MMAGXT860FRS/GMRS

Midland Radio Corporation

Click to zoom

Application Details

Equipment Class: FRF - Part 95 Family Radio Face Held Transmitter
Date of Grant: May 08, 2012
Application Purpose: Original Equipment
Date of Application: May 08, 2012
Equipment Note: FRS/GMRS
Frequency Range: 467.56250000 - 467.71250000
Company: Midland Radio Corporation
Country: United States

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Model GXT860/895 Series Page 2 www.midlandradio.com Welcome to the world of Midland electronics Congratulations on your purchase of a high quality MIDLAND product. Your 2-way radio represents the state-of-the-art in high-tech engineering. Designed for GMRS (General Mobile Radio Service) operation, this compact package is big in performance. It is a quality piece of electronic equipment, skillfully constructed with the finest components. The circuitry is all solid-state and mounted on a rugged printed circuit board. Your two-way radio is designed for reliable and trouble-free performance for years to come. Features - 42 GMRS/FRS Channel - 142 Privacy Codes (38 CTCSS / 104 DCS) - VOX - 10 Selectable Call Alert (5 additional Animal Sounds on GXT895) - NOAA Weather Radio - NOAA Weather Scan - NOAA Weather Alert - VIBRATE ALERT - Scan Function - MONITOR Function - Roger Beep Tone - Silent Operation - Keypad Lock - Power HI/MED/LO Settings - Speaker / Microphone Jacks - Battery Meter / Battery Low Indicator This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions : (1) this device does not cause harmful interference, and (2) this radio must accept any interference that may cause undesired operation. To maintain compliance with FCC’s RF exposure guidelines, for body-worn operation, this radio has been tested and meets the FCC RF exposure guidelines when used with Midland Radio Corp. accessories supplied or designated for this product. Use of other accessories may not ensure compliance with FCC RF exposure guidelines. (Tested with Headset Model: AVP-1) IMPORTANT NOTICE, FCC LICENSE REQUIRED FOR GMRS OPERATION (Only Applicable for GMRS Radio Use in the United States) The GXT860/895 Series operates on GMRS (General Mobile Radio Service) frequencies which require an FCC (Federal Communications Commission) license. You must be licensed prior to operating on channels 1 - 7 or 15 - 22, which comprise the GMRS channels of the GXT860/895 Series. Serious penalties could result for unlicensed use of GMRS channels, in violation of FCC rules, as stipulated in the Communications Acts Sections 501 and 502 (amended). You will be issued a call sign by the FCC which should be used for station identification when operating the radio on GMRS channels. You should also cooperate by engaging in permissible transmissions only, avoiding channel interference with other GMRS users, and being prudent with the length of their transmission time. To obtain a license or ask questions about the license application, contact the FCC at 1-888-CALL FCC or go to the FCC's website: http://www .fcc.govand request form 605. Exposure To Radio Frequency Energy Your Midland radio is designed to comply with the following national and international standards and guidelines regarding exposure of human being to radio frequency electromagnetic energy: - United States Federal Communications Commission, Code of Federal Regulations: 47 CFR part 2 sub-part J - American National Standards Institute (ANSI)/Institute of Electrical & Electronic Engineers (IEEE) C95. 1-1992 - Institute of Electrical and Electronic Engineers (IEEE) C95. 1-1999 Edition - National Council on Radiation Protection and Measurements (NCRP) of the United States, Report 86, 1986 - International Commission on Non-lonizing Radiation Protection (ICNIRP) 1998 To control your exposure and ensure compliance with the general population or uncontrolled environment exposure limits, transmit no more than 50% of the time. The radio generates measurable RF energy exposure only when transmitting. IMPORTANT:Changes or modifications to this unit not expressly approved by MIDLAND RADIO CORP. could void your right to operate this unit. Your radio is set up to transmit a regulated signal on an assigned frequency. It is against the law to alter or adjust the settings inside the COMMUNICATOR to exceed those limitations. Any adjustment to your radio must be made by qualified technicians. Model GXT860/895 Series Page 3 www.midlandradio.com LCD DISPLAY CONTROLS 1. KEY LOCK ICON – Indicates KEY LOCK mode is on. 2. VOX ICON– Indicates when VOX mode is active. 3. NOAA WEATHER (WX) BAND ICON– Indicates when the radio is in Weather Band mode. 4. CHANNEL NUMBER– Changes from 1~42 on GMRS/FRS band (1~10 on WX band). 5. PRIVACY CODE– Indicates Privacy Code selected by user (oF~38/oF~ 104). It can only be used on Ch 1~22. 6. BATTERY METER– Indicates the battery level. 7. VIBRATE ALERT ICON– Indicates when the Vibrate Alert feature is on. 8. RECEIVE (RX) ICON– Indicates radio is receiving a transmission. 9. TRANSMIT (TX) ICON– Indicates radio is transmitting a signal. 10. TRANSMIT POWER LEVEL ICON– Indicates TX Power setting (H/M/L). 11. PRIVACY CODE ICON– Indicates Privacy Code setting (CTCSS/DCS). 12. POWER/VOLUME KNOB– Turn clock- wise to turn the power on and increase the volume level. Turn counter-clockwise to decrease the volume level and turn the power off. 13. PTT Button– Press and hold to transmit voice communication. 14. CALL/LOCK Button– Press to send a CALL Alert signal. Press and hold to turn KEY LOCK on/off. 15. MIC– Built-in microphone. 16. SPEAKER– Built-in speaker. 17. ANTENNA 18. EXTERNAL SPEAKER/MIC JACK. 19. MENU/WX SCAN Button– Press to access Menu mode. Press and hold for 5 seconds to activate the NOAA Weather Scan function. 20. MONITOR/SCAN Button– Press to enter SCAN mode. Press and hold to enter MONITOR mode. 21. UPand DOWN Button– Make adjustments in MENU mode. 1 12 13 14 15 16 21 20 19 18 17 Model GXT860/895 Series Page 4 www.midlandradio.com 11 10 9 8 7 6 5 4 3 2 BA TTERY INSTALLATION Your GXT860/895 Series radio operates with either a NiMH battery pack or an optional 4 AA alkaline batteries. The belt clip should be removed (see below) to ease installation or removal of the batteries. To install the batteries: 1. With the back of the radio facing you, remove the belt clip (see diagram below) for easy access, then remove the Battery Co…

Text truncated - open the document above for the full version.

Cover Letter(s)

Date: 2012.02.01 Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 To whom it may concern: I, the undersigned, hereby authorize KT Kang of KES Co., Ltd. and hereafter referred to as KES Co., Ltd., to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by KT Kang of KES Co., Ltd. on our behalf shall have the same effect as acts of our own. I, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). In authorizing KES Co., Ltd. as our agent, we still recognize that we are responsible to: a) comply with the relevant provisions of the certification program; b) make all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c) make claims regarding certification only in respect of the scope for which certification has been granted; d) do not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our product certification which the Certification Division may consider misleading or unauthorized; e) upon suspension or cancellation of certification, discontinue use of all advertising matter that contains any reference thereto and return any certification documents as required by the Certification Division; f) use certification only to indicate the products are certified as being in conformity with specified standards; g) endeavor to ensure that no certificate or report nor any part thereof is used in a misleading manner; h) ensure that any reference to our product certification in communication media such as documents, brochures or advertising, complies with the requirements of the Certification Division; i) keep a record of all complaints made known to the us relating to the product’s compliance with requirements of the relevant standard and to make these records available to the Certification Division when requested; j) take appropriate action with respect to such complaints and any deficiencies found in products or services that affect compliance with the requirements for certification; k) document the actions taken. This authorization is valid until further written notice from the applicant. Sincerely Yours, David Kingsolver / Engineering Manager Midland Radio Corporation REMARK: 1. This authorization letter will be sent along with your application when filing with the Certification Division. 2. Please follow the format and type it on company letterhead and send original to us. 3. Authorized signature must be in agreement with grantee code contact in FCC database.

Cover Letter(s)

Date: April 26, 2012 Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID: MMAGXT860 Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Exhibit Type File Name Part List CONF APPENDIX_GXT860_Part List.PDF Schematics Diagram(s) CONF APPENDIX_ GXT860_Schemetics.PDF Block diagram CONF APPENDIX_ GXT860_Block diagram.PDF Operation description CONF APPENDIX_GXT860_Operation description.PDF The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, David Kingsolver / Engineering Manager Midland Radio Corporation

External Photos

www.kes.co.kr Model No.: GXT860 Page 1 of 4 EUT External photographs www.kes.co.kr Model No.: GXT860 Page 2 of 4 www.kes.co.kr Model No.: GXT860 Page 3 of 4 www.kes.co.kr Model No.: GXT860 Page 4 of 4 N/A

Internal Photos

www.kes.co.kr Model No.: GXT860 Page 1 of 1 EUT Internal photographs

Parts List/Tune Up Info

LABORATORY TESTING PROCEDURES GXT860/895 Page 1 UNIT TEST - (UNIT ASSEMBLED) TEST PREPARATION 1) Install Alkaline battery (observe polarity markings). 2) Turn on unit by pressing the power button. SYSTEM TEST 1) Radiated Transmit and Receive performance may be observed. 2) Audio out & Audio in are available at the Headset jack. LABORATORY TEST - (UNIT UN-ASSEMBLED) TEST PREPARATION 1) Disassemble unit (5 screws – 2 behind batteries). Remove the PCB from the cabinet. 2) Remove the antenna with soldering iron and install a 50 ohm coax cable in its place. 3) Either clip alligator leads or solder test leads to the power supply connections. The negative terminal is the lower right PCB area. The positive terminal is the lower left PCB area. 4) Connect 6VDC power source to the terminals, observing correct polarity. 5) Connect an 12-ohm load through the Headset jack 6) Connect a audio generator with 10uF coupling capacitor through the Headset jack 7) Select desired channel 1-42 using CH up/down keypad switch. The rubber keypad may be removed from the front cabinet and used directly on the PCB. LABORATORY TESTING PROCEDURES GXT860/895 Page 2 SPECIFIC TEST METHODS AND GUIDANCE Modulation Characteristics – (paragraph 2.1047(a) of the Rules) FOR TX AUDIO FILTER RESPONSE 1. Connect audio generator with 10uF coupling capacitor to microphone input jack. Press PTT button. 2. Connect RF output with modulation meter. (Filters of modulation meter should be set to a 25Hz to 15KHz.) 3. Adjust audio generator 6-7mVrms of 1KHz audio (approx. 0.75KHz modulation). 4. While transmitting, sweep generator and note measurement. 5. Results should be multiplied by a two times because of compressor. 6. Please compensate the back-ground noise level. Modulation Characteristics – (paragraph 2.1047(b) of the Rules FOR TX AUDIO LOW PASS FILTER RESPONSE. 1. Connect audio generator with 10uF coupling capacitor to microphone input jack. Press PTT button. 2. Connect AC voltmeter or other test equipment via jumper wire with junction (TP9) of C53, R82. 3. Adjust audio generator for 200mV. 4. While transmitting, sweep generator and note measurement. Occupied Bandwidth – (paragraph 2.1049(c) of the Rules) 1. Connect an audio frequency sweep generator with 10uF coupling capacitor to microphone input jack. 2. Adjust audio generator to a frequency of 2500Hz and a level of 51mV rms (+16dB above 8mV per FCC). 3. With a spectrum analyzer, transmit the radio and monitor the transmitter though an antenna. 4. Note required measurements per FCC.

RF Exposure Info

Report File No. : F690501/RF-SAR001998 Date of Issue :2012-04-25 Page :1 / 65 SAR TEST REPORT Equipment Under Test:FM Handheld Transceiver Model No.:GXT860 Applicant:Midland Radio Corporation Address of Applicant: 5900 Parretta Drive Kansas City Missouri United States 6420 FCC IDMMAGXT860 IC ID3690A-GXT860 Device Category:Portable Device Exposure Category:General Population /Uncontrolled Exposure Date of Receipt:2012-01-18 Date of Test(s):2012-04-09, 2012-04-10 Date of Issue:2012-04-25 Max. SAR:0.615 W/kg (Head 50 % Duty Cycle) 1.375 W/kg (Body 50 % Duty Cycle) Standards:FCC OET Bulletin 65 supplement C RSS-102 (Issue 4) IEEE 1528, 2003 ANSI/IEEE C95.1, C95.3 In the configuration tested, the EUT complied with the standards specified above. Remarks: Tested by:Fred Jeong2012-04-25 Approved by:Charles Kim2012-04-25 This report details the results of the testing carried out on one sample, the results contained in this test report do not relate to other samples of the same product. The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in this report. This report may only be reproduced and distributed in full. If the product in this report is used in any configuration other than that detailed in the report, the manufacturer must ensure the new system complies with all relevant standards. Any mention of SGS Testing Korea Co., Ltd. or testing done by SGS Testing Korea Co., Ltd. in connection with distribution or use of the product described in this report must be approved by SGS Testing Korea Co., Ltd. in writing. Report File No. : F690501/RF-SAR001998 Date of Issue :2012-04-25 Page :2 / 65 Contents 1. General Information 1.1 Testing Laboratory........................................................................................... 3 1.2 Details of Applicant.......................................................................................... 3 1.3 Version of Report............................................................................................. 3 1.4 Description of EUT(s)....................................................................................... 3 1.5 Test Environment............................................................................................. 4 1.6 Operation description........................................................................................ 4 1.7 Evaluation procedures....................................................................................... 5 1.8 The SAR Measurement System............................................................................ 6 1.9 System Components.......................................................................................... 8 1.10 SAR System Verification.................................................................................... 9 1.11 Tissue Simulant Fluid for the Frequency Band.......................................................... 11 1.12 Tissue Parameters Check Results....................................................................... 12 1.13 Test Standards and Limits................................................................................. 12 2. Instruments List.................................................................................... 14 3. Summary of Results................................................................................ 16 APPENDIX A. DASY4 SAR Report B. Uncertainty Analysis C. Calibration certificate Report File No. : F690501/RF-SAR001998 Date of Issue :2012-04-25 Page :3 / 65 1. General Information 1.1Testing Laboratory SGS Korea Co., Ltd. Wireless Div. 2FL, 18-34, Sanbon-dong, Gunpo-si, Gyeonggi-do, Korea 435-040 Telephone: +82 +31 428 5700 FAX: +82 +31 427 2371 Homepage:www.ee.sgs.com/Korea 1.2 Details of Applicant Manufacturer: Midland Radio Corporation Address: 5900 Parretta Drive Kansas City Missouri United States 64120 Contact Person: David Kingsolver Phone No.: 816-241-8500 Fax No.: 816-241-8500 E-mail: [email protected] 1.3 Version of Report Version NumberDateRevision 002012-04-25Initial issue 1.4 Description of EUT(s) EUT Type : FM Handheld Transceiver Model : GXT860 Serial Number : N/A Mode of Operation : GMRS, FRS Body worn Accessory : Belt Clip Tx Frequency Range : GMRS (462.5500㎒~ 462.7250㎒) FRS (467.5625㎒~ 467.7125㎒) Antenna : Fixed Type E.R.P. : GMRS:0.592W(High power) GMRS:0.583W(Middle power) GMRS:0.065 W(Low power) FRS:0.006 4 W Battery Type : Rechargeable Ni-MH battery pack (6.0 V) Report File No. : F690501/RF-SAR001998 Date of Issue :2012-04-25 Page :4 / 65 1.5 Test Environment Ambient temperature : (22±2) ° C Tissue Simulating Liquid : (22±2) ° C Relative Humidity : (55± 5)% R.H. 1.6 Operation Configuration Reference Positions for Handheld Radio Transmitters In general handheld radio transmitters like GMRS/FRS/LMR devices are used in held to face position or with a speaker/microphone combination as body-worn configuration. Held to face position For held to face position the flat section of a SAM Phantom or a flat phantom is used. The center of the radiating structure is to set on the middle position of the flat phantom. The distance between sample and flat phantom is 2.5 cm. For the measurement head tissue simulating liquid is used. Belt Clip/Holster Configuration Test configurations for body-worn operated EUTs are carried out while the belt-clip and/or holster is attached to the EUT and placed against a flat phantom in a regular configuration. An EUT with a headset output it tested with a headset connected to the device. Body dielectric parameters are used. There are two categories for accessories for body-worn operation configurations: 1.accessories not containing metallic components 2.accessories containing metallic components. When the EUT is equipped with accessories not containing metallic components the tests are done with the accessory that dictates the closest spacing to the body. For accessories containing metallic parts a tes…

Text truncated - open the document above for the full version.

Test Report

KES Co., Ltd. C-3701 Dongil Techno Town, 889-1, Gwanyang 2-dong, Dongan-gu, Anyang-si, Gyeonggi-do, 431-716, Korea Tel: +82-31-425-6200 / Fax: +82-31-424-0450 www.kes.co.kr Test report No.: KES-RF-120036 Page: (1) of (35) This report shall not be reproduced except in full, without the written approval of KES Co., Ltd. The test results in the report only apply to the tested sample. KES-P-5101-09 Rev.1 KES A4 TEST REPORT Part 95(A/B) & IC RSS-210(Issue 8) Equipment Under Test FRS / GMRS Model Name GXT860(Variant model: GXT895) FCC ID MMAGXT860 IC Certification 3690A- GXT860 Applicant Midland Radio Corporation Manufacturer Global Link Date of test(s) 2012.04.09 ~ 2012.04.25, 2012.05.02 Date of issue 2012.05.03 Issued to Midland Radio Corporation 5900 Parretta Drive Kansas City Missouri United States 64120 Issued by KES Co., Ltd. C3701 Dongil Techno Town, 889-1, Gwanyang 2-dong, Dongan-gu, Anyang-si, Gyeonggi-do, 431-716, Korea 477-6, Hageo-ri, Yeoju-eup, Yeoju-gun, Gyeonggi-do, 469-803, Korea Tel: +82-31-425-6200 / Fax: +82-31-424-0450 Test and report completed by : Report approval by : Jeff Do Test engineer Gyu-cheol Shin Technical manager KES Co., Ltd. C-3701 Dongil Techno Town, 889-1, Gwanyang 2-dong, Dongan-gu, Anyang-si, Gyeonggi-do, 431-716, Korea Tel: +82-31-425-6200 / Fax: +82-31-424-0450 www.kes.co.kr Test report No.: KES-RF-120036 Page: (2) of (35) This report shall not be reproduced except in full, without the written approval of KES Co., Ltd. The test results in the report only apply to the tested sample. KES-P-5101-09 Rev.1 KES A4 Revision history Revision Date of issue Test report No. Description - 2012.04.26 KES-RF-120032 Initial 1 2012.05.03 KES-RF-120036 <Addition> 1. DC input into the final amplifier in the test report on page 6 of 35. 2. The FRS frequency stability measurement in the report on page 33 of 35. <Retest> 1. Retest the battery end point of frequency stability in the report on page 33 of 35. KES Co., Ltd. C-3701 Dongil Techno Town, 889-1, Gwanyang 2-dong, Dongan-gu, Anyang-si, Gyeonggi-do, 431-716, Korea Tel: +82-31-425-6200 / Fax: +82-31-424-0450 www.kes.co.kr Test report No.: KES-RF-120036 Page: (3) of (35) This report shall not be reproduced except in full, without the written approval of KES Co., Ltd. The test results in the report only apply to the tested sample. KES-P-5101-09 Rev.1 KES A4 TABLE OF CONTENTS 1.0 General product description ............................................................................................................... 4 1.1 Information about variant model ........................................................................................................ 4 1.2 Device modifications ......................................................................................................................... 4 1.3 Test facility ......................................................................................................................................... 4 1.4 Laboratory accreditations and listings................................................................................................ 5 1.5 Conclusion of worst-case for each mode of representative channel respectively .............................. 6 2.0 Summary of tests ................................................................................................................................ 8 2.1 Test data ............................................................................................................................................. 9 2.1.1 RF output power and radiated spurious emission ....................................................................... 9 2.1.2 Modulation limiting .................................................................................................................. 18 2.1.3 Audio frequency response ........................................................................................................ 21 2.1.4 Low-pass filter response ........................................................................................................... 24 2.1.5 Occupied bandwidth and emission mask ................................................................................. 26 2.1.6 Frequency stability ................................................................................................................... 31 Appendix A. Test equipment used for test ....................................................................................................... 34 Appendix B. Test setup photo .......................................................................................................................... 35 KES Co., Ltd. C-3701 Dongil Techno Town, 889-1, Gwanyang 2-dong, Dongan-gu, Anyang-si, Gyeonggi-do, 431-716, Korea Tel: +82-31-425-6200 / Fax: +82-31-424-0450 www.kes.co.kr Test report No.: KES-RF-120036 Page: (4) of (35) This report shall not be reproduced except in full, without the written approval of KES Co., Ltd. The test results in the report only apply to the tested sample. KES-P-5101-09 Rev.1 KES A4 1.0 General product description Equipment under test FRS / GMRS Model name GXT860(Variant model: GXT895) Serial number N/A Frequency Range 462.562 5 ㎒ ~ 462.712 5 ㎒(GMRS Channels 1 ~7) 467.562 5 ㎒ ~ 467.712 5 ㎒(FRS Channels 8 ~ 14) 462.550 0 ㎒ ~ 462.725 0 ㎒(GMRS Channels 15 ~ 22) Emission type 11K0F3E E.R.P. GMRS: 0.592 W(High power), 0.583 W(Middle power), 0.065 W(Low power) // FRS: 0.064 W Number of channel 462.562 5 ㎒ ~ 462.712 5 ㎒(GMRS Channels 1 ~7) 467.562 5 ㎒ ~ 467.712 5 ㎒(FRS Channels 8 ~ 14) 462.550 0 ㎒ ~ 462.725 0 ㎒(GMRS Channels 15 ~ 22) Power source Rechargeable Ni-MH battery pack(DC 6 V) 1.1 Information about variant model Variant model (LXT895) is same as basic model (LXT860) for hardware, software and mechanical. Only variant model is different front panel than basic model. For detailed information, refer to the following; Basic model(GXT860) Variant model(GXT895) Front panel 1.2 Device mod…

Text truncated - open the document above for the full version.

Test Setup Photos

Contact Information

Applicant

Butch Rittmann(Director of Operations)

[email protected]816 241-8500Fax: 816 241-5713

Test Firm

KES Co., LtdInsung Ryu

[email protected]82-31-425-6200Fax: 82-31-424-0450

Technical Specifications

#	Rule Parts	Frequency Range	Power Output	Emission	Tolerance
4	95B	467.5625 MHz - 467.7125 MHz	64.00 mW	11K0F3E	2.5 ppm

Confidentiality

Long Term

Grant Notes

Listed Power is ERP. SAR compliance for body-worn operating configurations is limited to the specific body-worn accessories, such as belt-clips and holsters, tested for this filing. End-users must be informed of the body-worn operating requirements for satisfying RF exposure compliance. This device is authorized to operate in the following radio services: FRS (Part 95B) or GMRS (Part 95A). There must be an informational insert inside the box (product package) or the Users Manual must include information that clearly informs the consumer (buyer/owner) when the radio is transmitting on GMRS frequencies, that operation on GMRS frequencies requires an FCC license and such operation is subject to additional rules specified in 47 C.F.R. Part 95. The reported SAR values are for a maximum duty factor of 50 %. The highest reported SAR values for head and body-worn accessory are 0.62 W/kg and 1.38W/kg, respectively.
