N3ETRACKER70108T262-263 kHz Wireless Device - TX

Logo Spy Gear Name Spy Seeker Descriptor Remote tracking device Arrow / burst SKU No. Small Parts Age Grading Ages 6 and Up Copyline Important: Please save this instruction sheet. It contains valuable product information! Feature Callouts Bug Tracker On/Off Buttons LED power indicator Sensor Grid Subhead 1 PLAYING WITH YOUR SPY SEEKER: 1. ADULTS: Install the batteries (see below for directions) 2. Turn the Bug (small pod) on by pushing power button. LED indicator will illuminate. 3. Turn the Seeker Unit (large pod) on by pushing power button. LED indicator will illuminate. 4. Stash the Bug in something you wish to track down (like a backpack) or have a friend hide it for you to find. 5. The Seeker Unit will beep and light up depending on how close you are to the Bug. 6. Blue lights and slow beeping mean you're in range but farther away (COOL) 7. Yellow lights and medium beeping mean you're getting close (WARM) 8. Red lights and fast beeping mean you're very close (HOT!) 9. If the lights and beeping stop, but the indicator LED is still on, then you're out of range. PLAY TIPS: • Have a friend hide with the Bug in their pocket, then try to find them! • Treasure Hunt: Using a stopwatch, see who can locate the Bug first! • Bomb Squad: Set a timer, then try to find the Bug before time is up! Batteries/Subhead BATTERY INFORMATION: Spy Seeker takes 6 AAA batteries (3 for the Transmitter, 3 for the Seeker). ADULTS: To install or change batteries (each unit) 1. Using a Philips screwdriver, loosen the screw on the battery cover. The screw will not fall out. 2. Remove the cover. 3. Install three fresh AAA alkaline batteries in each unit, following the diagram engraved inside the battery box. IMPORTANT: Make sure to install batteries in each unit AS SHOWN: two up, one down. If your Seeker does not work, double check the battery positions. 4. Reinstall the battery cover and tighten the screw. Battery Safety: 1. Only adults should install and replace batteries. 2. Do not recharge non-rechargeable batteries. 3. Remove dead or exhausted batteries. 4. Insert batteries correctly. Match positive and negative signs. 5. Do not place anything across the battery terminals. 6. Only use the batteries specified above. 7. Do not use rechargeable batteries 8. Do not mix alkaline, standard (carbon-zinc), or rechargeable (nickel-cadmium) batteries. 9. Do not mix old and new batteries. 10. Do not dispose batteries in a fire; they may explode. 11. Dispose of batteries safely FCC legal Logo Wild Planet UPC Spy Seeker 0000-0000-0000 Consumers If you have any questions, please contact us at 1-800-247-6570. www.wildplanet.com ©2005 Wild Planet Toys, Inc. FCC NOTE: THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR TV INTERFERENCE CAUSED BY UNAUTHORIZED MODIFICATIONS TO THIS EQUIPMENT. SUCH MODIFICATIONS COULD VOID THE USER’S AUTHORITY TO OPERATE THE EQUIPMENT.

WILD PLANET TOYS INC. FCC ID: N3ETRACKER70108T EXTERNAL PHOTOS

FCC ID : N3ETRACKER70108T This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions : (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

WILD PLANET TOYS INC. FCC ID: N3ETRACKER70108T INTERNAL PHOTOS

TIMCO ENGINEERING INC. 849 NW State Road 45 Newberry, Florida 32669 http://www.timcoengr.com 888.472.2424 F 352.472.2030 email: [email protected] APPLICANT: WILD PLANET TOYS INC. FCC ID: N3ETRACKER70108T REPORT #: W\Wild_N3E\1069HT5\1069HT5TestReport.doc COVER SHEET Test Report Product Name: WIRELESS DEVICE TX FCC ID: N3ETRACKER70108T Applicant: WILD PLANET TOYS INC. 98 BATTERY STREET, SUITE 300 SAN FRANCISCO CA. 94111 Date Receipt: 5/17/2005 Date Tested: 5/17/2005 TIMCO ENGINEERING INC. 849 NW State Road 45 Newberry, Florida 32669 http://www.timcoengr.com 888.472.2424 F 352.472.2030 email: [email protected] APPLICANT: WILD PLANET TOYS INC. FCC ID: N3ETRACKER70108T REPORT #: W\Wild_N3E\1069HT5\1069HT5TestReport.doc TABLE OF CONTENTS TABLE OF CONTENTS APPLICANT: WILD PLANET TOYS INC. FCC ID: N3ETRACKER70108T REPORT CONTAINING: PAGE 1-3...........TEST EQUIPMENT LIST PAGE 4.............TEST PROCEDURE PAGE 5.............RADIATION INTERFERENCE TEST DATA PAGE 6.............OCCUPIED BANDWIDTH PAGE 7.............OCCUPIED BANDWIDTH PLOT EXHIBITS INCLUDING: CONFIDENTIALITY REQUEST LETTER BLOCK DIAGRAM SCHEMATIC LABEL SAMPLE LABEL LOCATION PARTS LIST INSTRUCTION MANUAL CIRCUIT DESCRIPTION EXTERNAL PHOTOGRAPHS INTERNAL PHOTOGRAPHS TIMCO ENGINEERING INC. 849 NW State Road 45 Newberry, Florida 32669 http://www.timcoengr.com 888.472.2424 F 352.472.2030 email: [email protected] APPLICANT: WILD PLANET TOYS INC. FCC ID: N3ETRACKER70108T REPORT #: W\Wild_N3E\1069HT5\1069HT5TestReport.doc Page 1 of 7 EMC Equipment List Device Manufacturer Model Serial Number Cal/Char Date Due Date or Status 3-Meter OATS TEI N/A N/A Listed 1/13/03 1/12/06 3/10-Meter OATS TEI N/A N/A Listed 3/27/04 3/26/07 Tan Tower Spectrum Analyzer HP 8566B Opt 462 3138A07786 3144A20661 CAL 9/23/03 9/23/05 Tan Tower RF Preselector HP 85685A 3221A01400 CAL 9/23/03 9/23/05 Tan Tower Quasi- Peak Adapter HP 85650A 3303A01690 CAL 9/23/03 9/23/05 Tan Tower Preamplifier HP 8449B-H023008A00372 CAL 9/23/03 9/23/05 Biconnical Antenna Eaton 94455-1 1096 CAL 8/17/04 8/17/06 BiconiLog Antenna EMCO 3143 9409-1043 No Cal Required Log-Periodic Antenna Electro-MetricsLPA-25 1122 CAL 8/26/04 8/26/06 Dipole Antenna Kit Electro-MetricsTDA-30/1- 4 153 CAL 9/26/03 9/26/05 Double-Ridged Horn Antenna Electro-MetricsRGA-180 2319 CAL 12/29/04 12/29/06 Horn Antenna *(at 3 meters) Electro-MetricsEM-6961 6246 CAL 3/31/03 3/31/05 Horn Antenna *(at 10 meters) Electro-MetricsEM-6961 6246 CAL 6/4/03 6/4/05 Termaline Wattmeter Bird Electronic Corporation 611 16405 CAL 7/16/04 7/16/06 Termaline Wattmeter Bird Electronic Corporation 6104 1926 CAL 7/16/04 7/16/06 Oscilloscope Tektronix 2230 300572 CAL 7/3/03 7/3/05 Temperature Chamber Tenney Engineering TTRC 11717-7 CHAR 1/22/03 1/22/05 AC Voltmeter HP 400FL 2213A14499 CAL 7/19/04 7/19/06 Peak Power Meter HP 8900C 2131A00545 CAL 7/2/03 7/2/05 Power Sensor Agilent Technologies 84811A 2551A02705 CAL 7/2/03 7/2/05 TIMCO ENGINEERING INC. 849 NW State Road 45 Newberry, Florida 32669 http://www.timcoengr.com 888.472.2424 F 352.472.2030 email: [email protected] APPLICANT: WILD PLANET TOYS INC. FCC ID: N3ETRACKER70108T REPORT #: W\Wild_N3E\1069HT5\1069HT5TestReport.doc Page 2 of 7 Device Manufacturer Model Serial Number Cal/Char Date Due Date or Status Power Meter HP 432A 1141A07655 CAL 4/11/05 4/11/07 Power Sensor HP 478A 72129 CAL 4/11/05 4/11/07 Power Meter And Sensor Bird 4421-107 & 4022 0166 & 0218 CAL 4/16/03 4/16/05 Digital Thermometer Fluke 2166A 42032 CAL 7/19/04 7/19/06 Thermometer Extech 4028 14871-2 CAL 3/7/03 3/7/05 Frequency Counter HP 5352B 2632A00165 CAL 8/3/04 8/3/06 Frequency Counter HP 5385A 2730A03025 CAL 4/15/05 4/15/07 Service Monitor IFR FM/AM 500A 5182 CAL 11/05/04 11/5/06 Signal Generator HP 8640B 2308A21464 CAL 8/26/04 8/26/06 Sweep Generator Wiltron 6648 101009 CAL 4/15/03 4/15/05 Sweep Generator Wiltron 6669M 007005 CAL 3/3/03 3/3/05 Modulation Analyzer HP 8901A 3435A06868 CAL 9/5/04 11/22/06 Audio Generator B&K Precision 3010 8739686 CHAR 12/1/04 12/1/06 Frequency Counter HP 5385A 3242A07460 CAL 4/15/05 4/15/07 Amplifier HP 11975A 2738A01969 No Cal Required Measuring Tape-20M Kraftixx 0631-20 CHAR 2/1/04 2/1/06 Measuring Tape- 7.5M Kraftixx 7.5M PROFI CHAR 2/1/04 2/1/06 Compliance Test System - AC Power Source California Instruments 1251RP L05865 CAL 2/25/04 2/25/06 Compliance Test System - PACS-1 Module California Instruments PACS-1 X71484 CAL 2/25/04 2/25/06 Amplifier Amplifier Research 10W1000B 23117 No Cal Required Field Monitor Amplifier Research FM5004 22288 No Cal Required TIMCO ENGINEERING INC. 849 NW State Road 45 Newberry, Florida 32669 http://www.timcoengr.com 888.472.2424 F 352.472.2030 email: [email protected] APPLICANT: WILD PLANET TOYS INC. FCC ID: N3ETRACKER70108T REPORT #: W\Wild_N3E\1069HT5\1069HT5TestReport.doc Page 3 of 7 Device Manufacturer Model Serial Number Cal/Char Date Due Date or Status Standard Gain Horn 1.0-2.4 GHz Polarad CA-L 235 No Cal Required Standard Gain Horn 2.14-4.34 GHz Polarad CA-S 203 No Cal Required Standard Gain Horn 3.95-5.85 GHz Scientific- Atlanta Inc. 11A-3.9 8448CG No Cal Required AC Voltmeter HP 400F 0950A05433 CAL 8/13/03 8/13/05 Electric Field Sensor Amplifier Research FP6001 302504 CAL 8/23/04 8/23/06 Electric Field Sensor Amplifier Research FP6001 302510 CAL 6/1/04 6/1/06 RF Power Amplifier Ophir RF, Inc. 5150F 1041 CHAR 10/31/03 10/31/05 3-Meter Anechoic Chamber Panashield N/A N/A Listed 5/12/04 5/11/07 Digital Multimeter Fluke 77III 79510408 CAL 7/19/04 7/19/06 Signal Generator HP 8648C 3847A04696 CAL 9/27/04 9/27/06 TIMCO ENGINEERING INC. 849 NW State Road 45 Newberry, Florida 32669 http://www.timcoengr.com 888.472.2424 F 352.472.2030 email: [email protected] APPLICANT: WILD PLANET TOYS INC. FCC ID: N3ETRACKER70108T REPORT #: W\Wild_N3E\1069HT5\1069HT5TestReport.doc Page 4 of 7 TEST PROCEDURES GENERAL: This report shall NOT be reproduced except in full without the written approval of TIMCO ENGINEERING, INC. RADIATION INTERFERENCE: The test procedure u…
