MMAXTC280AHD Action Camera

1 2 3 4 5 6 Insert Battery - Open battery door and install battery. Record - Slide the record switch for- ward. Recording starts in 8 seconds. Install Micro SD Card - Open & fold down rubber cover and insert Micro SD card. Close the rubber cover. Turn Off - Once you have finished recording, slide the switch to the off position. Mount Your Camera - Mount the camera where needed on your helmet, handle bar, vehicle etc. with the mounts supplied or purchased. Download & View Video - To download video simply remove your Micro SD Card & plug it into your computer. You can also plug your camera into the computer and slide the REC switch to the ON position. midlandusa.com Quick Start Guide 2www.midlandusa.com INDEX Quick Start Guide ..................................................................................................................................................................................1 Welcome to the XTC Action Camera Experience .................................................................................................................................3 What’s in the Box ..................................................................................................................................................................................3 Features and Controls ...........................................................................................................................................................................3 Getting to Know the Camera .................................................................................................................................................................4 Battery .............................................................................................................................................................................................4 Micro SD Card .................................................................................................................................................................................4 Recording ........................................................................................................................................................................................4 Image Stabilization ..........................................................................................................................................................................4 Camera Mounting and Aiming ...............................................................................................................................................................5 Reformatting the Micro SD card ............................................................................................................................................................5 Compatible Systems .............................................................................................................................................................................6 Downloading Videos .............................................................................................................................................................................6 Minimum System Requirements ...........................................................................................................................................................6 Tips and Tricks ......................................................................................................................................................................................7 Service and Technical Support .............................................................................................................................................................8 FCC Information ....................................................................................................................................................................................8 Accessories .........................................................................................................................................................................................25 Accessories Order Form .....................................................................................................................................................................26 Other Midland Products ......................................................................................................................................................................27 www.midlandusa.com 3 English François Español Features and Controls 1080 Features: - 30 frames per second - 118° lens - 16:9 aspect ratio - 1920 x 1080 resolution - Records as mp4 - Image Stabilization 720 Features: - 60 frames per second - 118° lens - 16:9 aspect ratio - 1280 x 720 resolution - Records as mp4 - Image Stabilization 118 Degree Lens Track for Mounting Accessories Microphone RECORD Switch Forward On/ Record RECORD Switch Backward Stop Recording/OFF Record LED Flashes RED when Camera is Recording Battery LED Micro SD Card LED Mini USB Connector Micro SD card Reformat Button Micro SD Card Slot H/L Mode Switch Welcome to the XTC Action Camera Experience Thank you for purchasing the XTC280 Action Camera. As someone who seeks adventure, we are proud to offer you the ultimate tool in capturing and recording your adventures. With easy to use one switch operation, 118° lens and 2 hour battery life, you never miss a minute of the action. Once captured, simply connect to your computer and upload the videos to share with friends. It is that simple. Enjoy! What’s in the Box XTC280VP3 Package Includes: 1. Midland XTC280 Camera 2. Submersible Case 3. USB Cable 4. Lithium-Ion Battery Pack 5. Helmet Adhesive Mount (includes 2 3M adhesive pads) 4www.midlandusa.com Getting to Know the Camera Battery 1. To insert the battery, push down the battery door latch on the right side of the camera. Door will release.…

Text truncated - open the document above for the full version.

Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID: MMAXTC280A Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Theory of Operation Block Diagram The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, We do not want these documents to be accessible to the general public. Sincerely David Free Project ENgineer Midland Radio Corporation Phone: 816-241-8500 E-mail: [email protected]

External photos of the EUT

Internal photos of the EUT

FCC TEST REPORT 47 CFR FCC Part 15 Subpart B Report Reference No. ..................... : FCC ID. ............................................. : TRE13060006 R/C:66072 MMAXTC280A Compiled by ( position+printed name+signature) .. : File administrators Eric Zhang Supervised by ( position+printed name+signature) .. : Test Engineer Yuchao Wang Approved by ( position+printed name+signature) .. : Manager Wenliang Li Date of issue ..................................... : Jun 18, 2013 Testing Laboratory Name .............. : Shenzhen Huatongwei International Inspection Co., Ltd Address ............................................ : Keji Nan No.12 Road, Hi-tech Park, Shenzhen, China Applicant’s name ............................ : Midland Radio Corporation Address ............................................ : 5900 Parretta Drive, Kansas City, MO, 64120, USA Test specification: Standard ........................................... : 47 CFR FCC Part 15 Subpart B - Unintentional Radiators ANSI C63.4: 2009 TRF Originator .................................. : Shenzhen Huatongwei International Inspection CO., Ltd Master TRF ....................................... : Dated 2006-06 Shenzhen Huatongwei International Inspection Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen Huatongwei International Inspection Co., Ltd is acknowledged as copyright owner and source of the material. Shenzhen Huatongwei International Inspection Co., Ltd takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description ..................... : HD Action Camera Trade Mark ....................................... : Manufacturer .................................... : Wicom Electronic Co., Ltd. Model/Type reference ....................... : XTC280 Listed Models .................................. : XTC285 Ratings ............................................. : DC3.7V Supplied by the Battery or DC5.0V Supplied by the PC Result................................................ : Positive Report No.: TRE13060006 Page 2 of 27 Issued:2013-06-18 T E S T R E P O R T Test Report No. : TRE13060006 Jun 18, 2013 ______________________________________________________________________________________________ Date of issue Equipment under Test : HD Action Camera Model /Type : XTC280 Listed Models : XTC285 Applicant : Midland Radio Corporation Address : 5900 Parretta Drive, Kansas City, MO, 64120, USA Manufacturer Wicom Electronic Co., Ltd Address : 4-6/F., Building A2, Penghongxin Industrial Park, Zhoushi Road, Huangmabu Community, Xixiang, Bao'an District, Shenzhen, China Test Result according to the standards on page 4: Positive The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Report No.: TRE13060006 Page 3 of 27 Issued:2013-06-18 Contents 1. TEST STANDARDS .................................................................. 4 2. SUMMARY ............................................................................. 5 2.1. General Remarks 5 2.2. Equipment Under Test 5 2.3. Short description of the Equipment under Test (EUT) 5 2.4. EUT operation mode 5 2.5. Modifications 5 2.6. Configuration of Tested System 5 2.7. NOTE 6 3. TEST ENVIRONMENT ............................................................... 7 3.1. Address of the test laboratory 7 3.2. Test Facility 7 3.3. Environmental conditions 8 3.4. Statement of the measurement uncertainty 8 3.5. Equipments Used during the Test 9 4. TEST CONDITIONS AND RESULTS ............................................ 10 4.1. Conducted Emissions Test 10 4.2. Radiated Emission Test 13 5. EXTERNAL AND INTERNAL PHOTOS OF THE EUT ....................... 21 Report No.: TRE13060006 Page 4 of 27 Issued:2013-06-18 1. TEST STANDARDS The tests were performed according to following standards: 47 CFR FCC Part 15 Subpart B - Unintentional Radiators ANSI C63.4: 2009 – American National Standard for Methods of Measurement of Radio-Noise Emissions from Low-Voltage Electrical and Electronic Equipment in the Range of 9 kHz to 40GHz Report No.: TRE13060006 Page 5 of 27 Issued:2013-06-18 2. SUMMARY 2.1. General Remarks Date of receipt of test sample : Jun 2, 2013 Testing commenced on : Jun 5, 2013 Testing concluded on : Jun 18, 2013 2.2. Equipment Under Test The Midland Radio Corporation’s Model: XTC280 or the “EUT” as referred to in this report; more general information as follows, for more details, refer to the user’s manual of the EUT. Power supply system utilised Power supply voltage : ○ 120V / 60 Hz ○ 115V / 60Hz ○ 12 V DC ○ 24 V DC ● Other (specified in blank below) DC3.7V Supplied by the Battery or DC 5.0V Supplied by the PC 2.3. Short description of the Equipment under Test (EUT) The EUT( (M/N: XTC280)) is HD Action Camera with the function of capturing scene and storing it in a TF card. The structure of M/N: XTC285 is all the same as M/N: XTC280 except for booy color. For more details, refer to the user’s manual of the EUT. Serial number: Prototype 2.4. EUT operation mode The EUT has been tested under typical operating condition recording mode 、charging mode and USB data transfer mode. 2.5. Modifications No modifications were implemented to meet testing criteria. 2.6. Configuration of Tested System Configuration of Tested System EUT PC USB Cable Report No.: TRE13060006 Page 6 of 27 Issued:2013-06-18 Equipment Used in Tested System No. Product Manufacturer Serial No. FCC ID 1 PC DELL E520 ------ 2 Displayer PHLIPS 19PFL3120/T3 ------ USB Line: Cable Length: 120cm ◇ Shielded ◆ Unshielded 2.7. NOTE The EUT is a HD Action Camera,The functions of the EUT listed as below: Test Standards Reference Report EMC REPORT FCC PART 15 Subpart B TRE13060006 Report No.: TRE13060006 Page 7 of 27 Issued:2013-06-18 3.…

Text truncated - open the document above for the full version.

Test setup photos of the EUT
