N96-120332ISElectronic Ballast

NEUTRON EMC LAB. Report No.NEI- FCC-E-03142 22/27 Photo # 1

NEUTRON EMC LAB. Report No.NEI- FCC-E-03142 27/27 -- FCC ID label -- The remained portion of label statement required by FCC is attached in the user’s manual. -- Location of Label on EUT -- 2.5 mm 22 mm FCC ID:N96-120332IS

NEUTRON EMC LAB. Report No.NEI- FCC-E-03142 23/27 Photo # 2 NEUTRON EMC LAB. Report No.NEI- FCC-E-03142 24/27 Photo # 3

1.5 Product Descriptions(Application/Features/Specification) ISM Equipment Category : RF Lighting Devices(Ballast) Electrical Power : 120V/60Hz AC input Power Cord : non-shielded type wire More details of EUT technical specification, please refer to the User's Manual.
