MSAB15CLCRT Monitor

Power management system This monitor complies with VESA, Nutek, and Energy Star power saving requirements.The power saving system works only when used with VESA DPMS compliant PC’sand/or graphic controllers.The monitor goes into various power saving stages depending on the incomingvideo signal as shown in the following tableNoteThe monitor automatically goes through the DPMS steps when it is idle. To release themonitor from the DPMS condition, press any key on the keyboard or mouse. Electrical SpecificationsMechanical SpecificationsEnvironmental SpecificationsPreset Timings This Monitor B15CL has preset modes for the 8 most popular industry standards for Plug and Play capability. Function of controlsAdjustment This monitor features an On Screen Display(OSD) that shows information about thisdisplay controls. On Screen Display (OSD) Controls. The OSD window appears on the screen when you press DO key. It is include the following extended controls such as Size, Position, Geometry, Color_temp, Degauss, Moire, Language, OSD-Position, Zoom and hidden Exit. Brightness This item adjusts the overall brightness of the displayed image. Press the "-" key first, and then adjust theproperly brightess.If you want to exit, press DO key. Contrast This item adjusts the contrast level of thedisplayed image.Press the "+" key first, and then adjust to theproperly contrast.If you want to exit, press DO key. OSD menu functions How to control functions on the main menu. Press the OSD control key (with RED icon)Move the desired control function.Adjust the properly displayed screen image.When you are done all progress, move the exit (None select) and then press DO key. OSD Adjust FUNCTION 15 Inch (Viewable size 13.8 ) High Resolution Color Monitor(B15CL) Users Manual Printed on the recyclable paper Printed in KoreaPart No. 942335020001 - 01 Package Congratulations on your purchase of this top quality color monitor!The items illustrated below are contained in the carton.First, be sure that your carton includes all of them. If any items are missing or damaged, please contact your local dealer or supplier. - Color Monitor- AC Power input cable- Stand Ass'y- User’s Manual Safety information Use only a power source and connection appropriate for the monitor as indicatedon the marking label. Slots and openings in the cabinet are provided for ventilation; these openings must not be blocked or covered. Never push objects of any kindinto cabinet slots or other openings. Never insert anything metallic into the monitor openings. Doing so may create a danger of electric shock. To avoid electric shock, never touch the inside of the monitor. Only a qualified technician should open the monitor s case. Unplug the monitor from the wall outlet before cleaning. Do not use liquid cleanersor aerosol cleaners. Use a damp, lint-free cloth for cleaning.Install the monitor near an outlet that you can reach easily. Disconnect the productby grasping the plug firmly and pulling in from the outlet. Never disconnect it by pulling the cord. Caution Changes or modifications not expressly approved by the party responsible forcompliance could void the user’s authority to operate the equipment. Notice The information contained in this document is subject to change without notice. Features Superior image On Screen menu fingertip control system to visually select and adjust screen usingbuttons on front panel and on screen menus. Super contrast screen for superior contrast and richer color.Advanced INVAR Shadow mask for superior focus, brightness and color.15", 0.28dot pitch high resolution, non-interlaced technology provides sharp, flicker-free images.On screen menu color control system easily allows the white of the image to beadjusted as well as R.G. B signals, resulting in true-to-life colors. Ergonomic Design Flat, square screen to reduce image distortion and glare, thus relieving eye strain.Tilt base allowing 90 rotation in the horizontal and 17 in the vertical for greater user comfort. Low-leak radiation prevention meeting MPR magnetic field emissions standards for increased user safety. Environmentally Friendly Power management circuit conforming to VESA DPMS standards controls energyconsumption when monitor is not in use, you save energy.All plastic parts are recyclable. All materials are strictly selected to ensure ease ofmaintenance, inspection and disposal. Timing Automatic tracking of horizontal frequencies of 30 to 72 kHz,and vertical frequenciesof 50 to 160 Hz.Eight timings are factory preset for image size and positionTen additional timings are user definable.Synchronizing input signals (separate, composite) can be automatically selected. System Flexibility Equipped with DDC1, DDC2B and DDC2Bi for Plug & Play compatibility.Monitor is compatible with VGA, SVGA, VESA and high resolution video modes upto 1280(H) 1024(V)@60Hz Monitor may be used with IBM or compatible PC, Mac.Automatic universal power supply is built in permitting AC power input of 100 - 240VAC, 50 or 60Hz.Self-test menu allows the display unit to be checked on screen without connectingto a computer.Compact case minimizes desktop space giving you a large screen image withoutloss of workspace.Power cable included easily plugs into a standard outlet. Connection to your computer CAUTIONEnsure that both the PC and the display monitor are switched off. To attach the monitor to your system, asshown in the following illustrations.1. Insert the AC power cord into monitor and then into an AC power outlet. 2. Connect the signal cable to the 15pin graphics connector of the system andtighten the fastening screws. 3. To turn on the monitor, push the power switch. Note : To attach the monitor to the Macintosh system, please contact an authorized dealer.(Need to use a special adaptor) Troubleshooting No picture Check that the AC cord is correctly connected.Check that the AC socket is live by plugging in another piece of equipment.Power switch and computer power switch should be in posit…
