MMALXT218VPFRS Two-way Radio

QUICK START GUIDE 1. Install 3 AAA Batteries 2. To turn the radio on, press and hold the MENU/POWER Button for 3 seconds 3. To select a channel, press and release the MENU button once, then press the UP/CALL or DOWN/LOCK buttons to select 1 of the 22 FRS channels * Press the TALK button to exit the MENU 4. Press and hold the TALK button to talk 1. CHANNEL NUMBER – Changes from 1~22 on FRS band (1~10 on Weather Band). 2. TRANSMIT (TX) ICON – Indicates radio is transmitting a signal. 3. BATTERY METER – Indicates the battery level. 4. NOAA WEATHER (WX) BAND ICON – Indicates when the radio is in Weather Band mode. 5. KEY LOCK ICON – Indicates KEY LOCK mode is on. 6. RECEIVE (RX) ICON – Indicates radio is receiving a transmission. 7. SCAN ICON - Indicates the radio is in scan mode 8. MIC – Built-in microphone. 9. MENU/Power Button – Press to enter the Menu mode. Press and hold to turn the radio on/off. 10. TALK Button – Press and hold to transmit voice communication. 11. DOWN/LOCK Button – Press to adjust the volume, or to scroll through the menu. Press and hold to lock the keypad 12. SPEAKER – Built-in speaker. 13. UP/CALL Button – Press to adjust the volume, or to scroll through the menu. Press and hold to send a call tone 14. MONITOR/SCAN Button – Press to enter SCAN mode. Press and hold to enter MONITOR mode. 15. ANTENNA MONITOR Pressing and holding the MONITOR/SCAN button for 3 seconds will let you hear noise so you can adjust the volume level of the radio when not receiving a signal. This could also be used to check any activity on your current channel before transmitting. Press and hold the MONITOR/SCAN button for 3 seconds again to get out of MONITOR mode. ABOUT RANGE Your radios are designed to give you maximum range under optimum conditions. Optimum Conditions are: * Over water * Open rural areas without obstructions * Flat areas where you can see the other person To ensure you get maximum range: * Be sure to use fresh batteries - low batteries will cause reduced range. MENU Quick Reference Chart CHANNEL SELECTION (FRS BAND) Press the MENU button once, and then press the UP/CALL or DOWN/LOCK buttons to select one of the 22 FRS channels. To confirm the selection, press the TALK button or press the MENU button again to move to the next feature setting. ROGER BEEP (end of transmission) TONE When the PTT button is released, the radio will beep to confirm to other users that your transmission has finished. To set the ROGER BEEP tone, press the MENU button until the display shows an “rb” icon. Select “on” or “oF” by pressing the UP/ CALL or DOWN/LOCK buttons. Push the TALK key to exit, or press the MENU button to move to the next feature setting. SILENT OPERATION Your radio has a SILENT OPERATION mode. In this mode, all “beeps” and “tones” are disabled. To set SILENT OPERATION, press the MENU button until the display shows a “bP” icon. Select “on” or “oF” by pressing the UP/CALL or DOWN/ LOCK buttons. Push the TALK key to exit, or press the MENU button to move to the next feature setting. NOAA WEATHER RADIO Your radio has a NOAA WEATHER RADIO function to enable the user to receive weather reports from designated NOAA stations. To turn the NOAA WEATHER RADIO on, press and hold the DOWN/LOCK and the UP/CALL buttons for 3 seconds while in FRS mode. The radio will go to the Weather Band mode. To set the channel in Weather Mode, press the MENU button, the display will show the current WX Band channel. While in WX Band mode press the UP/CALL or DOWN/ LOCK buttons to select one of the 10 NOAA WEATHER (WX) BAND channels. To confirm, press the TALK button or press the MENU button to move to the next feature setting. To turn the NOAA WEATHER RADIO off, press the TALK button. The current FRS radio setting will be displayed and the Weather icon will go off, unless alert is set. NOAA WEATHER ALERT Your radio has a NOAA WEATHER ALERT function, to enable you to automati- cally receive weather alerts from designated NOAA stations. To turn the NOAA WEATHER (WX) ALERT on while in Weather Radio mode, press the MENU button twice while in Weather Radio mode. The display shows “AL,” while on the right an “oF” icon appears blinking. Select “on” by pressing the UP/CALL or DOWN/ LOCK buttons. To confirm, press the TALK button or press MENU button. The radio will return to Weather Radio mode and the icon will continue blinking. If the radio receives a WX ALERT signal from a designated NOAA station while in FRS Radio mode, the radio will beep for 20 seconds while the display will automatically switch to Weather Radio mode. To turn the NOAA WEATHER (WX) ALERT off, press the MENU button twice while in Weather Radio mode. The display shows “AL,” while on the right an “on” icon appears blinking. Select “oF” by pressing the UP/CALL or DOWN/LOCK buttons. To confirm, press the TALK button or press the MENU button. BATTERY LEVEL INDICATOR Your radio has a BATTERY LEVEL METER that shows the battery power level. The greater the number of bars visible, the stronger the battery level. When the battery level is low, the Battery Shell icon will flash in the display indicating your batteries should be replaced. POWER ON/OFF AND VOLUME Press the POWER/MENU button for at least 3 seconds to turn the radio on/off. During Power On, the radio will beep once, the LCD will display all icons for 1 second and then the LCD display will indicate the last channel selected. To increase/decrease the volume level, press the up or down arrow buttons during RX or STANDBY mode RESTORING YOUR RADIO TO THE ORIGINAL SETTING To reset your radio to the original (default) setting, turn on the radio while pressing and holding the TALK button. The LCD display will reset to standby mode on chan- nel 1 with no Privacy Code, VOX Off, Roger Beep On, and Key Beep On. TRANSMITTING AND RECEIVING A CALL To communicate, all radios in your group must be set to the same channel. 1. For maximum clarity, hold the radio at least 1 inch (2.5 cm) from your mouth. 2. Press…

Text truncated - open the document above for the full version.

Midland Radio Corporation 5900 Parretta Drive Kansas City Missouri United States 64120-2134 Jul. 17, 2020 To: Federal Communication Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 Subject: Attestation statement regarding the Mobile Radio frequency Applicant: Midland Radio Corporation 5900 Parretta Drive Kansas City Missouri United States 64120-2134 TYPE OF QEUIPMENT: Licensed Non-Broadcast Transmitter Held to Face FCC ID: MMALXT218VP Dear Sir or Madam I attest that the product has one antenna, one battery capacity, one body-worn accessory. And that the product could program the frequency on computer through interface by manufacturer, is incapable of tuning, or readily being altered, by the end-user. Please contact the undersigned if you have any questions or need any further information. Regards Signature: Name, Job Title and Dept.: Butch Rittmannn / Director of Operations

Midland Radio Corporation 5900 Parretta Drive Kansas City Missouri United States 64120-2134 Agent Authorization Company: Midland Radio Corporation Address: 5900 Parretta Drive Kansas City Missouri United States 64120-2134 Product Name: Two-way Radio Model Number(s): LX218 Product Description: FRS Two-way Radio We authorize MiCOM Labs Inc., 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the certification of above named equipment. We declare that MiCOM Labs Inc. is allowed to forward all information related to the approval and certification of equipment to the regulatory agencies as required and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Signature: Date: Jul. 17,2020 Name: Butch Rittmannn Title: Director of Operations Company: Midland Radio Corporation

Midland Radio Corporation 5900 Parretta Drive Kansas City Missouri United States 64120-2134 Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: Jul. 17, 2020 Subject; Request for Confidentiality FCC ID: MMALXT218VP To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Parts List Operational Description Tune-up Procedure It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Butch Rittmannn Title: Director of Operations

External Photos WHOLE VIEW OF EUT TOP VIEW OF EUT BOTTOM VIEW OF EUT FRONT VIEW OF EUT BACK VIEW OF EUT LEFT VIEW OF EUT RIGHT VIEW OF EUT

FCC ID and IC Label Location 5mm*25mm FCC ID: MMALXT218VP IC: 3690A-LXT218 HVIN: LX218

Midland Radio Corporation 5900 Parretta Drive Kansas City Missouri United States 64120-2134 Jul. 17, 2020 Statement We, Midland Radio Corporation (FCC ID: MMALXT218VP) puts the label inside the battery compartment of this device. It is visible to the users as they purchase the products and install the battery. Regards Midland Radio Corporation Contact person: Butch Rittmannn Title: Director of Operations

Internal Photos OPEN VIEW-1 OF EUT OPEN VIEW-2 OF EUT OPEN VIEW-3 OF EUT INTERNAL VIEW-1 OF EUT Antenna INTERNAL VIEW-2 OF EUT INTERNAL VIEW-3 OF EUT INTERNAL VIEW-4 OF EUT INTERNAL VIEW-5 OF EUT

Ref : ACR.262.3.20.SA TU.A SHENZHEN STS TEST SERVICES CO., LTD. 1/F, BUILDING 2, ZHUOKE SCIENCE PARK,No.190, CHONGQING ROAD, FUYONG STREET, BAO’ AN DISTRICT, SHENZHEN,GUANGDONGCHINA MVG COMOSAR REFERENCE DIPOLE FREQUENCY: 450 MHZ SERIAL NO.: SN 30/14 DIP0G450-330 Calibrated at MVG US 2105 Barrett Park Dr. - Kennesaw, GA 30144 07/14/2020 Summary: This document presents the method and results from an accredited SAR reference dipole calibration performed in MVG USA using the COMOSAR test bench. All calibration results are traceable to national metrology institutions. SAR Reference Dipole Calibration Report SAR REFERENCE DIPOLE CALIBRATION REPORT Ref: ACR.262.3.20.SATU.A Page: 2/11 This document shall not be reproduced, except in full or in part, without the written approval of MVG. The information contained herein is to be used only for the purpose for which it is submitted and is not to be released in whole or part without written approval of MVG. Name Function Date Signature Prepared by : Jérôme LUC Product Manager 7/28/2020 Checked by : Jérôme LUC Product Manager 7/28/2020 Approved by : Kim RUTKOWSKI Quality Manager 7/28/2020 Customer Name Distribution : Shenzhen STS Test Services Co., Ltd. Issue Date Modifications A 7/28/2020Initial release SAR REFERENCE DIPOLE CALIBRATION REPORT Ref: ACR.262.3.20.SATU.A Page: 3/11 This document shall not be reproduced, except in full or in part, without the written approval of MVG. The information contained herein is to be used only for the purpose for which it is submitted and is not to be released in whole or part without written approval of MVG. TABLE OF CONTENTS 1 Introduction ................................................................................................................ 4 2 Device Under Test ..................................................................................................... 4 3 Product Description ................................................................................................... 4 3.1 General Information _______________________________________________________ 4 4 Measurement Method ................................................................................................ 5 4.1 Return Loss Requirements __________________________________________________ 5 4.2 Mechanical Requirements ___________________________________________________ 5 5 Measurement Uncertainty .......................................................................................... 5 5.1 Return Loss ______________________________________________________________ 5 5.2 Dimension Measurement ___________________________________________________ 5 5.3 Validation Measurement ____________________________________________________ 5 6 Calibration Measurement Results .............................................................................. 6 6.1 Return Loss and Impedance In Head Liquid ____________________________________ 6 6.2 Return Loss and Impedance In Body Liquid ____________________________________ 6 6.3 Mechanical Dimensions ____________________________________________________ 6 7 Validation measurement ............................................................................................ 7 7.1 Head Liquid Measurement __________________________________________________ 7 7.2 SAR Measurement Result With Head Liquid ____________________________________ 8 7.3 Body Liquid Measurement __________________________________________________ 9 7.4 SAR Measurement Result With Body Liquid __________________________________ 10 8 List of Equipment .................................................................................................... 11 SAR REFERENCE DIPOLE CALIBRATION REPORT Ref: ACR.262.3.20.SATU.A Page: 4/11 This document shall not be reproduced, except in full or in part, without the written approval of MVG. The information contained herein is to be used only for the purpose for which it is submitted and is not to be released in whole or part without written approval of MVG. 1 INTRODUCTION This document contains a summary of the requirements set forth by the IEEE 1528, OET 65 Bulletin C and CEI/IEC 62209 standards for reference dipoles used for SAR measurement system validations and the measurements that were performed to verify that the product complies with the fore mentioned standards. 2 DEVICE UNDER TEST Device Under Test Device Type COMOSAR 450 MHz REFERENCE DIPOLE Manufacturer MVG Model SID450 Serial Number SN 30/14 DIP0G450-330 Product Condition (new / used) New A yearly calibration interval is recommended. 3 PRODUCT DESCRIPTION 3.1 GENERAL INFORMATION MVG’s COMOSAR Validation Dipoles are built in accordance to the IEEE 1528, OET 65 Bulletin C and CEI/IEC 62209 standards. The produc t is designed for use with the COMOSAR test bench only. Figure 1 – MVG COMOSAR Validation Dipole SAR REFERENCE DIPOLE CALIBRATION REPORT Ref: ACR.262.3.20.SATU.A Page: 5/11 This document shall not be reproduced, except in full or in part, without the written approval of MVG. The information contained herein is to be used only for the purpose for which it is submitted and is not to be released in whole or part without written approval of MVG. 4 MEASUREMENT METHOD The IEEE 1528, OET 65 Bulletin C and CEI/IEC 62209 standards provide requirements for reference dipoles used for system validation measurements. The following measurements were performed to verify that the product complies with the fore mentioned standards. 4.1 RETURN LOSS REQUIREMENTS The dipole used for SAR system validation measurements and checks must have a return loss of -20 dB or better. The return loss measurement shall be performed against a liquid filled flat phantom, with the phantom constucted as outlined in the fore mentioned standards. 4.2 MECHANICAL REQUIREMENTS The IEEE Std. 1528 and CEI/IEC 62209 standards specify the mechanical components and dimensions of the validation dipoles, with the dimensions frequency and phantom shell thickness dependent. The COMOS…

Text truncated - open the document above for the full version.

Any reproduction of this document must be done in full. No single part of this document may be reproduced without permission from STS, All Test Data Presented in this report is only applicable to presented Test sample. ShenZhen STS Test Services Co.,Ltd. A 1/F, Building B, Zhuoke Science Park, No.190 Chongqing Road, HepingShequ, Fuyong Sub-District, Bao’an District, Shenzhen, Guang Dong, China TEL: +86-755 3688 6288 FAX: +86-755 3688 6277 E-mail:[email protected] SAR TEST REPORT Report No.: STS2009198H01 Issued for Midland Radio Corporation 5900 Parretta Drive Kansas City Missouri United States 64120-2134 Product Name: Two-way Radio Brand Name: Midland Model Name: LX218 Series Model: N/A FCC ID: MMALXT218VP IC: 3690A-LXT218 Test Standard: ANSI/IEEE Std. C95.1 FCC 47 CFR Part 2 ( 2.1093) RSS 102 Issue 5,March 2015 IEEE 1528: 2013; IEC 62209-2: 2010 Max. Report SAR (1g): Face up : 0.022 W/kg Back side: 0.060 W/kg S T L A B S Page 2 of 32 Report No.: STS2009168H01 Test Report Certification Applicant’s name ................. : Midland Radio Corporation Address ................................. : 5900 Parretta Drive Kansas City Missouri United States 64120-2134 Manufacture's Name ............ : Midland Radio Corporation Address ................................. : 5900 Parretta Drive Kansas City Missouri United States 64120-2134 Product description Product name ........................ : Two-way Radio Brand Name ........................... : Midland Model name ......................... : LX218 Series Model .......................... : N/A Standards ............................. : RSS 102 Issue 5,March 2015 IEEE 1528:2013 IEC 62209-2:2010 The device was tested by Shenzhen STS Test Services Co., Ltd. in accordance with the measurement methods and procedures specified in KDB 865664 The test results in this report apply only to the tested sample of the stated device/equipment. Other similar device/equipment will not necessarily produce the same results due to production tolerance and measurement uncertainties. Date of Test ........................................... : Date (s) of performance of tests ............. : 23 May 2020 Date of Issue .......................................... : 11 Sept. 2020 Test Result .............................................. : Pass Testing Engineer : ( Aaron Bu) Technical Manager : (Sean she) Authorized Signatory : (Vita Li) Page 3 of 32 Report No.: STS2009168H01 Table of Contents 1. General Information 4 1.1 EUT Description 4 1.2 Test Environment 5 1.3 Test Factory 5 2. Test Standards and Limits 6 3. SAR Measurement System 7 3.1 Definition of Specific Absorption Rate (SAR) 7 3.2 SAR System 7 4. Tissue Simulating Liquids 10 4.1 Simulating Liquids Parameter Check 10 5. SAR System Validation 12 5.1 Validation System 12 5.2 Validation Result 12 6. SAR Evaluation Procedures 13 7. EUT Test Position 14 8. Uncertainty 15 8.1 Measurement Uncertainty 15 8.2 System validation Uncertainty 16 9. Conducted Power Measurement 17 Test Result 17 10. Test Setup Photo 18 10.1 Setup Photo 18 11. SAR Result Summary 21 12. Equipment List 23 Appendix A. System Validation Plots 24 Appendix B. SAR Test Plots 26 Appendix C. Probe Calibration and Dipole Calibration Report 32 Page 4 of 32 Report No.: STS2009168H01 1. General Information 1.1 EUT Description Equipment Two-way Radio Brand Name Midland Model name LX218 Series Model N/A Model Difference N/A Device Category Portable Product stage Production unit RF Exposure Environment General Population/Uncontrolled Environments Hardware Version LXT218_V1.0 Software Version V1.0 Frequency Range FRS: 462.5625MHz -462.7125MHz(0.5W) 462.5500MHz-462.7250MHz(0.5W) 467.5625MHz-467.7125MHz(0.5W) Test Channel :4, 11 and 19 channel Channel Spacing 12.5KHz Max. Reported SAR(1g) with 50% duty cycle Frequency Band Face up (W/kg) Back Side (W/kg) 462.5625-462.71 25MHz(0.5W) 0.022 0.060 462.5500-462.72 50MHz(0.5W) 0.022 0.055 467.5625-467.71 25MHz(0.5W) 0.020 0.054 Modulation Type: F3E Antenna Specification: Inseparable Note: 1. The EUT battery must be fully charged and checked periodically during the test to ascertain uniform power Page 5 of 32 Report No.: STS2009168H01 1.2 Test Environment Ambient conditions in the SAR laboratory: Items Required Temperature (°C) 18-25 Humidity (%RH) 30-70 1.3 Test Factory ShenZhen STS Test Services Co.,Ltd. A 1/F, Building B, Zhuoke Science Park, No.190 Chongqing Road, HepingShequ, Fuyong Sub-District, Bao’an District, Shenzhen, Guang Dong, China FCC Registration No.: 625569 A2LA Certificate No.: 4338.01 IC Registration No.: 12108A Page 6 of 32 Report No.: STS2009168H01 2. Test Standards and Limits No. Identity Document Title 1 47 CFR Part 2 Frequency Allocations and Radio Treaty Matters; General Rules and Regulations 2 ANSI/IEEE Std. C95.1-1992 IEEE Standard for Safety Levels with Respect to Human Exposure to Radio Frequency Electromagnetic Fields, 3 kHz to 300 GHz 3 RSS 102 Issue 5, March 2015 Radio Frequency (RF) Exposure Compliance of Radio communication Apparatus (All Frequency Bands) 4 IEEE Std. 1528-2013 Recommended Practice for Determining the Peak Spatial-Average Specific Absorption Rate (SAR) in the Human Head from Wireless Communications Devices: Measurement Techniques 5 IEC 62209-2: 2010 Human exposure to radio frequency fields from hand-held and body-mounted wireless communication devices – Human models, instrumentation, and procedures –Part 2: Procedure to determine the Specific Absorption Rate (SAR) in the head and body for 30MHz to 6GHz Handheld and Body-Mounted Devices used inclose proximity to the body 6 FCC KDB 447498 D01 v06 Mobile and Portable Device RF Exposure Procedures and Equipment Authorization Policies 7 FCC KDB 865664 D01 v01r04 SAR Measurement 100 MHz to 6 GHz 8 FCC KDB 865664 D02 v01r02 RF Exposure Reporting 9 FCC KDB 643646 D001 SAR Test Reduction Considerations for Occupational PTT Radios (A). Limits for Occupational/Controlled Exposure (W/kg) Whole-Body Partial-Body Hands, Wrists, Feet and Ankle…

Text truncated - open the document above for the full version.

Page 1 of 50 FCC Part 95 Rules Test Report Report No.:AGC09350200401FE10 FCC ID : MMALXT218VP PRODUCT DESIGNATION : Two-way Radio BRAND NAME : Midland MODEL NAME : LX218 APPLICANT : Midland Radio Corporation DATE OF ISSUE : May 27, 2020 STANDARD(S) : FCC Part 95 Rules REPORT VERSION : V 1.0 Attestation of Global Compliance (Shenzhen) Co., Ltd CAUTION: This report shall not be reproduced except in full without the written permission of the test laboratory and shall not be quoted out of context. Report No.: AGC02931200702FE10 Page 2 of 50 Report Revise Record Report Version Revise Time Issued Date Valid Version Notes V1.0 / May 27, 2020 Valid Initial release Report No.: AGC02931200702FE10 Page 3 of 50 VERIFICATION OF COMPLIANCE Applicant Midland Radio Corporation Address 5900 Parretta Drive Kansas City Missouri United States 64120-2134 manufacturer Midland Radio Corporation Address 5900 Parretta Drive Kansas City Missouri United States 64120-2134 Factory Midland Radio Corporation Address 5900 Parretta Drive Kansas City Missouri United States 64120-2134 Product Designation: Two-way Radio Brand Name: Midland Test Model LX218 Date of Test: Mar. 10, 2020~May 24, 2020 WE HEREBY CERTIFY THAT: The above equipment was tested by Attestation of Global Compliance (Shenzhen) Co., Ltd. The data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in TIA/EIA 603. The sample tested as described in this report is in compliance with the FCC Rules Part 95 requirements. The test results of this report relate only to the tested sample identified in this report. Prepared By Calvin Liu (Project Engineer) May 24, 2020 Reviewed By Max Zhang (Reviewer ) May 27, 2020 Approved By Forrest Lei (Authorized Officer) May 27, 2020 Report No.: AGC02931200702FE10 Page 4 of 50 TABLE OF CONTENTS 1. GENERAL INFORMATION .............................................................................................................................. 5 1.1 PRODUCT DESCRIPTION ......................................................................................................................... 5 1.2 RELATED SUBMITTAL(S) / GRANT (S) ..................................................................................................... 7 1.3 TEST METHODOLOGY............................................................................................................................... 7 1.4 TEST FACILITY ........................................................................................................................................... 7 1.5 SPECIAL ACCESSORIES ........................................................................................................................... 7 1.6 EQUIPMENT MODIFICATIONS .................................................................................................................. 7 2. SYSTEM TEST CONFIGURATION .................................................................................................................. 8 2.1EUT CONFIGURATION ............................................................................................................................... 8 2.2 EUT EXERCISE .......................................................................................................................................... 8 2.4 CONFIGURATION OF TESTED SYSTEM .................................................................................................. 9 3. SUMMARY OF TEST RESULTS .................................................................................................................... 10 4. DESCRIPTION OF TEST MODES ................................................................................................................. 12 5. FREQUENCY TOLERANCE .......................................................................................................................... 13 5.1 PROVISIONS APPLICABLE ..................................................................................................................... 13 5.2 MEASUREMENT PROCEDURE .............................................................................................................. 13 5.3 TEST SETUP BLOCK DIAGRAM ............................................................................................................. 14 5.4 TEST RESULT ........................................................................................................................................... 15 6. EMISSION BANDWIDTH ............................................................................................................................... 16 6.1 PROVISIONS APPLICABLE ..................................................................................................................... 17 6.2 MEASUREMENT PROCEDURE .............................................................................................................. 17 6.3 TEST SETUP BLOCK DIAGRAM ............................................................................................................. 17 6.4 MEASUREMENT RESULT ........................................................................................................................ 20 7. UNWANTED RADIATION ............................................................................................................................... 22 7.1 PROVISIONS APPLICABLE ..................................................................................................................... 22 7.2 MEASUREMENT PROCEDURE .............................................................................................................. 22 7.3 TEST SETUP BLOCK DIAGRAM ............................................................................................................. 23 7.4 MEASUREMENT RESULTS: .................................................................................................................... 24 7.5 EMISSION …

Text truncated - open the document above for the full version.

Report No.: AGC02931200702FE10 Page 31 of 50 7.5 EMISSION MASK PLOT Standard Applicable [FCC Part 95.579] FRS: Unwanted emissions shall be attenuated below the unmodulated carrier power in accordance with the following: (1) At least 25 dB (decibels) on any frequency removed from the center of the authorized bandwidth by more than 50 %up to and including 100% of the authorized bandwidth. (2) At least 35 dB on any frequency removed from the center of the authorized bandwidth by more than 100 % up to and including 250 % of the authorized bandwidth. (3) At least 43 + 10 log10 (T) dB on any frequency removed from the center of the authorized bandwidth by more than250 %. The detailed procedure employed for Emission Mask measurements are specified as following: - The transmitter shall be modulated by a 2.5 kHz audio signal, - The level of the audio signal employed is 16 dB greater than that necessary to produce 50% of rated system deviation. Rated system deviation is 2.5 kHz. Report No.: AGC02931200702FE10 Page 32 of 50 Channel 4: The Worst Emission Mask for channel 4 -0.5W Report No.: AGC02931200702FE10 Page 33 of 50 Channel 11: The Worst Emission Mask for channel 11 -0.5W Report No.: AGC02931200702FE10 Page 34 of 50 Channel 19: The Worst Emission Mask for channel 19-0.5W Report No.: AGC02931200702FE10 Page 35 of 50 8. MAXIMUMN TRANSMITTER POWER 8.1 PROVISIONS APPLICABLE Per FCC §2.1046 and §95.567(h): Maximum ERP is dependent upon the station’s antenna HAAT and required service area. FCC Part 95.567 For FRS Each FRS transmitter type must be designed such that the effective radiated power (ERP) on channels 8 through 14 does not exceed 0.5 Watts and the ERP on channels 1 through 7 and 15 through 22 does not exceed 2.0 Watts. 8.2 TEST PROCEDURE (1) The spectrum setting for Equivalent Isotropically Radiated Power (EIRP) is RBW = 100 kHz, VBW = 300 kHz. Detector Mode is RMS. (2) In the semi-anechoic chamber, setup as illustrated above the EUT placed on the 1.5m height of Turn Table, rotated the table 45 degree each interval to sea…
