N9ZTHX301MPart 15 Security / Remote Control Transmitter

Thermo sensor Model: THX301 Instruction Manual Congratulations on your of purchasing our new long range outdoor thermo-hygrometer senor which can cover up to 75m range in an open area. This sensor is designed for everyday use for the home or office and used to monitor the temperature and humidity change of outdoor sites. A D C B Features A. LED indicator Flashes when remote unit transmits a reading. B. Channel number Indicates the remote sensor is set to which channel and the user can find the corresponding reading in the same channel in the linked receiving unit. C. Temperature/humidity display Display the measured temperature and humidity Description of buttons The remote sensor has 3 function buttons inside the battery compartment 1. [CH] button After the battery installation, the LED blinks slowly every 1.5 seconds and channel number shows ‘1’ to indicate it is now under channel setting mode and is set to channel 1 by default. If the user presses no key within ten seconds, the unit will auto-exit the channel setting. If the user press [CH] button once during the channel setting, the channel number is changed to ‘2’ to indicate the unit is set to channel 2. If the user press [CH] button again, the channel number will be advanced to channel ‘3’ and so on. The maximum channel number is ‘5’ and the unit will be scrolled back to channel ‘1’ at the 5 th press of the [CH] button. 2. [C/F] button Press to toggle unit °C or °F 3. [ RESET ] Button Press to hardware reset the unit to factory setting Setting procedure to link up with a receiving unit This device is designed for easy set up with no wire installation. The following steps are required to be done in proper sequence to link up with a receiving unit. Please insert batteries for the receiving unit before doing so for the remote unit. 1. Remove the bracket stand. 2. Unlock two latches in the bottom to release the semi-transparent jacket. 3. Slide down the battery door in the back. 4. Insert 2 pieces AAA size batteries according to polarity marking on the battery compartment. 5. The LED blinks slowly to indicate it is under the channel setting mode and the user can set it to other channel by press [CH] key. 6. The temperature of the sensor will appear on the selected channel of the receiving unit if it is linked up with the receiving unit successfully. 7. Close the battery door and use two latches in the bottom to lock it with the semi-transparent jacket. Follow the same procedure (1 to 7) to register other remote sensors. Note: For the user purchasing more than one remote sensor, he must set the sensors to different channel in the start up to avoid conflicts. Precautions a. Do not clean the unit with abrasive or corrosive compound. It may scratch the plastic parts and corrode the electronic circuits. b. Do not subject the unit to excessive force shock, dust, temperature or humidity, which may result in malfunctioning, shorter electronic life span, damaged battery and distorted parts. c. Do not tamper with these units’ internal components. Doing so will invalidate the warranty on the unit and may cause unnecessary damage battery and distorted parts. d. Do not subject the unit to excessive exposure to direct sunlight. The remote sensor is splash proof. Never immerse it in water or expose to heavy rain. e. Always read the users manual thoroughly before operating the unit. Specification Displayed temperature range : -50.0°C to +70.0°C (-58.0°F to +158.0°F) Proposed operating range : -20.0°C to +60.0°C (-4.0°F to +140.0°F) Temperature resolution : 0.1°C (0.2°F) Displayed range : 20% to 99% Proposed operating range : 20% to 99% RF transmission frequency : 433MHz RF transmission range : Maximum 75 meters in open area Batteries : Use 2 pieces UM-4 AAA size 1.5V alkaline battery This device could be sensitive to electrostatic discharge, If electrostatic discharge or malfunctioning occurs please reset this unit. CAUTION The above content is subject to change without notice. The displays printed in this manual may be different from the actual display because of printing limitations. The manufacturer and its suppliers hold no responsibility to you or any other person for any damage expenses, lost profits, or any other claims arisen by using this product. NOTE: THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR TV INTERFERENCE CAUSED BY UNAUTHORIZED MODIFICATIONS TO THIS EQUIPMENT. SUCH MODIFICATIONS COULD VOID THE USER AUTHORITY TO OPERATE THE EQUIPMENT NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technician for help NOTE: THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR TV INTERFERENCE CAUSED BY UNAUTHORIZED MODIFICATIONS TO THIS EQUIPMENT. SUCH MODIFICATIONS COULD VOID THE USER AUTHORITY TO OPERATE THE EQUIPMENT NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a re…

Text truncated - open the document above for the full version.

PHOTOGRAPH OF THE PRODUCT FRONT VIEW OF THE PRODUCT PHOTOGRAPH OF THE PRODUCT REAR VIEW OF THE PRODUCT

PHOTOGRAPH OF THE PRODUCT INNER CIRCUIT TOP VIEW PHOTOGRAPH OF THE PRODUCT INNER CIRCUIT BOTTOM VIEW

MODEL: THX301 General description This is a RF 433MHz thermometer & hygrometer remote sensor. The unit is capable to transmit 433MHz signal to receiver through 433MHz transmitter circuit. The unit can transmit the temperature unit in °C or °F. The unit uses 2 pcs AAA of 1.5V battery in-series connection. It gives 3V supply and it is a low power consumption design. Q&S Manufacturing CO. LTD. Signature Date Prepared by: Check by: Approved by:

THX301 FUNCTIONAL DESCRIPTION Temperature Sensor Convert the current temperature from sensor. Humidity Sensor Convert the current humidity from sensor. LCD Display LCD display the current temperature & humidity Crystal Oscillator A very stable crystal generate accurate pulses and feed into CPU as master clock. Battery Supply 3.0V In-series by dry battery 2 units AAA of 1.5V supply energy to whole circuit system. Low Battery Detect When the power voltage becomes low to specify value, circuit detection is activated RF Transmitter The unit is capable to transmit 433MHz signal to receiver through 433MHz transmitter circuit. CPU (Central Process Unit) A 4-bit CPU consist of all software. Q&S Manufacturing CO. LTD. Signature Date Prepared by: Check by: Approved by:

Application No.: H155954 Date: 14 April 2006 FCC ID: N9ZTHX301M Circuit Description The 433.9 MHz crystal oscillator drives the base of Q2 the final/buffer amplifier. The modulation provided by IC. The output of Q2 has the matching network consisting of L4, L5, L6, L7 and C17 that limit the harmonic content and effect the proper coupling of the antenna to the output stage. Antenna, Ground and Power Source There is no external antenna. There is no external ground connection. The ground is only that of the printed circuit board. Electric current is supplied by a 3 Volt (“AAA” size battery x 2) primary battery. Operation Descriptions The transmitter is a RF wireless transmitter for thermo and humidity operating at 433.9MHz band. The transmitter is powered by a 3V battery (AAA x 2) and the transmitting frequency is crystal controlled. The operation is achieved by different combinations of form pulse modulating signal on the 433.9MHz carrier frequency. Remarks: The transmitter is a 1 Trigger transmitter. It is Pulse transmitter, Modulation byIC; and type is Pulse modulation.

香 港 標 準 及 檢 定 中 心 Hong Kong Standards and Testing Centre Date : 2003-04-13 TEST REPORT Page 1 of 20 No. : HM155954 This report shall not be reproduced unless with prior written approval from the Hong Kong Standards and Testing Centre Ltd. 香港新界大埔工業村大宏街10號 10 Dai Wang Street, Taipo Industrial Estate, N.T., Hong Kong Tel: (852) 2666 1888 Fax: (852) 2664 4353 Homepage: www.hkstc.org E-mail: [email protected] For full text of “Conditions of Issuance of Test Report”, please refer to overleaf or refer to the website of STC: www.hkstc.org (the section “Application and Quotation”). Applicant: Ewig Industries Macao Commercial Offshore Limited. Rua de Pequim Macau Finance Centre 10E, Macau Description of Samples: Model name: RF WIRELESS TRANSMITTER / LONG RANGE THERMO & HUMIDITY SENSOR (WITH LCD) Model no.: THX301 Brand name: N/A FCC ID: N9ZTHX301M Date Samples Received: 2006-01-27 Date Tested: 2006-04-04 Investigation Requested: FCC Part 15 Subpart C Conclusions: The submitted product COMPLIED with the requirements of Federal Communications Commission [FCC] Rules and Regulations Part 15. The tests were performed in accordance with the standards described above and on Section 2.2 in this Test Report. Remarks: ---- LEE Kam Chuen, EMD For and on behalf of The Hong Kong Standards and Testing Centre Ltd. 香 港 標 準 及 檢 定 中 心 Hong Kong Standards and Testing Centre Date : 2006-04-13 TEST REPORT Page 2 of 20 No. : HM155954 香港新界大埔工業村大宏街10號 10 Dai Wang Street, Taipo Industrial Estate, N.T., Hong Kong Tel: (852) 2666 1888 Fax: (852) 2664 4353 Homepage: www.hkstc.org E-mail: [email protected] For full text of “Conditions of Issuance of Test Report”, please refer to overleaf or refer to the website of STC: www.hkstc.org (the section “Application and Quotation”). CONTENT: Cover Page 1 of 20 Content Page 2-3 of 20 1.0 General Details 1.1 Test Laboratory Page 4 of 20 1.2 Applicant Details Page 4 of 20 Applicant HKSTC Code Number for Applicant Manufacturer 1.3 Equipment Under Test [EUT] Page 5 of 20 Description of EUT operation 1.4 Date of Order Page 5 of 20 1.5 Submitted Sample Page 5 of 20 1.6 Test Duration Page 5 of 20 1.7 Country of Origin Page 5 of 20 2.0 Technical Details 2.1 Investigations Requested Page 6 of 20 2.2 Test Standards and Results Summary Page 6 of 20 3.0 Test Results 3.1 Emission Page 7-11 of 20 3.2 Bandwidth Measurement Page 12-13 of 20 香 港 標 準 及 檢 定 中 心 Hong Kong Standards and Testing Centre Date : 2006-04-13 TEST REPORT Page 3 of 20 No. : HM155954 香港新界大埔工業村大宏街10號 10 Dai Wang Street, Taipo Industrial Estate, N.T., Hong Kong Tel: (852) 2666 1888 Fax: (852) 2664 4353 Homepage: www.hkstc.org E-mail: [email protected] For full text of “Conditions of Issuance of Test Report”, please refer to overleaf or refer to the website of STC: www.hkstc.org (the section “Application and Quotation”). Appendix A List of Measurement Equipment Page 14 of 20 Appendix B Duty Cycle Correction During 100 msec Page 15-16 of 20 Appendix C Periodic Operation Page 17-18 of 20 Appendix D Photographs Page 19-20 of 20 香 港 標 準 及 檢 定 中 心 Hong Kong Standards and Testing Centre Date : 2006-04-13 TEST REPORT Page 4 of 20 No. : HM155954 香港新界大埔工業村大宏街10號 10 Dai Wang Street, Taipo Industrial Estate, N.T., Hong Kong Tel: (852) 2666 1888 Fax: (852) 2664 4353 Homepage: www.hkstc.org E-mail: [email protected] For full text of “Conditions of Issuance of Test Report”, please refer to overleaf or refer to the website of STC: www.hkstc.org (the section “Application and Quotation”). 1.0 General Details 1.1 Test Laboratory The Hong Kong Standards and Testing Centre Ltd. EMC Laboratory 10 Dai Wang Street, Taipo Industrial Estate New Territories, Hong Kong Telephone: 852 2666 1888 Fax: 852 2664 4353 1.2 Applicant Details Applicant Ewig Industries Macao Commercial Offshore Limited. Rua de Pequim Macau Finance Centre 10E, Macau Manufacturer Q & S Manufacturing Co., Ltd. Yin Shan District, Fu Gang Village, Xiang Mang West Road, Qing Xi Town, Dong Guan City, China 香 港 標 準 及 檢 定 中 心 Hong Kong Standards and Testing Centre Date : 2006-04-13 TEST REPORT Page 5 of 20 No. : HM155954 香港新界大埔工業村大宏街10號 10 Dai Wang Street, Taipo Industrial Estate, N.T., Hong Kong Tel: (852) 2666 1888 Fax: (852) 2664 4353 Homepage: www.hkstc.org E-mail: [email protected] For full text of “Conditions of Issuance of Test Report”, please refer to overleaf or refer to the website of STC: www.hkstc.org (the section “Application and Quotation”). 1.3 Equipment Under Test [EUT] Description of Sample Product: RF WIRELESS TRANSMITTER / LONG RANGE THERMO & HUMIDITY SENSOR (WITH LCD) Manufacturer: Q & S Manufacturing Co., Ltd. Brand Name: N/A Model Number: THX301 Rating: 3Vd.c (“AAA” size battery x 2) 1.3.1 Description of EUT Operation The Equipment Under Test (EUT) is a Ewig Industries Macao Commercial Offshore Limited., RF WIRELESS TRANSMITTER / LONG RANGE THERMO & HUMIDITY SENSOR (WITH LCD). The transmitter is a trigger transmitter. It is Pulse transmitter, Modulation by IC; and type is pulses modulation. 1.4 Date of Order 2006-01-27 1.5 Submitted Sample(s): 3 Samples per model 1.6 Test Duration 2006-04-04 1.7 Country of Origin China 香 港 標 準 及 檢 定 中 心 Hong Kong Standards and Testing Centre Date : 2006-04-13 TEST REPORT Page 6 of 20 No. : HM155954 香港新界大埔工業村大宏街10號 10 Dai Wang Street, Taipo Industrial Estate, N.T., Hong Kong Tel: (852) 2666 1888 Fax: (852) 2664 4353 Homepage: www.hkstc.org E-mail: [email protected] For full text of “Conditions of Issuance of Test Report”, please refer to overleaf or refer to the website of STC: www.hkstc.org (the section “Application and Quotation”). 2.0 Technical Details 2.1 Investigations Requested Perform ElectroMagnetic Interference measurement in accordance with FCC 47CFR [Codes of Federal Regulations] Part 15: 2005 and ANSI C63.4:2003 for FCC Certification. 2.2 Test Standards and Results Summary Tables EMISSION Results Summary Test Condition Test Requirement Test Method Class / Test Result Severity Pass Failed N/A Field Strength of Fundamental Emissions & Spurious…

Text truncated - open the document above for the full version.

TEST SET UP PHOTOGRAPH OF THE PRODUCT MEASUREMENT OF RADIATED EMISSION TEST SET UP
