N7N-MC5720Express Mini-PCI USB Wireless CDMA 1x EV-DO Module

Sierra Wireless, ULC

Click to zoom

Application Details

Equipment Class: PCB - PCS Licensed Transmitter
Date of Grant: Jun 16, 2005
Application Purpose: Original Equipment
Date of Application: Jun 16, 2005
Equipment Note: Express Mini-PCI USB Wireless CDMA 1x EV-DO Module
Frequency Range: 824.70000000 - 848.31000000
Company: Sierra Wireless, ULC
Country: Canada

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

PCI Express MiniCard Hardware Integration Guide Proprietary and Confidential 213xxxx Rev 0.1 >> PCI Express MiniCard Hardware Integration Guide 2 Proprietary and confidential 213XXXX Preface Important notice Due to the nature of wireless communications, transmission and reception of data can never be guaranteed. Data may be delayed, corrupted (i.e., have errors) or be totally lost. Although significant delays or losses of data are rare when wireless devices such as the Sierra Wireless modem are used in a normal manner with a well-constructed network, the Sierra Wireless modem should not be used in situations where failure to transmit or receive data could result in damage of any kind to the user or any other party, including but not limited to personal injury, death, or loss of property. Sierra Wireless accepts no responsibility for damages of any kind resulting from delays or errors in data transmitted or received using the Sierra Wireless modem, or for failure of the Sierra Wireless modem to transmit or receive such data. Safety and hazards Do not operate the Sierra Wireless modem in areas where blasting is in progress, where explosive atmospheres may be present, near medical equipment, near life support equipment, or any equipment which may be susceptible to any form of radio interference. In such areas, the Sierra Wireless modem MUST BE POWERED OFF. The Sierra Wireless modem can transmit signals that could interfere with this equipment. Do not operate the Sierra Wireless modem in any aircraft, whether the aircraft is on the ground or in flight. In aircraft, the Sierra Wireless modem MUST BE POWERED OFF. When operating, the Sierra Wireless modem can transmit signals that could interfere with various onboard systems. Some airlines may permit the use of cellular phones while the aircraft is on the ground and the door is open. Sierra Wireless modems may be used at this time. The driver or operator of any vehicle should not operate the Sierra Wireless modem while in control of a vehicle. Doing so will detract from the driver or operator's control and operation of that vehicle. In some states and provinces, operating such communications devices while in control of a vehicle is an offence. Limitation of liability The information in this manual is subject to change without notice and does not represent a commitment on the part of Sierra Wireless. SIERRA WIRELESS AND ITS AFFILIATES SPECIFICALLY DISCLAIM LIABILITY FOR ANY AND ALL DIRECT, INDIRECT, SPECIAL, GENERAL, INCIDENTAL, CONSEQUENTIAL, PUNITIVE OR EXEMPLARY DAMAGES INCLUDING, BUT NOT LIMITED TO, LOSS OF PROFITS OR REVENUE OR ANTICIPATED PROFITS OR REVENUE ARISING OUT OF THE USE OR Preface Rev 1.2 Apr-05 Proprietary and confidential 3 INABILITY TO USE ANY SIERRA WIRELESS PRODUCT, EVEN IF SIERRA WIRELESS AND/OR ITS AFFILIATES HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES OR THEY ARE FORESEEABLE OR FOR CLAIMS BY ANY THIRD PARTY. Notwithstanding the foregoing, in no event shall Sierra Wireless and/or its affiliates aggregate liability arising under or in connection with the Sierra Wireless product, regardless of the number of events, occurrences, or claims giving rise to liability, be in excess of the price paid by the purchaser for the Sierra Wireless product. Patents Portions of this product are covered by some or all of the following US patents: 5,515,013 5,617,106 5,629,960 5,682,602 5,748,449 5,845,216 5,847,553 5,878,234 5,890,057 5,929,815 6,169,884 6,191,741 6,199,168 6,327,154 6,339,405 6,359,591 6,400,336 6,643,501 6,516,204 6,561,851 6,653,979 D367,062 D372,248 D372,701 D416,857 D442,170 D452,495 D452,496 D453,733 D459,303 and other patents pending. This product includes technology licensed from QUALCOMM Incorporated under one or more of the following United States patents and/or their counterparts in other nations: 4,901,307 5,056,109 5,101,501 5,109,390 5,228,054 5,267,261 5,267,262 5,337,338 5,414,796 5,416,797 5,490,165 5,504,773 5,506,865 5,511,073 5,535,239 5,544,196 5,568,483 5,600,754 5,657,420 5,659,569 5,710,784 5,778,338 Copyright ©2005 Sierra Wireless. All rights reserved. Trademarks “Heart of the Wireless Machine” is registered trademark of Sierra Wireless. Sierra Wireless, the Sierra Wireless logo, the red wave design, the red-tipped antenna, and Watcher are trademarks of Sierra Wireless. Windows ® is a registered trademark of Microsoft Corporation. Qualcomm ® is a registered trademark of Qualcomm Incorporated. Other trademarks are the property of the respective owners. PCI Express MiniCard Hardware Integration Guide 4 Proprietary and confidential 213XXXX Comments Sales Desk: Phone: 1-604-232-1488 Hours: 8:00 AM to 5:00 PM Pacific Time E-mail: [email protected] Post: Sierra Wireless 13811 Wireless Way Richmond, BC Canada V6V 3A4 Fax: 1-604-231-1109 Web: www.sierrawireless.com Your comments and suggestions on improving this documentation are welcome and appreciated. Please e-mail your feedback, noting document 2130367 Rev 1.1, to [email protected]. Thank you. Consult our website for up-to-date product descriptions, documentation, application notes, firmware upgrades, troubleshooting tips, and press releases: www.sierrawireless.com Preface Rev 1.2 Apr-05 Proprietary and confidential 5 Table of Contents Preface.......................................................................................................................................... 2 Important notice ................................................................................................................2 Safety and hazards ........................................................................................................... 2 Limitation of liability ........................................................................................................... 2 Patents .............................................................................................................................. 3 Copyright .............…

Text truncated - open the document above for the full version.

Cover Letter(s)

1 Mike Kuo From: Danielle Zhan Sent: Monday, June 06, 2005 6:46 PM To: Mike Kuo Cc: Michael Heckrotte; Barbara Judge; Thu Chan Subject: RE: Sierra Wireless Inc., FCC ID: N7N-MC5720, Assessment NO.: AN05T4773, Notice#1, urgent!! Attachments: External Photos.pdf; Internal Photos.pdf; Setup Photos.pdf; 05U3389-1_FCC 22 & 24 _Revised 060305_avg=25dBm.pdf; MC5720 Modular Approval Letter.pdf Hi Mike, Please find answers to your questions contained below in blue. Since client needs the TCB/IC grants urgently, your further review at your earliest convenience would be greatly appreciated. Danielle -----Original Message----- From: Mike Kuo Sent: Tuesday, May 17, 2005 3:41 PM To: Thu Chan; Danielle Zhan Cc: Michael Heckrotte; Barbara Judge Subject: FW: Sierra Wireless Inc., FCC ID: N7N-MC5720, Assessment NO.: AN05T4773, Notice#1 Best Regards Mike Kuo Compliance Certification Services 561F Monterey Road Morgan Hill CA 95037 Tel: (408)463-0885 x: 105 Fax: (408)463-0888 http://www.ccsemc.com -----Original Message----- From: Compliance Certification Services [mailto:[email protected]] Sent: Tuesday, May 17, 2005 4:35 PM To: Mike Kuo Subject: Sierra Wireless Inc., FCC ID: N7N-MC5720, Assessment NO.: AN05T4773, Notice#1 Question #1: Please retake internal and external photos. The submitted photos are not clear enough to see all the components. [Danielle] New photos taken as attached. Also saved under the TCB and IC Submission drives. 2 External Photos.pdf (305 KB) Internal Photos.pdf (454 KB) Question #2: Due to the request for short term confidentiality on the test setup photos, please remove the test setup photos from the Part 22/24 test report. [Danielle] Setup Photos as attached have been removed from the revised test report. Also saved under TCB and IC Submission drives. Setup Photos.pdf (478 KB) Question #3: Based upon the technical specification, the max. antenna gain that can be used with this module are : 5 dBi / Cellular Band, 4.1 dBi / PCS band. Please base upon the antenna gain information and submit MPE estimate in a separate file. In addition, please based upon the measured output power to valid the max. allowed antenna gain Vs the output power limits. [Danielle] The antenna gain has been revised in the report to be 4.65 dBi for the Cellular band and 3.35 dBi for the PCS band. MPE has been re-calculated too. Please see revised report as attached below. 05U3389-1_FCC 22 & 24_Revised ... Question #4: The max. measured RF conducted output power for Cellular band is 29.84dBm and 29.65 dBM for PCS band. These two measured output power do not agree the rated output power in page 11 of hardware integration guide. Please explain the differences. [Danielle] The output power 24 dBm listed on page 11 of hardware integration guide is average power. New test results on the average power are 25.58 dBm for the Cellular band and 25.72 dBm for the PCS band. Are these new data acceptable? Please see revised report as attached. Question #5: Please submit a request for modular approval letter. [Danielle] Provided as attached. Also saved under the TCB and IC Submission drives. MC5720 Modular Approval Letter... Best Regards Mike Kuo The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information within 30 days of the original e-mail date may result in application dismissal and forfeiture of the filing fee. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the e-mail address listed below the name of the sender.

Cover Letter(s)

Sierra Wireless America, Inc 2290 Cosmos Ct. Carlsbad CA, 92011 Tel. 760-476-8700 Fax 760-476-8701 FCC ID: N7N-MC5720 Request for transmitter modular approval Transmitter Module Characteristics Item Requirements EUT 1 Have its own RF shielding Device is equipped with Metal shielding to cover RF section. Refer to external photos 2 Have buffered modulation/data inputs (if such inputs are provided), All inputs to the modules are buffered through logic or microprocessor inputs. 3 Have it own power supply regulation Internal 1.4V power regulator. Refer to Block diagram 4 Meet the antenna requirements of Section 15.203 Device is equipped with unique antenna (U.FL-R-SMT (10)) connector. Refer to external photos 5 Be tested in a stand-alone configuration, i.e., the antenna, AC or DC power and data input/output lines must be connected to the module but, the module must not be inside another case during testing Device was tested on a supplied development platform for full modular approval. Refer to setup photos. 6 Be labeled with its own FCC ID number, and if the FCC ID is not visible when the module is installed inside another device, then the outside of the device into which the module is installed must also display a label referring to the enclosed module. Two proposed FCC ID label format are included in the filing. One of label is to be placed on the daughter card for the development kit and the other label is to be placed in the Reference Guide. Refer to FCC ID label format and location file. 7 The modular transmitter is manufactured so that the user cannot influence the operation of the transmitter that will operate outside of the scope of the regulations. Refer to “User’s Guide, Reference Guide, and Development Kit User’s Manual” Exhibit 8 Address compliance with the Commission's RF exposure limits in Sections 1.1310 and 2.1091. In addition, spread spectrum transmitters operating under Section 15.247 are required to address RF exposure compliance in accordance with Section 15.247(b)(4). MPE was calculated.

Cover Letter(s)

Request for Limited Modular Approval FCC ID:N7N-MC5720 Item No Requirements EUT 1 The final device is designed for mobile or fixed operation (Portable is not permitted – Reference TCB Exclusion List (17 July 2002) II(g)). This Mini-PCI express CDMA Modem module will be installed in a host product where the transmitting antenna can provide 20 cm separation distance to the body of user. This module is sold to OEM and will only be installed by OEM or OEM authorized installer. Install this module in a portable configuration is not allowed unless proper equipment authorization has obtained. 2 The maximum antenna gain to allow compliance with RF exposure requirements is listed on the Grant of Certification for the module The antenna gain including cable loss must not exceed 4.65 dBi in Cellular Band and 3.35 dBi in PCS band , for purposes of 2.1043 and 2.1091. Above MPE estimate is based upon the measured peak conducted output power. 3 The licensed module must have a FCC ID label on the module itself. That FCC ID label must be visible through a window on the final device or it must be visible when an access panel, door or cover is easily removed. If not, a second label must be placed on the outside of the final device that contains the following text: Contains “FCC ID: xxxyyyzzz” Please refer to the FCC ID label format. Labeling instruction has been provided in the OEM installation instruction. 4 The Grant should include the following words in the device description or grant notes: “modular transmitter” or “transmitter module” Limited modular approval is requested for this application.

Cover Letter(s)

Licensed Modular Transmitters Licensed transmitters may be approved as modules for installation into other final devices provided the following criteria are met: The final device is designed for mobile or fixed operation (Portable is not permitted – Reference TCB Exclusion List (17 July 2002) II(g)). The maximum antenna gain to allow compliance with RF exposure requirements is listed on the Grant of Certification for the module The licensed module must have a FCC ID label on the module itself. That FCC ID label must be visible through a window on the final device or it must be visible when an access panel, door or cover is easily removed. If not, a second label must be placed on the outside of the final device that contains the following text: Contains “FCC ID: xxxyyyzzz” The Grant should include the following words in the device description or grant notes: “modular transmitter” or “transmitter module” Today’s Date: December 3, 2002 Effective Date: Immediately

ID Label/Location Info

PROPOSED FCC ID LABEL AND LOCATION SIERRA WIRELESS This device complies with Part 22/24 of the FCC Rules. FCC ID: N7N-MC5720 FCC ID LABEL LOCATION Express Mini-PCI USB Wireless CDMA Modem Module PROPOSED FCC ID LABEL FOR HOST DEVICE SIERRA WIRELESS This device contains FCC ID: N7N-MC5720

RF Exposure Info

REPORT NO: 05U3389-1 DATE: MAY 02, 2005 EUT: MINI-PCI USB WIRELESS CDMA MODEM MODULE FCC ID: N7N-MC5720 Page 40 of 51 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. 7.5. MAXIMUM PERMISSIBLE EXPOSURE LIMITS §1.1310 The criteria listed in Table 1 shall be used to evaluate the environmental impact of human exposure to radio-frequency (RF) radiation as specified in §1.1307(b), except in the case of portable devices which shall be evaluated according to the provisions of §2.1093 of this chapter. REPORT NO: 05U3389-1 DATE: MAY 02, 2005 EUT: MINI-PCI USB WIRELESS CDMA MODEM MODULE FCC ID: N7N-MC5720 Page 41 of 51 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. CALCULATIONS Given E = √ (30 * P * G) / d and S = E ^ 2 / 3770 where E = Field Strength in Volts/meter P = Power in Watts G = Numeric antenna gain d = Distance in meters S = Power Density in milliwatts/square centimeter Combining equations and rearranging the terms to express the distance as a function of the remaining variables yields: d = √ ((30 * P * G) / (3770 * S)) Changing to units of Power to mW and Distance to cm, using: P (mW) = P (W) / 1000 and d (cm) =100 * d (m) yields d = 100 * √ ((30 * (P / 1000) * G) / (3770 * S)) d = 0.282 * √ (P * G / S) where d = distance in cm P = Power in mW G = Numeric antenna gain S = Power Density in mW/cm^2 Substituting the logarithmic form of power and gain using: P (mW) = 10 ^ (P (dBm) / 10) and G (numeric) = 10 ^ (G (dBi) / 10) yields d = 0.282 * 10 ^ ((P + G) / 20) / √ S Equation (1) where d = MPE distance in cm P = Power in dBm G = Antenna Gain in dBi S = Power Density Limit in mW/cm^2 Equation (1) and the measured peak power is used to calculate the MPE distance. REPORT NO: 05U3389-1 DATE: MAY 02, 2005 EUT: MINI-PCI USB WIRELESS CDMA MODEM MODULE FCC ID: N7N-MC5720 Page 42 of 51 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. LIMITS From §1.1310 Table 1 (B), S = 1.0 mW/cm^2 RESULTS No non-compliance noted: NOTE: For mobile or fixed location transmitters, the minimum separation distance is 20 cm, even if calculations indicate that the MPE distance would be less. M odePowe r D e ns ityOutputAnte nnaM PE LimitPowe rGainDis tance (mW/cm^2)(dBm)(dBi)(cm) 800MHz Celllar0.629.844.6519.98 1900 MHz PCS1.029.653.3512.60

Test Report

FCC CFR47 PART 22 SUBPART H AND PART 24 SUBPART E CERTIFICATION TEST REPORT FOR EXPRESS MINI-PCI USB WIRELESS CDMA MODEM MODULE MODEL NUMBER: MC5720 FCC ID: N7N-MC5720 REPORT NUMBER: 05U3389-1 ISSUE DATE: MAY 02, 2005 Prepared for SIERRA WIRELESS 2290 COSMOS CT. CARLSBAD CALIFORNIA 92009 U.S.A Prepared by COMPLIANCE ENGINEERING SERVICES, INC. d.b.a. COMPLIANCE CERTIFICATION SERVICES 561F MONTEREY ROAD, MORGAN HILL, CA 95037, USA TEL: (408) 463-0885 FAX: (408) 463-0888 REPORT NO: 05U3389-1 DATE: MAY 02, 2005 EUT: MINI-PCI USB WIRELESS CDMA MODEM MODULE FCC ID: N7N-MC5720 Page 2 of 51 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. Revision History Rev. Revisions Revised By REPORT NO: 05U3389-1 DATE: MAY 02, 2005 EUT: MINI-PCI USB WIRELESS CDMA MODEM MODULE FCC ID: N7N-MC5720 Page 3 of 51 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. TABLE OF CONTENTS 1. ATTESTATION OF TEST RESULTS............................................................................................. 4 2. TEST METHODOLOGY .................................................................................................................. 5 3. FACILITIES AND ACCREDITATION .......................................................................................... 5 4. CALIBRATION AND UNCERTAINTY.......................................................................................... 5 4.1. MEASURING INSTRUMENT CALIBRATION ............................................................................. 5 4.2. MEASUREMENT UNCERTAINTY ............................................................................................... 5 5. EQUIPMENT UNDER TEST............................................................................................................6 5.1. DESCRIPTION OF EUT ..............................................................................................................6 5.2. MAXIMUM OUTPUT POWER .................................................................................................... 6 5.3. DESCRIPTION OF AVAILABLE ANTENNAS ............................................................................. 6 5.4. SOFTWARE AND FIRMWARE .................................................................................................... 6 5.5. WORST-CASE CONFIGURATION AND MODE......................................................................... 6 5.6. DESCRIPTION OF TEST SETUP ................................................................................................ 7 6. TEST AND MEASUREMENT EQUIPMENT ................................................................................ 9 7. LIMITS AND RESULTS ................................................................................................................. 10 7.1. OCCUPIED BANDWIDTH ........................................................................................................ 10 7.2. RF POWER OUTPUT.................................................................................................................17 7.3. SPURIOUS EMISSION AT ANTENNA TERMINAL................................................................... 20 7.4. FIELD STRENGTH OF SPURIOUS EMISSION ....................................................................... 35 7.5. MAXIMUM PERMISSIBLE EXPOSURE ................................................................................... 40 7.6. FREQUENCY STABILITY .......................................................................................................... 43 8. SETUP PHOTOS .............................................................................................................................. 47 REPORT NO: 05U3389-1 DATE: MAY 02, 2005 EUT: MINI-PCI USB WIRELESS CDMA MODEM MODULE FCC ID: N7N-MC5720 Page 4 of 51 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. 1. ATTESTATION OF TEST RESULTS COMPANY NAME: SIERRA WIRELESS 2290 COSMOS CT. CARLSBAD CALIFORNIA 92009 U.S.A EUT DESCRIPTION: EXPRESS MINI-PCI USB WIRELESS CDMA MODEM MODULE MODEL: MC5720 SERIAL NUMBER: 10505 DATE TESTED: APRIL 25 TO 28, 2005 APPLICABLE STANDARDS STANDARD TEST RESULTS FCC PART 22 SUBPART H NO NON-COMPLIANCE NOTED FCC PART 24 SUBPART E NO NON-COMPLIANCE NOTED Compliance Certification Services, Inc. tested the above equipment in accordance with the requirements set forth in the above standards. The test results show that the equipment tested is capable of demonstrating compliance with the requirements as documented in this report. Note: The results documented in this report apply only to the tested sample, under the conditions and modes of operation as described herein. This document may not be altered or revised in any way unless done so by Compliance Certification Services and all revisions are duly noted in the revisions section. Any alteration of this document not carried out by Compliance Certification Services will constitute fraud and shall nullify the document. No part of this report may be used to claim product certification, approval, or endorsement by NVLAP, NIST, or any government agency. Approved & Released For CCS By: Tested By: THU CHAN VIEN TRAN EMC SUPERVISOR EMC ENGINEER COMPLIANCE CERTIFICATION SERVICES COMPLIANCE CERTIFICATION SERVICES REPORT NO: 05U3389-1 DATE: MAY 02, 2005 EUT: MINI-PCI USB WIRELESS CDMA MODEM MODULE FCC ID: N7N-MC5720 Page 5 of 51 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA …

Text truncated - open the document above for the full version.

Test Report

Text truncated - open the document above for the full version.

Test Setup Photos

REPORT NO: 05U3389-1 DATE: JUNE 6, 2005 EUT: MINI-PCI USB WIRELESS CDMA MODEM MODULE FCC ID: N7N-MC5720 Page 47 of 51 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. 8. SETUP PHOTOS ANTENNA PORT CONDUCTED RF MEASUREMENT SETUP REPORT NO: 05U3389-1 DATE: JUNE 6, 2005 EUT: MINI-PCI USB WIRELESS CDMA MODEM MODULE FCC ID: N7N-MC5720 Page 48 of 51 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95…

Text truncated - open the document above for the full version.

Contact Information

Applicant

Ying Wang(Director, Regulatory Compliance)

[email protected]604-232-1440Fax: 604-231-1109

Test Firm

Compliance Certification Services IncSteve Cheng

[email protected]408-463-0085Fax: 408-463-0888

Technical Specifications

#	Rule Parts	Frequency Range	Power Output	Emission	Tolerance
2	22H	824.7 MHz - 848.31 MHz	964.00 mW	1M39F9W	2.5 ppm

Modular Type

Limited Single Modular Approval

Confidentiality

Long Term

Grant Notes

Output power listed is conducted. Limited Modular Approval for use as a module in mobile-only exposure conditions, antenna gain including cable loss must not exceed 4.65 dBi in Cellular Band and 3.35 dBi in PCS band , for purposes of 2.1043 and 2.1091. This device is allowed only for OEM integration into host products; consumer or end-user installation is not allowed. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons. The antenna(s) used for this transmitter must not be co-located or operating in conjunction with any other antenna or transmitter within a host device. End-users must be provided with specific information required to satisfy RF exposure compliance for final host devices and installations.
