N89-RV215WWireless-N VPN Firewall

Quick Start Guide Cisco Small Business RV215W Wireless-N VPN Fire wall Package Contents •Wireless-N VPN Firewal l •Ethern et Cable •Power Adapter •Quick Start Guide •Documentation and soft ware on CD-ROM Welcome Thank you for choosing the Cisco Smal l Business RV215W Wireless-N VPN Firewal l. The RV215W provides simple, affordable, secure business-cla ss connectivity to the In ternet for small offi ce/home offi ce (SoHo) and remote professionals. This guide describes how to physical ly install your Ci sco RV215W and launch the web-based Device Manag er to configure and manage your fi rewall. Installing the RV215W Pl acement T ip s •Ambi ent Temperature—To prevent the fi rewal l from overheating, do not operate it in an area that exceeds an ambient temperature of 104°F (40°C). •Air Flow—Be sure th at there is adequate air flow around the fi rewall. •Mechanical Loadi ng—Be sure that the fi rewal l i s level and stable to avoid any hazar dous conditions. Place the Cisco RV215W unit horizontally on a flat surface so that it sits on its four rubber feet. Cisco R V215W Features Front P anel 1 2 Back Panel PowerThe Power light is green to indicate the unit is powered on. The light flashes green when the power is coming on. W PSThe Wi-Fi Protected Setup (WPS) button is used to configure wireless access for devices in your network that are WPS-enabled. See the Administration Guide or Device Manager help page for more informat ion. W AN The WAN (In ternet) light is green when the Cisco RV215W is connected to the In ternet through your cable or DSL modem. The light is off when the Cisco RV215W is not connected to t he In ternet. The light flashes green when it is sending or receiving dat a W irelessThe Wirel ess light is green when the wireless module is enabled. The light is off when the wireless module is disabled. The light flashes green when the fi rewal l is transmitting or receiving data on the wireless module. L AN PortsThe numbered lights correspond to the LAN ports on the Cisco RV215W. If the lights are continuously lit green, the Ci sco RV215W is connected to a device through the corresponding port (1, 2, 3, or 4). The light for a port flashes green when the fi rewall is actively sending or receiving data over that port. RESET Button—The RESET button has two functions: •If the Ci sco RV215W is having problems connecting to the In ternet, press the R ESET button for at least 3 but no more than 10 seconds with a paper clip or a pencil tip. This is similar to pressing the r eset button on your PC to reboot it. •If you are experiencing extreme problems with the Cisco RV215W and have tri ed al l other troubleshoot ing measures, press and hold in the R ESET button for more th an 10 seconds. This reboots the unit and restores the factory defaults. Changes you have made to the Cisco RV215W settings are lost. L AN Ports (1-4)—These ports provide a LAN connection to network devices, such as PCs, p rint servers, o r switches. W AN (In ternet) Port—The WAN port is connected to your In ternet device, such as a cable or DSL modem. P OWER Button—Press this button to turn the fi rewall on and off. 1 2VDC Port—The 12VDC port is where you connect the provided 12 volt DC power adapter. Connecting the Equipment NOTEYou must connect one PC with an Ethernet cable for the purpose of the initial configuration. After you complete the initial conf igurat ion, administr ati ve tasks can be performed using a wire less connection. STEP1Power off all equipment, in cluding the cable or DSL modem, the PC you will use to connect to the Cisco RV215W, and the Ci sco RV215W. 3 STEP2You should al ready have an Ethernet cable connecting your PC to your current cable or DSL modem. Unplug one end of the cable from your PC and plug it in to the port marked “WAN” on the unit. STEP3Connect one end of a di fferent Ethernet cable to one of the LAN (Ethernet) ports on the back of the unit. (In this example, the LAN 1 port is used.) Connect the other end to an Ethernet port on the PC that you will use to run the web-based Setup Wizar d and Device Manager. STEP4Power on the cable or DSL modem and wait until the connection is acti ve. Versió n en Español para España en el CD Version en français sur CD Versione italiana sul CD Deutsch Ver sion auf CD Versão em português em CD Americas Headquarters Cisco Systems, In c. 170 West Tasman Drive San Jose, CA 95134-1706 USA www.cisco.com Small Business Suppor t US: 1-866-606-1866 (Tol l Fr ee, 24/7) Small Business S upport, Global: www.cisco. com/go/sbsc Cisco and the C isco Logo ar e trademarks of C isco Systems, Inc. and/or its affiliates in the U.S. and other countries. A lis ting of Cisco's trademar ks can be found at www.cisco.com/go/trademarks. Third party trademar ks mentio ned are the proper ty of their respective owners. The use of the word partner does not impl y a partnership relationship between Cisco and any other company. (1005R) © 2011 Cisco Systems, Inc. All rights reserved. 78-19329-01 STEP5Connect the power adapter to the Ci sco RV215W POWER port. CAUTIONUse only th e power adapter that is supplied with the unit. Using a different power adapter could damage the unit. STEP6Plug the ot her end of the adapter in to an el ectrical outlet. You may need to use a specific plug (supplied) for your country. STEP7On the Ci sco RV215W, push t he POWER button in to tu rn on the fi rewal l. The power light on the front panel is green when the power adapter is connected properly and the unit is turned on. Using t he S etup Wizard NOTEThe Setu p Wizard and Device Manager are supported on Micro soft Internet Expl orer 6.0 or later, Mozilla Fire fox 3. 0 or later, and Apple Safari 3.0 or later. STEP1Power on the PC that you connected to the LAN1 port in Step 2 of the Connecting the Equipment section. Your PC becomes a DHCP client of the firewal l and receives an I P address in the 192.168.1.xxx range. STEP2Start a web browser on your PC. In the Address bar , enter the default IP address of th …

Text truncated - open the document above for the full version.

Federal Communication Commission Interference Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. Radiation Exposure Statement: To comply with FCC/IC RF Exposure Limits set forth for an uncontrolled environment, the product must be installed and operated with a minimum separation distance (between nearby person(s) and radiating antenna) according to the following scenarios: 1. 20cm minimum when the product is operated alone without co-transmitting with a plug-in 3G USB dongle device. 2. 20cm minimum when the product is operated with a plug-in 3G USB device which has maximum of 2W ERP output power. 3. For co-transmission scenario which is not covered above, please consult the RF technician or device supplier. Industry Canada statement: This device complies with RSS-210 of the Industry Canada Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Ce dispositif est conforme à la norme CNR-210 d'Industrie Canada applicable aux appareils radio exempts de licence. Son fonctionnement est sujet aux deux conditions suivantes: (1) le dispositif ne doit pas produire de brouillage préjudiciable, et (2) ce dispositif doit accepter tout brouillage reçu, y compris un brouillage susceptible de provoquer un fonctionnement indésirable. RF EXPOSURE SAFEFY NOTICE: To comply with FCC/IC RF Exposure Limits set forth for an uncontrolled environment, the product must be installed and operated with a minimum separation distance (between nearby person(s) and radiating antenna) according to the following scenarios: 1. 20cm minimum when the product is operated alone without co-transmitting with a plug-in 3G USB dongle device. 2. 20cm minimum when the product is operated with a plug-in 3G USB device which has maximum of 2W ERP output power. 3. For co-transmission scenario which is not covered above, please consult the RF technician or device supplier. AVERTISSEMENT DE SECURITE CONCERNANT LES EXPOSITIONS AUX FREQUENCES RADIO Pour etre conforme aux limites d’exposition aux frequences radio FCC/IC etablies pour un environnement non controle (utilisation par le grand public), l’equipement doit etre installe et utilise en laissant une distance de separation de securite (entre la ou les personnes presentes dans le perimetre et l’antenne d’emission) selon les cas suivants : 1. 20cm au minimum quand le produit est utilise seul sans co-transmettre a l’aide d’un appareil 3G USB enfichable. 2. 20cm au minimum quand le produit est utilise avec un appareil 3G USB enfichable ayant une puissance de sortie maximale de 2W ERP. 3. Dans des cas de co-transmission non mentionnes ci-dessus, merci de bien vouloir consulter un technicien radio qualifie ou directement le fabricant de l’appareil. This device has been designed to operate with a Dipole antenna have a maximum gain of [2] dB. Antenna having a higher gain is strictly prohibited per regulations of Industry Canada. The required antenna impedance is 50 ohms. Under Industry Canada regulations, this radio transmitter may only operate using an antenna of a type and maximum (or lesser) gain approved for the transmitter by Industry Canada. To reduce potential radio interference to other users, the antenna type and its gain should be so chosen that the equivalent isotropically radiated power (e.i.r.p.) is not more than that necessary for successful communication. This radio transmitter (IC: 5005A-RV215W / Model: RV215W) has been approved by Industry Canada to operate with the antenna type, maximum permissible gain and required antenna impedance for each antenna type indicated. Antenna types not included in this user’s manual, having a gain greater than the maximum gain indicated for that type, are strictly prohibited for use with this device. Ce dispositif a été conçu pour fonctionner avec une antenne ayant un gain maximal de Dipole antenne avec dB [2]. Une antenne à gain plus élevé est strictement interdite par les règlements d'Industrie Canada. L'impédance d'antenne requise est de 50 ohms. Conformément à la réglementation d'Industrie Canada, le présent émetteur radio peutfonctionner avec une antenne d'un type et d'un gain maximal (ou inférieur) approuvé pourl'émetteur par Industrie Canada. Dans le but de réduire les risques de brouillage radioélectriqueà l'intention des autr…

Text truncated - open the document above for the full version.

CyberTAN Technology, Inc. No.99, Park Avenue III, Science-based Industrial Park, Hsinchu, Taiwan 308,R.O.C. General Declaration Date:2012/6/7 We, CyberTAN Technology, Inc. declares that device does not have “Ad Hoc on non-US frequencies” while applying for the follow product. FCC ID: N89-RV215W If you have any questions regarding the authorization, please don’t hesitate to contact us. Thank you! ------------------------------------------------------------------------------ Amy Wu Manager CyberTAN Technology, Inc. Tel.: 886 3-5777777 Fax: 886 3-5777788

CyberTAN Technology, Inc. No.99, Park Avenue III, Science-based Industrial Park, Hsinchu, Taiwan 308,R.O.C. Federal Communications Commission Authorization and Evaluation Division Date:2012/6/7 Confidentiality Request FCC ID: N89-RV215W Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying this Application as outlined below: Schematic Diagram Block Diagram The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely yours, ------------------------------------------------------------------------------ Amy Wu Manager CyberTAN Technology, Inc. Tel.: 886 3-5777777 Fax: 886 3-5777788

CyberTAN Technology, Inc. No.99, Park Avenue III, Science-based Industrial Park, Hsinchu, Taiwan 308,R.O.C. Federal Communications Commission Authorization and Evaluation Division Date: July 24, 2012 Confidentiality Request FCC ID: N89-RV215W Pursuant to DA 04-1705 of the Commission’s Rules, we request short-term confidential treatment for the following information until December. 30, 2012 of Equipment Authorization in order to ensure sensitive business information remains confidential until the actual marketing of the device: External Photos Test Setup Photos User’s Manual Internal Photo Thank you! Sincerely yours, ------------------------------------------------------------------------------ Amy Wu Manager CyberTAN Technology, Inc. Tel.: 886 3-5777777 Fax: 886 3-5777788

CyberTAN Technology, Inc. No.99, Park Avenue III, Science-based Industrial Park, Hsinchu, Taiwan 308,R.O.C. Power of Attorney Date:2012/6/7 To whom it may concern: We, the undersigned CyberTAN Technology, Inc. hereby authorize Bureau Veritas Consumer Products Services (H.K) Ltd., Taoyuan Branch. of Taiwan to act on our behalf in all matters relating to all processes required in the FCC Part 15C approval and any communication needed with the national authority. Any and all acts carried out by Bureau Veritas Consumer Products Services (H.K) Ltd., Taoyuan Branch. on our behalf shall have the same effects as acts of our own. If you have any questions regarding the authorization, please don’t hesitate to contact us. Thank you! Sincerely yours, ------------------------------------------------------------------------------ Amy Wu Manager CyberTAN Technology, Inc. Tel.: 886 3-5777777 Fax: 886 3-5777788

Report No.: 120531E03 Page 1 CONSTRUCTION PHOTOS OF EUT Report No.: 120531E03 Page 2 Report No.: 120531E03 Page 3 Report No.: 120531E03 Page 4

FCC ID：N89-RV215W LABEL LOCATION The label will be permanently affixed at a conspicuous location on the device.

Report No.: 120531E03 Page 1 CONSTRUCTION PHOTOS OF EUT Report No.: 120531E03 Page 2 Report No.: 120531E03 Page 3 Report No.: 120531E03 Page 4

FCC ID: N89-RV215W Report No.: RF 120531E03 Operational Description This device is an Wireless-N VPN Firewall, which operates in 2.4GHz band; the maximum data rate could be up to 300Mbps which OFDM technique. If the signal to noise radio is too poor which could not support 300Mbps, the 11Mbps data rate with DSSS technique will be applied. The transmitter of the EUT is powered by 12Vdc power adapter. The antenna is Dipole antenna without antenna connector. For more detailed instruction, please take a look at the user’s manual.

Report No.: SA120531E03 1 of 6 Report Format Version 5.0.0 Cancels and replaces the report No.: SA110718E01 dated Aug. 19, 2011 RF EXPOSURE REPORT REPORT NO.: SA120531E03 MODEL NO.: RV215W FCC ID: N89-RV215W RECEIVED: Apr. 26, 2012 TESTED: June 11, 2012 ISSUED: July 25, 2012 APPLICANT: CyberTAN Technology, Inc. ADDRESS: No.99, Park Avenue III, Science-based Industrial Park, Hsinchu, Taiwan 308,R.O.C. ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Hsin Chu Laboratory LAB ADDRESS: No. 81-1, Lu Liao Keng, 9th Ling,Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan, R.O.C. This report should not be used by the client to claim product certification, approval, or endorsement by any government agencies. This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification Report No.: SA120531E03 2 of 6 Report Format Version 5.0.0 Cancels and replaces the report No.: SA110718E01 dated Aug. 19, 2011 TABLE OF CONTENTS RELEASE CONTROL RECORD ..................................................................................... 3 1. CERTIFICATION ...................................................................................................... 4 2. RF EXPOSURE LIMIT .............................................................................................. 5 3. MPE CALCULATION FORMULA ............................................................................. 5 4. CLASSIFICATION .................................................................................................... 5 5. CALCULATION RESULT OF MAXIMUM CONDUCTED POWER ........................... 6 Report No.: SA120531E03 3 of 6 Report Format Version 5.0.0 Cancels and replaces the report No.: SA110718E01 dated Aug. 19, 2011 RELEASE CONTROL RECORD ISSUE NO. REASON FOR CHANGE DATE ISSUED SA120531E03 Original release July 25, 2012 Report No.: SA120531E03 4 of 6 Report Format Version 5.0.0 Cancels and replaces the report No.: SA110718E01 dated Aug. 19, 2011 1. CERTIFICATION PRODUCT: Wireless-N VPN Firewall BRAND NAME: CISCO MODEL NO.: RV215W TEST SAMPLE: ENGINEERING SAMPLE APPLICANT: CyberTAN Technology, Inc. TESTED DATE: June 11, 2012 STANDARDS: FCC Part 2: 2011, (Section 2.1091) FCC OET Bulletin 65, Supplement C (01-01) IEEE C95.1 The above equipment (Model: RV215W) has been tested by Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s EMC characteristics under the conditions specified in this report. PREPARED BY : , DATE: July 25, 2012 ( Elsie Hsu, Specialist ) APPROVED BY : , DATE: July 25, 2012 ( May Chen, Deputy Manager ) Report No.: SA120531E03 5 of 6 Report Format Version 5.0.0 Cancels and replaces the report No.: SA110718E01 dated Aug. 19, 2011 2. RF EXPOSURE LIMIT LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) FREQUENCY RANGE (MHz) ELECTRIC FIELD STRENGTH (V/m) MAGNETIC FIELD STRENGTH (A/m) POWER DENSITY (mW/cm 2 ) AVERAGE TIME (minutes) LIMITS FOR GENERAL POPULATION / UNCONTROLLED EXPOSURE 300-1500 ... ... F/1500 30 1500-100,000 ... ... 1.0 30 F = Frequency in MHz 3. MPE CALCULATION FORMULA Pd = (Pout*G) / (4*pi*r 2 ) where Pd = power density in mW/cm 2 Pout = output power to antenna in mW G = gain of antenna in linear scale pi = 3.1416 r = distance between observation point and center of the radiator in cm 4. CLASSIFICATION The antenna of this product, under normal use condition, is at least 20cm away from the body of the user. So, this device is classified as Mobile Device. Report No.: SA120531E03 6 of 6 Report Format Version 5.0.0 Cancels and replaces the report No.: SA110718E01 dated Aug. 19, 2011 5. CALCULATION RESULT OF MAXIMUM CONDUCTED POWER For WLAN: FREQUENCY BAND (MHz) CONDUCTED POWER (mW) ANTENNA GAIN (dBi) DISTANCE (cm) POWER DENSITY (mW/ cm 2 ) LIMIT (mW/cm 2 ) 2412-2462 408.348 2 20 0.12875 1.00 For USB Cellular Modem: DEVICE MAX EIRP (mW) MAX EIRP (dBm) DISTANCE (cm) POWER DENSITY (mW/ cm 2 ) LIMIT (mW/cm 2 ) USB Cellular Modem 1995.262 33.00 20 0.397 0.549 This product can operate with a plug-in USB Cellular Modem which has maximum of 2W EIRP output power. CONCLUSION: Based on the MPE calculation of the collocated radios listed in this report, it has demonstrated that both the WLAN and USB Cellular Modem can transmit simultaneously and still maintain the minimum user safe distance of 20cm. The MPE calculation formula is: CPD 1 / LPD 1 + CPD 2 / LPD 2 + ......etc. < 1 CPD = Calculation power density LPD = Limit of power density Therefore, the worst-case situation is 0.12875 / 1 + 0.397 / 0.549= 0.852, which is less than “1”. This confirmed that the dev…

Text truncated - open the document above for the full version.

Report No.: RF120531E03 1 of 54 Report Format Version 5.0.0 Reference No.: 110719E01, 120110E14 FCC TEST REPORT REPORT NO.: RF120531E03 MODEL NO.: RV215W FCC ID: N89-RV215W RECEIVED: Apr. 26, 2012 TESTED: Apr. 26 to June 11, 2012 ISSUED: July 25, 2012 APPLICANT: CyberTAN Technology, Inc. ADDRESS: No.99, Park Avenue III, Science-based Industrial Park, Hsinchu, Taiwan 308,R.O.C. ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Hsin Chu Laboratory LAB ADDRESS : No. 81-1, Lu Liao Keng, 9th Ling, Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan, R.O.C. TEST LOCATION (1): No. 81-1, Lu Liao Keng, 9th Ling, Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan, R.O.C. TEST LOCATION (2): No. 49, Ln. 206, Wende Rd., Shangshan Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan, R.O.C. This report should not be used by the client to claim product certification, approval, or endorsement by TAF or any government agencies. This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification Report No.: RF120531E03 2 of 54 Report Format Version 5.0.0 Reference No.: 110719E01, 120110E14 Table of Contents RELEASE CONTROL RECORD ........................................................................................ 4 1. CERTIFICATION .................................................................................................... 5 2. SUMMARY OF TEST RESULTS ............................................................................ 6 2.1 MEASUREMENT UNCERTAINTY .......................................................................... 6 3. GENERAL INFORMATION ..................................................................................... 7 3.1 GENERAL DESCRIPTION OF EUT ....................................................................... 7 3.2 DESCRIPTION OF TEST MODES ....................................................................... 10 3.2.1 TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL ........................ 11 3.3 GENERAL DESCRIPTION OF APPLIED STANDARDS ....................................... 14 3.4 DESCRIPTION OF SUPPORT UNITS .................................................................. 15 3.5 CONFIGURATION OF SYSTEM UNDER TEST ................................................... 16 4. TEST TYPES AND RESULTS .............................................................................. 17 4.1 CONDUCTED EMISSION MEASUREMENT ........................................................ 17 4.1.1 LIMITS OF CONDUCTED EMISSION MEASUREMENT ...................................... 17 4.1.2 TEST INSTRUMENTS .......................................................................................... 17 4.1.3 TEST PROCEDURES .......................................................................................... 18 4.1.4 DEVIATION FROM TEST STANDARD ................................................................. 18 4.1.5 TEST SETUP ....................................................................................................... 18 4.1.6 EUT OPERATING CONDITIONS ......................................................................... 19 4.1.7 TEST RESULTS ................................................................................................... 20 4.2 RADIATED EMISSION AND BANDEDGE MEASUREMENT ................................ 22 4.2.1 LIMITS OF RADIATED EMISSION AND BANDEDGE MEASUREMENT .............. 22 4.2.2 TEST INSTRUMENTS .......................................................................................... 23 4.2.3 TEST PROCEDURES .......................................................................................... 25 4.2.4 DEVIATION FROM TEST STANDARD ................................................................. 25 4.2.5 TEST SETUP ....................................................................................................... 26 4.2.6 EUT OPERATING CONDITIONS ......................................................................... 26 4.2.7 TEST RESULTS ................................................................................................... 27 4.3 6dB BANDWIDTH MEASUREMENT .................................................................... 40 4.3.1 LIMITS OF 6dB BANDWIDTH MEASUREMENT .................................................. 40 4.3.2 TEST INSTRUMENTS .......................................................................................... 40 4.3.3 TEST PROCEDURE ............................................................................................. 40 4.3.4 DEVIATION FROM TEST STANDARD ................................................................. 40 4.3.5 TEST SETUP ....................................................................................................... 40 4.3.6 EUT OPERA…

Text truncated - open the document above for the full version.

Report No. : 120531E03 1 PHOTOGRAPHS OF THE TEST CONFIGURATION CONDUCTED EMISSION TEST Report No. : 120531E03 2 RADIATED EMISSION TEST
