MMURTI1900Advanced Control Processor

 It’s Under Control ® This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: Reorient or relocate the receiving antenna. Increase the separation between the equipment and the receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference. 2. This device must accept any interference received including interference that may cause undesired operation. Federal CommuniCations Commission notiCe deClaration oF ConFormitY (doC) The Declaration of Conformity for this product can be found on the RTI website at: www.rticorp.com/declaration 117 612 914 FCC id: mmurti1900 iC (Canada): 3166a-rti1900

DC BA 4321 DC BA 4321 PAGE 1OF 1 TITLE PRODUCT ID LABEL . . REMOTE TECHNOLOGIES INC. Shakopee, MN 55379 PART NO. DOCUMENT NO REV. SIZE C This is an unpublished work containing Remote Technologies Inc. confidential and proprietary information. Disclosure, use or reproduction without the written authorization of Remote Technologies Inc. is strictly prohibited. MODEL APPROVALS DATE DFTG CHKD MFG APPVL REVISION RECORD REV DESCRIPTION DATE DRAFT FINISHMATERIAL MM (INCH) 25.4MM = 1 INCH TOLERANCES EXCEPT AS NOTED INCHES .0 } 0.1 .00 } 0.01 .000 } 0.015 DO NOT SCALE DRAWING NOTES A1 Initial Release 03/17/11 - MATTE OR GLOSS FINISH-COLOR (BLACK)- GLOSSY WHITE POLYESTER .003"- PERMANENT ACRYLIC ADHESIVE .001"- RELEASE LINER MAB XP-3 A1 03/17/11 MAB 2.00 [50.80mm] 1.50 [38.10mm] 40-210541-17 XP-3 Advanced Control Processor Remote Technologies Inc www.rticorp.com Serial No. 0.025 R [0.65mm] XP3/01 SERIAL NUMBERS = 610-WWYXXXX START AT 0001 AND INCREMENTRESET TO 0001 WHEN WEEK CHANGES INCREMENT EACH LABEL BY 1 (one)i.e. 610-0110001, 610 -0110002,....... 610 = PRODUCT CODE XXXX = SEQUENTIAL UNIT NUMBER WW = WEEK OF MANUFACTURE (01 - 52) Y = YEAR IN PRODUCTION (1 - 9) Model P/N 20-210142-12 N27917 1. MATERIAL: IDENTCO TT705, GLOSSY WHITE, SYNTHETIC .003" THICK, THERMAL TRANSFER FILM. ADHESIVE TO BE .001" THICK PERMANENT ACRYLIC PRESSURE SENSITIVE ADHESIVE, WITH A 50 LB. RELEASE LINER. BACKGROUND COLOR TO BE BLACK.2. VENDOR TO SUBMIT FIRST PIECE SAMPLE(S) FOR APPROVAL OF DIE-CUTS, THERMAL TRANSFER AND COLOR PRIOR TO PRODUCTION.3. GRAPHICS TO BE DIRECT READING FROM FRONT SIDE OF PIECE.4. PRINTING TO BE OF SUFFICIENT GRADE TO PREVENT ANY DEGRADATION, BLURRING, OR "SAWTOOTHING" OF LEGENDS WHEN VIEWED AT A DISTANCE OF 18". XP-3 Made in Taiwan A2 Power DC 12V 1A FCC ID: MMURTI1900 IC: 3166A-RTI1900

TEST REPORT Report Number: 100356551MIN-001 Project Number: G100356551 Testing performed on the XP-3 FCC ID: MMURTI1900 Industry Canada ID: 3166A-RTI1900 to 47 CFR Part 15. 249:2009 RSS- 210, Issue 8, 2010 47 CFR, Part 15:2009, §15.107 and §15.109, Class B RSS-Gen, Issue 3, 2010 ICES-003, Issue 4:2004 For Remote Technologies Inc Test Performed by: Test Authorized by: Intertek Testing Services NA, Inc. 7250 Hudson Blvd., Suite 100 Oakdale, MN 55128 USA Remote Technologies 5775-12th Avenue East, Suite 180 Shakopee, MN 55379 Prepared by: Date: May 23, 2011 Simon Khazon Reviewed by: Date: May 23, 2011 Norman Shpilsher This report is for the exclusive use of Intertek's Client and is provided pursuant to the agreement between Intertek and its Client. Intertek's responsibility and liability are limited to the terms and conditions of the agreement. Intertek assumes no liability to any party, other than to the Client in accordance with the agreement, for any loss, expense or damage occasioned by the use of this report. Only the Client is authorized to copy or distribute this report and then only in its entirety. Any use of the Intertek name or one of its marks for the sale or advertisement of the tested material, product or service must first be approved in writing by Intertek. The observations and test results in this report are relevant only to the sample tested. This report by itself does not imply that the material, product, or service is or has ever been under an Intertek certification program. This report must not be used to claim product endorsement by A2LA, NIST nor any other agency of the U.S. Government. EMC Report No: 100356551MIN-001 FCC ID: MMURTI1900 IC ID: 3166A-RTI1900 Page 2 of 42 TABLE OF CONTENTS 1.0 GENERAL DESCRIPTION.......................................................................................................... 3 1.1 Product Description; Test Facility ....................................................................................... 4 1.3 Environmental conditions.................................................................................................... 5 1.4 Measurement uncertainty ................................................................................................... 6 1.5 Field Strength Calculation................................................................................................... 6 2.0 TEST SUMMARY.......................................................................................................................... 7 3.0 TEST CONDITIONS AND RESULTS........................................................................................ 8 3.1 Field strength of fundamental and of harmonics and spurious emissions ......................... 8 3.2 Bandwidth of Emissions.................................................................................................... 25 3.3 Transmitter power line conducted emissions ................................................................... 32 3.4 Receiver/digital device radiated emissions....................................................................... 35 3.5 Digital device conducted emissions.................................................................................. 39 4.0 TEST EQUIPMENT..................................................................................................................... 42 EMC Report No: 100356551MIN-001 FCC ID: MMURTI1900 IC ID: 3166A-RTI1900 Page 3 of 42 1.0 GENERAL DESCRIPTION Model: XP-3, with RTI AC Adaptor model KSAS0101200100M2 Type of EUT: Advanced Control Processor Serial Number: N/A FCC ID: MMURTI1900 Industry Canada ID: 3166A-RTI1900 Related Submittal(s) Grants: N/A Company: Remote Technologies Inc. Customer: Mr. Mark Melville Address: 5775-12 th Avenue East Suite 180 Shakopee MN 55379 Phone: (952) 253-3116 Fax: (952) 253-3131 e-mail: [email protected] Test Standards: 47 CFR, Part 15:209, §15.249 RSS–210, Issue 8, 20010 RSS-Gen, Issue 3, 2010 47 CFR, Part 15:209, §15.107 and §15.109, Class B ICES-003, Issue 4:2004 Other Type of radio: Stand -alone Module Hybrid Date Sample Submitted: March 10, 2011 Test Work Started: March 10, 2011 Test Work Completed: March 25, 2011 Test Sample Conditions: Damaged Poor (Usable) Good EMC Report No: 100356551MIN-001 FCC ID: MMURTI1900 IC ID: 3166A-RTI1900 Page 4 of 42 1.1 Product Description; Test Facility Product Description: Advanced Control Processor Operating Frequency 2400-2483.5 MHz Modulation: Offset Quadrature Phase Shift Keying Emission Designator: 3M6G1D Antenna(s) Info: Bobbintron SA-006-01 external ½ wavelength antenna Antenna Installation: User Professional Factory Transmitter Power Configuration: Internal battery External power source 10-240VAC 400VAC VDC Other: USB 5VDC from the Host PC 0.4 Amp. 50/60Hz 60Hz Special Test Arrangement: None Test Facility Accreditation: A2LA (Certificate No. 1427.01) Test Methodology: Measurements performed according to the procedures in ANSI C63.10- 2009 EMC Report No: 100356551MIN-001 FCC ID: MMURTI1900 IC ID: 3166A-RTI1900 Page 5 of 42 1.2 EUT Configuration The equipment under test was operated during the measurement under the following conditions: - Standby - Continuous - Test program (customer specific) - Operating modes of the EUT: No. Description 1 The device was pre-programmed to transmit continuously in three separate frequency channels, low, middle, and upper frequency channel, one channel being transmitted at a given time. 2 Standby/Receiving mode Cables: No. Type Length Designation Note 1 Shielded, USB 6ft. Software loading 2 8 wires, unshielded 6 ft Power/Sense/Relays 3 Unshielded, RJ45 15 ft Ethernet 4 Unshielded, RJ45 6 ft RS-232 5 (2) Unshielded, Audio 6 ft Port 1 and 2 Support equipment/Services: No. Item Description 1 Dell Notebook, Latitude D610 Host PC 1.3 Environmental conditions During the measurement the environmental conditions were within the listed ranges: Normal Temperature: 15-35 ° C Humidity: 30-60 % Atmospheric pressu…
