N89-RT3572WLAN Dual Band 802.11 a/b/g/n module

R3572-A-IN Module USB Manual 1 RT3572-A-IN Wireless 802.11N Dual-band USB Module User Manual Rev 0.1 R3572-A-IN Module USB Manual 2 Table of Conetents Introduction Hardware installation Setting up Wireless Network by WZC service R3572-A-IN Module USB Manual 3 Chapter 1 Introduction Thank you for using the Wireless USB Module. RT3572-A-IN is a dual-band, quad-mode wireless network adapter that works on all the frequencies allocated for WLAN operation everywhere in the world. It is in compliance with the Draft IEEE802.11n standard in a 2x2 MIMO configuration. It also complies with the IEEE 802.11a, 802.11g, and 802.11b standards. RT3572-A-IN features the compactness and high bus speed of the USB specifications which gives users of laptops, notebooks, tablet PCs, and other mobile computing devices transparent Internet access anywhere in the world through any Wi-Fi network without software changes or additional hardware. Able to provide greater than 100Mbps real world throughput using high-speed spatial multiplexing modes, RT3572-A-IN provides the freedom to work as you wish, wherever you wish, using whatever kind of application you wish to use. The adapter installs directly in any host device with a USB slot: just plug it in and you’re ready to access local resources and/or the Internet at the highest speed the WLAN, the location, and the host com- puter can provide. It is ready to work “out of the box” in any embedded device or in any computer running Microsoft® Windows 2000, or XP. RT3572-A-IN USB Module is truly a “must-have” for every productivity-sensitive laptop, notebook, or tablet PC user and any bandwidth-sensitive embedded design. R3572-A-IN Module USB Manual 4 Feature z USB interface. z Draft IEEE 802.11n compatible. z Backward compatible with IEEE 802.11a/b/g standard. z Wire-free access to networked resources from anywhere beyond the desktop. z Delivers data rates up to 300 Mbps. z 802.11n: Dynamically shifts among 130, 117, 104, 78, 52, 39, 26 and 13Mbps in a 20MHz bandwidth and 300, 243, 216, 162, 108, 81, 54 and 27Mbps in a 40MHz bandwidth, based on signal strength, for maximum availability and reliability of connection. z 802.11a/g: Dynamically shifts between 54, 48, 36, 24, 18, 12, 9 and 6 Mbps network speed, based on signal strength, for maximum availability and reliability of connection. z 802.11b: Dynamically shifts between 11M, 5.5M, 2M, and 1 Mbps network speed, based on signal strength, for maximum availability and reliability of connection. z Allows users move between Access Points without resetting the connection reconfigurations. z Uses 2.4GHz and 5GHz frequency band, complying with regulatory worldwide z Supports most popular operating systems: Window 2000/XP. Linux support is also available. z Ensures great security by providing the 64/128 bits Wired Equivalent Privacy (WEP) and WiFi Protected Access (WPA) defined in the IEEE standard. z WPA support with Funk client. Radius clients in EAP-TLS, EAP, TTLS, EAP-LEAP, EAP, PEAP. z WPA2, WMM-compliant. R3572-A-IN Module USB Manual 5 Chapter 2 This chapter covers how to installing the Wireless USB Module in your embedded system. Hardware description The Wireless USB Module has a standard USB interface for attaching to the 2x5 pin header (pitch=1.27mm) on embedded system. And this module has IPEX connectors to connect to external antenna. Outlook Following is the USB module outlook R3572-A-IN Module USB Manual 6 Figure 1: USB module outlook R3572-A-IN Module USB Manual 7 Chapter 3 The Wireless Zero Configuration (WZC) service, available in Windows system, dynamically selects the wireless network to which attempts connection, based either on your preferences or on default settings. 3.1 Wireless Networks tab On the Wireless Networks tab, users are able to view and configure the following: z Use Windows to configure my wireless network settings: Enable this check box when you want to use the WZC service to configure your wireless settings. If users have third-party wireless configuration utility wants to use, please disable this check box. This option is enable by default. R3572-A-IN Module USB Manual 8 z Available networks: The list of wireless networks that are within the range of wireless adapter. To view or change the configuration of a specific wireless network and add it to the list of preferred networks, click it in the list of available networks, and then click Configure. To force the wireless adapter to initiate a new scan of wireless networks within range, please click Refresh. Preferred networks The list, by order of preference, of wireless networks with which the wireless client will attempt to connect and authenticate. To add a new wireless network that does not appear in the Available R3572-A-IN Module USB Manual 9 networks list, click Add. To remove a wireless network, click Remove. To configure the settings of a wireless network to which connected, click Properties. Advanced: To configure advanced wireless settings are independent of the wireless networks to which connected, click Advanced. User can use these advanced settings to specify whether you want to connect only to infrastructure or ad hoc wireless networks, and whether you want to attempt to automatically connect to wireless networks that are not in your R3572-A-IN Module USB Manual 10 preferred list (by using the Automatically connect to non-preferred networks setting, which is disabled by default). 3.2 Messages in notification area To enable the check box of Show icon in notification area when connected, if there is a condition that requires either user notification or intervention, the WZC service prompts you with a message in the notification area. R3572-A-IN Module USB Manual 11 R3572-A-IN Module USB Manual 12 Wireless Network Connection Status: User can check Wireless Network Connection Status, including which wireless network connected, data rate, signal strength and which IP the wireless adapter obtains. ( 11 R3572-A-IN Module USB Manual 1…

Text truncated - open the document above for the full version.

CyberTAN Technology, Inc. No.99, Park Avenue III, Science-based Industrial Park, Hsinchu, Taiwan 308,R.O.C. General Declaration Date:2011/1/17 We, CyberTAN Technology, Inc. declares that device does not have “Ad Hoc on non-US frequencies” while applying for the follow product. FCC ID: N89-RT3572 If you have any questions regarding the authorization, please don’t hesitate to contact us. Thank you! ------------------------------------------------------------------------------ Lasen Yueh Associate Director CyberTAN Technology, Inc. Tel.: 886 3-5777777 Fax: 886 3-5777788

CyberTAN Technology, Inc. No.99, Park Avenue III, Science-based Industrial Park, Hsinchu, Taiwan 308,R.O.C. Power of Attorney Federal Communications Commission Authorization and Evaluation Division Confidentiality Request FCC ID: N89-RT3572 Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying this Application as outlined below: Schematic Diagram Block Diagram The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely yours, ------------------------------------------------------------------------------ Lasen Yueh Associate Director CyberTAN Technology, Inc. Tel.: 886 3-5777777 Fax: 886 3-5777788

CyberTAN Technology, Inc. No.99, Park Avenue III, Science-based Industrial Park, Hsinchu, Taiwan 308,R.O.C. Federal Communications Commission Authorization and Evaluation Division Date: March 17, 2011 Confidentiality Request FCC ID: N89-RT3572 Pursuant to DA 04-1705 of the Commission’s Rules, we request short-term confidential treatment for the following information until March 30, 2011 of Equipment Authorization in order to ensure sensitive business information remains confidential until the actual marketing of the device: External Photos Test Setup Photos User’s Manual Internal Photo Thank you! Sincerely yours, ------------------------------------------------------------------------------ Lasen Yueh Associate Director CyberTAN Technology, Inc. Tel.: 886 3-5777777 Fax: 886 3-5777788

CyberTAN Technology, Inc. No.99, Park Avenue III, Science-based Industrial Park, Hsinchu, Taiwan 308,R.O.C. Power of Attorney Date:2011/1/18 To whom it may concern: We, the undersigned CyberTAN Technology, Inc. hereby authorize Bureau Veritas Consumer Products Services (H.K) Ltd., Taoyuan Branch. of Taiwan to act on our behalf in all matters relating to all processes required in the FCC Part 15C approval and any communication needed with the national authority. Any and all acts carried out by Bureau Veritas Consumer Products Services (H.K) Ltd., Taoyuan Branch. on our behalf shall have the same effects as acts of our own. If you have any questions regarding the authorization, please don’t hesitate to contact us. Thank you! Sincerely yours, ------------------------------------------------------------------------------ Lasen Yueh Associate Director CyberTAN Technology, Inc. Tel.: 886 3-5777777 Fax: 886 3-5777788

FCC ID: N89-RT3572 Report No.: RF991230E02 Modular Approval Request Letter Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch March 23, 2011 Dear Application Examiner, CyberTAN Technology, Inc., It’s a WLAN Dual Band 802.11 a/b/g/n module, FCC ID: N89-RT3572 would like to have your authorization as a modular device. The requirements of section 15.212 of FCC rules have been met and shown on the following statements. 1. “The modular transmitter must have its own RF shielding.”: The radio portion of this module has been shielded, please see exhibition External Photo. 2. “The modular transmitter must have buffered modulation/data inputs.” The EUT has buffered data input, it is integrated in chip RT3572. 3. “The modular transmitter must have its own power supply regulation.” The part number of this regulator is RT3572. 4. “The modular transmitter must comply with the antenna requirements of section 15.203 and 15.204(C).” The EUT meets the FCC antenna requirements. The spurious emission, unique antenna connector and photo of antennas are shown in the test report. 5. “The modular transmitter must be tested in a stand-alone configuration” The EUT was tested in a stand-alone configuration via extender. Please see section Photographs of Test Configuration in the test report, the EUT was plugged in this extender. 6. “The modular transmitter must be labeled with its own FCC ID number.” Please see exhibition Label Sample for the FCC ID of this module. And also in the exhibition Users Manual, there are instructions give to the OEM on how to label the end product. FCC ID: N89-RT3572 Report No.: RF991230E02 7. “The modular transmitter must comply with any specific rule or operating requirements applicable to the transmitter and the manufacturer must provide adequate instructions along with the module to explain any such requirements.” The EUT is compliant with all applicable FCC rules. Detail instructions for maintaining compliance are given in the Users Manual. 8. “The modular transmitter must comply with any applicable RF exposure requirements.” The EUT is compliant with all applicable RF exposure requirements. RF Exposure is addressed in the RF exposure exhibition. Please contact me if you have any further questions. Thanks for your attention. Best Regards, signature Hank Chung Assistant Manager Bureau Veritas Consumer Products Services (H.K.) Ltd., Hsinchu Branch

Page 1 CONSTRUCTION PHOTOS OF EUT Page 2

Model No: RT3572

(Fig. 1) FCC ID: N89-RT3572 FCC LABEL LOCATION The label will be permanently affixed at a conspicuous location on the device. Label

Page 1 CONSTRUCTION PHOTOS OF EUT Page 2 Page 3 Page 4

FCC ID: N89-RT3572 Report No.: RF991230E02 Operational Description This device is a WLAN Dual Band 802.11 a/b/g/n module, which operates in both of 2.4GHz and 5GHz bands; the maximum data rate could be up to 270Mbps which OFDM technique. If the signal to noise radio is too poor which could not support 270Mbps, the 11Mbps data rate with DSSS technique will be applied. The transmitter of the EUT is powered by 5Vdc from the host equipment. The antennas are Dipole and Metal PIFA antennas with I-PEX antenna connector. The other instruction, please have a look at the users manual. FCC 15.407(c) states: The device shall automatically discontinue transmission in case of either absence of information to transmit or operational failure. These provisions are not intended to preclude the transmission of control or signaling information or the use of repetitive codes used by certain digital technologies to complete frame or burst intervals. Applicants shall include in their application for equipment authorization a description of how this requirement is met” Data transmission is always initiated by software, which is then pass down through the MAC, through the digital and analog baseband, and finally to the RF chip. Several special packets (ACKs, CTS, PSPoll, etc...) are initiated by the MAC. There are the only ways the digital baseband portion will turn on the RF transmitter, which it then turns off at the end of the packet. Therefore, the transmitter will be on only while one of the aforementioned packets are being transmitted.

Report No.: SA991230E02 Report Format Version 4.0.0 1 RF EXPOSURE REPORT REPORT NO.: SA991230E02 MODEL NO.: RT3572 FCC ID: N89-RT3572 ACCORDING: FCC Guidelines for Human Exposure IEEE C95.1 APPLICANT: CyberTAN Technology, Inc. ADDRESS: No. 99, Park Avenue III, Science-based Industrial Park, Hsinchu, Taiwan 308, R.O.C. ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Hsin Chu Laboratory LAB ADDRESS: No. 81-1, Lu Liao Keng, 9th Ling,Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan Report No.: SA991230E02 Report Format Version 4.0.0 2 1. RF EXPOSURE LIMIT LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) FREQUENCY RANGE (MHz) ELECTRIC FIELD STRENGTH (V/m) MAGNETIC FIELD STRENGTH (A/m) POWER DENSITY (mW/cm 2 ) AVERAGE TIME (minutes) LIMITS FOR GENERAL POPULATION / UNCONTROLLED EXPOSURE 300-1500 ... ... F/1500 30 1500-100,000 ... ... 1.0 30 F = Frequency in MHz 2. MPE CALCULATION FORMULA Pd = (Pout*G) / (4*pi*r2) where Pd = power density in mW/cm2 Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm 3. CLASSIFICATION The antenna of this product, under normal use condition, is at least 20cm away from the body of the user. So, this device is classified as Mobile Device. Report No.: SA991230E02 Report Format Version 4.0.0 3 4. CALCULATION RESULT OF MAXIMUM EIRP For 15.247(2.4GHz): FREQUENCY BAND (MHz) CONDUCTED POWER (dBm) ANTENNA GAIN (dBi) DISTANCE (cm) POWER DENSITY (mW/ cm 2 ) LIMIT (mW/cm 2 ) 2412-2462 25.7 6 20 0.292 1.00 For 15.247(5GHz): FREQUENCY BAND (MHz) CONDUCTED POWER (dBm) ANTENNA GAIN (dBi) DISTANCE (cm) POWER DENSITY (mW/ cm 2 ) LIMIT (mW/cm 2 ) 5745-5825 24.8 5.21 20 0.199 1.00 For 15.407(5GHz): FREQUENCY BAND (MHz) CONDUCTED POWER (dBm) ANTENNA GAIN (dBi) DISTANCE (cm) POWER DENSITY (mW/ cm 2 ) LIMIT (mW/cm 2 ) 5180-5240 15.8 5.21 20 0.025 1.00

Report No.: RF991230E02 R1 1 Report Format Version 4.0.0 Cancels and replaces the report No.: RF991230E02 dated Mar. 18, 2011 FCC TEST REPORT (15.247) REPORT NO.: RF991230E02 R1 MODEL NO.: RT3572 FCC ID: N89-RT3572 RECEIVED: Dec. 30, 2010 TESTED: Jan. 06 to 10, 2011 ISSUED: Mar. 22, 2011 APPLICANT: CyberTAN Technology, Inc. ADDRESS: No. 99, Park Avenue III, Science-based Industrial Park, Hsinchu, Taiwan 308, R.O.C. ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Hsin Chu Laboratory LAB ADDRESS: No. 81-1, Lu Liao Keng, 9th Ling,Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan TEST LOCATION (1): No. 81-1, Lu Liao Keng, 9th Ling,Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan TEST LOCATION (2): No. 49, Ln. 206, Wende Rd., Shangshan Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan This test report consists of 154 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product certification, approval, or endorsement by TAF or any government agency. The test results in the report only apply to the tested sample. Report No.: RF991230E02 R1 2 Report Format Version 4.0.0 Cancels and replaces the report No.: RF991230E02 dated Mar. 18, 2011 Table of Contents RELEASE CONTROL RECORD............................................................................................5 1. CERTIFICATION.......................................................................................................6 2. SUMMARY OF TEST RESULTS...............................................................................7 2.1 MEASUREMENT UNCERTAINTY..........................................................................9 3. GENERAL INFORMATION......................................................................................10 3.1 GENERAL DESCRIPTION OF EUT.....................................................................10 3.2 DESCRIPTION OF TEST MODES.......................................................................13 3.2.1 TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL..............14 3.3 GENERAL DESCRIPTION OF APPLIED STANDARDS.......................................17 3.4 DESCRIPTION OF SUPPORT UNITS..................................................................18 3.5 CONFIGURATION OF SYSTEM UNDER TEST...................................................18 4. TEST TYPES AND RESULTS (802.11b & g, 2400 ~ 2483.5MHz Band)..................19 4.1 CONDUCTED EMISSION MEASUREMENT........................................................19 4.1.1 LIMITS OF CONDUCTED EMISSION MEASUREMENT............................19 4.1.2 TEST INSTRUMENTS................................................................................19 4.1.3 TEST PROCEDURES.................................................................................20 4.1.4 DEVIATION FROM TEST STANDARD.......................................................20 4.1.5 TEST SETUP..............................................................................................20 4.1.6 EUT OPERATING CONDITIONS................................................................21 4.1.7 TEST RESULTS..........................................................................................22 4.2 RADIATED EMISSION MEASUREMENT.............................................................24 4.2.1 LIMITS OF RADIATED EMISSION MEASUREMENT.................................24 4.2.2 TEST INSTRUMENTS................................................................................25 4.2.3 TEST PROCEDURES.................................................................................27 4.2.4 DEVIATION FROM TEST STANDARD.......................................................27 4.2.5 TEST SETUP..............................................................................................28 4.2.6 EUT OPERATING CONDITIONS................................................................28 4.2.7 TEST RESULTS (dipole antenna)...............................................................29 4.2.8 TEST RESULTS (PIFA antenna).................................................................58 4.3 6dB BANDWIDTH MEASUREMENT....................................................................87 4.3.1 LIMITS OF 6dB BANDWIDTH MEASUREMENT........................................87 4.3.2 TEST INSTRUMENTS................................................................................87 4.3.3 TEST PROCEDURE...................................................................................87 4.3.4 DEVIATION FROM TEST STANDARD.......................................................87 4.3.5 TEST SETUP..............................................................................................87 4.3.6 EUT OPERATING CONDITIONS................................................................87 Report No.: RF991230E02 R1 3 Report Format Version 4.0.0 Cancels and replaces the report No.: RF991230E02 dated Mar. 18, 2011 4.3.7 TEST RESULTS..........................................................................................88 4.4 MAXIMUM PEAK OUTPUT POWER....................................................................92 4.4.1 LIMITS OF MAXIMUM PEAK OUTPUT POWER MEASUREMENT...........92 4.4.2 INSTRUMENTS..........................................................................................92 4.4.3 TEST PROCEDURES.................................................................................92 4.4.4 DEVIATION FROM TEST STANDARD.......................................................92 4.4.5 TEST SETUP..............................................................................................92 4.4.6 EUT OPERATING CONDITIONS................................................................92 4.4.7 TEST RESULTS..................................................................................…

Text truncated - open the document above for the full version.

Report No.: RF991230E02-1 R1 1 Report Format Version 4.0.0 Cancels and replaces the report No.: RF991230E02-1 dated Mar. 18, 2011 FCC TEST REPORT (15.407) REPORT NO.: RF991230E02-1 R1 MODEL NO.: RT3572 FCC ID: N89-RT3572 RECEIVED: Dec. 30, 2010 TESTED: Jan. 07 to 10, 2011 ISSUED: Mar. 22, 2011 APPLICANT: CyberTAN Technology, Inc. ADDRESS: No. 99, Park Avenue III, Science-based Industrial Park, Hsinchu, Taiwan 308,R.O.C. ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Hsin Chu Laboratory LAB ADDRESS: No. 81-1, Lu Liao Keng, 9th Ling,Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan TEST LOCATION (1): No. 81-1, Lu Liao Keng, 9th Ling,Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan TEST LOCATION (2): No. 49, Ln. 206, Wende Rd., Shangshan Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan This test report consists of 96 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product certification, approval, or endorsement by TAF or any government agency. The test results in the report only apply to the tested sample. Report No.: RF991230E02-1 R1 2 Report Format Version 4.0.0 Cancels and replaces the report No.: RF991230E02-1 dated Mar. 18, 2011 Table of Contents RELEASE CONTROL RECORD..............................................................................4 1. CERTIFICATION...........................................................................................5 2. SUMMARY OF TEST RESULTS...................................................................6 2.1 MEASUREMENT UNCERTAINTY...............................................................7 3. GENERAL INFORMATION...........................................................................8 3.1 GENERAL DESCRIPTION OF EUT..............................................................8 3.2 DESCRIPTION OF TEST MODES..............................................................11 3.2.1 TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL:.............12 3.3 GENERAL DESCRIPTION OF APPLIED STANDARDS.............................14 3.4 DESCRIPTION OF SUPPORT UNITS........................................................15 3.5 CONFIGURATION OF SYSTEM UNDER TEST.........................................15 4. TEST TYPES AND RESULTS.....................................................................16 4.1 CONDUCTED EMISSION MEASUREMENT..............................................16 4.1.1 LIMITS OF CONDUCTED EMISSION MEASUREMENT............................16 4.1.2 TEST INSTRUMENTS................................................................................16 4.1.3 TEST PROCEDURES.................................................................................17 4.1.4 DEVIATION FROM TEST STANDARD.......................................................17 4.1.5 TEST SETUP..............................................................................................17 4.1.6 EUT OPERATING CONDITIONS................................................................18 4.1.7 TEST RESULTS..........................................................................................19 4.2 RADIATED EMISSION MEASUREMENT...................................................21 4.2.1 LIMITS OF RADIATED EMISSION MEASUREMENT.................................21 4.2.2 LIMITS OF UNWANTED EMISSION OUT OF THE RESTRICTED BANDS22 4.2.3 TEST INSTRUMENTS................................................................................23 4.2.4 TEST PROCEDURES.................................................................................25 4.2.5 DEVIATION FROM TEST STANDARD.......................................................25 4.2.6 TEST SETUP..............................................................................................26 4.2.7 EUT OPERATING CONDITION..................................................................26 4.2.8 TEST RESULTS (Dipole antenna)..............................................................27 4.2.9 TEST RESULTS (PIFA antenna).................................................................48 4.3 OUTPUT TRANSMIT POWER MEASUREMENT.......................................69 4.3.1 LIMITS OF OUTPUT TRANSMIT POWER MEASUREMENT.....................69 4.3.2 TEST INSTRUMENTS................................................................................69 4.3.3 TEST PROCEDURE...................................................................................69 4.3.4 DEVIATION FROM TEST STANDARD.......................................................69 4.3.5 TEST SETUP..............................................................................................70 4.3.6 EUT OPERATING CONDITIONS................................................................70 4.3.7 TEST RESULTS..........................................................................................71 4.4 PEAK POWER EXCURSION MEASUREMENT.........................................77 4.4.1 LIMITS OF PEAK POWER EXCURSION MEASUREMENT.......................77 4.4.2 TEST INSTRUMENTS................................................................................77 4.4.3 TEST PROCEDURE...................................................................................77 4.4.4 DEVIATION FROM TEST STANDARD.......................................................77 4.4.5 TEST SETUP..............................................................................................77 4.4.6 EUT OPERATING CONDITIONS................................................................77 4.4.7 TEST RESULTS..........................................................................................78 Report No.: RF991230E02-1 R1 3 Report Format Version 4.0.0 Cancels and replaces the report No.: RF991230E02-1 dated Mar. 18, 2011 4.5 PEAK POWER SPECTRAL DENSITY MEASUREMENT...........................81 4.5…

Text truncated - open the document above for the full version.

1 PHOTOGRAPHS OF THE TEST CONFIGURATION CONDUCTED EMISSION TEST 2 RADIATED EMISSION TEST (Dipole antenna) 3 4 RADIATED EMISSION TEST (PIFA antenna) 5
