N89-DTA171HDDigital Transport Adapter

Cisco HD Digital Transport Adapter (DTA) Quick Reference Guide IMPORTANT SAFETY INSTRUCTIONSNotice to InstallersThe servicing instructions in this notice are for use by qualifi ed service personnel only. To reduce the risk of electric shock, do not perform any servicing other than that contained in the operating instructions, unless you are qualifi ed to do so. 20080814_Installer820 Note to System Installer CAUTION: To reduce the risk of electric shock, do notremove cover (or back). No user-serviceable parts inside. Refer servicing to qualified service personnel. WARNING TO PREVENT FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS UNIT TO RAIN OR MOISTURE. For this apparatus, the coaxial cable shield/screen shall be grounded as close as practical to the point of entry of the cable into the building. For products sold in the US and Canada, this reminder is provided to call the system installer's attention to Article 820-93 and Article 820-100 of the NEC (or Canadian Electrical Code Part 1), which provides guidelines for proper grounding of the coaxial cable shield.This symbol is intended to alert you that uninsulated voltage within this product may have sufficient magnitude to cause electric shock.Therefore, it is dangerous to make any kind of contact with any inside part of this product.Ce symbole a pour but d’alerter toute personne qu’un contact avec une pièce interne de ce produit, sous tension et non isolée, pourrait être suffisant pour provoquer un choc électrique. Il est donc dangereux d’être en contact avec toute pièce interne de ce produit. This symbol is intended to alert you of the presence of important operating and maintenance (servicing) instructions in the literature accompanying this product. Ce symbole a pour but de vous avertir qu’une documentation importante sur le fonctionnement et l’entretien accompagne ce produit. 1) Read these instructions. 2) Keep these instructions. 3) Heed all warnings. 4) Follow all instructions. 5) Do not use this apparatus near water. 6) Clean only with dry cloth. 7) Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. 8) Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat. 9) Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other. A grounding-type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet. 10) Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit from the apparatus. 11) Only use attachments/accessories specified by the manufacturer. 12) Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over. 13) Unplug this apparatus during lightning storms or when unused for long periods of time. 14) Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as a power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped. Power Source WarningA label on this product indicates the correct power source for this product. Operate this product only from an electrical outlet with the voltage and frequency indicated on the product label. If you are uncertain of the type of power supply to your home or business, consult your service provider or your local power company.The AC inlet on the unit must remain accessible and operable at all times.Ground the Product WARNING: Avoid electric shock and fi re hazard! If this product connects to coaxial cable wiring, be sure the cable system is grounded (earthed). Grounding provides some protection against voltage surges and built-up static charges. WARNING: Avoid electric shock and fi re hazard! Do not locate an outside antenna system in the vicinity of overhead power lines or power circuits. Touching power lines or circuits might be fatal. This product may contain a tuner capable of receiving off-the-air broadcasts. Operating EnvironmentThis product is designed for operation indoors with a temperature range from 32° to 104° F (0° to 40°C). Each product should have adequate spacing on all sides so that the cooling air vents on the chassis are not blocked.(Protect from Exposure to Moisture and Foreign Objects)Protect from Exposure to Moisture and Foreign Objects WARNING: Avoid electric shock and fi re hazard! Do not expose this product to dripping or splashing liquids, rain, or moisture. Objects fi lled with liquids, such as vases, should not be placed on this apparatus. WARNING: Avoid electric shock and fi re hazard! Unplug this product before cleaning. Do not use a liquid cleaner or an aerosol cleaner. Do not use a magnetic/static cleaning device (dust remover) to clean this product. WARNING: Avoid electric shock and fi re hazard! Never push objects through the openings in this product. Foreign objects can cause electrical shorts that can result in electric shock or fi re. Service Warnings WARNING: Avoid electric shock! Do not open the cover of this product. Opening or removing the cover may expose you to dangerous voltages. If you open the cover, your warranty will be void. This product contains no user-serviceable parts. Check Product SafetyUpon completion of any service or repairs to this product, the service technician must perform safety checks to determine that this product is in proper operating condition.Protect the Product When Moving ItAlways disconnect the power source when moving…

Text truncated - open the document above for the full version.

CyberTAN Technology, Inc. No.99, Park Avenue III, Science-based Industrial Park, Hsinchu, Taiwan 308,R.O.C. Federal Communications Commission Authorization and Evaluation Division Date:2012/8/10 Confidentiality Request FCC ID: N89-171 Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying this Application as outlined below: Schematic Diagram Block Diagram The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely yours, ------------------------------------------------------------------------------ Amy Wu Manager CyberTAN Technology, Inc. Tel.: 886 3-5777777 Fax: 886 3-5777788

CyberTAN Technology, Inc. No.99, Park Avenue III, Science-based Industrial Park, Hsinchu, Taiwan 308,R.O.C. Federal Communications Commission Authorization and Evaluation Division Date: August 16, 2012 Confidentiality Request FCC ID: N89-DTA171HD Pursuant to DA 04-1705 of the Commission’s Rules, we request short-term confidential treatment for the following information until December. 30, 2012 of Equipment Authorization in order to ensure sensitive business information remains confidential until the actual marketing of the device: External Photos Test Setup Photos User’s Manual Internal Photo Thank you! Sincerely yours, ------------------------------------------------------------------------------ Amy Wu Manager CyberTAN Technology, Inc. Tel.: 886 3-5777777 Fax: 886 3-5777788

CyberTAN Technology, Inc. No.99, Park Avenue III, Science-based Industrial Park, Hsinchu, Taiwan 308,R.O.C. Power of Attorney Date:2012/8/7 To whom it may concern: We, the undersigned CyberTAN Technology, Inc. hereby authorize Bureau Veritas Consumer Products Services (H.K) Ltd., Taoyuan Branch. of Taiwan to act on our behalf in all matters relating to all processes required in the FCC Part 15C approval and any communication needed with the national authority. Any and all acts carried out by Bureau Veritas Consumer Products Services (H.K) Ltd., Taoyuan Branch. on our behalf shall have the same effects as acts of our own. If you have any questions regarding the authorization, please don’t hesitate to contact us. Thank you! Sincerely yours, ------------------------------------------------------------------------------ Amy Wu Manager CyberTAN Technology, Inc. Tel.: 886 3-5777777 Fax: 886 3-5777788

Report No.: 110610E02B 1 Reference No.: 111004E06 CONSTRUCTION PHOTOS OF EUT Model: DTA 170HD Report No.: 110610E02B 5 Reference No.: 111004E06 Model: DTA 171HD Report No.: 110610E02B 9 Reference No.: 111004E06 Report No.: 110610E02B 10 Reference No.: 111004E06 Report No.: 110610E02B 11 Reference No.: 111004E06 Report No.: 110610E02B 12 Reference No.: 111004E06

FCC ID：N89-DTA171HD LABEL LOCATION The label will be permanently affixed at a conspicuous location on the device.

Report No.: 110610E02B 2 Reference No.: 111004E06 Model: DTA 170HD Report No.: 110610E02B 3 Reference No.: 111004E06 Report No.: 110610E02B 4 Reference No.: 111004E06 Report No.: 110610E02B 6 Reference No.: 111004E06 Model: DTA 171HD Report No.: 110610E02B 7 Reference No.: 111004E06 Report No.: 110610E02B 8 Reference No.: 111004E06

FCC ID: N89-DTA171HD Report No.: RF 111004E06 Operational Description This device is a Digital Transport Adapter. The transmitter of the EUT is powered by 5Vdc from AC Adapter. The antenna is PIFA antenna without antenna connector. For more detailed instruction, please take a look at the user’s manual.

Report No.: RF110610E02B R1 1 Report Format Version 4.0.0 Reference No.: 111004E06 Cancels and replaces the report No.: RF110610E02B dated Nov. 24, 2011 FCC TEST REPORT REPORT NO.: RF110610E02B R1 MODEL NO.: DTA171 HD FCC ID: N89-DTA171HD RECEIVED: Sep. 21, 2011 TESTED: Sep. 21 to Oct. 06, 2011 ISSUED: Aug. 17, 2012 APPLICANT: CyberTAN Technology, Inc. ADDRESS: No.99, Park Avenue III, Science-based Industrial Park, Hsinchu, Taiwan 308,R.O.C. ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch LAB ADDRESS : No. 81-1, Lu Liao Keng, 9th Ling,Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan TEST LOCATION (1): No. 81-1, Lu Liao Keng, 9th Ling,Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan TEST LOCATION (2): No. 49, Ln. 206, Wende Rd., Shangshan Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan This test report consists of 32 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product certification, approval, or endorsement by TAF or any government agencies. The test results in the report only apply to the tested sample. Report No.: RF110610E02B R1 2 Report Format Version 4.0.0 Reference No.: 111004E06 Cancels and replaces the report No.: RF110610E02B dated Nov. 24, 2011 Table of Contents RELEASE CONTROL RECORD ................................................................................. 3 1 CERTIFICATION .............................................................................................. 4 2 SUMMARY OF TEST RESULTS ..................................................................... 5 2.1 MEASUREMENT UNCERTAINTY ................................................................... 5 3 GENERAL INFORMATION .............................................................................. 6 3.1 GENERAL DESCRIPTION OF EUT ....................................................................... 6 3.2 DESCRIPTION OF TEST MODES .......................................................................... 7 3.3 TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL ................... 8 3.4 GENERAL DESCRIPTION OF APPLIED STANDARDS .................................. 9 3.5 DESCRIPTION OF SUPPORT UNITS .......................................................... 10 3.6 CONFIGURATION OF SYSTEM UNDER TEST............................................ 11 4 TEST PROCEDURES AND RESULTS .......................................................... 12 4.1 RADIATED EMISSION MEASUREMENT ...................................................... 12 4.1.1 LIMITS OF RADIATED EMISSION MEASUREMENT ................................... 17 4.1.2 TEST INSTRUMENTS ................................................................................... 18 4.1.3 TEST PROCEDURES ................................................................................... 19 4.1.4 DEVIATION FROM TEST STANDARD .......................................................... 19 4.1.5 TEST SETUP ................................................................................................. 20 4.1.6 EUT OPERATING CONDITIONS .................................................................. 20 4.1.7 TEST RESULTS ............................................................................................ 21 4.2 CONDUCTED - OUT BAND MEASUREMENT ............................................. 28 4.2.1 LIMITS OF CONDUCTED - OUT BAND MEASUREMENT ........................... 28 4.2.2 TEST INSTRUMENTS ................................................................................... 28 4.2.3 TEST PROCEDURE ...................................................................................... 28 4.2.4 DEVIATION FROM TEST STANDARD .......................................................... 28 4.2.5 EUT OPERATING CONDITION ..................................................................... 28 4.2.6 TEST RESULTS ............................................................................................ 29 5 INFORMATION ON THE TESTING LABORATORIES ................................... 31 6 APPENDIX A - MODIFICATIONS RECORDERS FOR ENGINEERING CHANGES TO THE EUT BY THE LAB ......................................................... 32 Report No.: RF110610E02B R1 3 Report Format Version 4.0.0 Reference No.: 111004E06 Cancels and replaces the report No.: RF110610E02B dated Nov. 24, 2011 RELEASE CONTROL RECORD ISSUE NO. REASON FOR CHANGE DATE ISSUED RF111004E06 Original release Nov. 24, 2011 RF111004E06 R1 Modified the model name Aug. 17, 2012 Report No.: RF110610E02B R1 4 Report Format Version 4.0.0 Reference No.: 111004E06 Cancels and replaces the report No.: RF110610E02B dated Nov. 24, 2011 1 CERTIFICATION PRODUCT : Digital Transport Adapter BRAND NAME : Cisco MODEL NO. : DTA171 HD TEST SAMPLE : ENGINEERING SAMPLE APPLICANT : CyberTAN Technology, Inc. TESTED : Sep. 21 to Oct. 06, 2011 STANDARDS : FCC Part 15, Subpart C (Section 15.249) ANSI C63.4-2003 ANSI C63.10-2009 The above equipment (Model: DTA171 HD) has been tested by Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s EMC characteristics under the conditions specified in this report. PREPARED BY : , DATE: Aug. 17, 2012 ( Claire Kaun, Specialist ) APPROVED BY : , DATE: Aug. 17, 2012 ( May Chen, Deputy Manager ) Report No.: RF110610E02B R1 5 Report Format Version 4.0.0 Reference No.: 111004E06 Cancels and replaces the report No.: RF110610E02B dated Nov. 24, 2011 2 SUMMARY OF TEST RESULTS The EUT has been tested according to the following specifications: APPLIED STANDARD: 47 CFR Part 15, Subpart C Standard Paragraph Test Type ResultRemark 15.207 Condu…

Text truncated - open the document above for the full version.

Report No.: 110921E06 1 PHOTOGRAPHS OF THE TEST CONFIGURATION CONDUCTED EMISSION TEST Report No.: 110921E06 2 RADIATED EMISSION TEST
