MNT-G2BTSonik G2BT Base Transmitter

Sonik G2BT Base Transmitter User Manual March 14, 2002 1 7M487C4 2 nd Generation Base Transmitter (G2BT) User Manual Sonik G2BT Base Transmitter User Manual March 14, 2002 2 7M487C4 Vytek Wireless, Inc. Wireless Products Division 2310 Cousteau Court Vista, CA 92083 (760) 536-1000 Sonik G2BT Base Transmitter User Manual March 14, 2002 3 7M487C4 Table of Contents 1 Foreword ....................................................................................................................................... 6 1.1 General Information .................................................................................................. 6 1.2 Computer Software Copyrights................................................................................. 6 1.3 Warnings! ..................................................................................................................8 1.4 Human Exposure ....................................................................................................... 8 2 General Overview.......................................................................................................................... 9 2.1 G2BT Paging Transmitter Overview ........................................................................ 9 2.2 Cabinet Layout/Component Identification................................................................ 9 2.2.1 AC Distribution Module.................................................................................... 9 2.2.2 Amplifier Power-Supplies............................................................................... 10 2.2.3 CE Chassis................................................................................................... 10 2.2.4 Amplifier Indicators ........................................................................................ 10 3 Specifications .............................................................................................................................. 12 3.1 RF Specifications .................................................................................................... 12 3.2 Network & Protocol Specifications ........................................................................ 12 3.3 Power Specifications ............................................................................................... 12 3.4 Mechanical Specifications....................................................................................... 12 3.5 Communications Interface Specifications............................................................... 13 3.6 Environmental Specifications ................................................................................. 13 4 Electrical RequirEments.............................................................................................................. 14 5 Site Planning ............................................................................................................................... 15 6 Installation ................................................................................................................................... 16 6.1 Cabinet Grounding .................................................................................................. 16 6.2 Antenna Connections .............................................................................................. 16 6.2.1 GPS.................................................................................................................. 16 6.2.2 Transmitter RF ................................................................................................ 17 6.2.3 Satellite Receiver............................................................................................. 18 6.3 Network Connections .............................................................................................. 18 7 Operation ..................................................................................................................................... 19 7.1 Powering Up the System ......................................................................................... 19 Sonik G2BT Base Transmitter User Manual March 14, 2002 4 7M487C4 7.2 Connecting a terminal ............................................................................................. 19 7.2.1 Bootloader ....................................................................................................... 20 7.2.2 Application ...................................................................................................... 21 7.3 Quick-Start Configuration....................................................................................... 22 7.3.1 Distribution: Incoming MDP configuration .................................................... 22 7.3.2 Transmission: Outgoing Reflex configuration ................................................ 22 7.3.3 Network configuration .................................................................................... 23 7.3.4 Important Alarm Thresholds (if default of 20 minutes is not desired) ........... 23 7.3.5 Clear Alarms & Alarm Logs ........................................................................... 23 8 SUBSYSTEMS ........................................................................................................................... 24 8.1 G2BT Control Chassis ............................................................................................ 24 8.1.1 CE Backplane .................................................................................................. 25 8.2 CE Power Supply .................................................................................................... 34 9 User Interfaces............................................................................................................................. 35 9.1 Command Line Editor ............................................................................................. 35 9.2 Cons…

Text truncated - open the document above for the full version.

Exhibit 1. FCC Identifier Label The label shown below shall be attached on the rear side on the lower rail of the G2BT transmitter as demonstrated. FCC ID label Label Location Lower Rear Rail of G2BT Cabinet FCC ID : MNT-G2BT Model: G2BT S/N: XXXXXXXXX Sonik Technologies Corp. Made in USA 1.5” .5”

* Single-Level Explosion By Parent Part Identifier * Page 1 Parent Part Identifier Range: 008-0382-8 - 008-0382-8, Effective: 1/14/2002 LLC Part Identifier Description Effectivity Quantity QC UM LTO BT SCR ECN # BOM Revision PT Alternate Part Drawing # APPROVAL FOR THE LATEST REVISION Originator:____________________________ Date:____/____/____ Eng. VP:____________________________ Date:____/____/____ DDD :____________________________ Date:____/____/____ See Released ECO: 1 PAGE 1 OF 008-0382-8 CONTROLLER XEMOD, VIPER - A 1 008-0382-3 CONTROLLER XEMOD, VIPER 1.000000 U EA 0 N 0 T 1 010-0382-8 CONTROLLER XEMOD, VIPER 1.000000 U EA 0 N 0 A 1 100-0005 SOLDER WIRE 63/37 .031TK 0.001000 U EA 0 N 0 B 24-6337-3801 KESTER 1 314-0029 SW DIP 1POS VERT .1A 5V 1.000000 U EA 0 N 0 B BD01 C&K J7 * Single-Level Explosion By Parent Part Identifier * Page 1 Parent Part Identifier Range: 010-0382-8 - 010-0382-8, Effective: 1/2/2002 LLC Part Identifier Description Effectivity Quantity QC UM LTO BT SCR ECN # BOM Revision PT Alternate Part Drawing # APPROVAL FOR THE LATEST REVISION Originator:____________________________ Date:____/____/____ Eng. VP:____________________________ Date:____/____/____ DDD :____________________________ Date:____/____/____ See Released ECO: 1 PAGE 1 OF 010-0382-8 CONTROLLER XEMOD, VIPER - A 1 010-0382-3 CONTROLLER XEMOD, VIPER 1.000000 U EA 0 N 0 T 1 205-0325 10 PIN SHROUDED HEADER 2.000000 U EA 0 N 0 9163 B 205-0312 ASP-32296-01 SAMTEC J4,J5 1 205-0326 16 PIN SHROUDED HEADER 2.000000 U EA 0 N 0 9163 B 205-0313 ASP-32296-02 SAMTEC J1,J6 1 205-0327 26 PIN SHROUDED HEADER 1.000000 U EA 0 N 0 9163 B 205-0314 ASP-32296-03 SAMTEC J3 1 301-0026 CAP SMT.1UF 0805 50V 10% 27.000000 U EA 0 N 0 B GRM40034X7R104K050BL MRTA C4-C10,C19,C21-C28 CX1-CX10,CX12 1 301-0040 CAP SMT.01UF 0805 10%100V 1.000000 U EA 0 N 0 B GRM40X7R103K100BL MURATA C3 1 301-0044 CAP TNT 10UF 3216 20%6.3V 1.000000 U EA 0 N 0 B TAJA106M006R AVX C20 1 301-0107 CAP SM 3.9PF 0805 .25 50V 2.000000 U EA 0 N 0 B C0805C399C5GAC KEMET C1,C2 1 301-0236 CAP TNT 10uF 6032 35V 20% 10.000000 U EA 0 N 0 B PCT10/35CM NEMCO C11-C18, CX13,CX15 1 304-0034 RES SMT 0805 1K .1W 1% 5.000000 U EA 0 N 0 B CRCW08051001F DALE R35,R48-R50,R53 1 304-0035 RES SMT 0805 10K .1W 1% 11.000000 U EA 0 N 0 B CRCW08051002FT DALE R18,R20,R21-R27,R55,R56 1 304-0045 RES SMT 0805 2.15K .1W 1% 5.000000 U EA 0 N 0 B CRCW08052151F DALE R30,R32-R34,R46 1 304-0051 RES SMT 0805 47.5K .1W 1% 12.000000 U EA 0 N 0 B CRCW08054752F DALE R13-R15,R17,R19,R28,R29 R31,R36,R44,R45,R52 * Single-Level Explosion By Parent Part Identifier * Page 1 Parent Part Identifier Range: 010-0382-8 - 010-0382-8, Effective: 1/2/2002 LLC Part Identifier Description Effectivity Quantity QC UM LTO BT SCR ECN # BOM Revision PT Alternate Part Drawing # APPROVAL FOR THE LATEST REVISION Originator:____________________________ Date:____/____/____ Eng. VP:____________________________ Date:____/____/____ DDD :____________________________ Date:____/____/____ See Released ECO: 1 PAGE 1 OF 1 304-0067 RES SMT 0805 511 .1W 1% 1.000000 U EA 0 N 0 B CRCW08055110F DALE R51 1 304-0069 RES SMT 0805 80.6 .1W 1% 1.000000 U EA 0 N 0 B CRCW080580R6FT DALE R54 1 304-0111 RES SMT 0805 4.22K .1W 5% 2.000000 U EA 0 N 0 B CRCW08054221FT DALE R63,R66 1 304-0175 RES SMT 0805 51 .1W 1% 28.000000 U EA 0 N 0 B CRCW0805510JRT1 DALE R1-R12,R16,R37-R43,R57-R62,R65,R68 1 304-0196 RES SMT 0805 12.1K .1W 1% 2.000000 U EA 0 N 0 B CRCW08051212FRT1 DALE R64,R67 1 304-0246 RES SM 0402 3.0K 63mW 1% 5.000000 U EA 0 N 0 B CRCW04023001F DALE R69-R73 1 304-0247 RES SM 0402 8.25K 63mW 1% 5.000000 U EA 0 N 0 B RK73H1E8251FE KOA R74-R78 1 304-0260 RES SMT 10K 1206 1/4 W 1% 1.000000 U EA 0 N 0 B R47 1 311-0007 PROG HI-DENSITY PLCC48 1.000000 U EA 0 N 0 B ISPLSI2032-80LJI LATTICE U2 1 311-0012 M/CONT 8 BIT 12KAH PLCC44 1.000000 U EA 0 N 0 B AT89S53-24JI ATMEL U1 1 317-0019 OSC SMT 22.118MHz -40+85T 1.000000 U EA 0 N 0 B CM309B22.1184MABJT Y1 1 322-0024 IC PREC. REF 4.096V SO-8 1.000000 U EA 0 N 0 B LT1634BIS8-4.096 LINEAR VREF1 1 322-0025 AMP SMT QUAD R-TO-R INPUT 3.000000 U EA 0 N 0 9229 B LT1633CS LINEAR U13-U15 1 322-0069 IC OB/D 5V 4.5VTO5.5V 1.000000 U EA 0 N 0 B SN74HC541DW TI U4 * Single-Level Explosion By Parent Part Identifier * Page 1 Parent Part Identifier Range: 010-0382-8 - 010-0382-8, Effective: 1/2/2002 LLC Part Identifier Description Effectivity Quantity QC UM LTO BT SCR ECN # BOM Revision PT Alternate Part Drawing # APPROVAL FOR THE LATEST REVISION Originator:____________________________ Date:____/____/____ Eng. VP:____________________________ Date:____/____/____ DDD :____________________________ Date:____/____/____ See Released ECO: 1 PAGE 1 OF 1 323-0026 INV. SMT HEX SCHMITT. 1.000000 U EA 0 N 0 B MC74HC14AD MOTOROLA U8 1 323-0064 DAC uPWR OCTAL 10-BIT 1.000000 U EA 0 N 0 B LTC1660IGN LINEAR TECH U11 1 323-0066 MUX SMT 3/5V 8 CHL -40/85 1.000000 U EA 0 N 0 B ADG608BR ANALOG DEVICES U9 1 323-0068 MON. VRC SO-8 1.5V-5.5V 1.000000 U EA 0 N 0 B S93662S-B SUMMIT U3 1 323-0072 SERIAL I/O ADC 10 BIT 1.000000 U EA 0 N 0 B ADC10738CIWM NATIONAL SE U10 1 323-0074 DIGITAL POT 1K SINGLE 1.000000 U EA 0 N 0 B AD8400AR1 ANALOG DEVICES U12 1 323-0077 TRANSCEIVER DIFF BUS 3.000000 U EA 0 N 0 B LINEAR (TI-SN65176BD) U5,U6,U7 1 326-0003 DIODE SS SOT23 T/R3K 2.000000 U EA 0 N 0 B BAS16LT1 MOTOROLA D1,D2 1 330-0001 XTR NPN 1PJ SOT-23 1.000000 U EA 0 N 0 B MMBT2222ALT1 MOTOROLA Q1 Run Date: 05/21/2002 LSSonikTechnologies Corporation Page: 1 B/M Date: 05/21/02Time: 11:46 AM ALL LEVELS G2BT-400A5 (CURRENT)2nd Generation Base Transmitter,400 Watt -1.........6A487-4 *2nd Generation Base Transmitter,400 Watt --2........2D684-1*Crate,Wood,30"Lx39"Wx63"H,G2B --2........6A515-1 *Assy,Cabinet,G2BT ---3.......1J308-1Connector,BNC,Adaptor,50 ohm,T ---3.......1J448-3Conn,BNC 50 ohm,Male,Resistor ---3.......1P532-1Protector,Lightning,50 ohm,7/1 ---3.......1P532-2Protector,Lightning,50 ohm,N F ---3.......1P532-3Protector,Lighting,75 ohm,F Fe ---3.......1P532-4Capsu…

Text truncated - open the document above for the full version.

TÜV PRODUCT SERVICE 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone 858 546 3999 FAX 858 546 0364 Report No. 202170-03 Page 1 Rev.No 1.0 MEASUREMENT AND TECHNICAL REPORT SONIK TECHNOLOGIES CORPORATION VYTEK WIRELESS 2310 Cousteau Court Vista, CA 92024 DATE: 02 May 2002 This Report Concerns: Original Grant: X Class II Change: Equipment Type: NPCS Transmitter, Model G2BT Deferred grant requested per 47 CFR 0.457(d)(1)(ii)? Yes: Defer until: No: X Company Name agrees to notify the Commission by: N/A of the intended date of announcement of the product so that the grant can be issued on that date. Transition Rules Request per 15.37? Yes: *No: X (*) FCC Part 2, Paragraphs 2.1046; 2.1049; 2.1051; 2.1053; 2.1055 and Part 24, Paragraphs 24.131; 24.132(c); 24.133(a)(ii); 24.133(1)(ii); 24.135(a) Report Prepared by: TÜV PRODUCT SERVICE 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone: 858 546 3999 Fax: 858 546 0364 TÜV PRODUCT SERVICE 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone 858 546 3999 FAX 858 546 0364 Report No. 202170-03 Page 2 Rev.No 1.0 TABLE OF CONTENTS Pages 1 GENERAL INFORMATION 3 1.1 Product Description 4 1.2 Related Submittal Grant 4 1.3 Tested System Details 4 1.4 Test Methodology 4 1.5 Test Facility 4 2 SYSTEM TEST CONFIGURATION 5 2.1 Justification 5 2.2 EUT Exercise Software 5 2.3 Special Accessories 5 2.4 Equipment Modifications 5 2.5 Configuration of Tested System 5 3 RF POWER OUTPUT 6 4 MODULATION 8 5 OCCUPIED BANDWIDTH 18 6 SPURIOUS EMISSIONS AT ANTENNA TERMINALS 27 7 RADIATED EMISSION EQUIPMENT/DATA 61 Field Strength Calculation 63 8 FREQUENCY STABILITY 64 9 Attestation Statement 82 TÜV PRODUCT SERVICE 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone 858 546 3999 FAX 858 546 0364 Report No. 202170-03 Page 3 Rev.No 1.0 1 GENERAL INFORMATION 1.1 Product Description NPCS Transmitter, Model G2BT Power Requirements Voltage: 208-240 Vac # of Phases: 1 Current (Amps/phase(max)): 17.4a Current (Amps/phase(nominal)): 17.4a Typical Installation and/or Operating Environment Controlled access/radio room/vault EUT Power Cable X Permanent OR EUT Software. Revision Level: C6 EUT Operating Modes to be Tested - 1. 4 carriers transmission, 100 w/carrier 2. 3 carriers transmission, 1300 w/carrier 3. 2 carriers transmission, 200 w/carrier 4. 1 carriers transmission, 400 w/carrier EUT System Components - Description Control Chassis Power amplifier Array Power Supply Power Distribution Combiner and filter Support Equipment Description Computer GPS Antenna Oscillator Frequencies Frequency MHz 10 18.432 20 16.8 Power Supply Manufacturer Magnetek TÜV PRODUCT SERVICE 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone 858 546 3999 FAX 858 546 0364 Report No. 202170-03 Page 4 Rev.No 1.0 1 GENERAL INFORMATION (continued) 1.2 Related Submittal/Grant None 1.3 Tested System Details The FCC IDs for all equipment, plus descriptions of all cables used in the tested system are: None 1.4 Test Methodology Purpose of Test: To demonstrate compliance with the ANSI C63.4 setup. TEST FCC CFR 47 # PASS/FAIL RF Power Output Modulation Occupied Bandwidth Spurious Emissions at Antenna Terminals Radiated Spurious Frequency Stability Part 2, Para. 2.1046; Part 24; Para. 24.132(c) Part 2, Para. 2.1047; Part 24; Para. 24.133(1)(i) Part 2, Para. 2.1049; Part 24; Para. 24.131 Part 2, Para. 2.1051; Part 24; Para. 24.133 Part 2, Para. 2.1053; Part 24; Para. 24.133(a)(ii) Part 2, Para. 2.1055; Part 24; Para. 24.135(a) Pass Pass Pass Pass Pass Pass Both Conducted and radiated testing were performed according to the procedures in FCC/ANSI C63.4 and CSA 108.8 - M1983. Radiated testing was performed at an antenna-to-EUT distance of 3 meters (1 - 25 GHz). 1.5 Test Facility The open area test site and conducted measurement data were tested by: TÜV PRODUCT SERVICE 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone: 858 546 3999 Fax: 858 546 0364 The Test Site Data and performance comply with ANSI 63.4 and are registered with the FCC, 7435 Oakland Mills Rd, Columbia Maryland 21046. All Measurement Data is acquired according to the content of FCC Measurement Procedure and ANSI C63.4, unless supplemented with additional requirements as noted in the test report. TÜV PRODUCT SERVICE 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone 858 546 3999 FAX 858 546 0364 Report No. 202170-03 Page 5 Rev.No 1.0 2. SYSTEM TEST CONFIGURATION 2.1 Justification The EUT was initially tested for FCC emission in the following configuration: See Block Diagram. 2.2 EUT Exercise Software None 2.3 Special Accessories None 2.4 Modification None 2.5 Configuration of Tested System See Block Diagram. TÜV PRODUCT SERVICE 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone 858 546 3999 FAX 858 546 0364 Report No. 202170-03 Page 6 Rev.No 1.0 3 RF POWER OUTPUT (CHANNELS 1-4) TÜV PRODUCT SERVICE 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone 858 546 3999 FAX 858 546 0364 Report No. 202170-03 Page 7 Rev.No 1.0 TÜV PRODUCT SERVICE 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone 858 546 3999 FAX 858 546 0364 Report No. 202170-03 Page 8 Rev.No 1.0 4 MODULATION CHARACTERISTICS (CHANNELS 1, 2, 3 and 4, 930.500MHz and (CHANNELS 1, 2, 3 and 4, 940.500 MHz) TÜV PRODUCT SERVICE 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone 858 546 3999 FAX 858 546 0364 Report No. 202170-03 Page 9 Rev.No 1.0 TÜV PRODUCT SERVICE 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone 858 546 3999 FAX 858 546 0364 Report No. 202170-03 Page 10 Rev.No 1.0 TÜV PRODUCT SERVICE 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone 858 546 3999 FAX 858 546 0364 Report No. 202170-03 Page 11 Rev.No 1.0 TÜV PRODUCT SERVICE 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone 858 546 3999 FAX 858 546 0364 Report No. 202170-03 Page 12 Rev.No 1.0 TÜV PRODUCT SERVICE 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone 858 546 3999 FAX 858 546 0364 Report No. 202170-03 Page 13 Rev.No 1.0 TÜV PRODUCT SERVICE 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone 858 546 3999 FAX 858 546 0364 Report No. 20217…
