GXT800/850 Series GMRS/FRS Radio X-TRA TALK ® OWNER'S MANUAL www.midlandradio.com ® Model GXT800/850 Series Page 3www.midlandradio.com TABLE OF CONTENTS3 Introduction4 Important Notice, FCC Licensing5 LCD Display6 Controls6 Battery Installation7 Installing the Belt Clip7 Charging the Optional Battery Pack8 Low Battery Level Indicator8 Operating Your Radio9 - 18 External Speaker/Microphone Jack18 Troubleshooting Guide19 Use and Care19 Specifications and Frequency Charts20 - 21 Warranty Information22 MIDLAND Family Products23 Accessories23 - 26 Accessories Order Form27 ® Page 4www.midlandradio.com Welcome to the world of Midland electronics Congratulations on your purchase of a high quality MIDLAND product. Your 2-way radio represents the state-of-the-art in high-tech engineering. Designed for GMRS (General Mobile Radio Service) operation, this compact package is big in performance. It is a quality piece of electronic equipment, skillfully constructed with the finest components. The circuitry is all solid-state and mounted on a rugged printed circuit board. Your two-way radio is designed for reliable and trouble-free performance for years to come. Features - 22 GMRS/FRS Channel - 142 Privacy Codes (38 CTCSS / 104 DCS) - Water Resistant (IP4 Standard) - Direct Call - VOX - Selectable Call Alert (additional Animal Sound on GXT850) - NOAA Weather Radio - NOAA Weather Alert - VIBRATE ALERT - Scan Function - Monitor Function - Roger Beep Tone - Silent Operation - Keypad Lock - Power HI/MED/LO Settings - Speaker / Microphone Jacks - Battery Meter / Battery Low Indicator This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions : (1) this device does not cause harmful interference, and (2) this radio must accept any interference that may cause undesired operation. To maintain compliance with FCC’s RF exposure guidelines, for body-worn operation, this radio has been tested and meets the FCC RF exposure guidelines when used with Midland Radio Corp. accessories supplied or designated for this product. Use of other accessories may not ensure compliance with FCC RF exposure guidelines. (Tested with Headset Model: AVP-1) Model GXT800/850 Series ® Page 5www.midlandradio.com IMPORTANT NOTICE, FCC LICENSE REQUIRED FOR GMRS OPERATION The GXT800/850 Series operates on GMRS (General Mobile Radio Service) frequencies which require an FCC (Federal Communications Commission) license. You must be licensed prior to operating on channels 1 - 7 or 15 - 22, which comprise the GMRS channels of the GXT800/850 Series. Serious penalties could result for unlicensed use of GMRS channels, in violation of FCC rules, as stipulated in the Communications Act's Sections 501 and 502 (amended). You will be issued a call sign by the FCC which should be used for station identification when operating the radio on GMRS channels. You should also cooperate by engaging in permissible transmissions only, avoiding channel interference with other GMRS users, and being prudent with the length of their transmission time. To obtain a license or ask questions about the license application, contact the FCC at 1-888-CALL FCC or go to the FCC's website: http://www .fcc.govand request form 605. Exposure To Radio Frequency Energy Your Midland radio is designed to comply with the following national and international standards and guidelines regarding exposure of human being to radio frequency electromagnetic energy: - United States Federal Communications Commission, Code of Federal Regulations: 47 CFR part 2 sub-part J - American National Standards Institute (ANSI)/Institute of Electrical & Electronic Engineers (IEEE) C95. 1-1992 - Institute of Electrical and Electronic Engineer (IEEE) C95. 1-1999 Edition - National Council on Radiation Protection and Measurements (NCRP) of the United States, Report 86, 1986 - International Commission on Non-lonizing Radiation Protection (ICNIRP) 1998 To control your exposure and ensure compliance with the general population or uncontrolled environment exposure limits, transmit no more than 50% of the time. The radio generates measurable RF energy exposure only when transmitting. Model GXT800/850/850 Series IMPORTANT:Changes or modifications to this unit not expressly approved by MIDLAND RADIO CORP. could void your right to operate this unit. Your radio is set up to transmit a regulated signal on an assigned frequency. It is against the law to alter or adjust the settings inside the COMMUNICATOR to exceed those limitations. Any adjustment to your radio must be made by qualified technicians. ® Page 6www.midlandradio.com CONTROLS LCD DISPLA Y 1. BATTERY METER– Indicates the battery level. 2. KEY LOCK ICON – Indicates KEY LOCK mode is on. 3. VOX ICON– Indicates when VOX mode is active. 4. NOAA WEATHER (WX) BAND ICON– Indicates when the radio is in Weather Band mode. 5. CHANNEL NUMBER– Changes from 1~22 on GMRS/FRS band (1~10 on WX band). 6. PRIVACY CODE– Indicates Privacy Code selected by user (oF~38/oF~104). 7. GROUP MODE ICON– Indicates when the Group Mode is on. 8. VIBRATE-ALERT ICON– Indicates when the Vibrate-Alert feature is on. 9. RECEIVE (RX) ICON– Indicates radio is receiving a transmission. 10. TRANSMIT (TX) ICON– Indicates radio is transmitting a signal. 11. TRANSMIT POWER LEVEL ICON– Indicates TX Power setting (H/M/L) 12. PRIVACY CODE ICON– Indicates Privacy Code setting (CTCSS/DCS). 13. POWER/VOLUME KNOB– Turn clock- wise to turn the power on and increase the volume level. Turn counter-clockwise to decrease the volume level and turn the power off. 14. PTT Button– Press and hold to transmit voice communication. 15. CALL/LOCK Button– Press to send a CALL Alert signal. Press and hold to turn KEY LOCK on/off. 16. MENU Button– Press to access Menu mode. Press and hold to go to WX Band Receiver mode. 17. SPEAKER– Built-in speaker. 18. ANTENNA. 19. EXTERNAL SPEAKER/MIC JACK. 20. UPand DOWN Button– Make adjustments in MENU mode. 21. MONITOR/SCAN Button– Press to enter…

Text truncated - open the document above for the full version.

5900 Parretta Drive ● KANSAS CITY, MISSOURI ● 64120 TELEPHONE: (816) 241-8500 ● FAX: (816) 241-5713 EMAIL: [email protected] WEBSITE: www.midlandradio.com JAN 05, 2007 Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID: MMAGXT850 Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Exhibit Type File Name Schematics Diagram(s) MMAGXT850_Schematic_diagram _Confidentiality.pdf Operational Description MMAGXT850_Technical Description _Confidentiality.pdf Block Diagram MMAGXT850_Block_diagram _Confidentiality.pdf The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Midland Radio Corporation 5900 Parretta, Drive, Kansas City, MO 64120 .

GLOBALLINK CORPORATION LTD. GXT850Series - Bill of Material (Ver.AAA) GXT850 Dwg.No : GXT850-BOM-P-01 Rev.Date : 27 Dec, 2006 Q7 BFQ67W TRANSISTOR CHIP 1 Visay Array Q8 BFQ67W TRANSISTOR CHIP 1 Visay Array Q10 BFQ67W TRANSISTOR CHIP 1 Visay Array SPK1 DIA36 (8 ohm 0.25W) Speaker 1 Asahi Asahi C78 1.5PF CHIP CAPACITOR 0402 NPO ±0.25PF 1 Murata Asung C5 1PF CHIP CAPACITOR 0402 NPO ±0.25PF 1 Murata Asung C29 1PF CHIP CAPACITOR 0402 NPO ±0.25PF 1 Murata Asung C18 2PF CHIP CAPACITOR 0402 NPO ±0.25PF 1 Murata Asung C39 2PF CHIP CAPACITOR 0402 NPO ±0.25PF 1 Murata Asung C57 2PF CHIP CAPACITOR 0402 NPO ±0.25PF 1 Murata Asung C150 2PF CHIP CAPACITOR 0402 NPO ±0.25PF 1 Murata Asung C61 3.5PF CHIP CAPACITOR 0402 NPO ±0.25PF 1 Murata Asung C42 3PF CHIP CAPACITOR 0402 NPO ±0.25PF 1 Murata Asung C187C 3PF CHIP CAPACITOR 0402 NPO ±0.25PF 1 Murata Asung C187A 2PF (For "A" Grade 20.95MHz X-tal) CHIP CAPACITOR 0402 NPO ±0.25PF 1 Murata Asung C187B 3PF (For "A" or "B" Grade 20.95MHz X-tal) CHIP CAPACITOR 0402 NPO ±0.25PF 1 Murata Asung C62 4PF CHIP CAPACITOR 0402 NPO ±0.25PF 1 Murata Asung C46 5PF CHIP CAPACITOR 0402 NPO ±0.25PF 1 Murata Asung C180 6PF CHIP CAPACITOR 0402 NPO ±0.25PF 1 Murata Asung C49 7PF CHIP CAPACITOR 0402 NPO ±0.25PF 1 Murata Asung C79 7PF CHIP CAPACITOR 0402 NPO ±0.25PF 1 Murata Asung C92 7PF CHIP CAPACITOR 0402 NPO ±0.25PF 1 Murata Asung C51 8PF CHIP CAPACITOR 0402 NPO ±0.25PF 1 Murata Asung C45 9PF CHIP CAPACITOR 0402 NPO ±0.25PF 1 Murata Asung C77 9PF CHIP CAPACITOR 0402 NPO ±0.25PF 1 Murata Asung C7 100PF CHIP CAPACITOR 0402 NPO ±5% 1 Murata Asung C9 100PF CHIP CAPACITOR 0402 NPO ±5% 1 Murata Asung C20 100PF CHIP CAPACITOR 0402 NPO ±5% 1 Murata Asung C23 100PF CHIP CAPACITOR 0402 NPO ±5% 1 Murata Asung C26 100PF CHIP CAPACITOR 0402 NPO ±5% 1 Murata Asung C27 100PF CHIP CAPACITOR 0402 NPO ±5% 1 Murata Asung C28 100PF CHIP CAPACITOR 0402 NPO ±5% 1 Murata Asung C30 100PF CHIP CAPACITOR 0402 NPO ±5% 1 Murata Asung C31 100PF CHIP CAPACITOR 0402 NPO ±5% 1 Murata Asung C32 100PF CHIP CAPACITOR 0402 NPO ±5% 1 Murata Asung C35 100PF CHIP CAPACITOR 0402 NPO ±5% 1 Murata Asung C43 100PF CHIP CAPACITOR 0402 NPO ±5% 1 Murata Asung C47 100PF CHIP CAPACITOR 0402 NPO ±5% 1 Murata Asung C53 100PF CHIP CAPACITOR 0402 NPO ±5% 1 Murata Asung C54 100PF CHIP CAPACITOR 0402 NPO ±5% 1 Murata Asung C58 100PF CHIP CAPACITOR 0402 NPO ±5% 1 Murata Asung C63 100PF CHIP CAPACITOR 0402 NPO ±5% 1 Murata Asung C66 100PF CHIP CAPACITOR 0402 NPO ±5% 1 Murata Asung C69 100PF CHIP CAPACITOR 0402 NPO ±5% 1 Murata Asung C94 100PF CHIP CAPACITOR 0402 NPO ±5% 1 Murata Asung C98 100PF CHIP CAPACITOR 0402 NPO ±5% 1 Murata Asung C101 100PF CHIP CAPACITOR 0402 NPO ±5% 1 Murata Asung C121 100PF CHIP CAPACITOR 0402 NPO ±5% 1 Murata Asung C123 100PF CHIP CAPACITOR 0402 NPO ±5% 1 Murata Asung C147 100PF CHIP CAPACITOR 0402 NPO ±5% 1 Murata Asung C148 100PF CHIP CAPACITOR 0402 NPO ±5% 1 Murata Asung C163 100PF CHIP CAPACITOR 0402 NPO ±5% 1 Murata Asung Ref.No Items Manufacturer 1st Vendor Description Q'ty Global Link Corporation Confidential Proprietary page1/ 11 GLOBALLINK CORPORATION LTD. GXT850Series - Bill of Material (Ver.AAA) GXT850 Dwg.No : GXT850-BOM-P-01 Rev.Date : 27 Dec, 2006 Ref.No Items Manufacturer 1st Vendor Description Q'ty C164 100PF CHIP CAPACITOR 0402 NPO ±5% 1 Murata Asung C170 100PF CHIP CAPACITOR 0402 NPO ±5% 1 Murata Asung C173 100PF CHIP CAPACITOR 0402 NPO ±5% 1 Murata Asung C174 100PF CHIP CAPACITOR 0402 NPO ±5% 1 Murata Asung C175 100PF CHIP CAPACITOR 0402 NPO ±5% 1 Murata Asung C176 100PF CHIP CAPACITOR 0402 NPO ±5% 1 Murata Asung C178 100PF CHIP CAPACITOR 0402 NPO ±5% 1 Murata Asung C179 100PF CHIP CAPACITOR 0402 NPO ±5% 1 Murata Asung C182 100PF CHIP CAPACITOR 0402 NPO ±5% 1 Murata Asung C184 100PF CHIP CAPACITOR 0402 NPO ±5% 1 Murata Asung C185 100PF CHIP CAPACITOR 0402 NPO ±5% 1 Murata Asung C186 100PF CHIP CAPACITOR 0402 NPO ±5% 1 Murata Asung C188 100PF CHIP CAPACITOR 0402 NPO ±5% 1 Murata Asung C189 100PF CHIP CAPACITOR 0402 NPO ±5% 1 Murata Asung C190 100PF CHIP CAPACITOR 0402 NPO ±5% 1 Murata Asung C191 100PF CHIP CAPACITOR 0402 NPO ±5% 1 Murata Asung C192 100PF CHIP CAPACITOR 0402 NPO ±5% 1 Murata Asung C193 100PF CHIP CAPACITOR 0402 NPO ±5% 1 Murata Asung C194 100PF CHIP CAPACITOR 0402 NPO ±5% 1 Murata Asung C196 100PF CHIP CAPACITOR 0402 NPO ±5% 1 Murata Asung C314 100PF CHIP CAPACITOR 0402 NPO ±5% 1 Murata Asung C52 10PF CHIP CAPACITOR 0402 NPO ±5% 1 Murata Asung C60 10PF CHIP CAPACITOR 0402 NPO ±5% 1 Murata Asung C93 10PF CHIP CAPACITOR 0402 NPO ±5% 1 Murata Asung C41 12PF CHIP CAPACITOR 0402 NPO ±5% 1 Murata Asung C68 150PF CHIP CAPACITOR 0402 NPO ±5% 1 Murata Asung C187 150PF CHIP CAPACITOR 0402 NPO ±5% 1 Murata Asung C55 15PF CHIP CAPACITOR 0402 NPO ±5% 1 Murata Asung C64 15PF CHIP CAPACITOR 0402 NPO ±5% 1 Murata Asung C59 18PF CHIP CAPACITOR 0402 NPO ±5% 1 Murata Asung C80 18PF CHIP CAPACITOR 0402 NPO ±5% 1 Murata Asung C13 22PF CHIP CAPACITOR 0402 NPO ±5% 1 Murata Asung C15 22PF CHIP CAPACITOR 0402 NPO ±5% 1 Murata Asung C21 22PF CHIP CAPACITOR 0402 NPO ±5% 1 Murata Asung C76 22PF CHIP CAPACITOR 0402 NPO ±5% 1 Murata Asung C140 22PF CHIP CAPACITOR 0402 NPO ±5% 1 Murata Asung C6 27PF CHIP CAPACITOR 0402 NPO ±5% 1 Murata Asung C12 33PF CHIP CAPACITOR 0402 NPO ±5% 1 Murata Asung C75 33PF CHIP CAPACITOR 0402 NPO ±5% 1 Murata Asung C128 33PF CHIP CAPACITOR 0402 NPO ±5% 1 Murata Asung C158 33PF CHIP CAPACITOR 0402 NPO ±5% 1 Murata Asung C159 33PF CHIP CAPACITOR 0402 NPO ±5% 1 Murata Asung C171 33PF CHIP CAPACITOR 0402 NPO ±5% 1 Murata Asung C11 39PF CHIP CAPACITOR 0402 NPO ±5% 1 Murata Asung C56 39PF CHIP CAPACITOR 0402 NPO ±5% 1 Murata Asung C50 56PF CHIP CAPACITOR 0402 NPO ±5% 1 Murata Asung C115 0.22UF CHIP CAPACITOR 0402 X5R ±10% 1 Murata Asung C149 0.22UF CHIP CAPACITOR 0402 X5R ±10% 1 Murata Asung C141 0.0012UF CHIP CAPACITOR 0402 X7R ±10% 1 Murata Asung C119 0.0015UF CHIP CAPACITOR 0402 X7R ±10% 1 Murata Asung C14 0.001UF CHIP CAPACITOR 0402 X7R ±10% 1 Murata Asung C17 0.001UF CHIP C…

Text truncated - open the document above for the full version.

Model No:GXT800/850 Drawing No: GXT8XX-TAP-M-00 Customer: Midland Title: GXT800/850 Test & Alignment Procedure Rev. Date: Nov. 14, 2006 Created by: Approved by: Rev. No: 00 For Stage : EPP Release Date : Nov. 14, 2006 Page 0 of 9 These drawings and specifications are the property of Global Link Corporation Ltd. and shall not be reproduced or copied, or used as reference for design, manufacture, and sale of device without permission. GXT800/850 Test and Alignment Procedure Model No:GXT800/850 Drawing No: GXT8XX-TAP-M-00 Customer: Midland Title: GXT800/850 Test & Alignment Procedure Rev. Date: Nov. 14, 2006 Created by: Approved by: Rev. No: 00 For Stage : EPP Release Date : Nov. 14, 2006 Page 0 of 9 These drawings and specifications are the property of Global Link Corporation Ltd. and shall not be reproduced or copied, or used as reference for design, manufacture, and sale of device without permission. REVISION SHEET Rev. Code Rev. Date Revision Revised By: M-00 Model No:GXT800/850 Drawing No: GXT8XX-TAP-M-00 Customer: Midland Title: GXT800/850 Test & Alignment Procedure Rev. Date: Nov. 14, 2006 Created by: Approved by: Rev. No: 00 For Stage : EPP Release Date : Nov. 14, 2006 Page 0 of 9 These drawings and specifications are the property of Global Link Corporation Ltd. and shall not be reproduced or copied, or used as reference for design, manufacture, and sale of device without permission. TABLE OF CONTENT 1. RECOMMENDED EQUIPMENT ....................................................................................... 4 2. TEST PREPARATION ................................................................................................... 4 3. VOLTAGE REGULATOR TEST ....................................................................................... 4 4. VCO ADJUSTMENT ......................................................................................................... 5 5. TRANSMITTER FREQUENCY ALIGNMENT ................................................................. 5 6. TRANSMITTER OUTPUT POWER CHECK ................................................................... 5 7. TRANSMITTER DEVIATION ADJUSTMENT ............................................................... 5 8. RECEIVER ALIGNMENT ................................................................................................. 6 9. SQUELCH THRESHOLD AND HYSTERISIS ............................................................... 6 10. VOX TEST ...................................................................................................................... 6 11. LOW BATTERY LEVEL TEST ................................................................................... 7 12. JACK CHARGING TEST .............................................................................................. 7 13. DESKTOP CHARGING TEST ...................................................................................... 7 14. FREQUENCIES & CODE TABLE ............................................................................... 7 14.1 FRS & GMRS .................................................................................................... 7 14.2 WX BAND .......................................................................................................... 8 14.3 CTCSS CODE ....................................................................................................... 8 14.4 DCS CODE .......................................................................................................... 9 Model No:GXT800/850 Drawing No: GXT8XX-TAP-M-00 Customer: Midland Title: GXT800/850 Test & Alignment Procedure Rev. Date: Nov. 14, 2006 Created by: Approved by: Rev. No: 00 For Stage : EPP Release Date : Nov. 14, 2006 Page 0 of 9 These drawings and specifications are the property of Global Link Corporation Ltd. and shall not be reproduced or copied, or used as reference for design, manufacture, and sale of device without permission. 1. RECOMMENDED TEST EQUIPMENT 1.1 HP8920A,B Radio Communication Tester or equivalent with Spectrum Analyzer option. 1.2 Fluke 187 Digital Voltmeter or equivalent 1.3 HPE3615A Power Supply or equivalent 2. TEST PREPARATION 2.1 Connect a 6.0Vdc power supply to the positive battery terminal input point and the negative battery terminal input point (GND) into the negative terminal. 2.3 Connect the HP8920A,B RF Output port to the ANT point. 2.4 SPK (+) should be connected to the Audio In Hi and SPK (-) should be connected to the Audio In Lo of the HP8920B. 2.5 Set the unit at CH1 (462.5625MHz) 3. VOLTAGE REGULATOR TEST 3.1 MCU Regulator - Connect a voltmeter to TP9 (MCU REG) and measure the voltage. The value must be between TBD. 3.2 RX Regulator - Connect a voltmeter to TP10 (RX REG) and measure the voltage. The value must be between TBD. 3.3 TX Regulator - Connect a voltmeter to TP11 (TX REG) and measure the voltage. The value must be between TBD. 3.4 VCO Regulator - Connect a voltmeter to TP12 (VCO REG) and measure the voltage. The value must be between TBD. 3.5 IC Regulator - Connect a voltmeter to TP13 (IC REG) and measure the voltage. The value must be between TBD. 4. VCO ADJUSTMENT 4.1 Set the unit at CH1 and connect a digital voltmeter to VCO TP (R62 & C96 connect point). 4.2 Press and hold the PTT Button so the unit is in transmit mode. 4.3 Adjust L23 until the voltmeter reads 1.2 to 1.3Vdc (without VCO Plate). L23 is located under the shieldcan. Solder VCO Plate and let temperature stabilize. Recheck TX VCO at CH1, should be 1.0~1.3 Vdc 4.4 Release the PTT button so the unit will be in receive mode. 4.5 Observe the voltage at VCO TP, the voltage should be 0.6~2.5Vdc. 4.6 Set the unit at CH14. 4.7 Press and hold the PTT button so the unit is in transmit mode. 4.8 Observe the voltage at VCO TP, the voltage should be 1.0~2.5Vdc. Model No:GXT800/850 Drawing No: GXT8XX-TAP-M-00 Customer: Midland Title: GXT800/850 Test & Alignment Procedure Rev. Date: Nov. 14, 2006 Created by: Approved by: Rev. No: 00 For Sta…

Text truncated - open the document above for the full version.

Report No.: HCT-SAR07-0107 FCC ID: MMAGXT850 DATE: January 24, 2007 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr APPENDIX A – SAR TEST PLOTS Report No.: HCT-SAR07-0107 FCC ID: MMAGXT850 DATE: January 24, 2007 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr Report No.: HCT-SAR07-0107 FCC ID: MMAGXT850 DATE: January 24, 2007 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr Report No.: HCT-SAR07-0107 FCC ID: MMAGXT850 DATE: January 24, 2007 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr Report No.: HCT-SAR07-0107 FCC ID: MMAGXT850 DATE: January 24, 2007 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr Report No.: HCT-SAR07-0107 FCC ID: MMAGXT850 DATE: January 24, 2007 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr Report No.: HCT-SAR07-0107 FCC ID: MMAGXT850 DATE: January 24, 2007 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr Report No.: HCT-SAR07-0107 FCC ID: MMAGXT850 DATE: January 24, 2007 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr Report No.: HCT-SAR07-0107 FCC ID: MMAGXT850 DATE: January 24, 2007 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr Report No.: HCT-SAR07-0107 FCC ID: MMAGXT850 DATE: January 24, 2007 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr Report No.: HCT-SAR07-0107 FCC ID: MMAGXT850 DATE: January 24, 2007 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr Report No.: HCT-SAR07-0107 FCC ID: MMAGXT850 DATE: January 24, 2007 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr Report No.: HCT-SAR07-0107 FCC ID: MMAGXT850 DATE: January 24, 2007 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr Report No.: HCT-SAR07-0107 FCC ID: MMAGXT850 DATE: January 24, 2007 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr Report No.: HCT-SAR07-0107 FCC ID: MMAGXT850 DATE: January 24, 2007 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr Report No.: HCT-SAR07-0107 FCC ID: MMAGXT850 DATE: January 24, 2007 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr Report No.: HCT-SAR07-0107 FCC ID: MMAGXT850 DATE: January 24, 2007 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr

Report No.: HCT-SAR07-0107 FCC ID: MMAGXT850 DATE: January 24, 2007 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr APPENDIX B – EUT TEST SETUP PHOTOGRAPHS Report No.: HCT-SAR07-0107 FCC ID: MMAGXT850 DATE: January 24, 2007 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr Report No.: HCT-SAR07-0107 FCC ID: MMAGXT850 DATE: January 24, 2007 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr 15mm 25mm Report No.: HCT-SAR07-0107 FCC ID: MMAGXT850 DATE: January 24, 2007 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr Report No.: HCT-SAR07-0107 FCC ID: MMAGXT850 DATE: January 24, 2007 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr

Report No.: HCT-SAR07-0107 FCC ID: MMAGXT850 DATE: January 24, 2007 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr APPENDIX C – EUT PROFILE PHOTOGRAPHS Report No.: HCT-SAR07-0107 FCC ID: MMAGXT850 DATE: January 24, 2007 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr Report No.: HCT-SAR07-0107 FCC ID: MMAGXT850 DATE: January 24, 2007 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr Report No.: HCT-SAR07-0107 FCC ID: MMAGXT850 DATE: January 24, 2007 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr

Report No.: HCT-SAR07-0107 FCC ID: MMAGXT850 DATE: January 24, 2007 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr APPENDIX D – DIPOLE VALIDATION PLOTS Report No.: HCT-SAR07-0107 FCC ID: MMAGXT850 DATE: January 24, 2007 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr Report No.: HCT-SAR07-0107 FCC ID: MMAGXT850 DATE: January 24, 2007 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr Report No.: HCT-SAR07-0107 FCC ID: MMAGXT850 DATE: January 24, 2007 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr

Report No.: HCT-SAR07-0107 FCC ID: MMAGXT850 DATE: January 24, 2007 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr APPENDIX E – PROBE CALIBRATION DATA Report No.: HCT-SAR07-0107 FCC ID: MMAGXT850 DATE: January 24, 2007 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr Report No.: HCT-SAR07-0107 FCC ID: MMAGXT850 DATE: January 24, 2007 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr Report No.: HCT-SAR07-0107 FCC ID: MMAGXT850 DATE: January 24, 2007 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr Report No.: HCT-SAR07-0107 FCC ID: MMAGXT850 DATE: January 24, 2007 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr Report No.: HCT-SAR07-0107 FCC ID: MMAGXT850 DATE: January 24, 2007 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr Report No.: HCT-SAR07-0107 FCC ID: MMAGXT850 DATE: January 24, 2007 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr Report No.: HCT-SAR07-0107 FCC ID: MMAGXT850 DATE: January 24, 2007 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr Report No.: HCT-SAR07-0107 FCC ID: MMAGXT850 DATE: January 24, 2007 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr Report No.: HCT-SAR07-0107 FCC ID: MMAGXT850 DATE: January 24, 2007 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr

Report No.: HCT-SAR07-0107 FCC ID: MMAGXT850 DATE: January 24, 2007 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr APPENDIX F – DIPOLE CALIBRATION DATA Report No.: HCT-SAR07-0107 FCC ID: MMAGXT850 DATE: January 24, 2007 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL…
