N7NAB300ACellular 3W Power Booster for CDPD Modem

AirBlaster User Guide Warnings and Regulatory Text User Guide text in the section Safety and Hazards: Safety and Hazards Do not operate the Sierra Wireless RF amplifier in areas where blasting is in progress, where explosive atmospheres may be present, near medical equipment, near life support equipment, or any equipment which may be susceptible to any form of radio interference. In such areas, the host communications device MUST BE TURNED OFF. The RF amplifier can transmit signals that could interfere with this equipment. Do not operate your data transmitter in close proximity to any aircraft, whether the aircraft is on the ground or in flight. Near aircraft, the host communications device MUST BE TURNED OFF. When operating, the AirBlaster RF amplifier can transmit signals that could interfere with various onboard systems. The driver or operator of any vehicle should not operate a wireless data device while in control of a vehicle. Doing so will detract from the driver or operator's control and operation of that vehicle. In some states and provinces, operating such communications devices while in control of a vehicle is an offence. Regulatory Information The equipment certifications appropriate to your device are marked on the device and the accompanying product specific information. Where appropriate, the use of the equipment is subject to the following conditions: CAUTION – Unauthorized modifications or changes not expressly approved by Sierra Wireless, Inc. could void compliance with regulatory rules, and thereby your authority to use this equipment. WARNING – (EMI) - United States FCC Information - This equipment has been tested and found to comply with the limits pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in an appropriate installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communication. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna • Increase the separation between the equipment and receiver • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected • Consult the dealer or an experienced radio/TV technician for help WARNING (EMI) - Canada - This digital apparatus does not exceed the Class A limits for radio noise emissions from digital apparatus as set out in the interference causing equipment standard entitled "Digital Apparatus", ICES-003 of the Department of Communications. Cet appareil numérique respecte les limites de bruits radioélectriques applicables aux appareils numériques de Classe A prescrites dans la norme sur le matériel brouilleur: "Appareils Numériques", NMB-003 édictée par le ministre des Communications.

User Guide o Welcome o Overview o Components o Supported Prods. o Safety Notices o Specifications o Installation o Using AirBooster o Troubleshooting o Service o Contact Us 2110195 Rev C September 1999 Welcome to the AirBooster™ 350 RF amplifier The AirBooster 350 is an intelligent RF amplifier for boosting some Sierra Wireless Class III (600mW) CDPD devices to Class I (3W). The amplifier is an "intelligent" booster in that it does not simply apply a fixed gain to a varying input RF level like a linear amplifier would. Instead, the AirBooster amplifier takes a constant RF level from the CDPD device and applies as much gain as the CDPD system requires at that moment. A GPS Option is also available, adding a GPS receiver inside the package. This is available as a field upgrade kit or pre-installed at the factory. Documentation related to GPS is covered in a separate section. Your AirBooster 350 Components All AirBooster 350 packages will include the following components: AirBooster ™ 350 RF amplifier.l Power Cable.l Sierra Wireless Product CD-ROM with this Documentation including a 3 Year Warranty. l 4 Screws with Washers.l Mounting Template.l Quick Start Guide.l Units with the factory installed GPS option will also include: DB-9 Serial Cable. l Additional accessories are available from Sierra Wireless. These include: RF Connector Cables (an assortment of lengths and connector options are available). l GPS Options (Factory Installed or Field Upgrade Kit).l GPS antennas (Magnetic or Hard Mount options).l For details on these and other Sierra Wireless accessories contact sales or visit our web site. Supported Products At the time of this writing, the AirBooster 350 RF amplifier is supported by the following Sierra Wireless products: AirCard ® 350 CDPD Adapterl SB300 OEM Modulel Additional Sierra Wireless products may be added to this list. Consult our web site for a complete and current list. CAUTION - The AirBooster 350 amplifier is designed to be used exclusively with supported Sierra Wireless products. Attaching non-supported devices will not harm the device or the amplifier but will severely impair transmissions from the device. o Welcome (top) o Overview o Safety Notices o Hazards o Regulatory o Patents o Specifications Important Notice Because of the nature of wireless communications, transmission and reception of data can never be guaranteed. Data may be delayed, corrupted (i.e., have errors) or be totally lost. Although significant delays or losses of data are rare when wireless devices such as the AirBooster 350 RF amplifier are used in a normal manner with a well-constructed network, they should not be used in situations where failure to transmit or receive data could result in damage of any kind to the user or any other party, including but not limited to personal injury, death, or loss of property. Sierra Wireless, Inc. accepts no responsibility for damages of any kind resulting from delays or errors in data transmitted or received using the AirBooster 350 RF amplifier, or for failure of the AirBooster 350 amplifier to transmit or receive such data. Safety and Hazards Do not operate the AirBooster amplifier in areas where blasting is in progress, where explosive atmospheres may be present, near medical equipment, near life support equipment, or any equipment which may be susceptible to any form of radio interference. In such areas, the host communications device MUST BE TURNED OFF. The RF amplifier can transmit signals that could interfere with this equipment. Do not operate your data transmitter in close proximity to any aircraft, whether the aircraft is on the ground or in flight. Near aircraft, the host communications device MUST BE TURNED OFF. When operating, the AirBooster RF amplifier can transmit signals that could interfere with various onboard systems. The driver or operator of any vehicle should not operate a wireless data device while in control of a vehicle. Doing so will detract from the driver or operator's control and operation of that vehicle. In some states and provinces, operating such communications devices while in control of a vehicle is an offence. WARNING - The FCC has developed guidelines to reduce any possible hazard due to exposure of the human body to electromagnetic radiation (i.e. to radio waves). In accordance with these guidelines, the antenna should be positioned at a distance greater than 50 cm (1'8") from unshielded users and bystanders when transmitting. WARNING - In order to preserve FCC compliance, the antenna used with the AirBooster 350 must have a gain of 3dBd or less. The combination of cable loss and antenna gain must not exceed an overall gain of 1dB. Antennas meeting this specification are avaiable from the following manufacturers: AllgonLarsen Antenna SpecialistsMobile Mark Antenna WorldSinclair Regulatory Information The equipment certifications appropriate to your device are marked on the device and the accompanying product specific information. Where appropriate, the use of the equipment is subject to the following conditions: CAUTION - Unauthorized modifications or changes not expressly approved by Sierra Wireless, Inc. could void compliance with regulatory rules, and thereby your authority to use this equipment. WARNING (EMI) - United States FCC Information - This equipment has been tested and found to comply with the limits pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in an appropriate installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communication. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to …

Text truncated - open the document above for the full version.

User Guide o Welcome o Overview o Components o Supported Prods. o Safety Notices o Specifications o Installation o Using AirBooster o Troubleshooting o Service o Contact Us 2110195 Rev C November 1999 Welcome to the AirBooster™ 350 RF amplifier The AirBooster 350 is an intelligent RF amplifier for boosting some Sierra Wireless Class III (600mW) CDPD devices to Class I (3W). The amplifier is an "intelligent" booster in that it does not simply apply a fixed gain to a varying input RF level like a linear amplifier would. Instead, the AirBooster amplifier takes a constant RF level from the CDPD device and applies as much gain as the CDPD system requires at that moment. A GPS Option is also available, adding a GPS receiver inside the package. This is available as a field upgrade kit or pre-installed at the factory. Documentation related to GPS is covered in a separate section. Your AirBooster 350 Components All AirBooster 350 packages will include the following components: AirBooster ™ 350 RF amplifier.l Power Cable.l Sierra Wireless Product CD-ROM with this Documentation including a 3 Year Warranty. l 4 Screws with Washers.l Mounting Template.l Quick Start Guide.l Units with the factory installed GPS option will also include: DB-9 Serial Cable. l Additional accessories are available from Sierra Wireless. These include: RF Connector Cables (an assortment of lengths and connector options are available). l GPS Options (Factory Installed or Field Upgrade Kit).l GPS antennas (Magnetic or Hard Mount options).l For details on these and other Sierra Wireless accessories contact sales or visit our web site. Supported Products At the time of this writing, the AirBooster 350 RF amplifier is supported by the following Sierra Wireless products: AirCard ® 350 CDPD Adapterl SB300 OEM Modulel Additional Sierra Wireless products may be added to this list. Consult our web site for a complete and current list. CAUTION - The AirBooster 350 amplifier is designed to be used exclusively with supported Sierra Wireless products. Attaching non-supported devices will not harm the device or the amplifier but will severely impair transmissions from the device. o Welcome (top) o Overview o Safety Notices o Hazards o Regulatory o Patents o Specifications Important Notice Because of the nature of wireless communications, transmission and reception of data can never be guaranteed. Data may be delayed, corrupted (i.e., have errors) or be totally lost. Although significant delays or losses of data are rare when wireless devices such as the AirBooster 350 RF amplifier are used in a normal manner with a well-constructed network, they should not be used in situations where failure to transmit or receive data could result in damage of any kind to the user or any other party, including but not limited to personal injury, death, or loss of property. Sierra Wireless, Inc. accepts no responsibility for damages of any kind resulting from delays or errors in data transmitted or received using the AirBooster 350 RF amplifier, or for failure of the AirBooster 350 amplifier to transmit or receive such data. Safety and Hazards Do not operate the AirBooster amplifier in areas where blasting is in progress, where explosive atmospheres may be present, near medical equipment, near life support equipment, or any equipment which may be susceptible to any form of radio interference. In such areas, the host communications device MUST BE TURNED OFF. The RF amplifier can transmit signals that could interfere with this equipment. Do not operate your data transmitter in close proximity to any aircraft, whether the aircraft is on the ground or in flight. Near aircraft, the host communications device MUST BE TURNED OFF. When operating, the AirBooster RF amplifier can transmit signals that could interfere with various onboard systems. The driver or operator of any vehicle should not operate a wireless data device while in control of a vehicle. Doing so will detract from the driver or operator's control and operation of that vehicle. In some states and provinces, operating such communications devices while in control of a vehicle is an offence. WARNING - The FCC has developed guidelines to reduce any possible hazard due to exposure of the human body to electromagnetic radiation (i.e. to radio waves). In accordance with these guidelines, the antenna should be positioned at a distance greater than 20 cm (8") from unshielded users and bystanders when transmitting. WARNING - In order to preserve FCC compliance, the antenna used with the AirBooster 350 must have a gain of 3dBd or less. The combination of cable loss and antenna gain must not exceed an overall gain of 1dB. For FCC compliance only a tested and approved antenna should be used in conjunction with RG58 cable of at least 3.81m (12'6") in length. As of this writing the following antennas have been tested and approved: Larsen model MM3800FMEl Antenna World model CLR-877l Sierra Wireless continues to test other makes and models of antennas. For the most current list, consult our website. Regulatory Information The equipment certifications appropriate to your device are marked on the device and the accompanying product specific information. Where appropriate, the use of the equipment is subject to the following conditions: CAUTION - Unauthorized modifications or changes not expressly approved by Sierra Wireless, Inc. could void compliance with regulatory rules, and thereby your authority to use this equipment. WARNING (EMI) - United States FCC Information - This equipment has been tested and found to comply with the limits pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in an appropriate installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communication. However, there is no guarantee that …

Text truncated - open the document above for the full version.

User Guide o Welcome o Overview o Components o Supported Prods. o Safety Notices o Specifications o Installation o Using AirBooster o Troubleshooting o Service o Contact Us 2110195 Rev D November 1999 Welcome to the AirBooster™ 350 RF amplifier The AirBooster 350 is an intelligent RF amplifier for boosting some Sierra Wireless Class III (600mW) CDPD devices to Class I (3W). The amplifier is an "intelligent" booster in that it does not simply apply a fixed gain to a varying input RF level like a linear amplifier would. Instead, the AirBooster amplifier takes a constant RF level from the CDPD device and applies as much gain as the CDPD system requires at that moment. A GPS Option is also available, adding a GPS receiver inside the package. This is available as a field upgrade kit or pre-installed at the factory. Documentation related to GPS is covered in a separate section. Your AirBooster 350 Components All AirBooster 350 packages will include the following components: AirBooster ™ 350 RF amplifier.l Power Cable.l Sierra Wireless Product CD-ROM with this Documentation including a 3 Year Warranty. l 4 Screws with Washers.l Mounting Template.l Quick Start Guide.l Units with the factory installed GPS option will also include: DB-9 Serial Cable. l Additional accessories are available from Sierra Wireless. These include: RF Connector Cables (an assortment of lengths and connector options are available). l GPS Options (Factory Installed or Field Upgrade Kit).l GPS antennas (Magnetic or Hard Mount options).l For details on these and other Sierra Wireless accessories contact sales or visit our web site. Supported Products At the time of this writing, the AirBooster 350 RF amplifier is supported by the following Sierra Wireless products: AirCard ® 350 CDPD Adapterl SB300 OEM Modulel Additional Sierra Wireless products may be added to this list. Consult our web site for a complete and current list. CAUTION - The AirBooster 350 amplifier is designed to be used exclusively with supported Sierra Wireless products. Attaching non-supported devices will not harm the device or the amplifier but will severely impair transmissions from the device. o Welcome (top) o Overview o Safety Notices o Hazards o Regulatory o Patents o Specifications Important Notice Because of the nature of wireless communications, transmission and reception of data can never be guaranteed. Data may be delayed, corrupted (i.e., have errors) or be totally lost. Although significant delays or losses of data are rare when wireless devices such as the AirBooster 350 RF amplifier are used in a normal manner with a well-constructed network, they should not be used in situations where failure to transmit or receive data could result in damage of any kind to the user or any other party, including but not limited to personal injury, death, or loss of property. Sierra Wireless, Inc. accepts no responsibility for damages of any kind resulting from delays or errors in data transmitted or received using the AirBooster 350 RF amplifier, or for failure of the AirBooster 350 amplifier to transmit or receive such data. Safety and Hazards Do not operate the AirBooster amplifier in areas where blasting is in progress, where explosive atmospheres may be present, near medical equipment, near life support equipment, or any equipment which may be susceptible to any form of radio interference. In such areas, the host communications device MUST BE TURNED OFF. The RF amplifier can transmit signals that could interfere with this equipment. Do not operate your data transmitter in close proximity to any aircraft, whether the aircraft is on the ground or in flight. Near aircraft, the host communications device MUST BE TURNED OFF. When operating, the AirBooster RF amplifier can transmit signals that could interfere with various onboard systems. The driver or operator of any vehicle should not operate a wireless data device while in control of a vehicle. Doing so will detract from the driver or operator's control and operation of that vehicle. In some states and provinces, operating such communications devices while in control of a vehicle is an offence. WARNING - The FCC has developed guidelines to reduce any possible hazard due to exposure of the human body to electromagnetic radiation (i.e. to radio waves). This device is approved for operation with specific Sierra Wireless modem transmitters using a 3.0dBd or a 3.4dBd vehicle-mount antenna with at least 2dB cable loss, as described in the filing. The combination of cable loss and antenna gain must not exceed an overall gain of 1dB. The antenna installation must provide a separation distance of 20cm (8") or more between the antenna and all persons to satisfy MPE compliance. WARNING - For FCC compliance only a tested and approved antenna should be used in conjunction with RG58 cable of at least 4.5m (14'9") in length. As of this writing the following antennas have been tested and approved: Larsen model MM3800FMEl Antenna World model CLR-877l Sierra Wireless continues to test other makes and models of antennas. For the most current list, consult our website. Regulatory Information The equipment certifications appropriate to your device are marked on the device and the accompanying product specific information. Where appropriate, the use of the equipment is subject to the following conditions: CAUTION - Unauthorized modifications or changes not expressly approved by Sierra Wireless, Inc. could void compliance with regulatory rules, and thereby your authority to use this equipment. WARNING (EMI) - United States FCC Information - This equipment has been tested and found to comply with the limits pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in an appropriate installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference…

Text truncated - open the document above for the full version.

User Guide o Welcome o Overview o Components o Supported Prods. o Safety Notices o Specifications o Installation o Using AirBooster o Troubleshooting o Service o Contact Us 2110195 Rev D November 1999 Welcome to the AirBooster™ 350 RF amplifier The AirBooster 350 is an intelligent RF amplifier for boosting some Sierra Wireless Class III (600mW) CDPD devices to Class I (3W). The amplifier is an "intelligent" booster in that it does not simply apply a fixed gain to a varying input RF level like a linear amplifier would. Instead, the AirBooster amplifier takes a constant RF level from the CDPD device and applies as much gain as the CDPD system requires at that moment. A GPS Option is also available, adding a GPS receiver inside the package. This is available as a field upgrade kit or pre-installed at the factory. Documentation related to GPS is covered in a separate section. Your AirBooster 350 Components All AirBooster 350 packages will include the following components: AirBooster ™ 350 RF amplifier.l Power Cable.l Sierra Wireless Product CD-ROM with this Documentation including a 3 Year Warranty. l 4 Screws with Washers.l Mounting Template.l Quick Start Guide.l Units with the factory installed GPS option will also include: DB-9 Serial Cable. l Additional accessories are available from Sierra Wireless. These include: RF Connector Cables (an assortment of lengths and connector options are available). l GPS Options (Factory Installed or Field Upgrade Kit).l GPS antennas (Magnetic or Hard Mount options).l For details on these and other Sierra Wireless accessories contact sales or visit our web site. Supported Products At the time of this writing, the AirBooster 350 RF amplifier is supported by the following Sierra Wireless products: AirCard ® 350 CDPD Adapterl SB300 OEM Modulel Additional Sierra Wireless products may be added to this list. Consult our web site for a complete and current list. CAUTION - The AirBooster 350 amplifier is designed to be used exclusively with supported Sierra Wireless products. Attaching non-supported devices will not harm the device or the amplifier but will severely impair transmissions from the device. o Welcome (top) o Overview o Safety Notices o Hazards o Regulatory o Patents o Specifications Important Notice Because of the nature of wireless communications, transmission and reception of data can never be guaranteed. Data may be delayed, corrupted (i.e., have errors) or be totally lost. Although significant delays or losses of data are rare when wireless devices such as the AirBooster 350 RF amplifier are used in a normal manner with a well-constructed network, they should not be used in situations where failure to transmit or receive data could result in damage of any kind to the user or any other party, including but not limited to personal injury, death, or loss of property. Sierra Wireless, Inc. accepts no responsibility for damages of any kind resulting from delays or errors in data transmitted or received using the AirBooster 350 RF amplifier, or for failure of the AirBooster 350 amplifier to transmit or receive such data. Safety and Hazards Do not operate the AirBooster amplifier in areas where blasting is in progress, where explosive atmospheres may be present, near medical equipment, near life support equipment, or any equipment which may be susceptible to any form of radio interference. In such areas, the host communications device MUST BE TURNED OFF. The RF amplifier can transmit signals that could interfere with this equipment. Do not operate your data transmitter in close proximity to any aircraft, whether the aircraft is on the ground or in flight. Near aircraft, the host communications device MUST BE TURNED OFF. When operating, the AirBooster RF amplifier can transmit signals that could interfere with various onboard systems. The driver or operator of any vehicle should not operate a wireless data device while in control of a vehicle. Doing so will detract from the driver or operator's control and operation of that vehicle. In some states and provinces, operating such communications devices while in control of a vehicle is an offence. WARNING - The FCC has developed guidelines to reduce any possible hazard due to exposure of the human body to electromagnetic radiation (i.e. to radio waves). This device is approved for operation with specific Sierra Wireless modem transmitters using a 3.0dBd or a 3.4dBd vehicle-mount antenna with at least 2dB cable loss, as described in the filing. The combination of cable loss and antenna gain must not exceed an overall gain of 1dB. The antenna installation must provide a separation distance of 20cm (8") or more between the antenna and all persons to satisfy MPE compliance. WARNING - For FCC compliance only a tested and approved antenna should be used in conjunction with RG58 cable of at least 4.5m (14'9") in length. As of this writing the following antennas have been tested and approved: Larsen model MM3800FMEl Antenna World model CLR-877l Sierra Wireless continues to test other makes and models of antennas. For the most current list, consult our website. Regulatory Information The equipment certifications appropriate to your device are marked on the device and the accompanying product specific information. Where appropriate, the use of the equipment is subject to the following conditions: CAUTION - Unauthorized modifications or changes not expressly approved by Sierra Wireless, Inc. could void compliance with regulatory rules, and thereby your authority to use this equipment. WARNING (EMI) - United States FCC Information - This equipment has been tested and found to comply with the limits pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in an appropriate installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference…

Text truncated - open the document above for the full version.

June 23, 1999 Federal Communications Commission Authorization and Standards Division 7435 Oakland Mills Rd. Columbia, M.D. 21046 Gentlemen: Sierra Wireless Incorporated has tested this Cellular RF amplifier in accordance with the requirements contained in the appropriate Commission Regulations. To the best of my knowledge, these tests were performed using measurement procedures consistent with the Industry or Commission standards and demonstrates that the equipment complies with the published standard. We are unable to warrant against unpublished changes in requirements. The applicable rules are listed in the following test report. The Open Area Test Site used for these measurements is located at Intertek Testing Services, Menlo Park, California. Sincerely Trent McKeen RF Engineer

June 23, 1999 Federal Communications Commission Authorization and Standards Division 7435 Oakland Mills Rd. Columbia, M.D. 21046 Dear sir/madam: Re: FCC ID N7NAB300A and Request for Confidentiality We hereby request that the documentation listed below, submitted with our application for type acceptance, be withheld from public disclosure. This request is made under the provisions of Section 0.457(d) of the Commission’s Rules, and Section 552(b)(4) of the Freedom of Information Act. We cite trade secrets as the reason and purpose of the request. 1. AB300 modem schematics (foggy schematic.pdf) 2. AB300 block diagram (foggy block diagram.pdf) Sincerely, Trent McKeen RF Engineer

Qty Reference DesignatorMFGMFG Part #Description 1Q1MOTOROLA2N7002LT1N-CHANNEL T-MOS FET 1U8ATMELAT90S2313-10SI8-BIT MICROCONTROLLER 2K PROG FLASH 1L1TOKO646CY-100M10UH CHIP SM INDUCTOR 0.08R 1D4PHILIPSBAV99DUAL DIODE SOT-23 PKG 11C1-2 C5-6 C18 C40 C48-51 C57 MURATAGRM39COG101K050100PF/25V 0603 SM CERAMIC CAPACITOR 1C56MURATAGRM39COG101K050CAPACITOR CERAMIC 100PF 25V 2C4 C39MURATAGRM39X7R103K05010NF/25V 0603 SM CERAMIC CAPACITOR 4C9 C11 C19 C27CALCHIPGMC10Z5U104Z25NT0.1UF/25V 0603 SM CERAMIC CAPACITOR 5C8 C36-37 C52-53MURATAGRM39COG180K05018PF/50V 0603 SM CERAMIC CAPACITOR 1C41TAIYO YUDENUMK107B222KZ2.2NF/50V 0603 SM CERAMIC CAPACITOR 1C42TAIYO YUDENUMK107B682KZ6.8NF/50V 0603 SM CERAMIC CAPACITOR 12C7 C16-17 C28-34 C55 C58MURATAGRM39X7R102K0501NF/50V 0603 SM CERAMIC CAPACITOR 6C21 C23-24 C35 C46-47KEMETT491A105K016AS1UF TANT A-CASE 10V CAPACITOR 1C38MATSUO267E1002106KR10uF TANT A-CASE 10V CAPACITOR 1C22NICHICONTVX1A102MCACAP 1000UF AXIAL 10V 10X21 1C14SPRAGUE516D228M016PS6ACAP 2200UF AXIAL 16V 3C15 C25-26KEMETT491B106K016AS10UF/16V TANT-B SM CAPACITOR 2C12-13KEMETT491D226K025AS22UF/25V TANT-D SM CAPACITOR 1C20KEMETT491D476K016AS47UF/16V TANT-D SM CAPACITOR 1C10UNITED CHEMICONKME35VB221M10X12LL220UF/35V TANT K-CASE CAPACITOR 1C45MURATANFA62R00C221T1220PF/50V FEEDTHRU SM CAPACITOR ARRAY 1J5ASTRONAT-EMIDB-09-F-A-T3G-NRCONN …

Text truncated - open the document above for the full version.
