MTFTG5112597AResidential & Business Cellular Alarm Communicator

56033504 © 2007 Telular Corporation TELGUARD ® DIGITAL TG-4 Residential Primary & Small Business Cellular Alarm Communicator Cellular Alarm Transmission System Using GSM Digital Cellular Technology P/N: TG4G0001 INSTALLATION AND OPERATING INSTRUCTIONS For use by TELGUARD ® customers only. Distribution to others strictly prohibited. COMPANY CONFIDENTIAL Technical Support: 800-229-2326 M-F 8:00AM – 8:00PM EST Saturday 9:00 AM – 5:00 PM EST The activation form must be completed before leaving for the job site to install the Telguard product. The activation form may be completed by: • Fax – 678-945-1651 • Email – [email protected] • Online – www.telguardonline.com Revised May 23, 2007 TELGUARD ® is a registered trademark of Telular Corporation. Products are protected under one or more of the following U.S. patents: 4,658,096 4,737,975 4,775,997 4,868,519 4,922,517 © 2006 Telular Corporation 56033504 © 2007 Telular Corporation i FOREWORD Many customers purchase the Telguard  Digital because they prefer its price and features. The Telguard model TG-4 (p/n TG4G0001) is UL Listed for Household Fire systems, Household Burglary systems and Miscellaneous Supplemental Use. This means that the TG-4 may be used in Household Burglary systems or Household Fire systems as the main or secondary communication line. The TG-4 may not be used in applications that require UL Grade A Burglary or Fire Listings. If such UL Listings are not required, it is possible to use model TG-4. This means that the TG-4 will not enhance or degrade the grade of service if used for commercial purposes. NOTICES A BOUT THIS MANUAL This manual assumes that you have basic security system installation skills such as measuring voltages, stripping wire, properly connecting wires together, connecting wires to terminals, and checking phone lines. It also assumes that you have a familiarity with the proper installation and programming tasks related to various control communicator panels. The material and instructions covered in this manual have been carefully checked for accuracy and are presumed to be reliable. However, Telular assumes no responsibility for inaccuracies and reserves the right to modify and revise this manual without notice. It is our goal at Telular to always supply accurate and reliable documentation. If a discrepancy is found in this documentation, please mail or fax a photocopy of the corrected material to: Telular Security Products Technical Services Department 420 Thornton Road, Suite 109 Lithia Springs, GA 30122 Fax: 678-945-1651 © 2007 Telular Corporation. Lithia Springs, GA U.S.A. All rights reserved. FCC Notices E XPOSURE TO RADIO FREQUENCY ENERGY In 1991, the Institute of Electrical and Electronics Engineers (IEEE), and in 1992, the American National Standards Institute (ANSI), updated the 1982 ANSI Standard for safety levels with respect to human exposure to RF energy. Over 120 scientists, engineers and physicians from universities, government health agencies and industry, after reviewing the available body of research, developed this updated Standard. In March 1993, the U.S. Federal Communications Commission (FCC) proposed the adoption of this updated Standard. The design of your Telular Telguard complies with this updated Standard. Of course, if you want to limit RF exposure even further than the updated ANSI Standard, you may choose to install the unit in a manner that locates its antenna at an even greater distance from the general public than is recommended as a minimum by the standard. To insure compliance with the standard, when selecting a mounting location for your Telguard do not mount it (or its associated antenna) in an area where the general public could reasonably be within 8 inches (20 centimeters) of the antenna. EFFICIENT OPERATION Do not operate your Telular product when holding the antenna. Be sure to mount the unit such that its antenna is a minimum of eight (8) inches (20 centimeters) is maintained from the general public. For the best service quality, keep the antenna free from obstructions and point the antenna straight up. 56033504 © 2007 Telular Corporation ii ANTENNA CARE AND REPLACEMENT Do not use the unit with a damaged antenna. If a damaged antenna comes into contact with the skin, a minor burn may result. Have your antenna replaced by a qualified technician immediately. Use only a manufacturer-approved antenna. Non-approved antennas, modifications, or attachments could impair service quality, damage the Telguard and violate FCC regulations. ELECTRONIC DEVICES Most modern electronic equipment is shielded from RF energy. However, RF energy from cellular devices may affect inadequately shielded electronic equipment. RF energy may affect improperly installed or inadequately shielded electronic equipment operating in homes and businesses. Check with the manufacturer or its representative to determine if these systems are adequately shielded from external RF energy. Consult the manufacturer of any personal medical devices (such as pacemakers, hearing aids, etc.) to determine if they are adequately shielded from external RF energy. BLASTING AREAS To avoid interfering with blasting operations, turn OFF your unit when in a “blasting area” or in areas posted: “Turn off two-way radio.” Construction crews often use remote control RF devices to set off explosives. POTENTIALLY EXPLOSIVE ATMOSPHERES Turn OFF your unit when in any area with a potentially explosive atmosphere. It is rare, but your Telguard Digital or its accessories could generate sparks. Sparks in such areas could cause an explosion or fire resulting in bodily injury or even death. Areas with a potentially explosive atmosphere are often, but not always, clearly marked. They include fueling areas such as gas stations; below deck on boats; fuel or chemical transfer or storage facilities; areas where the air contains chemicals or particles, such as grain, dust, or metal powders; and any other area where you would normally be…

Text truncated - open the document above for the full version.

WM_ Wireless CPU Q24 Series Product Technical Specification Revision: 003 Date: November 2006 confidential © Page: 1 / 81 This document is the sole and exclusive property of WAVECOM. Not to be distributed or divulged without prior written agreement. WM_PRJ_Q24NG_PTS_001-003 November 2006 Wireless CPU Q24 Series Product Technical Specification Reference: WM_PRJ_Q24NG_PTS_001 Revision: 003 Date: November 2006 Powered by the Open AT ® Software Suite Wireless CPU Q24 Series confidential © Page: 2 / 81 This document is the sole and exclusive property of WAVECOM. Not to be distributed or divulged without prior written agreement. WM_PRJ_Q24NG_PTS_001-003 November 2006 Cautions This platform contains a modular transmitter. This device is used for wireless applications. Note that all electronics parts and elements are ESD sensitive. Information provided herein by WAVECOM is accurate and reliable. However, no responsibility is assumed for its use and any of such WAVECOM information is herein provided "as is" without any warranty of any kind, whether express or implied. Trademarks ®, WAVECOM ® , WISMO ® , Open AT ® and certain other trademarks and logos appearing on this document, are filed or registered trademarks of Wavecom S.A. in France or in other countries. All other company and/or product names mentioned may be filed or registered trademarks of their respective owners. Copyright This manual is copyrighted by WAVECOM with all rights reserved. No part of this manual may be reproduced in any form without the prior written permission of WAVECOM. No patent liability is assumed with respect to the use of their respective owners. Wireless CPU Q24 Series confidential © Page: 3 / 81 This document is the sole and exclusive property of WAVECOM. Not to be distributed or divulged without prior written agreement. WM_PRJ_Q24NG_PTS_001-003 November 2006 Web Site Support General information about Wavecom and its range of products: www.wavecom.com Specific support is available for the Q24 Classic, Plus, Extended and Auto Wireless CPU: www.wavecom.com/Q24Classic, www.wavecom.com/Q24Plus, www.wavecom.com/Q24Extended, www.wavecom.com/Q24Auto Carrier/Operator approvals: www.wavecom.com/approvals Open AT® Introduction: www.wavecom.com/OpenAT Developer support for software and hardware: www.wavecom.com/forum Wireless CPU Q24 Series confidential © Page: 4 / 81 This document is the sole and exclusive property of WAVECOM. Not to be distributed or divulged without prior written agreement. WM_PRJ_Q24NG_PTS_001-003 November 2006 Overview This Product Specification document defines and specifies the Wireless CPU Q24 Series is available in four different GSM/GPRS Class 10 quad-band versions: • Q24 Classic: EGSM 900/1800/850/1900 MHz version with 32 Mb of Flash memory and 16 Mb of PSRAM (32/16), T° range [-20°C / +55°C]. • Q24 Plus: EGSM/GPRS 900/1800/850/1900 MHz version with 32 Mb of Flash memory and 16 Mb of PSRAM (32/16), T° range [-20°C / +55°C]. • Q24 Extended: EGSM/GPRS 900/1800/850/1900 MHz version with 32 Mb of Flash memory and 4 Mb of SRAM (32/4), extended T° range. • Q24 Automotive: EGSM/GPRS 900/1800/850/1900 MHz version with 32 Mb of Flash memory and 4 Mb of PSRAM (32/4), extended T° range. This version is dedicated to automotive applications. This document covers the Wireless CPU alone and do not include the programmable capabilities provided in Open AT® Software Suites. For detailed software programming guides, refer to the documents shown in the "Reference documents" section. Open AT® Software Suites allow developers to natively execute ANSI C software programs directly on the Wireless CPU. Wireless CPU Q24 Series confidential © Page: 5 / 81 This document is the sole and exclusive property of WAVECOM. Not to be distributed or divulged without prior written agreement. WM_PRJ_Q24NG_PTS_001-003 November 2006 Document History Revision Date List of revisions 001 May 2006 Creation (Preliminary version) 002 September 2006 First update 003 November 2006 Update Wireless CPU Q24 Series confidential © Page: 6 / 81 This document is the sole and exclusive property of WAVECOM. Not to be distributed or divulged without prior written agreement. WM_PRJ_Q24NG_PTS_001-003 November 2006 Contents 1 References.......................................................................................................10 1.1 Reference Documents .....................................................................................10 1.1.1 Wavecom Reference Documents.............................................................10 1.1.2 General Reference Documents ................................................................10 1.2 Abbreviations..................................................................................................11 2 General Description .........................................................................................14 2.1 General Information ........................................................................................14 2.1.1 Overall Dimensions .................................................................................14 2.1.2 Open AT ® Software Suite ........................................................................14 2.1.3 GSM/GPRS Features ...............................................................................15 2.1.4 Interfaces ................................................................................................15 2.1.5 External RF Connection Interfaces...........................................................16 2.1.6 SIM Card Holder .....................................................................................16 2.1.7 Green Policy............................................................................................16 2.2 Functional Architecture...................................................................................17 2.2.1 RF Functionalities ...................................................................................18 2.2.2 …

Text truncated - open the document above for the full version.

DRAWN BY: DRAWING NUMBER: APPROVED BY: DES. ENG. MFG. MECH. DESIGN TITLE: DATE: SHT. OF ANTENNA, 2dBi, DIPOLE, 800/1900, TNC-MALE, KNUCKLE, (ROHS) G. EHRLICH 72006600 8/07/00 16 ® ® ACROBAT DOCUMENT Note: Vendor part numbers do not reflect production packaging. Packaging is left to the discretion of purchasing and/or Contract Manufacturer to optimize with insertion equipment. D.A.T. CORPORATION 311 South Wacker Drive Suite 4300 Chicago, IL 60606 REV DESCRIPTION DATE APPROVED - 8/15/00 RELEASED TO RECORDSRLK 1910 ~ 1930 MHz -3 to 3dBi 1930 ~ 1990 MHz -1 to 3dBi (RCV) VSWR: < 2.0 (XMT portion of band) { < 1.5 preferred} Antenna Requirements Design: Dipole-type with adjustable 0-90 degree swivel 1850 ~ 1910 MHz 0 to 3dBi (XMT) 1850 ~ 1990 MHz (PCS) Impedence (Nominal): 50W Polarization: Linear Radiation Pattern: Omnidirectional (nominal) RF Connector: TNC - male (dimensions per MIL-C-39012) Temperature Range: -30 C ~ +60 C (operating) O O 849 ~ 869 MHz -3 to 3dBi 869 ~ 894 MHz -1 to 3dBi (RCV) Antenna Gain 3 : 824 ~ 849 MHz 0 to 3dBi (XMT) Frequency Range: DUALBAND: 824 ~ 894 MHz (AMPS/TDMA) A REVISED PER CD504 9/24/01 RLK < 2.5 (RCV portion of band) B REVISED PER CD519 12/17/01 PRW C REVISED PER CD522 01/22/02 RLK D REVISED PER CD544 08/05/02 RLK E CHG XMT VSWR; CD627 06/06/05 RLK F ADD NOTE 3; CD629 07/19/05 RLK NOTES: 1) PACKAGE ANTENNA IN A BAG; OR MANNER WHICH IS IDENTIFIED WITH TELULAR PART NO. AND REVISION. 2) MECHANICAL SPECIFICATIONS WILL VARY FROM PART TO PART. REFER TO VENDOR DATASHEET FOR DETAILS. 3) ANTENNA GAIN MUST BE MEASURED IN A PLANE PERPENDICULAR TO THE LONG (E) AXIS OF THE ANTENNA. G ADD ANTE TEC; CD641 02/27/06 RLK H ANTETEC MARKING;CD642 04/03/06 RLK J RMV SHEPHERD; CD669 07/10/07 RLK TELULAR 72006600 Rev. J 1 of 6 PartANTE TECGALTRONICSAntenna No.Part No.Part No.Color 016010250102020356075-2098Black All parts must be compatible with 250 o C soldering Products must NOT contain: Lead (Pb), Polybrominated Biphenyls (PBB), Polybrominated Diphenyl Ethers (PBDE), Hexavalent Chromium, Cadmium, or Mercury. AnteTec Technologies Ltd. Addr: No.75, Xinfangzi Cun, Huaxiang,Fengtai Dist.,Beijing 100071, China Tel: +86 10 63783362 Fax: + 86 10 63781552 http://www.antetec.com Email: [email protected] 1 of 4 pages SPECIFICATION OF AT025N1C2ANTENNA (P/N: 6010250102) This coaxial dipole antenna designed for fixed CDMA WLL phone, terminal and other wireless equipment. This antenna is RoHS compliant. 1. Specification Summary: Frequency Range ( MHz) 824-894˗1850-1990 Gain ( dBi) 2 VSWR( max) 2˖1 Impedance ( ¡) 50 Connector TNC male Polarization Vertical Max Power ( W) 20 Color Black and others Dimensions ( mm) 223(length when straight angle) x 15(ž) Weight (g) 40   TELULAR 72006600 Rev. J 2 of 6 AnteTec Technologies Ltd. Addr: No.75, Xinfangzi Cun, Huaxiang,Fengtai Dist.,Beijing 100071, China Tel: +86 10 63783362 Fax: + 86 10 63781552 http://www.antetec.com Email: [email protected] 2 of 4 pages 2.Geometry Figure  (Unit˖mm) N1 Antenna Marking: "N1" for 800/1900MHz TELULAR 72006600 Rev. J 3 of 6 AnteTec Technologies Ltd. Addr: No.75, Xinfangzi Cun, Huaxiang,Fengtai Dist.,Beijing 100071, China Tel: +86 10 63783362 Fax: + 86 10 63781552 http://www.antetec.com Email: [email protected] 3 of 4 pages 3.Electrical Specifications 3.1 S11 Parameters BAND CDMA Frequency(MHz) 824 894 1850 1990 Return Loss (dB) -12.171 -14.984 -19.286 -11.823 VSWR 1.6223 1.4572 1.2582 1.6985  3.2 Test Results 3.2.1 Return Loss TELULAR 72006600 Rev. J 4 of 6 AnteTec Technologies Ltd. Addr: No.75, Xinfangzi Cun, Huaxiang,Fengtai Dist.,Beijing 100071, China Tel: +86 10 63783362 Fax: + 86 10 63781552 http://www.antetec.com Email: [email protected] 4 of 4 pages 3.2.2 Smith 3.2.3 VSWR  TELULAR 72006600 Rev. J 5 of 6 GALTRONICS TELULAR 72006600 Rev. J 6 of 6

ee eeeTELULAR@ ••CORPORATION Attention: ApplicationExaminer ReviewingEngineer Re:RequestforconfidentialityperSection0.459 ofFCCRules Applicant:TelularCorporation FCC!D:MTFTG5112597 To WhomItMayConcern, Requestis herebysubmittedbyTelularCorporation, towithholdfrompublicreview certainportions oftheapplicationforequipmentcertificationforthereferencedFCC identifier. Inparticular,the following sectionsoftheapplicationandreportarerequested to bekeptconfidential: •Schematics •DetailedBlockdiagrams •PartsList Rationaleforrequestforconfidentiality: TelularCorporationwishesto keeptheseitemsconfidentialtomaintaina competitive advantagein themarketplace. The $125 fee forconfidentialityhasbeensubmittedalongwiththe fee forcertification. If youhavequestionsorneedfurtherinformation,pleasecontacttheundersigned. - a~w ChrisBe~------- TelularCorporation TechnologyCenter>580OldWilletsPath.Hauppauge,NY 11788USA.Phone631~232-6070.Fax631-232-6082

From: Bryan Taylor ES-LEX Sent: Thursday, October 25, 2007 8:21 AM To: Suresh Kondapalli ES-MPK Cc: Terre Wolak Intertek Subject: RE: FCC ID: MTFTG5112597 Hi Suresh, I have addressed the items you mentioned below... 1) I changed the 731 form to match the ERP and EIRP values as well as the frequency tolerances in the report. A new 731 form is attached to this email 2) The MPE miscalculation was incorrect in a couple different ways... It should have been calculated using 3061mW as the ERP, not 5023mW. I am not sure where the 5023 came from. At any rate I have included a new MPE exhibit which should now be correct. 3) I added the test distance to page 30 of the report as you suggested. 4) I added the following statement to the transmitter spurious emissions results on page 24: “All emissions not reported are at least 10dB below the limit.” Best regards, Bryan -----Original Message----- From: Suresh Kondapalli ES-MPK Sent: Wednesday, October 24, 2007 10:24 PM To: Bryan Taylor ES-LEX Cc: Terre Wolak Intertek Subject: FCC ID: MTFTG5112597 Hi Bryan, The following are my observations on TCB application with the FCC ID: MTFTG5112597 1) Power levels and frequency tolerance as mentioned in the Form 731 do not match measured power levels and frequency tolerance in the test report. Please correct. Form 731 should indicate ERP for part 22 and EIRP for part 24. 2) MPE document, see Para 1.2 Power Spectral density calculated is wrong, it should be 0.99 instead of 0.6mw/sqcm For GSM radio, it is 0.99/8 = 0.123 This should be compared with the limit 824.2/1500= 0.54mw/sqcm 3) The test distance for the spurious emissions measurement. (Page 30 of the test report) should shown on the same page. 4) For transmitter spurious emissions, please provide statement like << OLE Object: Picture (Enhanced Metafile) >> Thanks, Suresh Kondapalli EMC Team Leader Phone: 650-463-2928 Fax : 650-463-2910 [email protected] Hi Suresh, I have attached an email from the client stating that the device does not transmit audio or voice. Please let me know if this is acceptable. Many thanks, Bryan No Audio Statement.txt (8 KB) W: FCC ID: MTFTG5112597From: Matthew McKiernan [[email protected]] Sent: Friday, October 26, 2007 10:41 AM To: Bryan Taylor ES-LEX Cc: Leslie Mishrell Subject: RE: FCC ID: MTFTG5112597 Bryan- Our Telguard product submitted for FCC Part 15/22/24 testing does not transmit audio. It is a data only device. Our product encodes alarm data into SMS (Short Messaging System) Protocol and transmits to the local digital cellular network provider. Our product does not have voice capability. Please let me know ASAP if this will meet your needs. If you need a formal letter, it will have to wait until next week sometime. We are shutting down servers and phones here today at 1:00 PM. Best regards, Matt -------------------------------------------------------------------------------- From: Bryan Taylor ES-LEX [mailto:[email protected]] Sent: Thursday, October 25, 2007 3:41 PM To: Matthew McKiernan; Leslie Mishrell Subject: FW: FCC ID: MTFTG5112597 Matt / Leslie, Per the reviewers email below, could you send me a statement which says “this unit does not transmit audio” or something to that effect? I believe that would wrap this up and he could then issue the grant. Many thanks, Bryan -----Original Message----- From: Suresh Kondapalli ES-MPK Sent: Thursday, October 25, 2007 1:39 PM To: Bryan Taylor ES-LEX Subject: RE: FCC ID: MTFTG5112597 Hi Bryan, Thanks for quick response. One more question. The Block Diagram enclosed by the client shows audio interface. We know that Equipment under certification does not use audio and you did not test it as audio device. We need a statement from client "This unit is does not transmit audio" or audio interface part not used. Or The Block diagram enclosed is from Wavecom. Client can replace this with his own modified block diagram showing only functional blocks actually used by him. Thanks, Suresh

Figure 1: Antenna Removed Figure 2: End with Antenna Removed Figure 3: Left Side Figure 4: Rear Side Figure 5: Right Side Figure 6: Top End Figure 7: Top Side Figure 8: AC Adapter

ES025A (6-94) DRAWNBY: DRAWING NUMBER: APPROVEDBY: DES. ENG.MFG.MECH. DESIG. TITLE: DATE: SHT. OF 11 LABEL, FCC, PART 15, 2” X 1”, Q24+, TG4 96039300 09/25/07 D. TOBIAS R. KANCIUS REV DESCRIPTION BY DATE APPROVED - RELEASED TO RECORDS xxx 09/xx/07 NOTE:1.2. TEXT FONTS, SIZE AND LOCATION SHALL BE APPROVED BY THE MARKETING DEPARTMENT PRIOR TO VOLUME PRODUCTION. MATERIAL: 2“ x 1” ADHESIVE-BACKED POLYESTER: TELULAR P/N 67020501 (ZEBRA #65598, Z-ULTIMATE 3000 WHITE LABEL) ZEBRA #5095BK (06045 2.36” X 450 METER BLACK RESIN RIBBON). 3. ALL MATERIALS AND APPLICABLE PROCESSES USED TOWARD PRODUCTION OF THIS ITEM MUST BE IN SUCH A MANNER AS TO MAINTAINCONFORMITY WITH THE RoHS DIRECTIVES. S. FIERRO K. JANUS D. TOBIAS P/N 96039301 This device complies with part 15 of theFCC rules. Operation is subject to thefollowing two conditions: (1) This devicemay not cause harmful interference and(2) this device must accept anyinterference received, includinginterference that may cause undesiredoperation. FCC ID: MTFTG5112597A P/N 96039301

New FCC part 15 label, 96039301

Figure 1: Inside Covers Figure 2: Main Board Figure 3: Radio Module Figure 4: Rear of Main Board

731 Enterprise Drive, Lexington KY 40510 Evaluation For:Telular Corporation FCC ID: MTFTG5112597A Model Number: TG-4 Report Number: 3131792LEX-001 Page 1 of 1 MPE Evaluation 1 MAXIMUM PERMISSIBLE EXPOSURE (MPE) CALCULATIONS The § 1.1310 Radiofrequency radiation exposure limits are listed in the table below. Frequency Range (MHz) Power Density Limit (mW/cm 2 ) 0.3-3.0 100 3.0-30 900/ Frequency2 30-300 1.0 300-1500 Frequency/300 Limits for Occupational/Controlled Exposures 1500-100,000 5.0 0.3-1.34 100 1.34-30 180/Frequency2 30-300 0.2 300-1500 Frequency/1500 Limits for General Population/Uncontrolled Exposure 1500-100,000 1.0 1.1 Test Procedure The maximum measured radiated power was 3061mW at 824.2MHz. This radiated RF power was used to calculate the maximum RF exposure at a 20 cm distance using the formula: Maximum RF Exposure at 20cm = (ERP in mW)/(4Pi(20cm) 2 ) 1.2 Test Results The following calculations show the Maximum RF Exposure from the TG-4 at 20cm for the worst case measured EIRP. The MPE level is below the limits for the general population described in the table above. Maximum Peak Measured ERP = 3061mW MPE = 3061mW / (4Pi(20cm) 2 ) = 0.61 mW/cm 2 The limit at 824.2MHz = (824.2MHz / 1500) = .54 mW/cm 2 GSM radios transmit in 1 out of 8 possible timeslots. Therefore, using source base time averaging as allowed under FCC rule § 2.1091, the final MPE value which compares to the limit is: (0.61 mW/cm 2 )*(1/8) = 0.076 mW/cm 2 The above calculations clearly show that the TG-4 meets the MPE requirements for

This report is for the exclusive use of Intertek's Client and is provided pursuant to the agreement between Intertek and its Client. Intertek's responsibility and liability are limited to the terms and conditions of the agreement. Intertek assumes no liability to any party, other than to the Client in accordance with the agreement, for any loss, expense or damage occasioned by the use of this report. Only the Client is authorized to copy or distribute this report and then only in its entirety. Any use of the Intertek name or one of its marks for the sale or advertisement of the tested material, product or service must first be approved in writing by Intertek. The observations and test results in this report are relevant only to the sample tested. This report by itself does not imply that the material, product, or service is or has ever been under an Intertek certification program. TEST REPORT Report Number: 3131792LEX-001 Project Number: 3131792 Evaluation of Model Number: TG-4 FCC ID: MTFTG5112597A FCC Part 15 Subpart B FCC Part 22 Subpart H FCC Part 24 Subpart E For Telular Corporation Test Performed by: Test Authorized by: Intertek 731 Enterprise Drive Lexington, KY 40510 Telular Corporation 580 Old Willets Path Hauppage, NY 11788 Prepared By:_______________________________Date:____________ Vinay Kutty, Senior Project Engineer Approved By:______________________________Date:_____________ Bryan C. Taylor, Team Leader Intertek 731 Enterprise Drive, Lexington, KY 40510 Telephone: 859-226-1000 Fax: 859-226-1040 Web: www.etlsemko.com 10/4/2007 10/4/2007 731 Enterprise Drive, Lexington KY 40510 Evaluation For:Telular Corporation FCC ID: MTFTG5112597A Model Number: TG-4 Report Number: 3131792LEX-001 Page 2 of 32 FCC Part 15, 22H and 24E Evaluation TABLE OF CONTENTS 1 JOB DESCRIPTION .......................................................................................................................... 4 1.1 COMPANY INFORMATION............................................................................................................ 4 1.2 TEST SAMPLE INFORMATION....................................................................................................... 4 1.3 SYSTEM SUPPORT EQUIPMENT.................................................................................................... 5 1.4 CABLES USED DURING TESTING................................................................................................. 5 1.5 SYSTEM BLOCK DIAGRAM(S) ...................................................................................................... 6 1.6 MODE(S) OF OPERATION / ENGINEERING JUDGMENTS................................................................ 6 2 EXECUTIVE SUMMARY................................................................................................................. 7 2.1 MODIFICATIONS REQUIRED FOR COMPLIANCE............................................................................ 7 3 TEST FACILITY................................................................................................................................ 8 3.1 TEST EQUIPMENT......................................................................................................................... 8 4 CONDUCTED RF POWER ..............................................................................................................9 4.1 TEST PROCEDURE........................................................................................................................ 9 4.2 TEST RESULTS............................................................................................................................. 9 5 RADIATED RF POWER ................................................................................................................. 10 5.1 TEST PROCEDURE...................................................................................................................... 10 5.2 TEST RESULTS........................................................................................................................... 11 6 EMISSION LIMITATIONS, OCCUPIED BANDWIDTH .......................................................... 12 6.1 TEST PROCEDURE...................................................................................................................... 12 6.2 TEST RESULTS........................................................................................................................... 12 7 OUT OF BAND EMISSION AT ANTENNA TERMINALS........................................................ 16 7.1 TEST PROCEDURE...................................................................................................................... 16 7.2 TEST RESULTS........................................................................................................................... 17 8 CONDUCTED VOLTAGE EMISSIONS....................................................................................... 22 8.1 TEST PROCEDURE...................................................................................................................... 22 8.2 TEST RESULTS........................................................................................................................... 22 9 RADIATED SPURIOUS EMISSIONS ........................................................................................... 24 9.1 TEST PROCEDURE...................................................................................................................... 24 9.2 TEST RESULTS........................................................................................................................... 24 10 RECEIVER SPURIOUS EMISSIONS ...................................................................................... 29 10.1 TEST LIMITS...............................................................................................................................29 731 Enterprise Drive, Lexington KY 40510 Evaluation For:T…

Text truncated - open the document above for the full version.

Figure 1: Radiated Emission Testing Figure 2: Conducted Emission Testing Figure 3: Antenna Terminal Conducted Testing Figure 4: Frequency Stability Testing
