MMALXT600FRS/ GMRS

Welcome to the world of Midland electronics Congratulations on your purchase of a high quality MIDLANDproduct. Your 2-way radio represents state-of-the-art high-techengineering. Designed for GMRS (General Mobile Radio Service)operation, this compact package is big on performance. It is aquality piece of electronic equipment, skillfully constructed with thefinest components. The circuitry is all solid-state and mounted on arugged printed circuit board. Your two-way radio is designed forreliable and trouble-free performance for years to come.Features- 36 GMRS/FRS Channels - 121 Privacy Codes (38 CTCSS / 83 DCS)- VOX- Selectable Call Alert - NOAA Weather Scan- NOAA Weather Radio- NOAA Weather Alert - Scan Function- Monitor Function- Roger Beep Tone- Silent Operation- Key Pad Lock- Power High / Low Settings- Speaker / Microphone Jacks- Battery Meter / Battery Low Indicator This device complies with Part 15 of the FCC Rules. Operation issubject to the following two conditions: (1) this device does not causeharmful interference, and (2) this radio must accept any interferencethat may cause undesired operation.To maintain compliance with FCC’s RF exposure guidelines, forbody-worn operation, this radio has been tested and meets the FCC RFexposure guidelines when used with Midland Radio Corp. accessoriessupplied or designated for this product. Use of other accessories maynot ensure compliance with FCC RF exposure guidelines. IMPORTANT NOTICE, FCC LICENSE REQUIRED FOR GMRS OPERATION(Only Applicable for GMRS Radio Use in the United States)The LXT600 Series operates on GMRS (General Mobile Radio Service)frequencies which require an FCC (Federal Communications Commission)license. You must be licensed prior to operating on channels 1 - 7 or 15 - 22,which comprise the GMRS channels of the LXT600 Series. Serious penaltiescould result from unlicensed use of GMRS channels, in violation of FCC rules, asstipulated in the Communications Acts Sections 501 and 502 (amended).You will be issued a call sign by the FCC which should be used for stationidentification when operating the radio on GMRS channels. You should alsocooperate by engaging in permissible transmissions only, avoiding channelinterference with other GMRS users, and being prudent with the length of yourtransmission time.To obtain a license or ask questions about the license application, contact theFCC at 1-888-CALL FCC or go to the FCC's website: http://www .fcc.gov and request form 605 . Exposure To Radio Frequency EnergyYour Midland radio is designed to comply with the following national andinternational standards and guidelines regarding exposure of human beings toradio frequency electromagnetic energy:- United States Federal Communications Commission, Code of Federal Regulations: 47 CFR part 2 sub-part J - American National Standards Institute (ANSI)/Institute of Electrical & Electronic Engineers (IEEE) C95. 1-1992 - Institute of Electrical and Electronic Engineers (IEEE) C95. 1-1999 Edition- National Council on Radiation Protection and Measurements (NCRP) of the United States, Report 86, 1986 - International Commission on Non-lonizing Radiation Protection (ICNIRP) 1998 To control your exposure and ensure compliance with the general population oruncontrolled environment exposure limits, transmit no more than 50% of thetime. The radio generates measurable RF energy exposure only whentransmitting. IMPORTANT: Changes or modifications to this unit not expressly approved by MIDLAND RADIO CORP. could void your right to operate this unit. Your radio is set up to transmit a regulated signal on anassigned frequency. It is against the law to alter or adjust the settingsinside the COMMUNICATOR to exceed those limitations. Any adjustmentto your radio must be made by qualified technicians. LCD DISPLA Y 1. KEY LOCK ICON – Indicates KEY LOCK mode is on. 2. VOX ICON – Indicates when VOX mode is active. 3. NOAA WEATHER (WX) BAND ICON – Indicates when the radio is in Weather Band mode. 4. CHANNEL NUMBER – Changes from 1~36 on GMRS/FRS band (1~10 on WXband). 5. PRIVACY CODE – Indicates Privacy Code selected by user (oF~38/oF~83). Itcan only be set in Ch 1~22. 6. BATTERY METER – Indicates the battery level. 7. RECEIVE (RX) ICON – Indicates radio is receiving a transmission. 8. TRANSMIT (TX) ICON – Indicates radio is transmitting a signal. 9. TRANSMIT POWER LEVEL ICON – Indicates TX Power setting (H/L). 10. PRIVACY CODE ICON – Indicates Privacy Code setting (CTCSS/DCS). 1 CONTR OLS 11. POWER/VOLUME KNOB – Turn clock- wise to turn the power on and increasethe volume level. Turn counter-clockwiseto decrease the volume level and turnthe power off. 12. PTT Button – Press and hold to transmit voice communication. 13. CALL/LOCK Button – Press to send a CALL Alert signal. Press and hold toturn KEY LOCK on/off. 14. MIC – Built-in microphone. 15. SPEAKER – Built-in speaker. 16. ANTENNA17. EXTERNAL SPEAKER/MIC/CHG JACK 18. MENU Button – Press momentarily to access Menu mode. 19. MONITOR/SCAN Button – Press to enter SCAN mode. Press and hold toenter MONITOR mode. 20. UP/WX SCAN s and DOWN t Buttons – Make adjustments in MENU mode. Press and hold the UP button for5 seconds to activate the NOAAWeather Scan function. 18 17 16 14 1312 11 76 32 15 19 4 5 8 9 10 BA T TER Y INS T ALLA TION Your LXT600 Series radio operates with either a NiMH battery packor optional 3 AAA alkaline batteries. The belt clip should be removed(see below) to ease installation or removal of the batteries. To install the batteries:1. With the back of the radio facing you, remove the belt clip (see diagram below) for easy access, then remove the Battery Cover bypressing down on the top center and sliding it down from the radio. 2. Insert 4 AAA batteries observing the polarity as shown. Installing the batteries incorrectly will prevent the unit from operating or maydamage the unit. 3. Return the Battery Cover by sliding it up on the radio. Replace the belt clip, making sure it locks into place. BATTERYCOMPAR…

Text truncated - open the document above for the full version.

Date: 2012.02.01 Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 To whom it may concern: I, the undersigned, hereby authorize KT Kang of KES Co., Ltd. and hereafter referred to as KES Co., Ltd., to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by KT Kang of KES Co., Ltd. on our behalf shall have the same effect as acts of our own. I, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). In authorizing KES Co., Ltd. as our agent, we still recognize that we are responsible to: a) comply with the relevant provisions of the certification program; b) make all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c) make claims regarding certification only in respect of the scope for which certification has been granted; d) do not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our product certification which the Certification Division may consider misleading or unauthorized; e) upon suspension or cancellation of certification, discontinue use of all advertising matter that contains any reference thereto and return any certification documents as required by the Certification Division; f) use certification only to indicate the products are certified as being in conformity with specified standards; g) endeavor to ensure that no certificate or report nor any part thereof is used in a misleading manner; h) ensure that any reference to our product certification in communication media such as documents, brochures or advertising, complies with the requirements of the Certification Division; i) keep a record of all complaints made known to the us relating to the product’s compliance with requirements of the relevant standard and to make these records available to the Certification Division when requested; j) take appropriate action with respect to such complaints and any deficiencies found in products or services that affect compliance with the requirements for certification; k) document the actions taken. This authorization is valid until further written notice from the applicant. Sincerely Yours, David Kingsolver / Engineering Manager Midland Radio Corporation REMARK: 1. This authorization letter will be sent along with your application when filing with the Certification Division. 2. Please follow the format and type it on company letterhead and send original to us. 3. Authorized signature must be in agreement with grantee code contact in FCC database.

Date: April 26, 2012 Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID: MMALXT600 Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Exhibit Type File Name Part List CONF APPENDIX_LXT600_Part List.PDF Schematics Diagram(s) CONF APPENDIX_LXT600_Schemetics.PDF Block diagram CONF APPENDIX_LXT600_Block diagram.PDF Operation description CONF APPENDIX_LXT600_Operation description.PDF The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, David Kingsolver / Engineering Manager Midland Radio Corporation

www.kes.co.kr Model No.: LXT600 Page 1 of 4 EUT External photographs www.kes.co.kr Model No.: LXT600 Page 2 of 4 www.kes.co.kr Model No.: LXT600 Page 3 of 4 www.kes.co.kr Model No.: LXT600 Page 4 of 4 N/A

www.kes.co.kr Model No.: LXT600 Page 1 of 1 EUT Internal photographs

LABORATORY TESTING PROCEDURES LXT600 Page 1 UNIT TEST - (UNIT ASSEMBLED) TEST PREPARATION 1) Install 3 AAA Alkaline batteries (observe polarity markings). 2) Turn on unit by pressing the power button. SYSTEM TEST 1) Radiated Transmit and Receive performance may be observed. 2) Audio out & Audio in are available at the Headset jack. LABORATORY TEST - (UNIT UN-ASSEMBLED) TEST PREPARATION 1) Disassemble unit (4 screws – 2 behind batteries). Remove the PCB from the cabinet. 2) Remove the antenna with soldering iron and install a 50 ohm coax cable in its place. 3) Either clip alligator leads or solder test leads to the power supply connections. The negative terminal is the lower right PCB area. The positive terminal is the lower left PCB area. 4) Connect 4.5VDC power source to the terminals, observing correct polarity. 5) Connect an 12-ohm load through the Headset jack 6) Connect a audio generator with 10uF coupling capacitor through the Headset jack 7) Select desired channel 1-36 using CH up/down keypad switch. The rubber keypad may be removed from the front cabinet and used directly on the PCB. LABORATORY TESTING PROCEDURES LXT600 Page 2 SPECIFIC TEST METHODS AND GUIDANCE Modulation Characteristics – (paragraph 2.1047(a) of the Rules) FOR TX AUDIO FILTER RESPONSE 1. Connect audio generator with 10uF coupling capacitor to microphone input jack. Press PTT button. 2. Connect RF output with modulation meter. (Filters of modulation meter should be set to a 25Hz to 15KHz.) 3. Adjust audio generator 6-7mVrms of 1KHz audio (approx. 0.75KHz modulation). 4. While transmitting, sweep generator and note measurement. 5. Results should be multiplied by a two times because of compressor. 6. Please compensate the back-ground noise level. Modulation Characteristics – (paragraph 2.1047(b) of the Rules FOR TX AUDIO LOW PASS FILTER RESPONSE. 1. Connect audio generator with 10uF coupling capacitor to microphone input jack. Press PTT button. 2. Connect AC voltmeter or other test equipment via jumper wire with junction (TP9) of C53, R82. 3. Adjust audio generator for 200mV. 4. While transmitting, sweep generator and note measurement. Sideband Spectrum – (paragraph 2.1049(c) of the Rules) 1. Connect an audio frequency sweep generator with 10uF coupling capacitor to microphone input jack. 2. Adjust audio generator to a frequency of 2500Hz and a level of 51mV rms (+16dB above 8mV per FCC). 3. With a spectrum analyzer, transmit the radio and monitor the transmitter though an antenna. 4. Note required measurements per FCC.

Report File No. : F690501/RF-SAR001999 Date of Issue :2012-04-25 Page :1 / 67 SAR TEST REPORT Equipment Under Test:FM Transceiver Model No.:LXT600 Applicant:Midland Radio Corporation Address of Applicant: 5900 Parretta Drive Kansas City Missouri United States 64120 FCC IDMMALXT600 IC ID3690A-LXT600 Device Category:Portable Device Exposure Category:General Population /Uncontrolled Exposure Date of Receipt:2012-01-18 Date of Test(s):2012-04-09, 2012-04-10 Date of Issue:2012-04-25 Max. SAR:0.2805 W/kg (Head 50 % Duty Cycle) 0.8700 W/kg (Body 50 % Duty Cycle) Standards:FCC OET Bulletin 65 supplement C RSS-102 (Issue 4) IEEE 1528, 2003 ANSI/IEEE C95.1, C95.3 In the configuration tested, the EUT complied with the standards specified above. Remarks: Tested by:Fred Jeong 2012-04-25 Approved by:Charles Kim2012-04-25 This report details the results of the testing carried out on one sample, the results contained in this test report do not relate to other samples of the same product. The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in this report. This report may only be reproduced and distributed in full. If the product in this report is used in any configuration other than that detailed in the report, the manufacturer must ensure the new system complies with all relevant standards. Any mention of SGS Testing Korea Co., Ltd. or testing done by SGS Testing Korea Co., Ltd. in connection with distribution or use of the product described in this report must be approved by SGS Testing Korea Co., Ltd. in writing. Report File No. : F690501/RF-SAR001999 Date of Issue :2012-04-25 Page :2 / 67 Contents 1. General Information 1.1 Testing Laboratory........................................................................................... 3 1.2 Details of Applicant.......................................................................................... 3 1.3 Version of Report............................................................................................. 3 1.4 Description of EUT(s)....................................................................................... 3 1.5 Test Environment............................................................................................. 4 1.6 Operation description........................................................................................ 4 1.7 Evaluation procedures....................................................................................... 5 1.8 The SAR Measurement System............................................................................ 6 1.9 System Components.......................................................................................... 8 1.10 SAR System Verification.................................................................................... 9 1.11 Tissue Simulant Fluid for the Frequency Band.......................................................... 11 1.12 Tissue Parameters Check Results....................................................................... 12 1.13 Test Standards and Limits................................................................................. 12 2. Instruments List.................................................................................... 14 3. Summary of Results................................................................................ 16 APPENDIX A. DASY4 SAR Report B. Uncertainty Analysis C. Calibration certificate Report File No. : F690501/RF-SAR001999 Date of Issue :2012-04-25 Page :3 / 67 1. General Information 1.1Testing Laboratory SGS Korea Co., Ltd. Wireless Div. 2FL, 18-34, Sanbon-dong, Gunpo-si, Gyeonggi-do, Korea 435-040 Telephone: +82 +31 428 5700 FAX: +82 +31 427 2371 Homepage:www.ee.sgs.com/Korea 1.2 Details of Applicant Manufacturer: Midland Radio Corporation Address: 5900 Parretta Drive Kansas City Missouri United States 64120 Contact Person: David Kingsolver Phone No.: 816-241-8500 Fax No.: 816-241-8500 E-mail: [email protected] 1.3 Version of Report Version NumberDateRevision 002012-04-25Initial issue 1.4 Description of EUT(s) EUT Type : FM Transceiver Model : LXT600 Serial Number : N/A Mode of Operation : GMRS, FRS Body worn Accessory : Belt Clip Tx Frequency Range : GMRS (462.5500㎒~ 462.7250㎒) FRS (467.5625㎒~ 467.7125㎒) Antenna : Fixed Type E.R.P : GMRS :0.101 4 W(High power) GMRS :0.081 7 W(Low power) FRS :0.077 8 W Battery Type : 3×AAA Alkaline(4.5 V) / Rechargeable Ni-MH battery pack (3.6 V) Report File No. : F690501/RF-SAR001999 Date of Issue :2012-04-25 Page :4 / 67 1.5 Test Environment Ambient temperature : (22±2) ° C Tissue Simulating Liquid : (22±2) ° C Relative Humidity : (55± 5)% R.H. 1.6 Operation Configuration Reference Positions for Handheld Radio Transmitters In general handheld radio transmitters like GMRS/FRS/LMR devices are used in held to face position or with a speaker/microphone combination as body-worn configuration. Held to face position For held to face position the flat section of a SAM Phantom or a flat phantom is used. The center of the radiating structure is to set on the middle position of the flat phantom. The distance between sample and flat phantom is 2.5 cm. For the measurement head tissue simulating liquid is used. Belt Clip/Holster Configuration Test configurations for body-worn operated EUTs are carried out while the belt-clip and/or holster is attached to the EUT and placed against a flat phantom in a regular configuration. An EUT with a headset output it tested with a headset connected to the device. Body dielectric parameters are used. There are two categories for accessories for body-worn operation configurations: 1.accessories not containing metallic components 2.accessories containing metallic components. When the EUT is equipped with accessories not containing metallic components the tests are done with the accessory that dictates the closest spacing to the body. For accessories containing metallic parts a test with ea…

Text truncated - open the document above for the full version.

KES Co., Ltd. C-3701 Dongil Techno Town, 889-1, Gwanyang 2-dong, Dongan-gu, Anyang-si, Gyeonggi-do, 431-716, Korea Tel: +82-31-425-6200 / Fax: +82-31-424-0450 www.kes.co.kr Test report No.: KES-RF-120037 Page: (1) of (37) This report shall not be reproduced except in full, without the written approval of KES Co., Ltd. The test results in the report only apply to the tested sample. KES-P-5101-09 Rev.1 KES A4 TEST REPORT Part 95(A/B) & IC RSS-210(Issue 8) Equipment Under Test FRS / GMRS Model Name LXT600 FCC ID MMALXT600 IC Certification 3690A- LXT600 Applicant Midland Radio Corporation Manufacturer Global Link Date of test(s) 2012.04.09 ~ 2012.04.25, 2012.05.02 Date of issue 2012.05.03 Issued to Midland Radio Corporation 5900 Parretta Drive Kansas City Missouri United States 64120 Issued by KES Co., Ltd. C3701 Dongil Techno Town, 889-1, Gwanyang 2-dong, Dongan-gu, Anyang-si, Gyeonggi-do, 431-716, Korea 477-6, Hageo-ri, Yeoju-eup, Yeoju-gun, Gyeonggi-do, 469-803, Korea Tel: +82-31-425-6200 / Fax: +82-31-424-0450 Test and report completed by : Report approval by : Jeff Do Test engineer Gyu-cheol Shin Technical manager KES Co., Ltd. C-3701 Dongil Techno Town, 889-1, Gwanyang 2-dong, Dongan-gu, Anyang-si, Gyeonggi-do, 431-716, Korea Tel: +82-31-425-6200 / Fax: +82-31-424-0450 www.kes.co.kr Test report No.: KES-RF-120037 Page: (2) of (37) This report shall not be reproduced except in full, without the written approval of KES Co., Ltd. The test results in the report only apply to the tested sample. KES-P-5101-09 Rev.1 KES A4 Revision history Revision Date of issue Test report No. Description - 2012.04.27 KES-RF-120035 Initial 1 2012.05.03 KES-RF-120037 <Addition> 1. DC input into the final amplifier in the test report on page 7of 37. 2. The frequency stability measurement in the report on page 34, 35 of 37. (FRS & GMRS- Low power) <Retest> 1. Retest the battery end point of frequency stability (GMRS-High power) in the report on page 34 of 37. KES Co., Ltd. C-3701 Dongil Techno Town, 889-1, Gwanyang 2-dong, Dongan-gu, Anyang-si, Gyeonggi-do, 431-716, Korea Tel: +82-31-425-6200 / Fax: +82-31-424-0450 www.kes.co.kr Test report No.: KES-RF-120037 Page: (3) of (37) This report shall not be reproduced except in full, without the written approval of KES Co., Ltd. The test results in the report only apply to the tested sample. KES-P-5101-09 Rev.1 KES A4 TABLE OF CONTENTS 1.0 General product description ............................................................................................................... 4 1.1 Information about variant model ........................................................................................................ 4 1.2 Device modifications ......................................................................................................................... 4 1.3 Test facility ......................................................................................................................................... 4 1.4 Laboratory accreditations and listings................................................................................................ 5 1.5 Conclusion of worst-case for each mode of representative channel respectively .............................. 6 2.0 Summary of tests ................................................................................................................................ 8 2.1 Test data ............................................................................................................................................. 9 2.1.1 RF output power and radiated spurious emission ....................................................................... 9 2.1.2 Modulation limiting .................................................................................................................. 17 2.1.3 Audio frequency response ........................................................................................................ 20 2.1.4 Low-pass filter response ........................................................................................................... 23 2.1.5 Occupied bandwidth and emission mask ................................................................................. 25 2.1.6 Frequency stability ................................................................................................................... 32 Appendix A. Test equipment used for test ....................................................................................................... 36 Appendix B. Test setup photo .......................................................................................................................... 37 KES Co., Ltd. C-3701 Dongil Techno Town, 889-1, Gwanyang 2-dong, Dongan-gu, Anyang-si, Gyeonggi-do, 431-716, Korea Tel: +82-31-425-6200 / Fax: +82-31-424-0450 www.kes.co.kr Test report No.: KES-RF-120037 Page: (4) of (37) This report shall not be reproduced except in full, without the written approval of KES Co., Ltd. The test results in the report only apply to the tested sample. KES-P-5101-09 Rev.1 KES A4 1.0 General product description Equipment under test FRS / GMRS Model name LXT600 Serial number N/A Frequency Range 462.562 5 ㎒ ~ 462.712 5 ㎒(GMRS Channels 1 ~7) 467.562 5 ㎒ ~ 467.712 5 ㎒(FRS Channels 8 ~ 14) 462.550 0 ㎒ ~ 462.725 0 ㎒(GMRS Channels 15 ~ 22) Emission type 11K0F3E E.R.P. GMRS: 0.101 4 W(High power), 0.081 7 W(Low power) // FRS: 0.077 8 W Number of channel 462.562 5 ㎒ ~ 462.712 5 ㎒(GMRS Channels 1 ~7) 467.562 5 ㎒ ~ 467.712 5 ㎒(FRS Channels 8 ~ 14) 462.550 0 ㎒ ~ 462.725 0 ㎒(GMRS Channels 15 ~ 22) Power source 3 × AAA Alkaline(4.5 V) // Rechargeable Ni-MH battery pack(3.6 V) 1.1 Information about variant model Not applicable 1.2 Device modifications No modifications were made during testing. 1.3 Test facility C3701 Dongil Techno Town, 889-1, Gwanyang 2-dong, Dongan-gu, Anyang-si, Gyeonggi-do, 431-716, Korea 477-6, Hageo-ri, Yeoju-eup, Yeoju-gun, Gyeonggi-do, 469-803, Korea Th…

Text truncated - open the document above for the full version.

KES Co., Ltd. C-3701 Dongil Techno Town, 889-1, Gwanyang 2-dong, Dongan-gu, Anyang-si, Gyeonggi-do, 431-716, Korea Tel: +82-31-425-6200 / Fax: +82-31-424-0450 www.kes.co.kr Test report No.: KES-RF-120035 Page: (35) of (35) This report shall not be reproduced except in full, without the written approval of KES Co., Ltd. The test results in the report only apply to the tested sample. KES-P-5101-09 Rev.1 KES A4 Appendix B. Test setup photo Radiated field emissions
