N5WNP16PSBDMHJKH2Dual Mode 800 MHz Phone AMPS/CDMA

NeoPoint™ 1600 User’s Guide NeoPoint - Your New Point of Communication Preliminary Draft © Copyright 1998, 1999 NeoPoint, Inc. SIMPLY MORE INTELLIGENTSIMPLY MORE INTELLIGENT iiNeoPoint™ 1600 User’s Guide About This Manual The information in this manual is for informational use only, subject to change without notice, and should not be construed as a commitment by NeoPoint. NeoPoint assumes no responsibility or liability for any errors or inaccuracies that may appear in this manual. No part of this manual may be reproduced, stored in a retrieval system, or transmitted, in any form or by any means, electronic, mechanical, recording, or otherwise, without the prior written permission of Innovative Global Solution, Inc. Document Number When ordering or referring to this publication, use the following number: Publication/PN: NPUG-1001, Rev. 1.03 For information or comments on this manual, please contact NeoPoint Technical Publications or visit our web site at: http://www.neopoint.com. NP1000SW120BLD Copyrights and Trademarks Copyright© 1998, 1999 NeoPoint, Inc. All Rights Reserved. NeoPoint ™ , SoftSync ™ , and the Simply More Intelligent ™ are trademarks of NeoPoint, Inc. T9 ™ Text Input and Tegic ™ are trademarks of Tegic Communications, Inc. Microsoft ® and MS-Outlook ™ are trademarks of Microsoft Corporation. HyperTerminal is a trademark of MicroSoft Corporation and Hilgraeve ProComm Plus® 32 is a registered trademark of Symantec Corporation WinFax Pro™ is a trademark of Symantec Corporation. HotFax™ is a trademark of Smith Micro Software MiniBrowser ™ and Phone.com ™ are trademarks of Phone.com, Inc. All other trademarks belong to their respective companies. Getting Technical Support You can contact NeoPoint Technical Support at: 1 (888) 458-4447 (toll free) or via e-mail at [email protected] NeoPoint, Inc. 4225 Executive Square, Suite 600 La Jolla, California 92037 Corporate office:(619) 458-2800 Fax:(619) 458-9588 NeoPoint™ 1600 User’s Guideiii FCC & Industry Canada Regulatory Compliance The NeoPoint phone is approved for use in CDMA networks. This device complies with Part 15 of the FCC Regulations. Operation of this phone is subject to the condition that it does not cause harmful interference. Your wireless hand-held portable telephone is a low power radio transmitter and receiver. When it is ON, it receives and also sends out radio frequency (RF) signals. In August 1996, the Federal Communications Commission (FCC) adopted RF exposure guidelines with safety levels for hand-held wireless phones. Those guidelines are consistent with safety standards previously set by both U.S. and international standards bodies: American National Standard Institute (ANSI), National Council of Radiation Protection and Measurements (NCRP), and International Commission on Non-Ionizing Radiation Protection (ICNRP). Those standards were based on comprehensive and periodic evaluations of the relevant scientific literature. Over 120 engineers, scientists, and physicians from universities, government health agencies and industries reviewed the available body of research to develop the ANSI Standard. The design of your phone complies with the FCC guidelines and those standards. Important: Read “Safety” on page xvii prior to using your NeoPoint phone. ivNeoPoint™ 1600 User’s Guide NeoPoint™ 1600 User’s Guidev Table of Contents About This Manual..............................................................................ii Document Number..............................................................................ii Copyrights and Trademarks................................................................ii Getting Technical Support..................................................................ii FCC & Industry Canada Regulatory Compliance..............................iii Table of Contents...........................................................................v Preface.........................................................................................xiii Daily Applications of Your NeoPoint 1600.....................................xiii Overview of This Manual................................................................xiv Dual-Mode........................................................................................xv About CDMA....................................................................................xv Signal Strength and Phone Performance....................................xv CDMA Advantages....................................................................xv Safety...............................................................................................xvii Chapter 1: Getting Started.........................................................19 Overview...........................................................................................19 Battery Installation and Charging.....................................................20 Inserting Your Battery...............................................................20 Charging Your Battery...............................................................22 NeoPoint Phone Description.............................................................24 Key Functions............................................................................25 Power On/Off Key..............................................................25 Volume/Scrolling Keys.......................................................25 Navigator Key.....................................................................26 viNeoPoint™ 1600 User’s Guide Soft Keys 1 & 2..................................................................26 Main/Menu and Back Keys................................................26 SEND, CLR, and END Keys..............................................26 SHIFT, NEXT, and SPACE Keys......................................27 Display Screen...........................................................................28 Main and Menu Screens......................…

Text truncated - open the document above for the full version.

NeoPoint 1600 User’s Guide Version 0.02 © Copyright 1998, 1999 NeoPoint, Inc. SIMPLY MORE INTELLIGENT TM iiNeoPoint 1600 User’s Guide About This Manual The information in this manual is for informational use only, subject to change without notice, and should not be construed as a commitment by NeoPoint. NeoPoint assumes no responsibility or liability for any errors or inaccuracies that may appear in this manual. No part of this manual may be reproduced, stored in a retrieval system, or transmitted, in any form or by any means, electronic, mechanical, recording, or otherwise, without the prior written permission of NeoPoint, Inc. Document Number When ordering or referring to this publication, use the following number: Publication/PN: NP16UG991115 For information or comments on this manual, please contact NeoPoint Technical Publications or visit our web site at: http://www.neopoint.com. NP16010055SWBLD Copyrights and Trademarks Copyright© 1998, 1999 NeoPoint, Inc. All Rights Reserved. NeoPoint ™ , SoftSync ™ , and the Simply More Intelligent ™ are trademarks of NeoPoint, Inc. T9 ™ Text Input and Tegic ™ are trademarks of Tegic Communications, Inc. MiniBrowser ™ and Phone.com ™ are trademarks of Phone.com, Inc. All other trademarks are the property of their owners. Getting Technical Support You can contact NeoPoint Technical Support via e-mail at: [email protected] NeoPoint, Inc. 4225 Executive Square, Suite 600 La Jolla, California 92037 NeoPoint 1600 User’s Guideiii FCC & Industry Canada Regulatory Compliance The NeoPoint phone is approved for use in CDMA networks. This device complies with Part 15 of the FCC Regulations. Operation of this phone is subject to the condition that it does not cause harmful interference. Your wireless hand-held portable telephone is a low power radio transmitter and receiver. When it is ON, it receives and also sends out radio frequency (RF) signals. In August 1996, the Federal Communications Commission (FCC) adopted RF exposure guidelines with safety levels for hand-held wireless phones. Those guidelines are consistent with safety standards previously set by both U.S. and international standards bodies: American National Standard Institute (ANSI), National Council of Radiation Protection and Measurements (NCRP), and International Commission on Non-Ionizing Radiation Protection (ICNRP). Those standards were based on comprehensive and periodic evaluations of the relevant scientific literature. The design of your phone complies with the FCC guidelines and applicable standards. NOTE:You should only use the manufacturer specified hands-free kit with the NeoPoint phone away from your body (not in your pocket); or use it with the handset in the manufacturer specified leather case. For body worn operations, third party hands-free accessories that have not been SAR tested may not comply with FCC RF exposure limits and should not be used. Important: Read “Safety” on page xvii prior to using your NeoPoint phone. ivNeoPoint 1600 User’s Guide NeoPoint 1600 User’s Guidev Table of Contents About This Manual..............................................................................ii Document Number..............................................................................ii Copyrights and Trademarks................................................................ii Getting Technical Support..................................................................ii FCC & Industry Canada Regulatory Compliance..............................iii Table of Contents...........................................................................v Preface.........................................................................................xiii Daily Applications of Your NeoPoint 1600.....................................xiii Overview of This Manual................................................................xiv Dual-Mode........................................................................................xv About CDMA....................................................................................xv Signal Strength and Phone Performance....................................xv CDMA Advantages...................................................................xvi Safety...............................................................................................xvii Chapter 1: Getting Started...........................................................1 Overview.............................................................................................1 Battery Installation and Charging.......................................................2 Inserting Your Battery.................................................................2 Charging Your Battery.................................................................4 NeoPoint Phone Description...............................................................5 Key Functions..............................................................................6 End/Power Key.....................................................................6 Volume/Scrolling Keys.........................................................6 Navigator Key.......................................................................6 viNeoPoint 1600 User’s Guide Soft Keys 1 & 2....................................................................7 Main/Menu and Back Keys..................................................7 SEND and CLR Keys...........................................................7 SHIFT, NEXT, and SPACE Keys........................................8 Display Screen.............................................................................9 Main and Menu Screens............................................................10 Onscreen Icons...........................................................................11 Entering Text, Number, and Symbol Characters.......................13 ALPHA/alpha Mode...........................................................13 T…

Text truncated - open the document above for the full version.

NeoPoint 1600 User’s Guide Version 1.00 © Copyright 1999, 2000 NeoPoint, Inc. NeoPoint TM 6,03/<025(,17(//,*(17 TM iiNeoPoint 1600 User’s Guide About This Manual The information in this manual is for informational use only, subject to change without notice, and should not be construed as a commitment by NeoPoint. NeoPoint assumes no responsibility or liability for any errors or inaccuracies that may appear in this manual. No part of this manual may be reproduced, stored in a retrieval system, or transmitted, in any form or by any means, electronic, mechanical, recording, or otherwise, without the prior written permission of NeoPoint, Inc. Document Number When ordering or referring to this publication, use the following number: Publication/PN: 70-16010-00 For information or comments on this manual, please contact NeoPoint Technical Publications or visit our web site at: http://www.neopoint.com. NP16010058SWBLD Copyrights and Trademarks Copyright© 1999, 2000 NeoPoint, Inc. All Rights Reserved. NeoPoint ™ , SoftSync Plus ™ , and the Simply More Intelligent ™ are trademarks of NeoPoint, Inc. T9 ™ Text Input and Tegic ™ are trademarks of Tegic Communications, Inc. Phone.com ™ is a trademark of Phone.com, Inc. All other trademarks are the property of their owners. Getting Technical Support You can contact NeoPoint Technical Support via e-mail at: [email protected] NeoPoint, Inc. 4225 Executive Square, Suite 600 La Jolla, California 92037 NeoPoint 1600 User’s Guideiii FCC & Industry Canada Regulatory Compliance The NeoPoint phone is approved for use with CDMA and AMPS networks. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Your wireless hand-held portable telephone is a low power radio transmitter and receiver. When it is ON, it receives and also sends out radio frequency (RF) signals. In August 1996, the Federal Communications Commission (FCC) adopted RF exposure guidelines with safety levels for hand-held wireless phones. Those guidelines are consistent with safety standards previously set by both U.S. and international standards bodies: American National Standard Institute (ANSI), National Council of Radiation Protection and Measurements (NCRP), and International Commission on Non-Ionizing Radiation Protection (ICNRP). Those standards were based on comprehensive and periodic evaluations of the relevant scientific literature. The design of your phone complies with the FCC guidelines and applicable standards. Important: Read “Safety” on page xvii prior to using your NeoPoint phone. WARNING: You should only use the manufacturer specified hands-free kit with the NeoPoint phone away from your body (not in your pocket); or use it with the handset in the manufacturer specified leather case. For body worn operations, third party hands-free accessories that have not been SAR tested may not comply with FCC RF exposure limits and should not be used. ivNeoPoint 1600 User’s Guide NeoPoint 1600 User’s Guidev Table of Contents About This Manual.............................................................................. ii Document Number .............................................................................. ii Copyrights and Trademarks ................................................................ ii Getting Technical Support .................................................................. ii FCC & Industry Canada Regulatory Compliance.............................. iii Table of Contents........................................................................... v Preface ......................................................................................... xiii Daily Applications of Your NeoPoint 1600 .....................................xiii Overview of This Manual ................................................................ xiv Dual-Mode ........................................................................................ xv About CDMA.................................................................................... xv Signal Strength and Phone Performance.................................... xv CDMA Advantages................................................................... xvi Safety............................................................................................... xvii Did You Know... .............................................................................. xix Chapter 1: Getting Started ........................................................... 1 Overview ............................................................................................. 1 Battery Installation and Charging ....................................................... 2 Inserting Your Battery ................................................................. 2 Charging Your Battery................................................................. 4 NeoPoint Phone Description ............................................................... 5 Key Functions .............................................................................. 6 End/Power Key ..................................................................... 6 Volume/Scrolling Keys......................................................... 6 viNeoPoint 1600 User’s Guide Navigator Key ...................................................................... 6 Soft Keys 1 & 2 .................................................................... 7 Main/Menu and Back Keys .................................................. 7 SEND and CLR Keys ........................................................... 7 SHIFT, NEXT, and SPACE Keys ........................................ 8 Display Screen ............................................................................. 9 Main and Menu Screens ............................…

Text truncated - open the document above for the full version.

NeoPoint 1600 Dual Mode 800 MHz AMPS CDMA Phone August 1999 APREL Project No.: NEOB-NEOPOINT-1600-3273 Consulting * Research * Training * Certification Testing Since 1981 NeoPoint 1600 Dual Mode 800 MHz AMPS CDMA Phone August 1999 APREL Project No.: NEOB-NEOPOINT-1600-3273 Consulting * Research * Training * Certification Testing Since 1981 NeoPoint 1600 Dual Mode 800 MHz AMPS CDMA Phone August 1999 APREL Project No.: NEOB-NEOPOINT-1600-3273 Consulting * Research * Training * Certification Testing Since 1981 NeoPoint 1600 Dual Mode 800 MHz AMPS CDMA Phone August 1999 APREL Project No.: NEOB-NEOPOINT-1600-3273 Consulting * Research * Training * Certification Testing Since 1981 NeoPoint 1600 Dual Mode 800 MHz AMPS CDMA Phone August 1999 APREL Project No.: NEOB-NEOPOINT-1600-3273 Consulting * Research * Training * Certification Testing Since 1981 NeoPoint 1600 Dual Mode 800 MHz AMPS CDMA Phone August 1999 APREL Project No.: NEOB-NEOPOINT-1600-3273 Consulting * Research * Training * Certification Testing Since 1981 NeoPoint 1600 Dual Mode 800 MHz AMPS CDMA Phone August 1999 APREL Project No.: NEOB-NEOPOINT-1600-3273 Consulting * Research * Training * Certification Testing Since 1981 NeoPoint 1600 Dual Mode 800 MHz AMPS CDMA Phone August 1999 APREL Project No.: NEOB-NEOPOINT-1600-3273 Consulting * Research * Training * Certification Testing Since 1981 NeoPoint 1600 Dual Mode 800 MHz AMPS CDMA Phone August 1999 APREL Project No.: NEOB-NEOPOINT-1600-3273 Consulting * Research * Training * Certification Testing Since 1981 NeoPoint 1600 Dual Mode 800 MHz AMPS CDMA Phone August 1999 APREL Project No.: NEOB-NEOPOINT-1600-3273 Consulting * Research * Training * Certification Testing Since 1981 NeoPoint 1600 Dual Mode 800 MHz AMPS CDMA Phone August 1999 APREL Project No.: NEOB-NEOPOINT-1600-3273 Consulting * Research * Training * Certification Testing Since 1981

Back view of phone with battery removed. Sample FCC Label FCC ID: N5WNP16PSBDMHJKH2 FCC ID: N5WNP16PSBDMHJKH2

Technical Descriptions: NeoPoint 1600 is a Single Band Cellular Dual Mode CDMA/AMPS phone with Personal Digital Assistant (PDA) functionality. It is designed to comply with Part 15 and Part 22 of the CFR as well as ANSI IS-98A standard. The PDA functionality of NeoPoint 1600 allows electronic organizer capabilities and data communications with a PC through a cable. TX frequencies: 824.04 MHz (Ch. 991) – 848.97MHz (Ch. 799) RX frequencies: 869.04 MHz (Ch. 991) – 893.97MHz (Ch. 799) LO frequencies: 954.42 MHz (Ch. 991) – 979.35MHz (Ch. 799) Output Power: (1) CDMA: -50dBm (min) to +23dBm (max) (2) AMPS: 8dBm (min) to +28dBm (max or lower per SAR requirement) DC voltage and current into final RF power amplifier: 4V to 5V, 120mA to 350mA Battery voltage: nominal 7.6V prismatic two-cell Li-Ion (supplied with phone) Antenna Specifications: Peak gain: 0dBi (retracted) and 2dBi (extended) over TX and RX frequencies; Omnidirectional; VSWR < 3:1 Alignment/Tune-up Procedure: This product has factory preset frequency adjustments. There is no frequency field adjustment for this product. In field operation, frequency is locked to the base station and controlled by the VCTCXO adjustments to offset any possible errors through microprocessor control in the phone. Frequency Stabilization: A voltage controlled temperature compensated crystal oscillator (VCTCXO) is utilized as a frequency reference for all of the transceiver local oscillators. This crystal oscillator is specified to a frequency stability of +/- 2.45ppm. The synthesizer lock status is constantly monitored by the microprocessor and transmission is disabled whenever an out of lock condition is detected. The mobile is locked to the base station during operation. The mobile receiver constantly monitors the received signal from the base station and makes necessary frequency adjustment on the VCTCXO to correct any frequency errors between the mobile and the base station. Suppression of Spurious Radiation: Spurious and harmonic suppression is achieved by proper design with various filters and sufficient use of metallic shields. Rigorous testing at the factory ensures continuous compliance. Limiting Output Power: Each mobile is individually calibrated at the factory to ensure max power within specified limits by employing proper frequency and temperature compensation schemes for both the TX and RX automatic gain control amplifiers. A power detector at the output of the power amplifier also constantly monitors TX output power to ensure proper limiting. Limiting Modulation: The audio input is sampled, digitally limited, and then filtered to amplitude and frequency limit the signal applied to the modulator. The device supports the ANSI IS98A dual mode operation. The device has an operating temperature range of –30C to +60C. The functions include Compandor, PLL lock detector, filtering of received data, audio signal filtering for signals. Oscillator Frequencies: 19.68MHz TCXO reference frequency 27MHz Resonator frequency for microprocessor 32.768KHz Real time clock crystal

Certification Report (Revised) on Specific Absorption Rate (SAR) Experimental Analysis NeoPoint Inc. Single Band Dual Mode Cellular Phone Date: 9 August, 1999 51 Spectrum Way Nepean ON K2R 1E6 Tel: (613) 820-2730 Fax: (613) 820-4161 email: [email protected] This report shall not be reproduced, except in full, without the express written approval of APREL Laboratories. Page 1 of 20© APREL Project #: NEOB-NP1600-3271 51 Spectrum WayTel. (613) 820-2730 Nepean, Ontario, K2R 1E6Fax (613) 820 4161 e-mail: [email protected] CERTIFICATION REPORT Subject:Specific Absorption Rate (SAR) Experimental Analysis Product:Single Band Dual Mode Cellular Telephone Model:NP1600 Client:NeoPoint, Inc. Address:4225 Executive Square Suite 700 La Jolla, CA 92037 Project #:NEOB-NP1600-3271 Prepared by:APREL Laboratories 51 Spectrum Way Nepean, Ontario K2R 1E6 Tested by____________________________Date: _________________ Heike Wünschmann, C.E.T. Submitted by____________________________Date: _________________ Dr. Paul G. Cardinal Director, Laboratories Approved by____________________________Date: _________________ Dr. Jacek J. Wojcik, P. Eng. Page 2 of 20© APREL Project #: NEOB-NP1600-3271 51 Spectrum WayTel. (613) 820-2730 Nepean, Ontario, K2R 1E6Fax (613) 820 4161 e-mail: [email protected] FCC ID:N5WNP16PSBDMHJKH2 Applicant:NeoPoint, Inc. Equipment:Single Band Dual Mode Cellular phone Model:NP1600 Standard:FCC 96 –326, Guidelines for Evaluating the Environmental Effects of Radio- Frequency Radiation ENGINEERING SUMMARY This report contains the results of the engineering evaluation performed on a NeoPoint NP1600 single band dual mode cellular phone. The measurements were carried out in accordance with FCC 96-326. The dual mode cellular phone was evaluated for its nominal maximum AMPS power level of 400 mW (26 dBm) and CDMA power level of 200 mW (23 dBm). The NP1600 was tested at high, middle, and low frequencies in both AMPS and CDMA modes, with the maximum SAR coinciding with the peak performance RF output power of channel 991 (low, 824 MHz) in AMPS mode. Test data and graphs are presented in this report. Based on the test results, it is certified that the product meets the requirements as set forth in the above specifications, for uncontrolled RF exposure environment. Page 3 of 20© APREL Project #: NEOB-NP1600-3271 51 Spectrum WayTel. (613) 820-2730 Nepean, Ontario, K2R 1E6Fax (613) 820 4161 e-mail: [email protected] TABLE OF CONTENTS 1.Introduction........................................................................................................................4 2.Applicable Documents.......................................................................................................4 3.Equipment Under Test.......................................................................................................4 4.Test Equipment..................................................................................................................5 5.Test Methodology..............................................................................................................5 6.Test Results........................................................................................................................6 6.1.Transmitter Characteristics........................................................................................6 6.2.SAR Measurements....................................................................................................6 7.Conclusions........................................................................................................................9 Appendix A..............................................................................................................................10 Appendix B..............................................................................................................................15 Appendix C..............................................................................................................................16 Appendix D..............................................................................................................................17 Appendix E...............................................................................................................................20 Page 4 of 20© APREL Project #: NEOB-NP1600-3271 51 Spectrum WayTel. (613) 820-2730 Nepean, Ontario, K2R 1E6Fax (613) 820 4161 e-mail: [email protected] 1. INTRODUCTION Tests were conducted to determine the Specific Absorption Rate (SAR) of a sample of a NeoPoint NP1600 dual mode cellular phone. These tests were conducted at APREL Laboratories’ facility located at 51 Spectrum Way, Nepean, Ontario, Canada. A view of the SAR measurement setup can be seen in Appendix A Figure 1. This report describes the results obtained. 2. APPLICABLE DOCUMENTS The following documents are applicable to the work performed: 1) FCC 96-326, Guidelines for Evaluating the Environmental Effects of Radio- Frequency Radiation 2) ANSI/IEEE C95.1-1992, IEEE Standard for Safety Levels with Respect to Human Exposure to Radio Frequency Electromagnetic Fields, 3 kHz to 300 GHz. 3) ANSI/IEEE 95.3-1992, IEEE Recommended Practice for the Measurement of Potentially Hazardous Electromagnetic Fields – RF and Microwave. 4) OET Bulletin 65 (Edition 97-01) Supplement C (Edition 97-01), “Evaluating Compliance with FCC Guidelines for Human Exposure to Radio Frequency Electromagnetic Fields”. 3. EQUIPMENT UNDER TEST • NeoPoint NP1600, single band cellular dual mode CDMA/AMPS phone. The phone’s antenna is a retractable antenna with a nominal gain of 2 dB when it is extended and 0 dB when it is retracted. It is located on the right hand side of the top of the phone. Please refer to Appendix B for photographs of the antenna. The axis of the antenna is 17 mm from the front surface plane of the handset. Page 5 of 20© APREL Project #: NEOB-NP1600-3271 51 Spectrum WayTel. (613) 820-2730 Nepean, Ontario, K2R 1E6Fax (613) 820 …

Text truncated - open the document above for the full version.

Certification Report on Specific Absorption Rate (SAR) Experimental Analysis NeoPoint Inc. Single Band Dual Mode Cellular Phone Date: 9 August, 1999 51 Spectrum Way Nepean ON K2R 1E6 Tel: (613) 820-2730 Fax: (613) 820-4161 email: [email protected] This report shall not be reproduced, except in full, without the express written approval of APREL Laboratories.

* Consulting * Research * Training * Certification Testing Since 1981 51 Spectrum Waytel: (613) 820-2730 Nepean, Ontariovisit our Web Pages: www.aprel.comfax: (613) 820-4161 Canada K2R 1E6email: [email protected] 15 November, 1999 Mr. Frank Coperich FCC Application Processing Branch Re:Questions from the FCC FCC ID:N5WNP16PSBDMHJKH2 Correspondence Reference Number:10181 731 Confirmation NumberEA95150 Date of Original E-Mail:10/14/1999 Dear Mr. Coperich: Pursuant to your e-mail to our Mr. Jay Sarkar I am forwarding to you our responses and a bit of additional support information …

Text truncated - open the document above for the full version.
