MMURTI0800T3V Remote Control

FEDERAL COMMUNICATIONS COMMISSION NOTICE This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and the receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC ID: MMURTI0800 CONTAINS FCC ID : S2 Y-WL A N-11B-G CAN : 3166-R TI 0800

Remote Technologies Incorporated TheaterTouch System Controlle r RF Block/Signal Diagram 300-5000 BPS 01-28-2000 Vcc Data In SAW Oscillato r RF Amplifie r Output Isolation and Filte r Keyed Output 50 Ohm RF Out (Ant.) 433 MHz Remote Technologies Incorporated TheaterTouch T3V System Controlle r Block/Signal Diagram 433 MHz Battery Voltage Regulators (Backlights) CPU Power Supply PXA255 3.6864Mhz Crystal Flash SDRAM Codec & Speakers 24.576 MHz SDIO Socket RF Dau g hterboard LCD Display Linx RF Transmitte r 433Mhz Linx Splatch Antenna

Remote Technologies, Inc. 7651 Anagram Drive Eden Prairie, MN 55344 January 23, 2008 To: Intetek ETL Semko Subject: Confidentiality Request FCC ID: MMURTI0800 Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of the following information accompanying this Application: – T3V Main Board Schematic – T3V RF Daughterboard Schematic The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of this information might be harmful to the Applicant and provide unjustified benefits to its competitors Sincerely, Paul Weichelt Electrical Engineer Remote Technologies, Inc.

D C B A 4321 D C B A 4321 PAGE 1 OF 1 TITLE PRODUCT ID LABEL .. REMOTE TECHNOLOGIES INC. EDEN PRAIRIE, MN 55344 PART NO.DOCUMENT NOREV.SIZE C This is an unpublished work containing Remote Technologies Inc. confidential and proprietary information. Disclosure, use or reproduction without the written authorization of Remote Technologies Inc. is strictly prohibited. MODEL APPROVALSDATE DFTG CHKD MFG APPVL REVISION RECORD REVDESCRIPTIONDATEDRAFT FINISH MATERIAL MM (INCH) 25.4MM = 1 INCH TOLERANCES EXCEPT AS NOTED INCHES .0 } 0.1 .00 } 0.01 .000 } 0.015 DO NOT SCALE DRAWING NOTES A1 Initial Release12/27/07 1. MATERIAL: IDENTCO TT705, GLOSSY WHITE, SYNTHETIC .003" THICK, THERMAL TRANSFER FILM. ADHESIVE TO BE .001" THICK PERMANENT ACRYLIC PRESSURE SENSITIVE ADHESIVE, WITH A 50 LB. RELEASE LINER. BACKGROUND COLOR TO BE BLACK. 2. VENDOR TO SUBMIT FIRST PIECE SAMPLE(S) FOR APPROVAL OF DIE-CUTS, THERMAL TRANSFER AND COLOR PRIOR TO PRODUCTION. 3. GRAPHICS TO BE DIRECT READING FROM FRONT SIDE OF PIECE. 4. PRINTING TO BE OF SUFFICIENT GRADE TO PREVENT ANY DEGRADATION, BLURRING, OR "SAWTOOTHING" OF LEGENDS WHEN VIEWED AT A DISTANCE OF 18". MATERIAL SEQUENCE - MATTE FINISH - COLOR (BLACK) - GLOSSY WHITE POLYESTER .003" - PERMANENT ACRYLIC ADHESIVE .001" - RELEASE LINER JMD T3-V A1 12/27/07 JMD Made in Taiwan 1.00 [25.40mm] 0.190 [4.80mm] 40-210374-21 40-210374-10-22 SERIAL NUMBERS P/N 20-210066-17FCC ID: MMURTI0800 S/N For Home or Office Use 0.070 R [1.80mm] SERIAL NUMBERS = 260-WWYXXXX START AT 0001 AND INCREMENT RESET TO 0001 WHEN WEEK CHANGES INCREMENT EACH LABEL BY 1 (one) i.e. 260-0110001, 260-0110002, 260-0110003,....... 260 = PRODUCT CODE XXXX = SEQUENTIAL UNIT NUMBER WW = WEEK OF MANUFACTURE (01 - 52) Y = YEAR IN PRODUCTION (1 - 9) D C B A 4321 D C B A 4321 PAGE 1 OF 1 TITLE PRODUCT ID LABEL .. REMOTE TECHNOLOGIES INC. EDEN PRAIRIE, MN 55344 PART NO.DOCUMENT NOREV.SIZE C This is an unpublished work containing Remote Technologies Inc. confidential and proprietary information. Disclosure, use or reproduction without the written authorization of Remote Technologies Inc. is strictly prohibited. MODEL APPROVALSDATE DFTG CHKD MFG APPVL REVISION RECORD REVDESCRIPTIONDATEDRAFT FINISH MATERIAL MM (INCH) 25.4MM = 1 INCH TOLERANCES EXCEPT AS NOTED INCHES .0 } 0.1 .00 } 0.01 .000 } 0.015 DO NOT SCALE DRAWING NOTES A1 Initial Release12/27/07 1. MATERIAL: IDENTCO TT705, GLOSSY WHITE, SYNTHETIC .003" THICK, THERMAL TRANSFER FILM. OVERLAMINATED WITH CLEAR MATTE FINISH. ADHESIVE TO BE .001" THICK PERMANENT ACRYLIC PRESSURE SENSITIVE ADHESIVE, WITH A 50 LB. RELEASE LINER. BACKGROUND COLOR TO BE MEDIUM GRAY. 2. VENDOR TO SUBMIT FIRST PIECE SAMPLE(S) FOR APPROVAL OF DIE-CUTS, THERMAL TRANSFER AND COLOR PRIOR TO PRODUCTION. 3. GRAPHICS TO BE DIRECT READING FROM FRONT SIDE OF PIECE. 4. PRINTING TO BE OF SUFFICIENT GRADE TO PREVENT ANY DEGRADATION, BLURRING, OR "SAWTOOTHING" OF LEGENDS WHEN VIEWED AT A DISTANCE OF 18". MATERIAL SEQUENCE - MATTE OR GLOSS FINISH - COLOR (BLACK) - GLOSSY WHITE POLYESTER .003" - PERMANENT ACRYLIC ADHESIVE .001" - RELEASE LINER JMD T3-V A1 12/27/07 JMD T3-V Universal System Controller Docking Station Remote Technologies Inc www.rticorp.com 1.97 [50.0mm] 1.22 [31.0mm] 40-210375-22 40-210375-10-23 P/N 20-210067-18 LED: Red = Charging, Blue = Charge Complete Made in Taiwan For indoor use only For use with supplied power adapter only DC 6V 1A + - T3V/01

Universal System Controller Operational Description Purpose of the TheaterTouch The intended use of the Universal System Controller is to transmit IR, (infrared) control signals to home electronic devices. These devices include VCRs, DVD players, TV cable boxes, audio surround decoders, satellite receivers, televisions, etc. The Universal System Controller is a custom programmable device that contains a touchscreen display and keypad buttons. The Touchscreen display and keypad are programmed with the users set of electronic equipment and the parameters that can be controlled. The user interface on the touchscreen display is also custom programmable. The Universal System Controller is then programmed with the IR controls for each electronic device that the user desires to use. Universal System Controller Transmitter When the user interface for the electronic devices to be controlled and the IR control signals have been programmed into the Universal System Controller it is ready to use. When a user presses on the touchscreen or keypad to transmit, for example to start the play control on a VCR, the microprocessor, PXA255, senses the push. The PXA sends a serial command to the RF transmitter board. The control signal is modulated on the RF transmitter board and output. The RF signal is received by an external device and converted to an IR signal to control the intended device. The PXA255 microprocessor uses an internal PLL running at 200 MHz which is fed from an external 3.6864 crystal. The RF module uses an internal 433MHz SAW oscillator. TheaterTouch Antenna The antenna on the Universal System Controller is a grounded line SMD Planar (Splatch), soldered to the RF module, internal to the chassis and is not easily accessible. Remote Technologies Incorporated •7630 Executive Dr. • Eden Prairie, MN 55344 • Tel. 612.937.2600 • Fax 612.937.7527

TEST REPORT Report Number: 3138589MIN-001 Project Number: 3138589 Testing performed on the T3V FCC ID: MMURTI0800 Industry Canada ID: 3166-RTI0800 to 47 CFR Part 15. 231:2006 RSS- 210 , Issue 7, 2007 For Remote Technologies Inc. Test Performed by: Test Authorized by: Intertek Testing Services NA, Inc. 7250 Hudson Blvd., Suite 100 Oakdale, MN 55128 Remote Technologies 7651 Anagram Drive Eden Prairie, MN 55344 Prepared by: Date: December 3, 2007 Norman Shpilsher Reviewed by: Date: December 3, 2007 Uri Spector This report is for the exclusive use of Intertek's Client and is provided pursuant to the agreement between Intertek and its Client. Intertek's responsibility and liability are limited to the terms and conditions of the agreement. Intertek assumes no liability to any party, other than to the Client in accordance with the agreement, for any loss, expense or damage occasioned by the use of this report. Only the Client is authorized to copy or distribute this report and then only in its entirety. Any use of the Intertek name or one of its marks for the sale or advertisement of the tested material, product or service must first be approved in writing by Intertek. The observations and test results in this report are relevant only to the sample tested. This report by itself does not imply that the material, product, or service is or has ever been under an Intertek certification program. This report must not be used to claim product endorsement by A2LA, NIST nor any other agency of the U.S. Government. EMC Report No: 3138589MIN-001 FCC ID: MMURTI0800 IC ID: 3166-RTI0800 Page 2 of 26 TABLE OF CONTENTS 1.0 GENERAL DESCRIPTION.............................................................................. 3 1.1 Product Description; Test Facility......................................................................................4 1.3 Environmental conditions ..................................................................................................5 1.4 Measurement uncertainty..................................................................................................6 1.5 Field Strength Calculation .................................................................................................6 2.0 TEST SUMMARY.......................................................................................... 7 3.0 TEST CONDITIONS AND RESULTS................................................................. 8 3.1 Transmitter deactivation time ............................................................................................8 3.2 Transmitter field strength of emissions .............................................................................9 3.2.1 Average correction factor calculation .............................................................. 13 3.3 Bandwidth of Emissions ..................................................................................................17 3.4 Transmitter power line conducted emissions ..................................................................20 3.5 Digital device radiated emissions ....................................................................................21 3.6 Digital device conducted emissions ................................................................................25 4.0 TEST EQUIPMENT.......................................................................................26 EMC Report No: 3138589MIN-001 FCC ID: MMURTI0800 IC ID: 3166-RTI0800 Page 3 of 26 1.0 GENERAL DESCRIPTION Model: T3V Type of EUT: Universal Remote Control Serial Number: N/A FCC ID: MMURTI0800 Industry Canada ID: 3166-RTI0800 Related Submittal(s) Grants: None Company: Remote Technologies Customer: Mr. Paul Weichelt Address: 7651 Anagram Drive Eden Prairie, MN 55344 Phone: (952) 253-3113 Fax: (952) 253-3131 Test Standards: FCC Part 15.231 RSS–210, Issue 7, 2007 RSS-Gen, Issue 1, 2005 47 CFR, Part 15:2005, §15.107 and §15.109, Class B Other Type of radio: Stand -alone Module Hybrid Date Sample Submitted: November 28, 2007 Test Work Started: November 28, 2007 Test Work Completed: November 29, 2007 Test Sample Conditions: Damaged Poor (Usable) Good EMC Report No: 3138589MIN-001 FCC ID: MMURTI0800 IC ID: 3166-RTI0800 Page 4 of 26 1.1 Product Description; Test Facility Product Description: Remote control transmitter Operating Frequency 433.9 MHz Modulation: Emission Designator: Antenna(s) Info: Integral Antenna Antenna Installation: User Professional Factory Transmitter power configuration: Internal rechargeable battery External power source 120VAC 230VAC 400VAC 3.6 VDC Other: Amp. 50Hz 60Hz Test Methodology: Emission measurements were performed according to the procedures in ANSI C63.4-2003. All field strength radiated emissions measurements were performed in the semi-anechoic chamber, and for each scan, the procedure for maximizing emissions in were followed. All field strength radiated tests were performed at an antenna to EUT distance of 3 meters, unless stated otherwise in the "Justification Section" of this Application Special Test Arrangement: As a hand-held device the EUT was rotated through three orthogonal axes to determine and tested with the maximum emissions Test Facility: The test site facility used to collect the radiated and conducted measurement data is located at 7250 Hudson Blvd., Suite 100, Oakdale, Minnesota. This test facility has been accredited by A2LA (Certificate No. 1427.01) Justification: None EMC Report No: 3138589MIN-001 FCC ID: MMURTI0800 IC ID: 3166-RTI0800 Page 5 of 26 1.2 EUT Configuration The equipment under test was operated during the measurement under the following conditions: - Standby - Continuous - Continuous transmission (see below) - Test program (customer specific) - Operating modes of the EUT: No. Description 1 The special test mode which allowed transmit continuously was used 2 Cables: No. Type Length Designation Note 1 None 2 Support equipment/Services: No. Item Description 1 None 2 1.3 Environmental condi…

Text truncated - open the document above for the full version.

Test Setup Photos
