MMACLIPTALKTransceiver

Midland Radio Corporation 5900 Parretta Drive, Kansas City, Missouri, United States This document is proprietary and confidential. No part of this document may be disclosed in any manner to a third party without the prior written consent of Midland Radio. ClipTalk Transceiver Ultra small low power two-way UHF radio User Interface Specifications Revision History Version Description Date Author 0 Release 9-17-2025 R Hollis A Added “BT Connected mode under programming mode 10-18-2025 R Hollis B Clarified UI volume and channel behavior 10/18/2025 J Paulson C Rewritten for clarity. Added “double beep” requirement for max and min volume. Eliminated flash requirement for channel display during Tx. Added double beep requirement for Tx 1minute timeout. 11-03-2025 R Hollis ClipTalk User Manual.docx Page 2 of 6 Midland Radio Corporation 5900 Parretta Drive, Kansas City, Missouri, United States This document is proprietary and confidential. No part of this document may be disclosed in any manner to a third party without the prior written consent of Midland Radio. User Operation • User controls o PTT button (side) o Select button o + button o - button • Power on/off o Press and hold Select for 2 seconds to turn the radio power on.  The display will light with battery icon and channel number.  If there is no key activity for 5 seconds, the display will turn off.  If there is no key activity, the bottom segment of the battery icon will flash every 5 seconds to indicate that the unit is active and power is on. o Press and hold Select for 2 seconds to turn the radio power off. • Transmit o Press the PTT button to transmit. This is a momentary key and the radio will transmit while the key is depressed. User Operation User Operation - button Select button + button PTT button (side) - button Select button + button PTT button (side) ClipTalk User Manual.docx Page 3 of 6 Midland Radio Corporation 5900 Parretta Drive, Kansas City, Missouri, United States This document is proprietary and confidential. No part of this document may be disclosed in any manner to a third party without the prior written consent of Midland Radio. If the PTT is pressed for 1 minute the unit will stop transmitting, the display will go blank and the user will hear a “double beep”. The radio will not transmit again until the PTT is released and pressed again. o The channel number will show steady during transmission. • Display Channel & Volume o If the display is blank, pressing SELECT will cause the display to turn on and show the current Channel. o The current Channel will always be shown when the display is active. • Volume Up/Down o A quick press of the “+” (less than 2 seconds) will increase the volume one level and play a 400 Hz tone at the corresponding volume level selected. If he volume setting reaches maximum (9) the next press of the “+” key will produce a “double beep” to indicate that volume is at the maximum. o A quick press of the “-” (less than 2 seconds) will decrease the volume one level and play a 400 Hz tone at the corresponding volume level selected. If he volume setting reaches minimum (1) the next press of the “-” key will produce a “double beep” to indicate that volume is at the maximum. o The volume level is never shown on the display. • Channel selection o A long press on the + or – button greater than 2 seconds will adjust the channel in the appropriate direction. o Once the “+” channel change occurs, a tone of 1000 Hz will be played to indicate an increased channel. o Once the “-” channel change occurs, a tone of 1000 Hz will be played to indicate an increased ClipTalk User Manual.docx Page 4 of 6 Midland Radio Corporation 5900 Parretta Drive, Kansas City, Missouri, United States This document is proprietary and confidential. No part of this document may be disclosed in any manner to a third party without the prior written consent of Midland Radio. channel. oContinuing to hold the + or – button for another 0.5 seconds will increment or decrement the continuously at a 2 Hz rate until the button is released. oThe channel display has a value of 1 to 22 and rolls from 22 to 1 when increased and 1 to 22 when decreased. •Key timeout oAfter 5 seconds of no key activity, the display will go blank. •ANC (Noise canceling) On/Off oHolding down the PTT when turning the radio on will cause ANC to toggle between on and off. When the unit powers on, the display will show either “On” or “Of” depending on the previous state. “On” and OFF” are displayed for 1 second and then display returns to standby. •Programming mode oTo enter programming mode, confirm that the unit is turned on then hold down the + and – keys together for 3 seconds. The display will show the 3 dots in each outside segment in a racetrack pattern. The unit is now discoverable with the ClipTalk phone app. oWhen the unit is connected to the app, the unit will display a “cross” patter that will blink at a 1Hz rate. oPressing PTT will cause the radio to exit programming mode and return to FRS standby. Power: TX /RX:462.5500-462.7250MHz:23.75dBm; 467.5625-467.7125MHz: 23.25 dBm B LE: 2402-2480MHz: 0.67dBm ClipTalk User Manual.docx Page 5 of 6 Midland Radio Corporation 5900 Parretta Drive, Kansas City, Missouri, United States This document is proprietary and confidential. No part of this document may be disclosed in any manner to a third party without the prior written consent of Midland Radio. F CC Statement Any Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rul…

Text truncated - open the document above for the full version.

Midland Radio Corporation ADD: 5900 Parretta Drive, Kansas City, Missouri, United States TEL: 816-241-8500 FAX: 816-241-5713 E-mail: [email protected] Attestation Letter Date: 2026-03-02 FEDERAL COMMUNICATIONS COMMISSION Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD21046 Dear Sir or Madam: We, Midland Radio Corporation type of Equipment: Transceiver, Model name: ClipTalk, FCC ID: MMACLIPTALK The product only support: FM TX/RX:462.5500-462.7250MHz; 467.5625-467.7125MHz and BLE: 2402-2480 MHz (1M), for the purpose of marketing, other frequencies has been shielded by software, the end user has no capability to activate it. Best Regards, Sincerely Yours, Signature: Contact Person: Jeremy J Pensick Title: CEO

Midland Radio Corporation ADD: 5900 Parretta Drive, Kansas City, Missouri, United States TEL: 816-241-8500 FAX: 816-241-5713 E- mail: [email protected] CFR 47 §2.911(d)(5)(i)(ii) Attestation Letter Attestation Letter Date: 2026-03-02 FEDERAL COMMUNICATIONS COMMISSIONS Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Ref: Attestation Statements CFR 47 §2.911(d)(5)(i)(ii) Filing FCC ID: MMACLIPTALK Midland Radio Corporation (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Midland Radio Corporation (“the applicant”) certifies that as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Midland Radio Corporation (“the applicant”) certifies that the equipment does not use Kaspersky's software information. Sincerely, Signature: Contact Person: Jeremy J Pensick Title: CEO

U.S. AGENT LETTER OF ATTESTATION Date: 2026-03-02 FEDERAL COMMUNICATIONS COMMISSION Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Ref: Attestation Statements CFR 47 §2.911(d)(7) Filing FCC ID: MMACLIPTALK Midland Radio Corporation (“the Applicant”) certifies that, as of the date of the filing of the application, Midland Radio Corporation (U.S. agent) is our designated U.S. agent for service of process for the above referenced FCC ID. Midland Radio Corporation (“the Applicant”) accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. Midland Radio Corporation (U.S. agent) accepts, as of the date of the filing of the application, the obligation of the designated U.S. agent for service of process for the above referenced FCC ID. Designated U.S. Agent and Applicant Information: Name: Midland Radio Corporation Address: 5900 Parretta Drive, Kansas City, Missouri, United States FRN: 0032804825 Tel.: 816-241-8500 Email: [email protected] Signed by (printed name): Jeremy J Pensick Signature:

QA-FR-170-B Midland Radio Corporation ADD: 5900 Parretta Drive, Kansas City, Missouri, United States TEL: 816-241-8500 FAX: 816-241-5713 E- mail: [email protected] FCC Authorization Date: 2026-03-02 FEDERAL COMMUNICATIONS COMMISSION Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Subject: Agent Authorization To whom it may concern: We Midland Radio Corporation hereby authorizes Bay Area Compliance Laboratories Corp. (Xiamen) to act on its behalf in all matters relating to application for Equipment authorization, including the signing of all documents relating to these matters. All acts carried out by Bay Area Compliance Laboratories Corp. (Xiamen) on our behalf shall have the same effect as our own action. We, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. This authorization is valid until further written notice from the applicant. Sincerely Yours, Client’s signature: Contact Person: Jeremy J Pensick Title: CEO

QA-FR-172-A Midland Radio Corporation ADD: 5900 Parretta Drive, Kansas City, Missouri, United States TEL: 816-241-8500 FAX: 816-241-5713 E-mail: [email protected] FCC Confidential Authorization Date: 2026-03-02 FEDERAL COMMUNICATIONS COMMISSION Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Subject: Confidentiality Request regarding application for certification of FCC ID: MMACLIPTALK In accordance with Sections 0.457 and 0.459 of the Commission’s Rules, Midland Radio Corporation hereby requests long-term confidential treatment of information accompanying this application as outlined below: • Block Diagram • Schematics • Operation Description • BOM • Tune Up Procedure The above materials contain proprietary and confidential information not customarily released to the public. The public disclosure of these materials provides unjustified benefits to its competitors in the market. Sincerely, Signature: Contact Person: Jeremy J Pensick Title: CEO

Bay Area Compliance Laboratories Corp. (Xiamen) Report No.: 2507Z31947E-RF-EXP Page 1 / 8 EUT EXTERNAL PHOTOS Bay Area Compliance Laboratories Corp. (Xiamen) Report No.: 2507Z31947E-RF-EXP Page 2 / 8 Bay Area Compliance Laboratories Corp. (Xiamen) Report No.: 2507Z31947E-RF-EXP Page 3 / 8 Bay Area Compliance Laboratories Corp. (Xiamen) Report No.: 2507Z31947E-RF-EXP Page 4 / 8 Bay Area Compliance Laboratories Corp. (Xiamen) Report No.: 2507Z31947E-RF-EXP Page 5 / 8 Bay Area Compliance Laboratories Corp. (Xiamen) Report No.: 2507Z31947E-RF-EXP Page 6 / 8 Bay Area Compliance Laboratories Corp. (Xiamen) Report No.: 2507Z31947E-RF-EXP Page 7 / 8 Bay Area Compliance Laboratories Corp. (Xiamen) Report No.: 2507Z31947E-RF-EXP Page 8 / 8

Bay Area Compliance Laboratories Corp. (Xiamen) Report No.: 2507Z31947E-RF-INP Page 1 / 6 EUT INTERNAL PHOTOS Bay Area Compliance Laboratories Corp. (Xiamen) Report No.: 2507Z31947E-RF-INP Page 2 / 6 Bay Area Compliance Laboratories Corp. (Xiamen) Report No.: 2507Z31947E-RF-INP Page 3 / 6 Antenna (The red cable and the black cable are antenna) Bay Area Compliance Laboratories Corp. (Xiamen) Report No.: 2507Z31947E-RF-INP Page 4 / 6 Bay Area Compliance Laboratories Corp. (Xiamen) Report No.: 2507Z31947E-RF-INP Page 5 / 6 Bay Area Compliance Laboratories Corp. (Xiamen) Report No.: 2507Z31947E-RF-INP Page 6 / 6 BT Antenna - front BT Antenna - back

FCC §1.1307(b)(1) & §2.1093 Page 1 of 7 RF EXPOSURE REPORT For Midland Radio Corporation 5900 Parretta Drive, Kansas City, Missouri, United States FCC ID: MMACLIPTALK Report Type: Original Report Product Name: Transceiver Report Number: 2507Z31947E-RF-04 Report Date: 2026-02-05 Reviewed By: Ash Lin Approved By: Miles Chen Prepared By: Bay Area Compliance Laboratories Corp. (Xiamen) Unit 102, No. 902 Meifeng South Road, Binhai West Avenue, Science and Technology Innovation Park, Torch High tech Zone XiaMen Tel: +86-592-3200111 www.baclcorp.com.cn Bay Area Compliance Laboratories Corp. (Xiamen) Report No.: 2507Z31947E-RF-04 FCC §1.1307(b)(1) & §2.1093 Page 2 of 7 TABLE OF CONTENTS REPORT REVISION HISTORY................................................................................................................................. 3 GENERAL INFORMATION ....................................................................................................................................... 4 PRODUCT DESCRIPTION FOR EQUIPMENT UNDER TEST (EUT) ..................................................................................... 4 RF EXPOSURE EVALUATION ................................................................................................................................. 5 APPLICABLE STANDARD .............................................................................................................................................. 5 MEASUREMENT RESULT .............................................................................................................................................. 5 APPENDIX A - EUT PHOTOGRAPHS ..................................................................................................................... 6 Bay Area Compliance Laboratories Corp. (Xiamen) Report No.: 2507Z31947E-RF-04 FCC §1.1307(b)(1) & §2.1093 Page 3 of 7 REPORT REVISION HISTORY Number of Revisions Report No. Version Issue Date Description 0 2507Z31947E-RF-04 R1V1 2026-02-05 Initial Release Bay Area Compliance Laboratories Corp. (Xiamen) Report No.: 2507Z31947E-RF-04 FCC §1.1307(b)(1) & §2.1093 Page 4 of 7 GENERAL INFORMATION Product Description for Equipment under Test (EUT) Applicant: Midland Radio Corporation Product Name: Transceiver Tested Model: ClipTalk Multiple Model(s): N/A Trade Mark: MIDLAND Power Supply: DC 5V from Adapter or DC 3.7V from battery Adapter information Model: XZ0500-2400UU Input: AC 100-240V, 50/60Hz, 0.4A Output: DC 5V, 2.4A, 12W Maximum Peak Conducted Output Power: 0.67 dBm Operating Band/Frequency: 2402-2480MHz Modulation Type: GFSK Antenna Type: PCB Antenna ★Maximum Antenna Gain: 1 dBi EUT Received Status: Good Note: 1. The Maximum Antenna Gain was declared by manufacturer. Test Facility The Test site used by Bay Area Compliance Laboratories Corp. (Xiamen) to collect test data is located on the Unit 102, No. 902 Meifeng South Road, Binhai West Avenue, Science and Technology Innovation Park, Torch High tech Zone XiaMen. Bay Area Compliance Laboratories Corp. (Xiamen) Lab is accredited to ISO/IEC 17025 by A2LA (Certificate Number: 7134.01) and the lab has been recognized as the FCC accredited lab under the KDB 974614 D01, the FCC Designation No. : CN1384. Bay Area Compliance Laboratories Corp. (Xiamen) Report No.: 2507Z31947E-RF-04 FCC §1.1307(b)(1) & §2.1093 Page 5 of 7 RF EXPOSURE EVALUATION Applicable Standard According to§2.1093, systems operating under the provisions of this section shall be operated in a manner that ensure that the public is not exposed to radio frequency energy level in excess of the Commission's guideline According to KDB447498 D01 General RF Exposure Guidance v06 The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances < 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] *[√f(GHz)] < 3.0 for 1-g SAR and < 7.5 for 10-g extremity SAR, where f(GHz) is the RF channel transmit frequency in GHz Power and distance are rounded to the nearest mW and mm before calculation The result is rounded to one decimal place for comparison 3.0 and 7.5 are referred to as the numeric thresholds in the step 2 below The test exclusions are applicable only when the minimum test separation distance is ≤50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is <5 mm, a distance of 5 mm according to 5) in section 4.1 is applied to determine SAR test exclusion. Measurement Result For BLE: The max conducted power including tune-up tolerance is 1 dBm (1.26 mW). [(max. power of channel, mW)/(min. test separation distance, mm)][√f(GHz)] =1.26/5*(√2.480) = 0.40< 3.0 Result: Compliant. The stand-alone SAR evaluation is not necessary. Bay Area Compliance Laboratories Corp. (Xiamen) Report No.: 2507Z31947E-RF-04 FCC §1.1307(b)(1) & §2.1093 Page 6 of 7 APPENDIX A - EUT PHOTOGRAPHS Please refer to the attachment 2507Z31947E-RF-EXP EUT EXTERNAL PHOTOGRAPHS and 2507Z31947E-RF-INP EUT INTERNAL PHOTOGRAPHS. Bay Area Compliance Laboratories Corp. (Xiamen) Report No.: 2507Z31947E-RF-04 FCC §1.1307(b)(1) & §2.1093 Page 7 of 7 Declarations 1. Bay Area Compliance Laboratories Corp. (Xiamen) is not responsible for authenticity of any information provided by the applicant. Information from the applicant that may affect test results are marked with an asterisk “★”. 2. Unless otherwise stated, the results shown in this test report refer only to the sample(s) tested. 3. Unless required by the rule provided by the applicant or product regulations, then decision rule in this report did not consider the uncertainty. 4. The extended uncertainty given in this report is obtained by combining the standard uncertainty times the coverage factor k=2 with the 95% confidence interval. 5. This report cannot be reproduced except in full, without prior written approval of Bay Area Compliance Laboratories Corp. (Xiamen). 6. This report is va…

Text truncated - open the document above for the full version.

Fujian Quanzhou Huahong Communication Co., Ltd. Jiangnan Hi-tech Electronic Industry Zone, Licheng District, Quanzhou City, Fujian Province, China Model name: X-2-3 2.4G-NF17 电气参数 ELECTRICAL SPECIFICATIONS 机械特性 MECHANICAL SPECIFICATIONS 频率范围 2402-2480MHz Frequency Range 输入阻抗 50Ω Impedance 驻波比 ≤5 VSWR 增益 1 dBi Gain 极化方式 垂直 Vertical Polarization 辐射方向 全向 Omni Radiation 功率容量 0.5W Maximum Power Input-watts 高度 10± mm Height Antenna Type PCB Antenna 天线重量 1±0.2g Antenna Weight

FCC Part 15.247 Page 1 of 56 FCC PART 15.247 TEST REPORT For Midland Radio Corporation 5900 Parretta Drive, Kansas City, Missouri, United States Report Type: Original Report Product Name: Transceiver Report Number: 2507Z31947E-RF-03 Re port Date: 2026-02-05 Reviewed By: Ash Lin Approved By: Miles Chen Prepared By: Bay Area Compliance Laboratories Corp. (Xiamen) Unit 102, No. 902 Meifeng South Road, Binhai West Avenue, Science and Technology Innovation Park, Torch High tech Zone XiaMen Tel: +86-592-3200111 www.baclcorp.com.cn FCC ID: MMACLIPTALK Bay Area Compliance Laboratories Corp. (Xiamen) Report No.: 2507Z31947E-RF-03 FCC Part 15.247 Page 2 of 56 TABLE OF CONTENTS REPORT REVISION HISTORY ................................................................................................................................ 4 GENERAL INFORMATION ....................................................................................................................................... 5 PRODUCT DESCRIPTION FOR EQUIPMENT UNDER TEST (EUT) ..................................................................................... 5 OBJECTIVE ................................................................................................................................................................... 5 TEST METHODOLOGY .................................................................................................................................................. 5 MEASUREMENT UNCERTAINTY .................................................................................................................................... 6 SYSTEM TEST CONFIGURATION .......................................................................................................................... 7 TEST MODE AND VOLTAGE .......................................................................................................................................... 7 DESCRIPTION OF TEST CONFIGURATION ...................................................................................................................... 7 EQUIPMENT MODIFICATIONS ....................................................................................................................................... 7 ★EUT EXERCISE SOFTWARE ...................................................................................................................................... 7 DUTY CYCLE ............................................................................................................................................................... 8 SUPPORT EQUIPMENT LIST AND DETAILS .................................................................................................................... 8 EXTERNAL I/O CABLE ................................................................................................................................................. 8 BLOCK DIAGRAM OF TEST SETUP ................................................................................................................................ 9 SUMMARY OF TEST RESULTS ............................................................................................................................. 11 TEST EQUIPMENT LIST ......................................................................................................................................... 12 FCC §15.203 - ANTENNA REQUIREMENT .......................................................................................................... 13 APPLICABLE STANDARD ............................................................................................................................................ 13 ANTENNA CONNECTOR CONSTRUCTION .................................................................................................................... 13 FCC §15.207 (a) – AC LINE CONDUCTED EMISSIONS ..................................................................................... 14 APPLICABLE STANDARD ............................................................................................................................................ 14 EUT SETUP ................................................................................................................................................................ 14 EMI TEST RECEIVER SETUP ....................................................................................................................................... 14 TEST PROCEDURE ...................................................................................................................................................... 14 RESULT &MARGIN CALCULATION ............................................................................................................................. 15 TEST DATA ................................................................................................................................................................ 15 FCC §15.209, §15.205 & §15.247(d) - SPURIOUS EMISSIONS............................................................................. 18 APPLICABLE STANDARD ............................................................................................................................................ 18 EUT SETUP ................................................................................................................................................................ 18 EMI TEST RECEIVER & SPECTRUM ANALYZER SETUP .............................................................................................. 20 TEST PROCEDURE ...................................................................................................................................................... 20 RESULT &MARGIN CALCULATION ............................................................................................................................. 21 TEST DATA .....................................................................…

Text truncated - open the document above for the full version.

Bay Area Compliance Laboratories Corp. (Xiamen) Report No.: 2507Z31947E-TSP-RF-03 Page 1 / 5 EUT SETUP PHOTOS Conducted Emissions - Front View Conducted Emissions - Left View Bay Area Compliance Laboratories Corp. (Xiamen) Report No.: 2507Z31947E-TSP-RF-03 Page 2 / 5 RE (9kHz~30MHz) RE – Front View (30MHz~1GHz) Bay Area Compliance Laboratories Corp. (Xiamen) Report No.: 2507Z31947E-TSP-RF-03 Page 3 / 5 RE – Rear View (30MHz~1GHz) RE – Front View (1 GHz~18 GHz) Bay Area Compliance Laboratories Corp. (Xiamen) Report No.: 2507Z31947E-TSP-RF-03 Page 4 / 5 RE – Rear View (1 GHz~18 GHz) RE – Front View (18 GHz~25 GHz) Bay Area Compliance Laboratories Corp. (Xiamen) Report No.: 2507Z31947E-TSP-RF-03 Page 5 / 5 RE – Rear View (18 GHz~25 GHz)
