MMURTI0100Home Theater Universal R/C

TheaterTouch System Controller User’s Guide and Programming Manual T T h h e e P P o o w w e e r r O O f f A A T T o o u u c c h h s s c c r r e e e e n n I In T T h he P Pa l lm O O f f TheaterTouch System Controller FEDERAL COMMUNICATIONS COMMISSION NOTICE This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and the receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference and (2) this device must accept any interference received, including interference that may cause undesired operation. For environmental reasons, your TheaterTouch universal system controller uses “environmentally sound” nickel-metal hydride rechargeable batteries. The batteries do not contain any poisonous heavy metals that can damage the environment. In the interest of recycling, please do not dispose of these batteries in the household waste at the end of their useful life. Instead, dispose of them at an appropiate collection site. Copyright © 2000 Remote Technologies Incorporated All rights reserved. Part No. 70-210009-19 Printed in the United States TheaterTouch System Controller Remote Technologies Incorporated • 7630 Executive Dr. • Eden Prairie, MN • 55344 - 3677 USA www.rticorp.com • Tel: 612-937-2600 • Fax: 612-937-7527 SAFETY SUGGESTIONS Read Instructions. Read all safety and operating instructions before operating the unit. Retain Instructions. Keep the safety and operating instructions for future reference. Heed Warnings. Adhere to all warnings on the unit and in the operating instructions. Follow Instructions. Follow operating instructions and instructions for use. Heat. Keep the unit away from heat sources such as radiators, heat registers, stoves, etc., including amplifiers that produce heat. Power Sources. Connect the unit only to a power supply of the type described in the operating instructions, or as marked on the unit. Power Cord Protection. Route power supply cords so that they are not likely to be walked on or pinched by items placed on or against them, paying particular attention to the cords at plugs, at convenient receptacles, and at the point at which they exit from the unit. Nonuse Periods. Unplug the power supply from the outlet when the unit is to be left unused for a long period. Water and Moisture. Do not use the unit near water—for example, near a sink, in a wet basement, near a swimming pool, near an open window, etc. Object and Liquid Entry. Do not allow objects to fall or liquids to be spilled into the enclosure through openings. Cleaning. The unit should be cleaned only as recommended by the manufacturer. Servicing. Do not attempt any service beyond that described in the operating instructions. Refer all other service needs to qualified service personnel. Damage Requiring Service. The unit should be serviced by qualified service personnel when: • The power supply cord or the plug has been damaged. • Objects have fallen or liquid has been spilled into the unit. • The unit has been exposed to rain. • The unit does not appear to operate normally or exhibits a marked change in performance. • The unit has been dropped, or the enclosure damaged. WARNING ! TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THE UNIT TO RAIN OR MOISTURE. TheaterTouch System Controller VI LIMITED WARRANTY AND DISCLAIMER Remote Technologies Incorporated warrants its products for a period of one (1) year from the date of purchase from Remote Technologies Incorporated or an authorized Remote Technologies Incorporated dealer. This warranty may be enforced by the original purchaser and subsequent owners during the warranty period, so long as the original dated sales receipt or other proof of warranty coverage is presented when warranty service is required. Except as specified below, this warranty covers all defects in material and workmanship in this product. The following are not covered by the warranty: Damage resulting from: 1. Accident, misuse, abuse, or neglect. 2. Failure to follow instructions contained in your User’s Guide. 3. Repair or attempted repair by anyone other than Remote Technologies Incorporated. 4. Failure to perform recommended periodic maintenance. 5. Causes other than product defects, including lack of skill, competence or experience of user. 6. Shipment of this product (claims must be made to the carrier). 7. Being altered or which the serial number has been defaced, modified or removed. Remote Technologies Incorporated is not liable for any damages caused by its products or for its failure of its products to perform, including any lost profits, lost savings, incidental damages, or consequential damages. Remote Technologies Incorporated is not liable for damages based upon inconvenience, loss of use of the product, loss of time, interrupted operation, commercial loss, any claim made by a third party or made by you for a third party. Remote Technologies Incorporated’s liability for any de…

Text truncated - open the document above for the full version.

DCBA 4321 DC BA 4321 PAGE 1 OF 1 TITLE REMOTE BOTTOM . . REMOTE TECHNOLOGIES INC. EDEN PRAIRIE, MN 55344 PART NO. DOCUMENT NO REV. SIZE A This is an unpublished work containing Remote Technologies Inc. confidential and proprietary information. Disclosure, use or reproduction without the written authorization of Remote Technologies Inc. is strictly prohibited. MODEL APPROVALS DATE DFTGCHKD MFG APPVL REVISION RECORD REV DESCRIPTION DATE DRAFT FINISHMATERIAL MM (INCH) 25.4MM = 1 INCH TOLERANCES EXCEPT AS NOTED INCHES .0 } 0.1 .00 } 0.01 .000 } 0.005 DO NOT SCALE DRAWING NOTES A1 A1 MCM Placement of FCC labelThe FCC label is located on the bottom ofunit as shown in the picture below. TheaterTouch System Controller Remote Technologies Inc. www.rticorp.com Made in Taiwan ROC FCC ID MMURTI0100 Model Serial Number

DCBA 4321 DC BA 4321 PAGE 1 OF 1 TITLE PRODUCT ID LABEL . . REMOTE TECHNOLOGIES INC. EDEN PRAIRIE, MN 55344 PART NO. DOCUMENT NO REV. SIZE C This is an unpublished work containing Remote Technologies Inc. confidential and proprietary information. Disclosure, use or reproduction without the written authorization of Remote Technologies Inc. is strictly prohibited. MODEL APPROVALS DATE DFTG CHKD MFG APPVL REVISION RECORD REV DESCRIPTION DATE DRAFT FINISHMATERIAL MM (INCH) 25.4MM = 1 INCH TOLERANCES EXCEPT AS NOTED INCHES .0 } 0.1 .00 } 0.01 .000 } 0.015 DO NOT SCALE DRAWING NOTES A1 Initial Release 12/27/99 1. MATERIAL: IDENTCO TT705, GLOSSY WHITE, SYNTHETIC .003" THICK, THERMAL TRANSFER FILM. OVERLAMINATED WITH CLEAR MATTE FINISH. ADHESIVE TO BE .001" THICK PERMANENT ACRYLIC PRESSURE SENSITIVE ADHESIVE, WITH A 50 LB. RELEASE LINER. BACKGROUND COLOR TO BE BLACK.2. VENDOR TO SUBMIT FIRST PIECE SAMPLE(S) FOR APPROVAL OF DIE-CUTS, THERMAL TRANSFER AND COLOR PRIOR TO PRODUCTION.3. GRAPHICS TO BE DIRECT READING FROM FRONT SIDE OF PIECE.4. PRINTING TO BE OF SUFFICIENT GRADE TO PREVENT ANY DEGRADATION, BLURRING, OR "SAWTOOTHING" OF LEGENDS WHEN VIEWED AT A DISTANCE OF 18". MATERIAL SEQUENCE - MATTE FINISH- COLOR (BLACK)- GLOSSY WHITE POLYESTER .003"- PERMANENT ACRYLIC ADHESIVE .001"- RELEASE LINER JMD THEATERTOUCH T2 A1 12/27/99 MCM T2 Battery Charger www.rticorp.com Remote Technologies Inc. USE ONLY ORIGINAL POWER SUPPLY TheaterTouch System Controller Remote Technologies Inc. www.rticorp.com Made in Taiwan ROC FCC ID MMURTI0100 Model 2.210 [56.14MM] 1.010 [25.66MM] BLACK BACKGROUNDWHITE LEGENDSERIAL NUMBER PRINTING AREA MODEL PRINTING AREA FCC ID NUMBER WITH WHITE INSERT WHITE INSERT 40-210040-11 40-210040-10-12 SERIAL NUMBERSSERIAL NUMBERS = 010-XXXXXX START AT 001000 (one thousand)AND INCREMENT. INCREMENT EACH LABEL BY 1 (one)i.e. 010-001001, 010-001002, 010-001003,....... 010 = PRODUCT CODE XXXXXX = SEQUENTIAL SERIAL NUMBER Serial Number

TheaterTouch System Controller Remote Technologies Inc. www.rticorp.com Made in Taiwan ROC Serial Number FCC ID MMURTI0100Model

Remote Technologies Incorporated TheaterTouch System Controller Block/Signal Diagram 418 MHz MCU (Dallas 80C320) SRAM Memory PROM Memory FLASH Memory Linx RF Transmitter 418Mhz Linx Splatch Antenna PPI Port Expander LCD Display 24Mhz Oscillator Battery Negative Contrast Supply VoltageInverter (Backlight) VCC Supply

A REMOTE TECHNOLOGIES INC. Application For Certification TheaterTouch System Controller (FCC ID: MMURTI0100) February 28, 2000 All services undertaken are subject to the following general policy: Reports are submitted for exclusive use of the client to whom they are addressed. Their significance is subject to the adequacy and representative character of the samples and to the comprehensiveness of the tests, examinations or surveys made. No quotations from reports or use of Intertek Testing Services name is permitted except as expressly authorized by Intertek Testing Services in writing. The report must not be used by the client to claim product endorsement by NVLAP or any agency of the U.S. Government. The NVLAP logo is applicable for testing to I EC/CISPR 22:1993 and FCC-47 CFR part 15 only. A TABLE OF CONTENTS 1.0General Description............................................................................................1 1.1Related Submittal(s) Grants ..........................................................................1 1.2Product Description ...................................................................................1 1.3Test Methodology .....................................................................................1 1.4Test Facility ............................................................................................1 2.0System Test Configuration...................................................................................2 2.1Justification .............................................................................................2 2.2EUT Exercising Software ............................................................................2 2.3Special Accessories....................................................................................2 2.4Equipment Modification ..............................................................................2 2.5Support Equipment List and Description ..........................................................2 2.6Test Configuration Block Diagram .................................................................2 3.0Emission Results................................................................................................3 3.1Field Strength Calculation............................................................................3 3.2Radiated Emission Data ..............................................................................4 3.3Test Equipment ........................................................................................5 4.0Test Procedures.................................................................................................6 EXHIBIT I Test Set Up Photographs .......................................................................................6 EXHIBIT II Emissions Test Data........................................................................................... 16 EXHIBIT III FCC ID Label Location ...................................................................................... 26 EXHIBIT IV Internal Photographs .......................................................................................... 27 EXHIBIT V Electrical Schematics and Block Diagram................................................................. 28 EXHIBIT VI User Manual and Operational Description ................................................................ 29 A FCC ID: MMURTI0100Report No:J99025762 – February 28, 2000 Page 1 of 29 1.0 GENERAL DESCRIPTION 1.1 Related Submittals Grants This is single application of the TheaterTouch System Controller for Certification under Part 15.231 There are no other simultaneous applications . 1.2 Product Description Purpose of the TheaterTouch The intended use of the TheaterTouch unit is to transmit IR, (infrared) control signals to home electronic devices. These devices include VCRs, DVD players, TV cable boxes, audio surround decoders, satellite receivers, televisions, etc. The TheaterTouch is a custom programmable device that contains a touchscreen display and keypad buttons. The Touchscreen display and keypad are programmed with the user set of electronic equipment and the parameters that can be controlled. The user interface on the touchscreen display is also custom programmable. The TheaterTouch is then programmed with the IR controls for each electronic device that the user desires to use. TheaterTouch Transmitter When the user interface for the electronic devices to be controlled and the IR control signals have been programmed into the TheaterTouch it is ready to use. When a user presses on the touchscreen or keypad to transmit, for example to start the play control on a VCR, the microprocessor, 80C320, senses the push via a PPI, 82C55. The IR control signal corresponding to that location on the touchscreen or keypad is then pulled from the FLASH memory. When the IR control signal is identified, the control signal is routed to the RF transmitter board. The control signal is modulated on the RF transmitter board and output. All timing is derived from 24MHz and 418MHz oscillators. TheaterTouch Antenna The antenna on the TheaterTouch is a grounded line SMD Planar (Splatch), soldered to the RF module, internal to the chassis and is not easily accessible. Receiver The receiver module demodulates the RF signal and combines the IR control signals carrier frequency to acquire the IR control signal. The IR control signal is then routed out to a connector on the receiver and is now available to the home electronic devices. A FCC ID: MMURTI0100Report No:J99025762 – February 28, 2000 Page 2 of 29 1.3Test Methodology Radiated emission measurements were performed according to the procedures in ANSI C63.4 (1992). All measurements were performed in Open Area Test Sites. Preliminary scans were performed in the Open Area Test Sites only to determine worst case modes. For each scan, the procedure for maximizing emissions in Appendices D and E were followed. All Radiated t…

Text truncated - open the document above for the full version.

Remote Technologies Incorporated •7630 Executive Dr. • Eden Prairie, MN 55344 • Tel. 612.937.2600 • Fax 612.937.7527 TheaterTouch RF Functional Circuit Description Purpose of the TheaterTouch The intended use of the TheaterTouch unit is to transmit IR, (infrared) co ntrol signals to home electro nic devices. These devices include VCRs, DVD players, TV cable boxes, audio surround decoders, satellite receivers, televisions, etc. The TheaterTouch is a custom programmable device that contains a touchscreen display and keypad butto ns. The Touchscreen display and keypad are programmed with the users set of electronic equipment and the parameters that can be controlled. The user interface on the touchscreen display is also custom programmable. The TheaterTouch is then programmed with the IR controls for each electronic device that the user desires to use. TheaterTouch Transmitter When the user interface for the electronic devices to be co ntrolled and the IR co ntrol signals have been programmed into the TheaterTouch it is ready to use. When a user presses on the touchscreen or keypad to transmit, for example to start the play co ntro l on a VCR, the microprocessor, 80C320, senses the push via a PPI, 82C55. The IR co ntrol signal corresponding to that location on the to uchscreen or keypad is then pulled from the FLASH memory. When the IR control signal is identified, the co ntrol signal is routed to the RF transmitter board. The control signal is modulated on the RF transmitter board and o utput. All timing is derived from 24MHz and 418MHz oscillators. TheaterTouch Antenna The antenna on the TheaterTouch is a grounded line SMD Planar (Splatch), soldered to the RF module, internal to the chassis and is not easily accessible. Receiver The receiver module demodulates the RF signal and combines the IR co ntrol signals carrier frequency to acquire the IR co ntrol signal. The IR co ntrol signal is then ro uted o ut to a connector on the receiver and is now available to the home electronic devices.
