MSAB17BF-1LCD Monitor

Parts 3 Connection to Computer 4 How to Adjust Monitor Angle 5 Installing Monitor Driver 6 Name and Function of Front Keys 8 Power Management Feature 10 PC Menu 11 Video Menu 15 TV 18 SOUND Menu 21 Configuration OSD Menu 23 Picture In Pincture(PIP) function 26 Remote Controller 27 Standard Signal Table 28 Specification 29 Troubleshooting 30 Warning 32 Table of Contents 3 2 Parts Parts LCD Monitor Place the monitor to face the user and then adjust the monitor angle.Take a break (for about 10 minutes) at every hour during the work withmonitor. Refer to the following figure to take the correct posture. about 50cm Look down the monitor below the horizon. Relax shoulders and arms, and sit back on the chair. Adjust the monitor to prevent reflection. Adjust the monitor stand to acquire required angle. Keep feet flat on the ground. Maintain the arms horizontally and place hands softly on the keyboard. Good Posture Guide RCA Cable (Pair) Stereo Cable S-VHS Cable 12V-DC Adapter Remote Controller/Battery User's Manual / Warranty Card Installation Diskette Signal Cable Antenna Cable AC Power Cable 5 4 Applied Connection How to Adjust monitor Angle Connection to Computer Basic Connection 1. Use 220 V or 110 V. (Free Voltage)2. Connect monitor and computer via Signal cable (See figure ) 3. Power on the monitor and computer. 1. Connect the adapter to "12V DC" input terminal.2. Connect the computer cable to PC1.3. Connect video (V1) connection cable or SVHS (V2) connection cable to DVD, VCR or camcorder. 4. Connect audio output (computer, DVD, VCR or camcorder) to Audio In (L), Audio In (R) or Audio In (Stereo). 5. Connect headphone or earphone to H-Phone terminal. 6. Connect antenna or CATV connection cable to "Antenna" terminal. Port for 12V DC cable from DC adapter. Port for Signal cable from Signal Source. General For Macintosh In Usinga dapter. Adapter for Macintosh (Optional)Refer to the table on the rear side ofthe optional Macintosh adapter andadjust DIP switch by the resolution ofthe monitor. 7 6 Click 'Finish'. Click 'Next>'. Click 'Advanced..'. Click 'Next>'. Click 'Monitor'. Click 'Display a list of all...'.Click 'Next>'. Click 'Have Disk..'. Select the driver and click 'OK'. Click 'Next>'. 3. Select Exit if the monitor model is changed, and then reboot Windows. Installing Monitor Driver 1. Insert the CD in the CD-ROM driver. 2. "Installation Manager" window appears. (Or, double-click Install.exe in the CD-ROM driver folder using search function.) 3. Click "Driver Installation" icon.4. Select the model and click "OK".5. Select inf file of the model in the Drivers folder in CD-ROM driver, and then click "OK" button. 6. Click "Exit" to close the installation. Automatic Installation Manual Installation 1. Insert the CD in the CD-ROM driver.2. Click 'My Computer' and follow the procedure below. Click 'Control Panel'. Click 'Display'. Click 'Settings'. Run (Click) Install at CD-ROM driver and select the product model to set the optimumdisplay in Window 95 or 98. Use the Driver CD provided.Download the latest driver from home page of Hansol Electronics Inc. (http://www.hansolel.co.kr). 9 8 Functions Name and Function of Front Keys Front panel MUTE KEY SOURCE KEY AUTO/SELECT KEY MENU KEY VOL KEY VOL KEY CH KEY CH KEY POWER KEY Power Switch Power switch is located in the lower center of the monitor stand.You can push the switch to turn on/off the power. Power Saving LED Dark : Power offGreen : Normal modeGreen blinking : Power Saving mode or check signal Cable mode. Signal Source LED Each of the five LEDs (from left; PC1, PC2, TV, V1 and V2) over the powerswitch indicates the source of the signal which the monitor displays. On Screen Display (OSD) Function Button OSD buttons on the front of the monitor perform the following functions. MUTE : Cut off sound SOURCE : monitor displays source of the signal in order. (PC VIDEO VIDEO V) AUTO/SELECT : Press this button, when OSD is not displayed, to perform automatic setting. If you press this button when OSD is displayed, you can select icons. MENU : Press this button to display menus. if you press this button when OSD is displayed, You can switch display to the previous menu and exit menu. POWER : Power switch. CH : Press this button to select TV channel in TV mode when OSD is not displayed. Or press the button, when OSD is displayed, to move the cursor into the menus which you want. when OSD is not displayed, you can adjust brightness or contrast in PC/VIDEO mode. VOL : Press this button to adjust volume of audio when OSD is not displayed. By pressing this button when OSD is displayed, you can move cursor into the menus or change gate level. 11 PC MENU Brightness Contrast Horizontal Position 10 No image is displayed with LED blinking. Monitor is in power saving mode.Use mouse or keyboard to release power saving mode. No image is displayed without LED on. Power cable plug must be pulled out.Check the power plugs on monitor and on the wall. Power Management Feature When not in use for a long period of time, the monitor automatically reduces its power consumption, meeting powersaving standards of EPA and NUTEK. The monitor is equipped with a power saving circuit that conforms to the world-standard Display Power ManagerSignalling (DPMS) mode of Video Electronics StandardAssociation (VESA).The power management feature requires that the video cardof the computer should support DPMS function. Status LED Sign Power Consumption Normal Normal Power DPMS mode Green Blinking 5 W or Below Move to Move to Move to Move to Move to Move to Use to have the monitor darker, to brighter. Use or to adjust contrast. Use or to adjust display left or right. 13 12 Vertical Position Clock Color Preset Color User Color Scaling Move to Move to Move to Move to Move to Move to Move to"FULL,9300K,6500K" Move to Move to Move to Move to Use or to adjust display upward or downward. If Auto Adjustment function fails to remove video noise, Use or to remove vertical noise. (Adjusting phase i…

Text truncated - open the document above for the full version.

SCALER (SAMSUNGS5D2530) Micom (NT68F63) LVDS TRANSMITTER ADC (AD9883-140) DC/DC CONVERTER DC12V Adapter ANALOG RGB (PC) OSDKeyControls +12V +9V +5V V I D E O P O R T HOSTI/F D I S P L A Y P O R T 17" TFT-LCD Panel Inverter +12V GRAPHICPORT +3.3V +2.5V TV TUNER SVHS Video VIDEO DECODER (TW9901) AUDIO




















































!"
"%











































!


!"  "%

ROVALSDATE M L OO TITLE PRODUCT LABEL H710,OWN,TCO99,HJ REV. A SIZE A4 SHEET 1 OF 1 UNIT mm SCALE 1 / 1 MATERIAL POLYESTER FILM Q’TY 1 DWG. NO. 922267320001 REF. Made in KOREA HJ 922267320001 - 01 Manufactured: CAUTION TO PREVENT ELECTRIC SHOCK, DO NOT REMOVE COVER, NO USER-SERVICEABLE PARTS INSIDE, REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. Hansol Electronics Inc. 27-29 Hanchon-Ri Duksan-Myun Jinchon-Kun Choongbuk, KOREA ATTENTION AFIN D’EVITER TOUT RISQUE D’ELECTROCUTION, NE PAS ENLEVER L’ARRIERE. AUCUNE PIECE REPARABLE PAR L’USAGER A L’INTERIEUR. POUR REPARATIONS, APPELER UN TECHNICIEN QUALIFIE. FCC ID : MSA B17BF-1 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions. 1) This device may not cause harmful interference and 2) This device must accept any interference received, including interference that may cause undesired operation. MODEL Name : H710T MODEL No. : B17BF ELECTRICAL RATING DC 12V , 4.5A For use only with power supply MANUFACTURER :Hansol MODEL : AP0040NAN MANUFACTURER : Hansol MODEL : HLS-40












































$
