MMA9001CB TRANSCEIVER

www.midlandradio.com 1 9001z INDEX Thank You ................................................................................................................................................................................2 Major 9001z Features ...........................................................................................................................................................2 Installation ...........................................................................................................................................................................2-3 CB Antenna .............................................................................................................................................................................3 9001z Features and Controls .............................................................................................................................................4 Feature Operation .................................................................................................................................................................5 How to Operate Your CB ...................................................................................................................................................6 Technical Specifications ........................................................................................................................................................7 Limited Warranty ...................................................................................................................................................................7 Limitation of Liability ............................................................................................................................................................7 Service and Technical Support ........................................................................................................................................8 Accessories ........................................................................................................................................................................8 Accessories Order Form ................................................................................................................................................9 Other Midland Products ...............................................................................................................................................10 2 www.midlandradio.com Thank you Congratulations on your purchase of a state-of-the-art Midland 9001z mobile CB radio. In the years ahead, you can expect to realize time and again why Midland holds the front running position among CB users everywhere. You will come to know that American Original is not just a slogan, but the heading of long list of hearable, seeable benefits. As your Midland CB experience unfolds and grows we hope you will remember that CB radios are only one kind of electronic excellence available under the Midland name. Your 40 channel CB radio represents the state of the art in high tech enginee - ring. The unit incorporates microprocessor controlled PLL circuitry for precise tuning. The 9001z is a classic style CB with the innovative Guardian alert feature that is skillfully constructed with the finest components.This radio is designed for reliable and trouble-free performance for years to come. Enjoy! Midland Radio Corporation Hereby certifies that this unit has been designed, manufactured, FCC type accepted and certified in accordance with part 95 and Part 15, Subpart C of the current FCC rules and regulations as of the date of manufacture. • 40 CB Channels • 4 Watt Output Power • Guardian Alert • Weather Scan • XTRA TALK Mic Control • Instant Channel 9/19 • RF Gain • Switchable Noise Blanker(NB) • Delta Tune • SWR Calibration • XR Technology • Automatic Noise Limiter(ANL) • PA Function • Last Channel Memory • Push to talk ergonomically designed microphone • 9 ft coil Mic cord • Includes mounting bracket/hardware and fuse DC power cord Major 9001z Features Installation This transceiver may be installed in any 12-volt negative ground-system car or truck. Most current U.S. and Foreign vehicles use a negative system, but some older models and some newer large trucks may have a positive ground. Check the requirements for your vehicle before you begin installation. Generally, you have a negative-ground system if the minus (-) battery terminal is connected to the motor block. Contact your dealer in the event you are unable to determine your vehicle’s polarity system. Location Your new Midland CB is designed to be installed under the dash or vertically on a console of your vehicle. Safety and convenience are the primary considerations in deciding exactly where to locate your radio. Caution: Be sure that the unit is located so that it does not interfere with the driver, supplemental restraint systems (air bags), or impair access to any controls. Connecting cables must be routed and secured in such a manner as not to interfere with the operation of the brake, accelerator or other controls. Interference from either the unit or connecting cables may contribute to the loss of control of the vehicle. Mechanical Mounting Step 1: Plug power cable into back of radio marked “Power”. Be sure to observe polarity markings. Step 2: Use the mounting bracket as a template for marking the location of screw holes under the dash. Use a nail or other sharp pointed object to mark the hole locations. Step 3: Drill a ‘1/8” hole for each screw hole in the mounting bracket. Attach the bracket to the dash with the Phillips head sheet metal screws provided. NOTE: Extreme care should be exercised when drilling into the dash to avoid damage to under- dash electronic ignition, cruise control, instrument and/ or accessory wiring. Step 4: Attach removable 3-pin plug-in DC cord to polari- zed DC jack on the rear of the tran…

Text truncated - open the document above for the full version.

5900 Parretta Drive ● KANSAS CITY, MISSOURI ● 64120 TELEPHONE: (816) 241-8500 ● FAX: (816) 241-5713 EMAIL: [email protected] WEBSITE: www.midlandradio.com Midland Radio Corporation 5900 Parretta Drive, Kansas City, MO. 64120 Phone: (816) 241-8500 Fax: (816) 241-5713 Website: wwwl.midlandradio.com E-Mail: [email protected] June 15, 2010 Equipment Authorization Division Office of Engineering and Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Ref: FCC ID: MMA9001 Request for Confidentiality Dear Sirs: With regard to the referenced application, Midland Radio Corporation is requesting confidentiality of certain sections of the accompanying documents. The documents for which Midland Radio Corporation is requesting confidentiality are: Schematic Diagram Block Diagram Operational Descriptions This request is made under the provisions of Section 0.457(d) of the Commission’s Rules, and Section 552(b)(4) of the Freedom of Information Act. The material for which confidentiality is requested falls within the scope of Section 552(b)(4) as trade secrets and includes material covered by Section 0.459 of the Commission’s Rules. Sincerely, David Kingsolver, Director of Engineering

MIDLAND RADIO CORP. FCC ID: MMA9001 EXTERNAL PHOTOS

CB Midland Name Label 9001z Polyester NA 96-00171 00 1/1 -Material: Polyester silver t=0.05 mm -Printed: Graphics - Black Background - Silver NOTES

MIDLAND RADIO CORP. FCC ID: MMA9001 INTERNAL PHOTOS

ALIGMENT PROCEDURES MIDLAND 9001Z 1.0 TEST CONDITION STANDARD DC POWER SUPPLY 13.8 VDC MEASUREMENT CHANNEL CB CH19(27.185MHZ),WX CH4(162.475MHZ) STANDARD AUDIO LOADING 8 OHM ANTENNA IMPEDANCE 50 OHM STANDARD REF.MODULATION 30 %(AM),WX 3.3KHZ(FM) STANDARD REF.AUDIO OUTPUT 0.5W 2.0 EQUIPMENT SETUP AS BELOW. 2.1 TX TEST SETUP Spectrum analyzer Modulation meter Audio generator Distortion meter Watt meter Frequency counter Power supply M9001z UUT Oscilloscope 2.2 RX TEST SETUP 3.0 VCO ADJUST CONNECT U.U.T(UNIT UNDER TEST) M9001Z IN TX SETUP CH1 USE VOLTMETER MEASURE RX VCO AT TP1 ADJUST L401 ABOUT 1.8-1.9 V PRESS PTT AND TX VCO 1.8 – 1.9V SWITCH TO CH40 RX VCO AROUND 2.1 – 2.3V AND TX VCO AROUND 2.1 – 2.3V 4.0 TX FREQUENCY ADJUST CH20 PRESS PTT CHECK TX FREQUENCY AT FREQUENCY COUNTER 27.205 MHZ +/- 300 Hz ADJUST TO CENTER BY ADJUST CT1 AND CHECK CH1 AND CH40 5.0 TX POWER OUTPUT ADJUST CONNECT U.U.T(UNIT UNDER TEST) M9001Z IN TX SETUP CH20 PRESS PTT CHECK TX POWER OUTPUT AT WATT METER 4.0W BY ADJUST RV6 AND CHECK CH1 AND CH40 MUST BE IN SPEC 3.6 – 4.4 W Sinad meter RFsignal generator Distortion meter 8 ohm load Power supply M9001z UUT Oscilloscope 6.0 TX MODULATION ADJUST CONNECT U.U.T(UNIT UNDER TEST) M9001Z IN TX SETUP SET AUDIO GENNERATOR 50MV GO TO CH20 PRESS PTT ADJUST PEAK TX MODULATION BY ADJUST RV5 95 % AM MOD AND CHECK CH1 AND CH40 MUST BE IN SPEC 90% – 100% 7.0 TX HARMONIC AND BALANCE MOD ADJUST CONNECT U.U.T(UNIT UNDER TEST) M9001Z IN TX SETUP SET AUDIO GENNERATOR OFF GO TO CH1 SEE SPECTRUM ANALYZER PRESS PTT SEE HARMONIC LINE 13MHZ ADJUST L10 AND L11 UNTIL HARMONIC 13MHZ IS MINNIMUM AND GO TO CH40 PRESS PTT SEE HARMONIC LINE 13MHZ MUST BE IN SPEC LESS THAN 60dBc IF STILL OUT WILL ADJUST L10 AND L11 AGAIN UNTIL IN SPEC AND RECHECK CH1 BOTH 8.0 TX POWER S- METER ADJUST CONNECT U.U.T(UNIT UNDER TEST) M9001Z IN TX SETUP GO TO PRESS PTT ADJUST RV1 UNTIL RED PIN = 7 AT S9-METER 9.0 ANTENNA RED LAMP ADJUST DISCONNECT ANTENNA AND U.U.T M9001Z PRESS PTT ADJUST RV 8 UNTIL RED LAMP ON THEN CONNECT ANTENNA PRESS PTT RED LAMP MUST BE OFF 10.0 RX SENSITIVITY ADJUST CONNECT U.U.T(UNIT UNDER TEST) M9001Z IN RX SETUP SET RF SIGNAL GENERATOR FREQUENCY 27.185MHZ MOD AM 30% AMPLITUDE -107dBm GO TO CH19 MAX VOLUME ADJUST RX MAXIMUM SENSITIVITY FIRST AT L1,L2,L3 AND L4 MORE THAN 12 dB SINAD AT SINADER METER. 11.0 SQUELCH ADJUST CONNECT U.U.T(UNIT UNDER TEST) M9001Z IN RX SETUP SET RF SIGNAL GENERATOR FREQUENCY 27.185MHZ MOD AM 30% AMPLITUDE -47dBm GO TO CH19 MAX VOLUME ADJUST , MAX SQUELCH AND MAX RF GAIN ADJUST RV2 TURN OFF AND TURN ON SIGNAL INCREASE SIGNAL AMPLITUDE UNTIL SQUELCH OFF AND DECREASE SIGNAL AMPLITUDE UNTIL SQUELCH ON IN SPEC -53 TO -41 dBm 12.0 S-9 METER ADJUST SET RF SIGNAL GENERATOR FREQUENCY 27.185MHZ MOD AM 30% AMPLITUDE -67dBm GO TO CH19 MAX VOLUME ADJUST RV7 UNTIL RED PIN = 9 AT S9-METER 13.0 WX VCO ADJUST SET RF SIGNAL GENERATOR FREQUENCY 162.4 MHZ MOD FM 3.3 KHZ AMPLITUDE -47dBm SELECT SWITCH TO WX MODE USE VOLTMETER MEASURE WX VCO AT TP1 CH1 ADJUST L201 ABOUT 2.5 V GO TO CH7 CHECK WX VCO AROUND 2.6 V 14.0 WX AUDIO & SENSITIVITY ADJUST SET RF SIGNAL GENERATOR FREQUENCY 162.4 MHZ MOD FM 3.3 KHZ AMPLITUDE -47dBm CH2 SET AUDIO MAXIMUM ADJUST L5 UNTIL AUDIO MAXIMUM AND CHANGE AMPLITUDE TO -107dBm CONTROL VOLUME 2 VOLT AND ADJUST L204 AND L205 TO MAXIMUM SENSITIVITY AND CHECK WX SENSITIVITY CH2 MUST BE >0.5uv@ 12dBsinad AND RECHECK CH2 MUST BE >0.5uv@ 12dBsinad 15.0 WX SQUELCH ADJUST SET RF SIGNAL GENERATOR FREQUENCY 162.4 MHZ MOD FM 3.3 KHZ ADJUST UNTIL WX SENSITIVITY = 12dBsinad ADJUST RV10 TO TURN OFF SQUELCH AND TURN ON AGAIN

Any and all SANYO products described or contained herein do not have specifications that can handle applications that require extremely high levels of reliability, such as life-support systems, aircraft’s control systems, or other applications whose failure can be reasonably expected to result in serious physical and/or material damage. Consult with your SANYO representative nearest you before using any SANYO products described or contained herein in such applications. SANYO assumes no responsibility for equipment failures that result from using products at values that exceed, even momentarily, rated values (such as maximum ratings, operating condition ranges,or other parameters) listed in products specifications of any and all SANYO products described or contained herein. NPN Epitaxial Planar Silicon Transistor 27MHz RF Power Amplifier Applications Ordering number:ENN462E 2SC2078 SANYO Electric Co.,Ltd. Semiconductor Company TOKYO OFFICE Tokyo Bldg., 1-10, 1 Chome, Ueno, Taito-ku, TOKYO, 110-8534 JAPAN 11504TN (KT)/N1098HA (KT)/D251MH/4147KI/3145KI/2274KI No.462–1/4 Specifications Absolute Maximum Ratings at Ta = 25 ̊C Package Dimensions unit:mm 2010C [2SC2078] ̊C ̊C Electrical Characteristics at Ta = 25 ̊C 1 : Base 2 : Collector 3 : Emitter SANYO : TO-220 retemaraPlobmySsnoitidnoCsgnitaRtinU egatloVesaB-ot-rotcelloCV OBC 08V egatloVrettimE-ot-rotcelloCV REC 57V egatloVesaB-ot-rettimEV OBE 5V tnerruCrotcelloCI C 3A )esluP(tnerruCrotcelloCI PC 5A noitapissiDrotcelloCP C 2.1W 01W erutarepmeTnoitcnuJjT051 erutarepmeTegarotSgtsT051+ot55– retemaraPlobmySsnoitidnoC sgnitaR tinU nimpytxam tnerruCffotuCrotcelloCI OBC V BC I,V04= E 0=01Aμ tnerruCffotuCrettimEI OBE V BE I,V4= C 0=01Aμ niaGtnerruCCD h EF V EC I,V5= C A5.0= *52*002 tcudorPhtdiwdnaB-niaGf T V EC I,V01= C A1.0= 001051zHM ecnaticapaCtuptuOC bo V BC zHM1=f,V01= 5406Fp * : The 2SC2078 are classified by 0.5A h FE as follows :Continued on next page. Tc=50 ̊C knaRBCDE h EF 05ot5208ot04021ot06002ot001 R BE =150Ω 10.2 5.1 3.6 18.0 5.6 2.7 6.3 15.1 1.2 14.0 0.8 1.3 4.5 0.4 2.55 2.55 2.7 123 2SC2078 No.462–2/4 retemaraPlobmySsnoitidnoC sgnitaR tinU nimpytxam egatloVnoitarutaSrettimE-ot-rotcelloCV )tas(EC I C I,A1= B A1.0= 51.06.0V egatloVnoitarutaSrettimE-ot-esaBV )tas(EB I C I,A1= B A1.0= 9.02.1V egatloVnoitarutaSesaB-ot-rotcelloCV OBC)RB( I C I,Aμ001= B 0=08V egatloVnoitarutaSrettimE-ot-rotcelloCV REC)RB( I C R,Am1= EB 051=Ω57V egatloVnoitarutaSesaB-ot-rettimEV OBE)RB( I E I,Aμ001= C 0=5V ]tiucrictsetdeificepstA[ rewoPtuptuOP O V CC W2.0=iP,zHM72=f,V21= 0.4W ycneiciffErewoP η 06% 27MHz Output Power Test Circuit Continued from preceding page. V CC =12V +-- INPUT OUTPUT 10μF0.02 0.005 RFC to 100pF to 100pF to 100pF to 100pF 68pF 33Ω L1 L2 Coil dataL1 : 0.3mm tinned wire 9ø 4T L2 : 0.6mm tinned wire 9ø 9T RFC2.2μH 2SC2078 0 0.4 0.8 1.2 1.6 2.0 00.40.81.21.6 I C -- V CE ITR05108 1.0 2 3 5 10 2 3 5 100 2 3 5 1000 2 3 2 0.50.60.70.80.9 I C -- V BE ITR05110 0 4 8 12 16 20 24 0 1020304050607080 I C -- V CE ITR05109 50 μ A 500 μ A 450 μ A 400 μ A 350 μ A 300 μ A 250 μ A 200 μ A 150 μ A 100 μ A V CE =10V 325 0.10.01 325 1.0 32 f T -- I C ITR05111 3 100 2 5 1000 7 3 5 7 V CE =10V I B =0 80mA 60mA 50mA 40mA 30mA 20mA 10mA 100mA I B =0 Collector Current, I C – A Collector-to-Emitter Voltage, V CE –V Collector Current, I C – mA Collector-to-Emitter Voltage, V CE –V Base-to-Emitter Voltage, V BE –V Collector Current, I C – mA Gain-Bandwidth Product, f T – MHz Collector Current, I C –A 2SC2078 No.462–3/4 0.2 0 0.4 0.6 0.8 1.0 1.2 1.4 1.6 0 2 4 6 8 10 0 20 40 60 80 100 8910111213141516 020406080100120140160 Po, ηc -- V CC ITR05115 P C -- Ta ITR05116 f=27MHz R L =50Ω From top Pi=0.5W 0.4W 0.3W 0.2W From top Pi=0.5, 0.4W 0.3W 0.2W η c Po 0 2 4 6 8 10 00.10.20.30.40.5 Po -- Pi ITR05114 f=27MHz R L =50Ω 14V 12V 10V 8V V CC =16V No heat sink 0 2 4 6 8 10 12 020406080100120140160 P C -- Ta ITR05117 3 2 3 2 5 100 7 7 10 5 Cob -- V CB 1.0 23523 5 10 235 100 ITR05113 f=1MHz I E =0 100 7 5 3 2 3 2 10 23 523 5 101.0 23 5 100 23 5 100010000 h FE -- I C ITR05112 V CE =5V V CE =10V 5V DC Current Gain, h FE Collector Current, I C –mA Output Power, Po – W Input Power, Pi–W Output Power, Po – W Collector Efficiency, η c – % Supply Voltage, V CC –V Output Capacitance, Cob – pF Collector-to-Base Voltage, V CB -- V Collector Dissipation, P C – W Ambient Temperature, Ta– ̊C Collector Dissipation, P C – W Ambient Temperature, Ta– ̊C Specifications of any and all SANYO products described or contained herein stipulate the performance, characteristics, and functions of the described products in the independent state, and are not guarantees of the performance, characteristics, and functions of the described products as mounted in the customer's products or equipment. To verify symptoms and states that cannot be evaluated in an independent device, the customer should always evaluate and test devices mounted in the customer's products or equipment. SANYO Electric Co., Ltd. strives to supply high-quality high-reliability products. However, any and all semiconductor products fail with some probability. It is possible that these probabilistic failures could give rise to accidents or events that could endanger human lives, that could give rise to smoke or fire, or that could cause damage to other property. When designing equipment, adopt safety measures so that these kinds of accidents or events cannot occur. Such measures include but are not limited to protective circuits and error prevention circuits for safe design, redundant design, and structural design. In the event that any or all SANYO products(including technical data,services) described or contained herein are controlled under any of applicable local export control laws and regulations, such products must not be exported without obtaining the export license from the authorities concerned in accordance with the above law. No part of this publication may be reproduced or transmitted in any form or by any means, electronic or mechan…

Text truncated - open the document above for the full version.

FCC PART 95 SUBPART D TEST REPORT FOR CB TRANSCEIVERS APPLICANT MIDLAND RADIO CORPORATION 5900 PARRETTA DRIVE KANSAS CITY MISSOURI 64120 USA FCC ID MMA9001 MODEL NUMBER 9001Z PRODUCT DESCRIPTION CB TRANSCEIVER DATE SAMPLE RECEIVED 1/22/2011 DATE TESTED 2/23/2011 TESTED BY Joe Scoglio APPROVED BY Mario R. de Aranzeta TIMCO REPORT NO. 134AT11TestReport.doc TEST RESULTS PASS FAIL THE ATTACHED REPORT SHALL NOT BE REPRODUCED EXCEPT IN FULL WITHOUT THE WRITTEN APPROVAL OF TIMCO ENGINEERING, INC. 849 NW STATE ROAD 45 NEWBERRY, FL 32669 USA PH: 888.472.2424 OR 352.472.5500 FAX: 352.472.2030 EMAIL: [email protected] HTTP: //WWW.TIMCOENGR.COM Testing Certificate # 0955-01 APPLICANT: MIDLAND RADIO CORPORATION FCC ID: MMA9001 REPORT #: M\MidlandRadio MMA\134AT11\134AT11TestReport.doc Page 2 of 19 TABLE OF CONTENTS GENERAL REMARKS................................................................................................. 3 GENERAL INFORMATION .......................................................................................... 4 TEST ENVIRONMENT ................................................................................................ 5 TEST SETUP SUMMARY ............................................................................................ 5 TEST EQUIPMENT LIST............................................................................................. 6 TEST PROCEDURE ................................................................................................... 7 RF POWER OUTPUT .................................................................................................. 8 MODULATION CHARACTERISTICS............................................................................ 9 AUDIO FREQUENCY RESPONSE ............................................................................... 9 AUDIO LOW PASS FILTER RESPONSE .................................................................... 10 AUDIO INPUT VS MODULATION.............................................................................. 11 OCCUPIED BANDWIDTH ......................................................................................... 12 SPURIOUS EMISSIONS AT ANTENNA TERMINALS (CONDUCTED)........................... 14 FIELD STRENGTH OF SPURIOUS EMISSIONS......................................................... 16 METHOD OF MEASUREMENT................................................................................. 18 FREQUENCY STABILITY.......................................................................................... 19 APPLICANT: MIDLAND RADIO CORPORATION FCC ID: MMA9001 REPORT #: M\MidlandRadio MMA\134AT11\134AT11TestReport.doc Page 3 of 19 GENERAL REMARKS The attached report shall not be reproduced except in full without the written permission of Timco Engineering Inc. The test results relate only to the items tested. Summary The device under test does: fulfill the general approval requirements as identified in this test report not fulfill the general approval requirements as identified in this test report Attestations This equipment has been tested in accordance with the standards identified in this test report. To the best of my knowledge and belief, these tests were performed using the measurement procedures described in this report. All instrumentation and accessories used to test products for compliance to the indicated standards are calibrated regularly in accordance with ISO 17025: 2005 requirements. Testing Certificate # 0955-01 I attest that the necessary measurements were made, under my supervision, at: Timco Engineering Inc. 849 NW State Road 45 Newberry, Fl 32669 Authorized Signatory Name: Mario de Aranzeta C.E.T. Compliance Engineer/ Lab. Supervisor Date: February/23/2011 APPLICANT: MIDLAND RADIO CORPORATION FCC ID: MMA9001 REPORT #: M\MidlandRadio MMA\134AT11\134AT11TestReport.doc Page 4 of 19 GENERAL INFORMATION DUT Specification DUT Description CB TRANSCEIVER FCC ID MMA9001 Model Number 9001Z Serial Number N/A Operating Frequency 26.965-27.405 MHz No. of Channels 40 Type of Emission 6KOOA3E Bn = 2M M = 3000 Bn = 6000 Modulation AM 110–120Vac/50– 60Hz DC Power DUT Power Source Battery Operated Exclusively Prototype Pre-Production Test Item Production Fixed Mobile Type of Equipment Portable APPLICANT: MIDLAND RADIO CORPORATION FCC ID: MMA9001 REPORT #: M\MidlandRadio MMA\134AT11\134AT11TestReport.doc Page 5 of 19 TEST ENVIRONMENT Test Facility Timco Engineering, Inc. 849 NW State Road 45 Newberry, FL 32669 USA. Test Condition in the laboratory Temperature: 26ºC Relative humidity: 50% TEST SETUP SUMMARY Test Setup Diagram/ Description The DUT was placed on the turntable per setup per ANSI C63.4: 2003. A test set up photo is provided for clarification. Deviation from the standard/procedure No deviation Modification of DUT No modification Applicable Standards EIA/TIA-382-A, FCC CFR 47 PART 95 APPLICANT: MIDLAND RADIO CORPORATION FCC ID: MMA9001 REPORT #: M\MidlandRadio MMA\134AT11\134AT11TestReport.doc Page 6 of 19 TEST EQUIPMENT LIST Device Manufacturer Model Serial Number Cal/Char Date Due Date 3-Meter Semi- Anechoic Chamber Panashield N/A N/A Listed 3/10/10 3/10/12 AC Voltmeter HP 400FL 2213A14499 CAL 3/23/09 3/23/11 Antenna: Dipole Kit Electro- Metrics TDA-30/1-4 153 CHAR 6/10/09 6/10/11 Frequency Counter HP 5385A 3242A07460 CAL 5/26/09 5/26/11 Modulation Analyzer HP 8901A 3435A06868 CAL 5/26/09 5/26/11 Digital Multimeter Fluke FLUKE-77-3 79510405 CAL 5/18/09 5/18/11 Analyzer Tan Tower Preamplifier HP 8449B-H02 3008A00372 CAL 11/21/09 11/21/11 Analyzer Tan Tower Quasi- Peak Adapter HP 85650A 3303A01690 CAL 11/22/09 11/22/11 Analyzer Tan Tower RF Preselector HP 85685A 3221A01400 CAL 11/21/09 11/21/11 Analyzer Tan Tower Spectrum Analyzer HP 8566B Opt 462 3138A07786 3144A20661 CAL 11/24/09 11/24/11 Temperature Chamber Tenney Engineering TTRC 11717-7 CHAR 4/25/10 4/25/12 APPLICANT: MIDLAND RADIO CORPORATION FCC ID: MMA9001 REPORT #: M\MidlandRadio MMA\134AT11\134AT11TestReport.doc Page…

Text truncated - open the document above for the full version.
