MOZRI-4ATY-ACar Immobilizer

JAPAN QUALITY ASSURANCE ORGANIZATION 2096, OHHATA, TSURU-SHI, YAMANASHI 402-0045, JAPAN PHONE (0554) 43-5517, FAX (0554) 43-6316 JQA APPLICATION NO.: 400-00212 Issue Date : July 25, 2000 Page 1 of 25 EMI TEST REPORT JQA APPLICATION NO. : 400-00212 Model No. : RI-4ATY(a) Type of Equipment : Immobilizer System Regulations Applied : CFR 47 FCC Rules and Regulations Part 15 FCC ID : MOZRI-4ATY-A Applicant : TOKAI RIKA CO., LTD. Address : 260, Toyota 3-chome, Oguchi-cho, Niwa-gun, Aichi-ken 480-0195, Japan Manufacture : TOKAI RIKA CO., LTD. Address : 260, Toyota 3-chome, Oguchi-cho, Niwa-gun, Aichi-ken 480-0195, Japan Received date of EUT : June 22, 2000 Final Judgment : Passed TEST RESULTS IN THIS REPORT are obtained in use of equipment that is traceable to Electrotechnical Lab. of MITI Japan and Communications Research Lab. of MPT Japan. The test results only respond to the tested sample. It is not allowed to copy this report even partly without the allowance of the JQA EMC Engineering Dept. Testing Div. C O P Y JQA Application No. :400-00212 FCC ID :MOZRI-4ATY-A Model No. :RI-4ATY(a) Issue Date :July 25, 2000 Standard :CFR 47 FCC Rules Part 15 Page 2 of 25 JAPAN QUALITY ASSURANCE ORGANIZATION TABLE OF CONTENTS Page 1 Documentation 1.1 Test Regulation 3 1.2 General Information 3 1.3 Test Condition 4 – 8 1.4 EUT Modifications / Deviation from Standard 9 1.5 Test results 10 1.6 Summary 11 1.7 Test Configuration / Operation of EUT 12 1.8 EUT Arrangement(Drawing) 13 1.9 Preliminary Test and Test-setup (Drawings) 14 – 19 1.10 EUT Arrangement (Photographs) 20 2 Test Data 2.1 AC Power Line Conducted Emission 0.45 MHz – 30 MHz N / A 2.2 Radiated Emission (Electric Field)9 kHz – 30 MHz 21 – 22 2.3 Radiated Emission (Electric Field)30 MHz – 1000 MHz 23 – 24 2.4 Radiated Emission (Electric Field) Above 1 GHz N / A 2.5 Frequency Stability N / A 2.6 Occupied Bandwidth N / A C O P Y JQA Application No. :400-00212 FCC ID :MOZRI-4ATY-A Model No. :RI-4ATY(a) Issue Date :July 25, 2000 Standard :CFR 47 FCC Rules Part 15 Page 3 of 25 JAPAN QUALITY ASSURANCE ORGANIZATION 1 DOCUMENTATION 1.1 TEST REGULATION FCC Rules and Regulations Part 15 Subpart A and C (June 23, 1989) Intentional Radiators Test procedure : AC power line conducted emission, radiated emission, frequency stability and occupied bandwidth tests were performed according to the procedures in ANSI C63.4-1992. 1.2 GENERAL INFORMATION 1.2.1 Test facility : 1) Test Facility located at EMC Engineering Dept. Testing Div. : - No.2 and 3 Anechoic Chambers( 3 meters Site ). - Shielded Enclosure. Expiration date of FCC test facility filing : June 4, 2002 TSURU EMC Branch: Open Site No.1, No.2, An Anechoic Chamber (3 m and 10 m, on common plane) and a Shielded Room (Date of Listing: March 30,1999) 2) EMC Engineering Dept. Testing Div. and TSURU EMC Branch are recognized under the National Voluntary Laboratory accreditation Program for satisfactory compliance established in title 15, Part 285 Code of Federal Regulations. NVLAP Lab Code : 200189-0 (Effective through : June 30, 2001) NVLAP Lab Code : 200192-0 (Effective through : June 30, 2001) 1.2.2 Description of the Equipment Under Test (EUT) : 1) Type of Equipment : Immobilizer System 2) Product Type : Production 3) Category : Low Power Communication Device Transmitter 4) EUT Authorization : Certification 5) FCC ID : MOZRI-4ATY-A 6) Trade Name : - 7) Model No. : RI-4ATY(a) 8) Operating Frequency Range : 133.8 kHz 9) Highest Frequency Used in the EUT : 133.8 kHz 10) Serial No. : - 11) Date of Manufacture : - 12) Power Rating : 12.0 VDC 13) EUT Grounding : None 1.2.3 Definitions for symbols used in this test report : x - indicates that the listed condition, standard or equipment is applicable for this report. - indicates that the listed condition, standard or equipment is not applicable for this report. C O P Y JQA Application No. :400-00212 FCC ID :MOZRI-4ATY-A Model No. :RI-4ATY(a) Issue Date :July 25, 2000 Standard :CFR 47 FCC Rules Part 15 Page 4 of 25 JAPAN QUALITY ASSURANCE ORGANIZATION 1.3 TEST CONDITION 1.3.1 The measurement of the AC Power Line Conducted Emission - was performed in the following test site. x - was not applicable. Test location : Safety Testing Center EMC Engineering Dept. Tsuru EMC Branch 2096 Ohhata, Tanbozawa, Tsuru-shi Yamanashi-ken 402-0045, JAPAN - Shielded Room No.1 - Shielded Room No.2 - Anechoic Chamber - Open Site No.1 - Open Site No.2 Used test instruments : Type Model No. Manufacturer Serial No. Last Cal. Interval - Test Receiver ESH-3 Rohde & Schwarz 872992/047 May. 2000 1 Year - Test Receiver ESH-3 Rohde & Schwarz 881460/016 May. 2000 1 Year - LISN(for Peripheral) KNW-407 Kyoritsu Electrical 8-833-5 May. 2000 1 Year - LISN(for EUT) KNW-407 Kyoritsu Electrical 8-680-14 May. 2000 1 Year - LISN KNW-243C Kyoritsu Electrical 8-831-1 May. 2000 1 Year - LISN KNW-243C Kyoritsu Electrical 8-831-2 May. 2000 1 Year - LISN KNW-243C Kyoritsu Electrical 8-831-3 May. 2000 1 Year - LISN KNW-243C Kyoritsu Electrical 8-831-4 May. 2000 1 Year - LISN ESH 2-Z5 Rohde & Schwarz 879341/007 May. 2000 1 Year - RF Cable 3D-2W Fujikura No.1 May. 2000 1 Year - RF Cable 3D-2W Fujikura No.2 May. 2000 1 Year - RF Cable 3D-2W Fujikura No.3 May. 2000 1 Year - 50ohm Termination - TDC 15406501E1 Feb. 2000 1 Year - 50ohm Termination - - 15406502E1 Feb. 2000 1 Year C O P Y JQA Application No. :400-00212 FCC ID :MOZRI-4ATY-A Model No. :RI-4ATY(a) Issue Date :July 25, 2000 Standard :CFR 47 FCC Rules Part 15 Page 5 of 25 JAPAN QUALITY ASSURANCE ORGANIZATION 1.3.2 The measurement of the Radiated Emission(9 kHz – 30 MHz) x - was performed in the following test site. - was not applicable. Test location : Safety Testing Center EMC Engineering Dept. Tsuru EMC Branch 2096 Ohhata, Tsuru-shi, Yamanashi-ken 402-0045, JAPAN - Open Site No. 1 (3, 10 or 30 meters) x - Open Site No. 2 (3, 10 or 30 meters) - Anechoic Chamber(3 or 10 meters) Validation of Site Attenuation : 1) Last Confirmed Date : N/A 2) Interval : N/A Used t…
