MWI-EZ8820RFCordless Office Keyboard

© Copyright 1995-2002 EzKey CORP. all rights reserved User’s Guide Version 1.2 Page: 1 / 28 USER’S GUIDE (Version 1.2) COMPLETE CORDLESS SOLUTION FOR SMART OFFICE KEYBOARD AND MOUSE Specifications and information contained in this Guide are furnished for informational use only, and are subject to change at any time without notice, and should not be construed as a commitment by EzKey. All another product name is trademarks of their respective owners. © Copyright 1995-2002 EzKey CORP. all rights reserved Table of Contents 1. Introduction:........................................................................2 2. System Requirement:.........................................................2 3. Quick Hardware Installation:..............................................3 4. Software Driver or Application Installation:.......................5 5. Feature and Function Description:....................................6 6. Smart Office Keyboard Software:....................................15 7. Troubleshooting:...............................................................18 8. Patent Descriptions:.........................................................26 © Copyright 1995-2002 EzKey CORP. all rights reserved User’s Guide Version 1.2 Page: 2 / 28 Congratulations on your purchase of this cordless RF keyboard and mouse kit. This keyboard and mouse will finally free you of the constraints of your desktop by providing a cordless connection between your keyboard/mouse and your PC. This User’s Guide contains all information that helps you to operate your cordless keyboard/mouse. In order to enjoy your cordless RF Smart Office keyboard and mouse to their full potential we recommended you read this Guide carefully prior to installation. Please keep the CD Title in a safe place for future maintenance after installation. 1. Introduction: This cordless RF keyboard and mouse kit consists of a Smart Office Keyboard, a mouse and a compact receiverbuild with optional three feet pedestal. The cordless smart office keyboard and mouse can operate freely within a radius of at least 6.5 feet Typicalfrom the compact receiver, which itself use radio frequencies to transmit the cordless signal it has no constriction on viewing angles. The kit also offers more extra functionality greater efficiency and productivity when working with a PC. Now you have more hot keys including “Office Key Zone”, “Internet Key Zone”, “Multimedia Key Zone”, “Clipboard Key Zone” and “Application Key Zone” that make your job more easy and quick access by a simple press of a key. The Navig. Wheel bar builds on the keyboard, it allow you to scroll up & down and with an optional “Pop-up” function that provides you an OnScreen Menu for quick access to frequently used text, tasks or application--with a simple scroll and click as if you were using a mouse. When using computer, as with many activities, you may experience occasional discomfort to your hands, arms, shoulders, neck, or other parts of the body. When using Smart Office Keyboard; eventually, you will not need taking your hand off the keyboard as frequently as when using a mouse. It saves up to 70% of the time and effort involved in continually changing over from the keyboard to the mouse. Moreover, reduced typing activities and movements between keyboard and mouse can prevent “Repetitive Stress Injure”. By using Smart Office Keyboard you will not only experience and enjoy the most powerful and user-friendly input device, but also the personalized configuration and comfort. Smart Office Keyboard is compatible with Office 97/2000/2002XPSome future applications and Win95/98/ME/NT/2000/XP or later operation systems. NO driver is required except the models with scrolling function, as scroll wheel requires the driver in order to activate this function. The “Word”, “Excel”, “Power Point”, “Calendar” and “Calculator” keys also require a shortcut. Basically you can just install “Smart Office Keyboard” per plug and play without necessitating a driver, or install the driver to empower the keyboard with additional functions. What’s in this package • A cordless smart office keyboard • A cordless mouse • A compact receiverbuild with three feet pedestal • A driver CD • Quick Installation Guide • Batteries3pcs of AA2pcs of AAA Go Top 2. System Requirement: Microsoft Windows 95 / 98 / ME/ 2000/ XP or laterNT4.0 with Service Pack 6 or later © Copyright 1995-2002 EzKey CORP. all rights reserved User’s Guide Version 1.2 Page: 3 / 28 Microsoft Office 97 / 2000 / XP or later (Recommended not require) Microsoft Internet Explorer 5.0 or later (Win98 or later build-in already) CD-ROM or DVD drivefor CD and Video operation Standard sound card for CD and Video operation (Recommended not require) Two available PS/2 port, If build with optional “PS2 to USB adapter”, it require one available USB port support. Note: “Sleep” hot key functionality on the keyboard that is only available if your system supports power management (ACPI), if this is enabled and all the peripherals (e.g. VGA, Sound card...) are compatible with the power management. The Windows NT cannot support USB function. So, the Keyboard only supports PS2 port while running on Windows NT system. Go Top 3. Quick Hardware Installation: • PS2 only and without optional “PS2 to USB adapter” 1. Make sure your PC is switch off. Connect the receiver to your PC by plugging in the receiver’s green connector into the mouse port of your PC and the purple connector into the keyboard. 2. Take the Keyboard and make sure the batteries on the back are installed correctly. Follow the polarity signs in the battery compartment. 3. Take the mouse and make sure the batteries on the back are installed correctly. Follow the polarity signs in the battery compartment. 4. Turn On your PC, the mouse and keyboard (expect special hot key and wheelwill work properly. 5. In case you got trouble, try the alternate channel for the receiver, keyboard and mouse in case the initially selected ch…

Text truncated - open the document above for the full version.

Ezkey Corp . KEYBOARD BLOCK DIAGRAM MICRO CONTORLLER KEY MATRIX OSC POWER CONTROL RF CIRCUIT LOW VOLTAGE DECTECTOR VOLUMN AND SCROLL ENCODER

Compliance Certification Services Inc. Report No: C30819412 Date of Issue: September 17, 2003 Page 1 Total Page: 4 Rev. 00 PHOTOGRAPHS OF EUT

FCC ID LABEL FORMAT AND LOCATION Applicant: Ezkey Corp. FCC ID: MWI-EZ8820RF FCC ID: MWI-EZ8820RF This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC ID LABEL AREA

Compliance Certification Services Inc. Report No: C30819412 Date of Issue: September 17, 2003 Page 2 Rev. 00 Compliance Certification Services Inc. Report No: C30819412 Date of Issue: September 17, 2003 Page 3 Rev. 00 Compliance Certification Services Inc. Report No: C30819412 Date of Issue: September 17, 2003 Page 4 Rev. 00

Compliance Certification Services Inc. Report No: C30819412-RP FCC ID : MWI-EZ8820RF Date of Issue: September 17, 2003 Page 1 Total Page: 18 Rev. 00 FCC CFR 47 PART 15 SUBPART C TEST REPORT For Ezkey Corp. Cordless office keyboard Model: Ez-8820 RF Trade Name: Ezkey Corp. Prepared for Ezkey Corp. 15F-7, No.258, Lian Cheng Rd., Chung Ho City, Taipei Hsien, Taiwan, R.O.C. Prepared by Compliance Certification Services Inc. No.165, Chung Sheng Road, Hsin Tien City, Taipei, Taiwan, R.O.C. TEL: (02) 2217-0894 FAX: (02) 2217-1029 Note: This report shall not be reproduced except in full, without the written approval of Compliance Certification Services Inc. This document may be altered or revised by Compliance Certification Services Inc. personnel only, and shall be noted in the revision section of the document. Lab. Code: 200617-0 Compliance Certification Services Inc. Report No: C30819412-RP FCC ID : MWI-EZ8820RF Date of Issue: September 17, 2003 Page 2 Rev. 00 TABLE OF CONTENTS 1. TEST RESULT CERTIFICATION......................................................................................3 2. EUT DESCRIPTION............................................................................................................4 3. TEST METHODOLOGY.....................................................................................................5 3.1 EUT CONFIGURATION...............................................................................................5 3.2 EUT EXERCISE...........................................................................................................5 3.3 GENERAL TEST PROCEDURES.................................................................................5 3.4 FCC PART 15.205 RESTRICTED BANDS OF OPERATIONS.......................................6 3.5 DESCRIPTION OF TEST MODES................................................................................6 4. INSTRUMENT CALIBRATION..........................................................................................7 5. FACILITIES AND ACCREDITATIONS..............................................................................7 5.1 FACILITIES.................................................................................................................7 5.2 EQUIPMENT................................................................................................................7 5.3 LABORATORY ACCREDITATIONS AND LISTINGS.................................................7 5.4 TABLE PF ACCREDITATIONS AND LISTINGS.........................................................8 6. SETUP OF EQUIPMENT UNDER TEST............................................................................9 6.1 SETUP CONFIGURATION OF EUT.............................................................................9 6.2 SUPPORT EQUIPMENT...............................................................................................9 7. FCC PART 15.227 REQUIREMENTS................................................................................10 7.1 26 DB BANDWIDTH..................................................................................................10 7.2 RADIATED EMISSIONS............................................................................................12 7.3 POWERLINE CONDUCTED EMISSIONS..................................................................17 Compliance Certification Services Inc. Report No: C30819412-RP FCC ID : MWI-EZ8820RF Date of Issue: September 17, 2003 Page 3 Rev. 00 1. TEST RESULT CERTIFICATION Applicant: Ezkey Corp. 15F-7, No.258, Lian Cheng Rd., Chung Ho City, Taipei Hsien, Taiwan, R.O.C. Equipment Under Test: Cordless office keyboard Trade Name: Ezkey Corp. Model: Ez-8820 RF Model Difference N/A Report Number: C30819412-RP Date of Test: August 13- August 15, 2003 APPLICABLE STANDARDS STANDARD TEST RESULT FCC Part 15 Subpart C No non-compliance noted The above equipment was tested by Compliance Certification Services Inc. The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.4 (1992) and the energy emitted by the sample EUT tested as described in this report is in compliance with conducted and radiated emission limits of FCC Rules Part 15.227. The test results of this report relate only to the tested sample identified in this report. Approved by: Reviewed by: David Wang Vince Chiang Manager of Hsin Tien Laboratory Supervisor Compliance Certification Services Inc. Compliance Certification Services Inc. Compliance Certification Services Inc. Report No: C30819412- RP FCC ID : MWI- EZ8820RF Date of Issue: September 17, 2003 Page 4 Rev. 00 2. EUT DESCRIPTION Product Cordless office keyboard Trade Name Ezkey Corp. Model Ez-8820 RF Model Discrepancy None Power Supply DC From Battery AA size X 3 pcs. Operate Frequency 27.095MHz, 27.145MHz Modulation Technique Frequency Shift Keying (FSK) Number of Channels 2 Antenna Designation Fixed Antenna, which is built in EUT Note: The product is a composite system which includes Transmitter and Receiver. This submittal(s) (test report) is intended for FCC ID: MWI -EZ8820RF filing to comply with Section 15.227 of the FCC Part 15 Subpart C Rules. The composite system (digital device) is compliance with Subpart B is authorized under a DoC procedure. Compliance Certification Services Inc. Report No: C30819412- RP FCC ID : MWI- EZ8820RF Date of Issue: September 17, 2003 Page 5 Rev. 00 3. TEST METHODOLOGY The tests documented in this report were performed in accordance with ANSI C63.4 and FCC CFR 47 Part 15 Subpart C. 3.1 EUT CONFIGURATION The EUT configuration for testing is installed on RF field strength measurement to meet the Commissions requirement and operating in a manner that intends to maximize its emission characteristics in a continuous normal application. 3.2 EUT EXERCISE The calibrated antennas used to sample the radiated field strength are mounted on a non-condu…

Text truncated - open the document above for the full version.

Compliance Certification Services Inc. Report No: C30819412-RP FCC ID : MWI-EZ8820RF Date of Issue: September 17, 2003 Page 18 Rev. 00 APPENDIX 1 PHOTOGRPHS OF TEST SETUP
