1/16W +/-5% Tape Pack Green Product....5 160/ 1 G300Y1401541+003 Chip Res, 0402, 150K,1/16W,+/- R59,R205,R603,R105 0.00 0 4.0000 pcs 0 采购 否 物料文本 : Chip Res, 0402, 150K,1/16W, +/-5% Tape Pack "YAGEO" GP....5 170/ 1 G300Y1402201+003 CHIP RES,R0402,22 Ohm 1/16w,+/ R22,R77 0.00 0 2.0000 pcs 0 采购 否 物料文本 : CHIP RES,R0402,22 Ohm 1/16w, +/-5%,"YAGEO",GP(XHA002)....5 180/ 1 G300Y1402211+003 CHIP RES,R0402,220 Ohm 1/16w,+ R109,R8,R212 0.00 0 3.0000 pcs 0 采购 否 物料文本 : CHIP RES,R0402,220 Ohm 1/16w, +/-5%,"YAGEO",GP(XHA002)....5 190/ 1 G300+1402221+003 Chip Res,0402 2.2K 1/16W +/-5% R4,R32,R84 0.00 0 3.0000 pcs 0 采购 否 物料文本 : Chip Res,0402 2.2K1/16W +/-5% Tape Pack Green Product....5 200/ 2 G300+1402721+003 Chip Res,0402 2.7K 1/16W +/-5% R45,R605,R206 0.00 0 3.0000 pcs 0 采购 否 物料文本 : Chip Res,0402 2.7K1/16W +/-5% Tape Pack Green Product....5 210/ 2 G300+1402231+003 Chip Res,0402 22K 1/16W +/-5% R39,R43,R967,R213,R608 0.00 0 5.0000 pcs 0 采购 否 物料文本 : Chip Res,0402 22K1/16W +/-5% Tape Pack Green Product....5 220/ 1 G300Y1402731+003 Chip Res, 0402, 27K,1/16W,+/-5 R2,R12 0.00 0 2.0000 pcs 0 采购 否 物料文本 : Chip Res, 0402, 27K,1/16W, +/-5% Tape Pack "YAGEO" GP....5 230/ 1 G300+1402241+003 Chip Res,0402 220K 1/16W +/-5% R604 0.00 0 1.0000 pcs 0 采购 否 物料文本 : Chip Res,0402 220K1/16W +/-5% 日期 : 12/04/13 [16:39] MULTI-LEVEL PRODUCTION BOMS (WINKLER GP) 页面 : 3 Winkler Industrial Co., Ltd. （包括 工艺流程） GREEN Product 公司 : 301 制造物料 : G102+6100100+002 1001L-WX SI4707 MIDLAND REV:2 库存单位: pcs修订号 : 0 虚拟件 : 否 BOM 单位 : 0 层 位置 物料 说明 Reference (BOM Text) 长度 [mm ] No. of Unit 净数量 单位 废品 % 物料类型 虚拟件 Tape Pack Green Product....5 240/ 1 G300Y1403941+003 Chip Res, 0402,390K,1/16W,+/-5 R13 0.00 0 1.0000 pcs 0 采购 否 物料文本 : Chip Res, 0402,390K,1/16W, +/-5%,Tape pack "YAGEO" GP....5 250/ 2 G300Y1403311+003 CHIP RES,R0402,330 Ohm 1/16w,+ R26,R310 0.00 0 2.0000 pcs 0 采购 否 物料文本 : CHIP RES,R0402,330 Ohm 1/16w, +/-5%,"YAGEO",GP(XHA002)....5 260/ 2 G300+1403911+003 Chip Res,0402 390 Ohm 1/16W +/ R60 0.00 0 1.0000 pcs 0 采购 否 物料文本 : Chip Res,0402 390 Ohm 1/16W +/-5% Tape Pack Green Prod uct ....5 270/ 1 G300+1403321+003 Chip Res,0402 3.3K 1/16W +/-5% R38,R10,R210 0.00 0 3.0000 pcs 0 采购 否 物料文本 : Chip Res,0402 3.3K1/16W +/-5% Tape Pack Green Product....5 280/ 1 G300Y1403921+003 Chip Res, 0402, 3.9K,1/16W,+/- R106,R202 0.00 0 2.0000 pcs 0 采购 否 物料文本 : Chip Res, 0402, 3.9K,1/16W, +/-5% Tape Pack "YAGEO" GP....5 290/ 1 G300+1403331+003 Chip Res,0402 33K 1/16W +/-5% R108,R217 0.00 0 2.0000 pcs 0 采购 否 物料文本 : Chip Res,0402 33K1/16W +/-5% Tape Pack Green Product....5 300/ 1 G300+1403931+003 Chip Res,0402 39K 1/16W +/-5% R42 0.00 0 1.0000 pcs 0 采购 否 物料文本 : Chip Res,0402 39K1/16W +/-5% Tape Pack Green Product....5 310/ 1 G300Y1404791+003 Chip Res, 0402,4.7 Ohm,1/16W,+ R70 0.00 0 1.0000 pcs 0 采购 否 物料文本 : Chip Res, 0402,4.7 Ohm,1/16W, +/-5% Tape Pack "YAGEO" GP....5 320/ 2 G300Y1404701+003 CHIP RES,R0402,47 Ohm 1/16w,+/ R9,R53,R601 0.00 0 3.0000 pcs 0 采购 否 物料文本 : CHIP RES,R0402,47 Ohm 1/16w,…

Text truncated - open the document above for the full version.

1 1001LWX（SI4707）Tuning Procedures REV:0 DATE:28-Mar-13 1-1 Testing Equipment Equipment Grade and Range DC power supply Output voltage : 13.8 V DC Current capacity : 3 A or more Digital Multimeter Frequency counter Frequency range : 0.1–300 MHz Frequency accuracy : ±1 ppm or better Sensitivity : 100 mV or better RF COMMUNICATIONS TEST SET(8920A) (RF Tester) Frequency range : 0.4–1000 MHz Oscilloscope Frequency range : DC–20 MHz Measuring range : 0.01–20V External speaker Input impedance : 8Ω Capacity : 5 W or more 2 1-2 VCO Tuning Tuning Items Setting Test Standard Tuning Location Testing Point Location Tuning Point Loop lock voltage  Channel：CH 19  RX Main board Use multi-meter to check the voltage of VCO on main board. 3.0-3.6V Main board L8 The reference oscillator frequency  Channel：CH 19  TX Main board Connect the frequency output to frequency counter 27.185MHZ +/-200Hz Main board VC1 3 1-3 TX Tuning Tuning Items Setting Test Standard Tuning Location Testing Point Location Tuning Point Carrier Output Power  Channel：CH 19  TX Main board Connect RF tester to antenna input port 3.8~4W Main board L801 The Maximum Modulation Frequency Offset  Channel: ：CH 19  The audio signal is connected to the hand-held microphone. Audio output level: 800mV Audio Output RFrequency: 1000Hz.  TX Main board Connect RF tester to antenna port 90%~93% Main board RV2 80% MOD Distortion  Channel： CH 19  The audio signal is connected to the hand-held microphone. Audio output level: 15mV  TX Main board Connect RF tester to antenna port <8% Main board L5 L6 Signal Meter  Channel： CH 19  TX LCD Connect RF tester to antenna port Signal meter at full indication. Main board RV4 4 1-4 RX Tuning Tuning Items Setting Test Standard Tuning Location Testing Point Location Tuning Point Sensitivity  Channel: CH 19  Connect antenna port to output of tester  RX Main board External speaker signal is connected to the 8 ohm dummy load and then connected to the audio input of RF tester. 10dB SINAD receiving sensitivity not less than 1uV Distortion is less than 5%. Main board L1 T3 T4 T5 L3  Channel: CH 19  Connect antenna port to output of tester  RX Main board External speaker signal is connected to the 8 ohm dummy load and then connected to the audio input of RF tester. SQ Tight， 60dBuV open Main board RV1 Signal Meter  Channel ： CH 19  RX LCD Connect RF tester to antenna port 40dBuV at S9 Main board RV3

FCC PART 95 SUBPART D AND IC RSS-236 (issue 1) TEST REPORT FOR CB TRANSCEIVERS APPLICANT MIDLAND RADIO CORPORATION 5900 PARRETTA DRIVE KANSAS CITY, MISSOURI 64120 USA FCC ID MMA1001LWXA IC 3690A-1001LWXA MODEL NUMBER 1001LWX PRODUCT DESCRIPTION MOBILE CB TRANSCEIVER DATE SAMPLE RECEIVED 3/27/2013 DATE TESTED 4/11/2013 TESTED BY John A. Day APPROVED BY John A. Day TIMCO REPORT NO. 535AUT13TestReport.doc TEST RESULTS PASS FAIL THE ATTACHED REPORT SHALL NOT BE REPRODUCED EXCEPT IN FULL WITHOUT THE WRITTEN APPROVAL OF TIMCO ENGINEERING, INC. Testing Certificate 0955-01 849 NW STATE ROAD 45 NEWBERRY, FL 32669 USA PH: 888.472.2424 OR 352.472.5500 FAX: 352.472.2030 EMAIL: [email protected] HTTP://WWW.TIMCOENGR.COM APPLICANT: MIDLAND RADIO CORPORATION FCC ID: MMA1001LWXA IC: 3690A-1001LWXA REPORT #: M\MIDLAND_MMA\535AUT13\535AUT13TestReport.doc Page 2 of 18 TABLE OF CONTENTS GENERAL REMARKS ................................................................................................... 3 GENERAL INFORMATION ............................................................................................ 4 TEST ENVIRONMENT .................................................................................................. 5 TEST SETUP SUMMARY .............................................................................................. 5 EQUIPMENT LIST ........................................................................................................ 6 TEST PROCEDURE ...................................................................................................... 7 RF POWER OUTPUT .................................................................................................... 8 MODULATION CHARACTERISTICS.............................................................................. 9 AUDIO FREQUENCY RESPONSE ................................................................................. 9 AUDIO LOW PASS FILTER RESPONSE ...................................................................... 10 AUDIO INPUT VS MODULATION ................................................................................ 11 OCCUPIED BANDWIDTH ........................................................................................... 12 SPURIOUS EMISSIONS AT ANTENNA TERMINALS (CONDUCTED)............................ 14 FIELD STRENGTH OF SPURIOUS EMISSIONS .......................................................... 16 METHOD OF MEASUREMENT ................................................................................... 17 FREQUENCY STABILITY ............................................................................................ 18 APPLICANT: MIDLAND RADIO CORPORATION FCC ID: MMA1001LWXA IC: 3690A-1001LWXA REPORT #: M\MIDLAND_MMA\535AUT13\535AUT13TestReport.doc Page 3 of 18 GENERAL REMARKS The attached report shall not be reproduced except in full without the written permission of Timco Engineering Inc. The test results relate only to the items tested. Summary The device under test does: fulfill the general approval requirements as identified in this test report not fulfill the general approval requirements as identified in this test report Attestations This equipment has been tested in accordance with the standards identified in this test report. To the best of my knowledge and belief, these tests were performed using the measurement procedures described in this report. All instrumentation and accessories used to test products for compliance to the indicated standards are calibrated regularly in accordance with ISO 17025 requirements. Testing Certificate # 0955-01 I attest that the necessary measurements were made, under my supervision, at: Timco Engineering Inc. 849 NW State Road 45 Newberry, Fl 32669 Authorized Signatory Name: John A. Day Testing Tech./Project Manager Date: 4/12/2013 APPLICANT: MIDLAND RADIO CORPORATION FCC ID: MMA1001LWXA IC: 3690A-1001LWXA REPORT #: M\MIDLAND_MMA\535AUT13\535AUT13TestReport.doc Page 4 of 18 GENERAL INFORMATION DUT Specification DUT Description 1001LWXA FCC ID MMA1001LWXA IC 3690A-1001LWXA Model Number 1001LWX Serial Number N/A Operating Frequency 26.965-27.405 MHz No. of Channels 40 Type of Emission 6KOOA3E Bn = 2M M = 3000 Bn = 6000 Modulation A3E/ J3E DUT Power Source 110–120Vac/50– 60Hz DC Power Battery Operated Exclusively Test Item Prototype Pre-Production Production Type of Equipment Fixed Mobile Portable APPLICANT: MIDLAND RADIO CORPORATION FCC ID: MMA1001LWXA IC: 3690A-1001LWXA REPORT #: M\MIDLAND_MMA\535AUT13\535AUT13TestReport.doc Page 5 of 18 TEST ENVIRONMENT Test Facility Timco Engineering, Inc. 849 NW State Road 45 Newberry, FL 32669 USA. Test Condition in the laboratory Temperature: 26ºC Relative humidity: 50% TEST SETUP SUMMARY Test Setup Diagram/ Description The DUT was placed on the turntable per setup per ANSI C63.4: 2003. A test set up photo is provided for clarification. Deviation from the standard/procedure No deviation Modification of DUT Added wires for mic input and PTT Applicable Standards EIA/TIA-382-A, FCC CFR 47 PART 95, RSS-GEN ISSUE 8, RSS-236 ISSUE 1 APPLICANT: MIDLAND RADIO CORPORATION FCC ID: MMA1001LWXA IC: 3690A-1001LWXA REPORT #: M\MIDLAND_MMA\535AUT13\535AUT13TestReport.doc Page 6 of 18 EQUIPMENT LIST Device Manufacturer Model Serial Number Cal/Char Date Due Date Analyzer Tan Tower Spectrum Analyzer HP 8566B Opt 462 3138A07786 3144A20661 10/28/11 10/28/13 Analyzer Tan Tower Preamplifier HP 8449B-H02 3008A00372 10/28/11 10/28/13 Antenna: Biconnical Electro- Metrics BIA-25 1171 06/13/12 06/13/14 Antenna: Biconnical Eaton 94455-1 1096 05/04/11 05/04/13 Antenna: Log- Periodic Electro- Metrics LPA-25 1122 05/04/11 05/04/13 Antenna: Dipole Kit Electro- Metrics TDA-30/1-4 152 11/01/09 11/01/99 Frequency Counter HP 5352B 2632A00165 06/22/11 06/22/13 Frequency Counter HP 5385A 2730A03025 08/17/11 08/17/13 Signal Generator HP 8640B 2308A21464 02/23/12 02/23/14 Hygro- Thermometer Extech 445703 0602 06/15/11 06/15/13 Digital Multimeter Fluke 7…
