1216264_002 Exede Residential Satellite Modem – RM5110 Series Page 1 Residential Satellite Modem RM5110 Series Models: RM5110N-030, Ka W arranty, Safety, and Environmental Information This is an interim draft manual. for beta customer shipments. This manual will be replaced by its final version prior to production release and customer shipments. ViaSat, Inc. 6155 El Camino Real Carlsbad, CA 92009 1699 USA ViaSat document: 1216264_002 Contact your service provider for additional information or questions. 1216264_002 Exede Residential Satellite Modem – RM5110 Series Page 2 Contents Warranty, Safety, and Environmental Information Warranty, Safety, and Environmental Information Warranty Information  ViaSat, Inc. (“ViaSat”), the provider of Exede Internet, does not provide a warranty to the end user for this product. Any such warranty from ViaSat, including the implied warranty of merchantability or fitness for a particular purpose, is hereby disclaimed.  Your service provider may provide a warranty for this product. For warranty information and repairs, please contact your service provider. TRADEMARK NOTICE  Exede, the Exede logo, ViaSat and the ViaSat logo are trademarks or registered trademarks of ViaSat,. in the U.S. and/or other countries. DOCUMENTATION NOTICE  © Copyright 2015 ViaSat, Inc., all rights reserved. The information, specifications, and features contained in this document are subject to change without notice and should not be construed as a commitment by ViaSat. Environmental Alerts WEEE  ViaSat has marked this product with the WEEE symbol as a convenience to its customers for environmental responsibility per European Union Directive 2012/19/EC. This product shall be collected and disposed of in accordance with national and local laws. Waste electrical and electronic products must not be disposed of with household waste. For information on proper disposal, contact your equipment distributor or service provider. ROHS Compliant  This product is in compliance with EU Directive 2011/65/EC. REACH Compliant  This product is in compliance with EU Directive 1907/2006/EC.  If additional information is required you may send correspondence to: Compliance- [email protected].  ViaSat declares that this Satellite Modem is cULus Listed and is in compliance with Canadian and U.S. safety standards and complies with the RoHS directive for hazardous materials reduction.  ViaSat declares that this Satellite Modem is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC. 1216264_002 Exede Residential Satellite Modem – RM5110 Series Page 3 Open Source Software Information  This product incorporates various open source software packages that are distributed under license terms as described at http://www.viasat.com/FOSS-Usage. Important Safety Instructions  Grounding Statement - The cable distribution system should be grounded (earthed) in accordance with ANSI/NFPA 70,the National Electrical Code (NEC), in particular Section 820.93, Grounding of Outer Conductive Shield of a Coaxial Cable.  BEFORE INSTALLING THE SATELLITE MODEM, MAKE SURE YOUR ELECTRICAL OUTLET IS PROPERLY WIRED AND YOUR COMPUTER EQUIPMENT IS PROPERLY GROUNDED. CONSULT WITH A LICENSED ELECTRICIAN IF YOU ARE NOT SURE.  READ AND UNDERSTAND ALL OPERATING INSTRUCTIONS IN THIS USER’S GUIDE.  READ AND UNDERSTAND ALL SAFETY PRECAUTIONS PRIOR TO CONNECTING CABLES TO THE SATELLITE MODEM. Warnings - A WARNING is defined as a procedure or practice that, if not correctly followed, could result in injury, death, or long term health hazard. Always observe the following WARNINGS:  There are no user-serviceable parts inside any of the equipment in your system. There are potentially lethal voltages inside the equipment. It should only be opened by a technician trained and certified to service the product.  RF Radiation Hazard. The transmitting equipment is capable of generating RF levels above the maximum permissible uncontrolled exposure level. Do not enter the radiation beam pattern of the transmitter feed horn and / or antenna when the transmitter is on.  When the Satellite Modem is powered on, DC voltage is present on the rear panel IFL connector.  To prevent fire or shock hazard, do not expose this Satellite Modem to rain or moisture. The Satellite Modem must not be exposed to dripping or splashing and no objects filled with liquids, such as vases, should be placed on or around the Satellite Modem.  Postpone Satellite Modem installation until there is no risk of thunderstorm or lightning activity in the area.  To prevent electrical shock, if the unit is provided with a polarized plug, do not connect the plug into an extension cord, receptacle or other outlet unless the plug can be fully inserted with no part of the blades exposed.  The In-Line Power Supply input power cord must be connected to a properly grounded three- prong AC outlet. Do not use adapter plugs, or remove the grounding prong from the p lug.  Maintain the Satellite Modem in a climate-controlled location with adequate air circulation at temperature that is always greater than 40 degrees Fahrenheit and less than 90 degrees Fahrenheit.  The Satellite Modem, including the coaxial cable connector, may become hot. Avoid touching the coaxial cable connector unless its power adapter has been unplugged from the power outlet for at least one minute.  To prevent overheating, do not block the ventilation holes on the sides, top, or bottom of the Satellite Modem. 1216264_002 Exede Residential Satellite Modem – RM5110 Series Page 4  Ensure that the Satellite Modem at all times has at least three inches of clearance from other objects on each side and that air can flow freely to the Satellite Modem.  Do not place anything on top of the Satellite Modem.  Keep the Satellite Modem out of the reach of children and pets. Keep the Satellite Modem upright at all times and firmly secured in the provided stand.  Do n…

Text truncated - open the document above for the full version.

FCC Statement: Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: ● Reorient or relocate the receiving antenna. ● Increase the separation between the equipment and receiver. ● Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. ● Consult the dealer or an experienced radio/TV technician for help. FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate this equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. For product available in the USA/Canada market, only channel 1~11 can be operated. Selection of other channels is not possible. This device and it's antennas(s) must not be co-located or operating in conjunction with any other antenna or transmitter except in accordance with FCC multi-transmitter product procedures. This device is restricted for indoor use. IMPORTANT NOTE: FCC Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20 cm between the radiator & your body.

Report No.:530462 SPORTON International Inc. PAGE NUMBER : 1 OF 5 TEL : 886-3-327-3456 ISSUED DATE : May 06, 2015 FAX : 886-3-327-0973 Photographs of EUT Report No.:530462 SPORTON International Inc. PAGE NUMBER : 2 OF 5 TEL : 886-3-327-3456 ISSUED DATE : May 06, 2015 FAX : 886-3-327-0973 Report No.:530462 SPORTON International Inc. PAGE NUMBER : 3 OF 5 TEL : 886-3-327-3456 ISSUED DATE : May 06, 2015 FAX : 886-3-327-0973 Adapter Report No.:530462 SPORTON International Inc. PAGE NUMBER : 4 OF 5 TEL : 886-3-327-3456 ISSUED DATE : May 06, 2015 FAX : 886-3-327-0973 Report No.:530462 SPORTON International Inc. PAGE NUMBER : 5 OF 5 TEL : 886-3-327-3456 ISSUED DATE : May 06, 2015 FAX : 886-3-327-0973 Foot Holder RJ-45 Cable

Label: Label Here

Report No.:530462 SPORTON International Inc. PAGE NUMBER : 1 OF 23 TEL : 886-3-327-3456 ISSUED DATE : May 06, 2015 FAX : 886-3-327-0973 Photographs of EUT Report No.:530462 SPORTON International Inc. PAGE NUMBER : 2 OF 23 TEL : 886-3-327-3456 ISSUED DATE : May 06, 2015 FAX : 886-3-327-0973 Report No.:530462 SPORTON International Inc. PAGE NUMBER : 3 OF 23 TEL : 886-3-327-3456 ISSUED DATE : May 06, 2015 FAX : 886-3-327-0973 Report No.:530462 SPORTON International Inc. PAGE NUMBER : 4 OF 23 TEL : 886-3-327-3456 ISSUED DATE : May 06, 2015 FAX : 886-3-327-0973 Report No.:530462 SPORTON International Inc. PAGE NUMBER : 5 OF 23 TEL : 886-3-327-3456 ISSUED DATE : May 06, 2015 FAX : 886-3-327-0973 Report No.:530462 SPORTON International Inc. PAGE NUMBER : 6 OF 23 TEL : 886-3-327-3456 ISSUED DATE : May 06, 2015 FAX : 886-3-327-0973 Report No.:530462 SPORTON International Inc. PAGE NUMBER : 7 OF 23 TEL : 886-3-327-3456 ISSUED DATE : May 06, 2015 FAX : 886-3-327-0973 Report No.:530462 SPORTON International Inc. PAGE NUMBER : 8 OF 23 TEL : 886-3-327-3456 ISSUED DATE : May 06, 2015 FAX : 886-3-327-0973 Report No.:530462 SPORTON International Inc. PAGE NUMBER : 9 OF 23 TEL : 886-3-327-3456 ISSUED DATE : May 06, 2015 FAX : 886-3-327-0973 Report No.:530462 SPORTON International Inc. PAGE NUMBER : 10 OF 23 TEL : 886-3-327-3456 ISSUED DATE : May 06, 2015 FAX : 886-3-327-0973 Report No.:530462 SPORTON International Inc. PAGE NUMBER : 11 OF 23 TEL : 886-3-327-3456 ISSUED DATE : May 06, 2015 FAX : 886-3-327-0973 Report No.:530462 SPORTON International Inc. PAGE NUMBER : 12 OF 23 TEL : 886-3-327-3456 ISSUED DATE : May 06, 2015 FAX : 886-3-327-0973 Report No.:530462 SPORTON International Inc. PAGE NUMBER : 13 OF 23 TEL : 886-3-327-3456 ISSUED DATE : May 06, 2015 FAX : 886-3-327-0973 Report No.:530462 SPORTON International Inc. PAGE NUMBER : 14 OF 23 TEL : 886-3-327-3456 ISSUED DATE : May 06, 2015 FAX : 886-3-327-0973 Report No.:530462 SPORTON International Inc. PAGE NUMBER : 15 OF 23 TEL : 886-3-327-3456 ISSUED DATE : May 06, 2015 FAX : 886-3-327-0973 Report No.:530462 SPORTON International Inc. PAGE NUMBER : 16 OF 23 TEL : 886-3-327-3456 ISSUED DATE : May 06, 2015 FAX : 886-3-327-0973 Report No.:530462 SPORTON International Inc. PAGE NUMBER : 17 OF 23 TEL : 886-3-327-3456 ISSUED DATE : May 06, 2015 FAX : 886-3-327-0973 Report No.:530462 SPORTON International Inc. PAGE NUMBER : 18 OF 23 TEL : 886-3-327-3456 ISSUED DATE : May 06, 2015 FAX : 886-3-327-0973 Report No.:530462 SPORTON International Inc. PAGE NUMBER : 19 OF 23 TEL : 886-3-327-3456 ISSUED DATE : May 06, 2015 FAX : 886-3-327-0973 Report No.:530462 SPORTON International Inc. PAGE NUMBER : 20 OF 23 TEL : 886-3-327-3456 ISSUED DATE : May 06, 2015 FAX : 886-3-327-0973 Report No.:530462 SPORTON International Inc. PAGE NUMBER : 21 OF 23 TEL : 886-3-327-3456 ISSUED DATE : May 06, 2015 FAX : 886-3-327-0973 Report No.:530462 SPORTON International Inc. PAGE NUMBER : 22 OF 23 TEL : 886-3-327-3456 ISSUED DATE : May 06, 2015 FAX : 886-3-327-0973 Report No.:530462 SPORTON International Inc. PAGE NUMBER : 23 OF 23 TEL : 886-3-327-3456 ISSUED DATE : May 06, 2015 FAX : 886-3-327-0973

Report No.: FR530462 FCC ID: N89-RM5110 Page No. : B1 of B3 Appendix B. Maximum Permissible Exposure Report No.: FR530462 FCC ID: N89-RM5110 Page No. : B2 of B3 1. Maximum Permissible Exposure 1.1. Applicable Standard Systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy levels in excess limit for maximum permissible exposure. In accordance with 47 CFR FCC Part 2 Subpart J, section 2.1091 this device has been defined as a mobile device whereby that distance of at least 0.2 m is normally maintained between the user and the device. (A) Limits for Occupational / Controlled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/ cm²) Averaging Time |E|²,|H|² or S (minutes) 0.3-3.0 614 1.63 (100)* 6 3.0-30 1842 / f 4.89 / f (900 / f)* 6 30-300 61.4 0.163 1.0 6 300-1500 F/300 6 1500-100,000 5 6 (B) Limits for General Population / Uncontrolled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/ cm²) Averaging Time |E|²,|H|² or S (minutes) 0.3-1.34 614 1.63 (100)* 30 1.34-30 824/f 2.19/f (180/f)* 30 30-300 27.5 0.073 0.2 30 300-1500 F/1500 30 1500-100,000 1.0 30 Note: f = frequency in MHz ; *Plane-wave equivalent power density 1.2. MPE Calculation Method E (V/m) ＝ d GP30 Power Density: Pd (W/m²) ＝ 377 2 E E ＝ Electric field (V/m) P ＝ Average RF output power (W) G ＝ EUT Antenna numeric gain (numeric) d ＝ Separation distance between radiator and human body (m) The formula can be changed to Pd ＝ 2 377 30 d GP   From the EUT RF output power, the minimum mobile separation distance, d=0.2m, as well as the gain of the used antenna, the RF power density can be obtained. Report No.: FR530462 FCC ID: N89-RM5110 Page No. : B3 of B3 1.3. Calculated Result and Limit Exposure Environment: General Population / Uncontrolled Exposure For 5GHz Band: Antenna Type : Printed Antenna Conducted Power for IEEE 802.11n HT20: 24.07dBm verage Output Power Distance (m) Test Freq. (MHz) Antenna Gain (dBi) Antenna Gain (numeric) (dBm) (mW) Power Density (S) (mW/cm²) Limit of Power Density (S) (mW/cm²) Test Result 0.2 5785 3.70 2.3442 24.0660 255.0327 0.119000 1 Complies For 2.4GHz Band: Antenna Type : Printed Antenna Conducted Power for IEEE 802.11n HT20: 22.36 dBm Average Output Power Distance (m) Test Freq. (MHz) Antenna Gain (dBi) Antenna Gain (numeric) (dBm) (mW) Power Density (S) (mW/cm²) Limit of Power Density (S) (mW/cm²) Test Result 0.2 2437 2.30 1.6982 22.3636 172.3307 0.058252 1 Complies

Report No.: FR530462 FCC ID: N89-RM5110 Page No. : A1 of A5 Appendix A. Test Photos Report No.: FR530462 FCC ID: N89-RM5110 Page No. : A2 of A5 1. Photographs of Conducted Emissions Test Configuration Test Mode: Mode 2 FRONT VIEW REAR VIEW Report No.: FR530462 FCC ID: N89-RM5110 Page No. : A3 of A5 2. Photographs of Radiated Emissions Test Configuration Test Configuration: 9kHz ~30MHz / Test Mode: Mode 2 FRONT VIEW REAR VIEW Report No.: FR530462 FCC ID: N89-RM5110 Page No. : A4 of A5 Test Configuration: 30MHz~1GHz / Test Mode: Mode 2 FRONT VIEW REAR VIEW Report No.: FR530462 FCC ID: N89-RM5110 Page No. : A5 of A5 Test Configuration: Above 1GHz / Test Mode: Mode 1 FRONT VIEW REAR VIEW
