N3ESEEKER70108R915-916MHz WIRELESS TOY -RX

Logo Spy Gear Name Spy Seeker Descriptor Remote tracking device Arrow / burst SKU No. Small Parts Age Grading Ages 6 and Up Copyline Important: Please save this instruction sheet. It contains valuable product information! Feature Callouts Bug Tracker On/Off Buttons LED power indicator Sensor Grid Subhead 1 PLAYING WITH YOUR SPY SEEKER: 1. ADULTS: Install the batteries (see below for directions) 2. Turn the Bug (small pod) on by pushing power button. LED indicator will illuminate. 3. Turn the Seeker Unit (large pod) on by pushing power button. LED indicator will illuminate. 4. Stash the Bug in something you wish to track down (like a backpack) or have a friend hide it for you to find. 5. The Seeker Unit will beep and light up depending on how close you are to the Bug. 6. Blue lights and slow beeping mean you're in range but farther away (COOL) 7. Yellow lights and medium beeping mean you're getting close (WARM) 8. Red lights and fast beeping mean you're very close (HOT!) 9. If the lights and beeping stop, but the indicator LED is still on, then you're out of range. PLAY TIPS: • Have a friend hide with the Bug in their pocket, then try to find them! • Treasure Hunt: Using a stopwatch, see who can locate the Bug first! • Bomb Squad: Set a timer, then try to find the Bug before time is up! Batteries/Subhead BATTERY INFORMATION: Spy Seeker takes 6 AAA batteries (3 for the Transmitter, 3 for the Seeker). ADULTS: To install or change batteries (each unit) 1. Using a Philips screwdriver, loosen the screw on the battery cover. The screw will not fall out. 2. Remove the cover. 3. Install three fresh AAA alkaline batteries in each unit, following the diagram engraved inside the battery box. IMPORTANT: Make sure to install batteries in each unit AS SHOWN: two up, one down. If your Seeker does not work, double check the battery positions. 4. Reinstall the battery cover and tighten the screw. Battery Safety: 1. Only adults should install and replace batteries. 2. Do not recharge non-rechargeable batteries. 3. Remove dead or exhausted batteries. 4. Insert batteries correctly. Match positive and negative signs. 5. Do not place anything across the battery terminals. 6. Only use the batteries specified above. 7. Do not use rechargeable batteries 8. Do not mix alkaline, standard (carbon-zinc), or rechargeable (nickel-cadmium) batteries. 9. Do not mix old and new batteries. 10. Do not dispose batteries in a fire; they may explode. 11. Dispose of batteries safely FCC legal Device operates at 915MHz Logo Wild Planet UPC Spy Seeker 0000-0000-0000 Consumers If you have any questions, please contact us at 1-800-247-6570. www.wildplanet.com ©2005 Wild Planet Toys, Inc. FCC NOTE: THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR TV INTERFERENCE CAUSED BY UNAUTHORIZED MODIFICATIONS TO THIS EQUIPMENT. SUCH MODIFICATIONS COULD VOID THE USER’S AUTHORITY TO OPERATE THE EQUIPMENT.

Mar 9, 2005. Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we, Wild Planet Toys Inc., hereby request confidential treatment of information accompanying this Application (FCC ID: N3ESEEKER70108R) as outlined below: Schematics Block Diagram, Operational Descriptions The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to us, Wild Planet Toys Inc., and provide unjustified benefits to its competitors. We, Wild Planet Toys Inc., understand that pursuant to Rule 0.457, disclosure of this Application (FCC ID: N3ESEEKER70108R) and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Wild Planet Toys Inc. ------------------------------- Shannon Bruzelius Product Integrity Manager

FCC ID : N3ESEEKER70108R This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions : (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

THRUlab & Engineering. RM302,BOKJO,29-15 , CHONGPA3-DONG YONGSAN-GU, SEOUL, KOREA 81221095059F81221095056 email [email protected] APPLICANT: WILD PLANET TOYS INC. FCC ID: N3ESEEKER70108R REPORT :THRU-503010 COVER SHEET Test Report Product Name: 915-916 MHz Wireless Toy - RX FCC ID: N3ESEEKER70108R Applicant: WILD PLANET TOYS INC. 98 Battery Street, Suite 300, San Francisco, CA 94111 U.S.A Date Receipt:Mar/14/2005 Date Tested: Mar/24/2005 THRUlab & Engineering. RM302,BOKJO,29-15 , CHONGPA3-DONG YONGSAN-GU, SEOUL, KOREA 81221095059F81221095056 email [email protected] APPLICANT: WILD PLANET TOYS INC. FCC ID: N3ESEEKER70108R REPORT :THRU-503010 TABLE OF CONTENTS TABLE OF CONTENTS LIST APPLICANT: WILD PLANET TOYS INC. FCC ID: N3ESEEKER70108R TEST REPORT CONTAINING: PAGE 1...............TEST EQUIPMENT LIST PAGE 2...............TEST PROCEDURES PAGE 3...............RADIATION INTERFERENCE TEST DATA EXHIBITS CONTAINING: EXHIBIT 1............BLOCK DIAGRAM EXHIBIT 2............SCHEMATIC EXHIBIT 3............INSTRUCTION MANUAL EXHIBIT 4............SAMPLE OF FCC ID LABEL EXHIBIT 5............LOCATION OF FCC ID LABEL EXHIBIT 6............EXTERNAL PHOTO - FRONT SIDE EXHIBIT 7............EXTERNAL PHOTO - BACK SIDE EXHIBIT 8............INTERNAL PHOTO - COMPONENT SIDE EXHIBIT 9............INTERNAL PHOTO - COPPER SIDE EXHIBIT 10...........CIRCUIT DESCRIPTION EXHIBIT 11...........TEST SET UP PHOTO THRUlab & Engineering. RM302,BOKJO,29-15 , CHONGPA3-DONG YONGSAN-GU, SEOUL, KOREA 81221095059F81221095056 email [email protected] APPLICANT: WILD PLANET TOYS INC. FCC ID: N3ESEEKER70108R REPORT :THRU-503010 Page 1 of 3 APPLICANT: WILD PLANET TOYS INC. FCC ID: N3ESEEKER70108R TEST EQUIPMENT LIST DEVICE MODEL MFGR SERNO DUE.CAL EMI Test Receiver ESVS 10 Rohde & Schwarz 830489/001 2005.04.07. Spectrum Analyzer 8566B Hewlett Packard 2311A02394 2005.04.07. Spectrum Display 85662A Hewlett Packard 2542A12429 2005.04.07. Quasi-Peak Adapter 85650A Hewlett Packard 2521A00887 2005.04.07. RF Preselector 85685A Hewlett Packard 2648A00504 2005.04.07. Pre-Amplifier 8449B Hewlett Packard 3008A00375 2005.04.07. Pre-Amplifier 8447F Hewlett Packard 3113A05367 2005.04.07. Spectrum Monitor EZM Rohde & Schwarz 862304/007 2005.04.07. Bico-Antenna 94455-1 Eaton 977 2005.03.17. Log-Periodic Antenna 3146 EMCO 2051 2005.03.17. Dipole Antenna TDA25/1/2 Electro Metrics 176/200/200 2005.03.17. Horn Antenna SAS-571 A.H Systems 414 2005.03.17. Spectrum Analyzer R3261C Advantest 71720189 2005.04.07. LISN KNW-242 Kyoritsu 8-923-2 2004.07.17. LISN 8012-50-R- 24 Solar 8379121 2004.07.17. Loop Ant 6507 EMCO 1435 2004.10.06. Signal Generator SMS Rohde & Schwarz 872165/100 2005.04.07. Modulation Analyzer 8901B Hewlett Packard 3438A05094 2005.04.07. Frequency Counter CMC251 Tektronic CMC-251TW52489 2005.04.07. THRUlab & Engineering. RM302,BOKJO,29-15 , CHONGPA3-DONG YONGSAN-GU, SEOUL, KOREA 81221095059F81221095056 email [email protected] APPLICANT: WILD PLANET TOYS INC. FCC ID: N3ESEEKER70108R REPORT :THRU-503010 Page 2 of 3 TEST PROCEDURE GENERAL: This report shall NOT be reproduced except in full without the written approval of ThruLab & Engineering. RADIATION INTERFERENCE: The test procedure used was ANSI STANDARD C63.4-1992 using a HEWLETT PACKARD spectrum analyzer with a preselector. The bandwidth of the spectrum analyzer was 100 kHZ with an appropriate sweep speed. The analyzer was calibrated in dB above a microvolt at the output of the antenna. The resolution bandwidth was 100KHZ and the video bandwidth was 300KHZ. The ambient temperature of the UUT was 7ºC with a humidity of 35%. FORMULA OF CONVERSION FACTORS: The Field Strength at 3m was established by adding the meter reading of the spectrum analyzer (which is set to read in units of dBuV) to the antenna correction factor supplied by the antenna manufacturer. The antenna correction factors are stated in terms of dB. The gain of the Preselector was accounted for in the Spectrum Analyzer Meter Reading. Example: Freq (MHz) METER READING + ACF = FS 33 20 dBuV + 10.36 dB = 30.36 dBuV/m @ 3m ANSI STANDARD C63.4-1992 10.1.7 MEASUREMENT PROCEDURES: The unit under test was placed on a table 80 cm high and with dimensions of 1m by 1.5m. The table used for radiated measurements is capable of continuous rotation. When an emission was found, the table was rotated to produce the maximum signal strength. At this point, the antenna was raised and lowered from 1m to 4m. The antenna was placed in both the horizontal and vertical planes. ANSI STANDARD C63.4-1992 12.1.1.1 SUPERREGENERATIVE RECEIVER: A signal Generator was set to the unit under test operating frequency. An un- Modulated continuous wave (CW) signal was radiated at the super regenerative receiver operating frequency to cohere the characteristic broadband emissions from the receiver. The situation was similar for the conducted measurement except that the table did not rotate. The EUT was setup as described in ANSIC63.4-1992 with the EUT 40 cm from the vertical ground wall. Not Applicable, battery operated. THRUlab & Engineering. RM302,BOKJO,29-15 , CHONGPA3-DONG YONGSAN-GU, SEOUL, KOREA 81221095059F81221095056 email [email protected] APPLICANT: WILD PLANET TOYS INC. FCC ID: N3ESEEKER70108R REPORT :THRU-503010 Page 3 of 3 APPLICANT: WILD PLANET TOYS INC. FCC ID: N3ESEEKER70108R NAME OF TEST: RADIATION INTERFERENCE RULES PART NO.: 15.109 REQUIREMENTS: 30 to 88 MHz: 40.0 dBuV/M @ 3 METERS 88 to 216 MHz: 43.5 dBuV/M 216 to 960 MHz: 46.0 dBuV/M ABOVE 960 MHz: 54.0 dBuV/M TEST RESULTS: A search was made of the spectrum from 30 to 1000MHz and the measurements indicate that the unit DOES meet the FCC requirements. TEST DATA: No Emission Frequency (MHz) Meter Reading dBuV Ant. Polaritry Correction Factor dB Cable Loss dB Field Strength (dBuv/m) Margin (dBuv) Limit (dBuv/m) 1 49.98 4.6 V 10.9 1.0 16.5 -23.5 40.0 2 73.19 9.6 H 6.3 1.3 17.2 -22.8 40.0 3 79.56 7.5 H 8.0 1.3 16.8 -23.2 40.0 4 96.99 6.4 V 11.0 1.6 19.0 -24.5 43.5 5 132.42 4.6 H 13.3 1.9 19…

Text truncated - open the document above for the full version.

THRUlab & Engineering. RM302,BOKJO,29-15 , CHONGPA3-DONG YONGSAN-GU, SEOUL, KOREA 81221095059F81221095056 email [email protected] APPLICANT:WILD PLANET TOYS INC. FCC ID: N3ESEEKER70108R REPORT :THRU-503010 THRUlab & Engineering. RM302,BOKJO,29-15 , CHONGPA3-DONG YONGSAN-GU, SEOUL, KOREA 81221095059F81221095056 email [email protected] APPLICANT:WILD PLANET TOYS INC. FCC ID: N3ESEEKER70108R REPORT :THRU-503010 THRUlab & Engineering. RM302,BOKJO,29-15 , CHONGPA3-DONG YONGSAN-GU, SEOUL, KOREA 81221095059F81221095056 email [email protected] APPLICANT:WILD PLANET TOYS INC. FCC ID: N3ESEEKER70108R REPORT :THRU-503010
