N9ZTPX303Wireless Cooking Thermo
Ewig Industries Macao Commercial Offshore Limited
Click to zoom
Application Details
- Equipment Class
- DSC - Part 15 Security/Remote Control Transmitter
- Date of Grant
- Jul 04, 2008
- Application Purpose
- Original Equipment
- Date of Application
- Jul 04, 2008
- Equipment Note
- Wireless Cooking Thermo
- Frequency Range
- 433.80000000 - 433.80000000
- Country
- Macau
Documents & Files
Document Text
Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.
Users Manual
Page 1 of 10 WIRELESS GRILL THERMOMETER MODEL: TPR303 INSTRUCTION MANUAL Congratulations on your purchase of the Wireless Grill Thermometer, a programmable wireless food thermometer. You will now be able to remotely monitor the time and temperature of food cooking in the oven or outdoors from anywhere in your home. The receiver unit will beep to alert you when the cooking temperature is within the 10°F (5°C) range or already reaching the target temperature. Receiver Features LCD - Liquid crystal display to show display icons, Food-Taste, Timer, Received & Set temperatures. See LCD diagram for detailed information. CLIP – Detachable clip for attaching the receiver unit on a wrist belt or for resting on cradle. BATTERY COMPARTMENT - Holds two (2) ‘AAA’ 1.5V batteries. Description of buttons 1. [HR/▲] In Timer mode, press to set hour from 0hr to 23hr. Press and hold for 2 seconds; the hour setting will increase at a faster rate. In Thermometer mode, press to increase the manual temperature from 14ºF to 482ºF ( -10ºC to 250ºC ). LCD CLIP BATTERY COMPARTMENT 1 2 3 4 5 6 7 8 9 Page 2 of 10 Press and hold for 2 seconds, the temperature setting will increase at a faster rate. 2. [MIN/▼] In Timer mode, press to set minutes from 0 min to 59 min. Press and hold for 2 seconds; the minute setting will increase at a faster rate. In Thermometer mode, press to decrease the manual temperature from 14ºF to 482 ºF ( -10ºC to 250ºC ). Press and hold for 2 seconds; the temperature setting will decrease at a faster rate. 3. [CLEAR] While the timer count-down or count-up process is stopped, press once to clear the timer reading to zero. In thermometer mode, press to select temperature unit in Celsius or Fahrenheit. 4. [MODE] Press to select Thermometer or Timer mode. Press and hold for 2 seconds to enter RF registration mode. The ‘---‘ icon will appear in the place of the probe temperature and flash in 1Hz; press [Mode] button again to stop the RF registration. 5. [START/STOP] Press to start or stop the timer count-down or count-up. Press to stop the temperature/timer alert sound. 6. [MEAT] In Thermometer mode, toggle [MEAT] button to select meat type: BEEF ‡ VEAL ‡ LAMB ‡ PORK ‡ CHICK (chicken) ‡ TURKY (turkey) ‡ HAM (pre-cooked Ham) ‡ return. Press and hold for 2 seconds to change the display language from English to French. The meat type will be BOEUF, VEAU, AGNEA, PORC, POUL, DINDE and JAMBO. Press and hold [MEAT] button for another 2 seconds to switch the language back to English. 7. [TASTE] In Thermometer mode, toggle [TASTE] button to select the taste level: WELL DONE, MEDIUM, MEDIUM RARE or RARE. 8. [ON/OFF] Power switch for the receiver unit. 9. [LIGHT] Press once to turn on backlight for 10 seconds. While the backlight is on, press any key will extend the backlight illumination for another 10 seconds. Page 3 of 10 Timer mode (Count up /Count down) Count up Count down How to use the count up timer 1. Press [MODE] button to select the Timer mode, the timer icon ‘’ will appear. 2. In Timer mode and while the timer is stop running, press [CLEAR] button to reset the timer to 0:00. 3. While the timer display is 0:00, press [START/STOP] button will trigger timer to count up, the icon ‘’ will flash in 1Hz. Press [START/STOP] button again to temporarily stop the counting. 4. When the timer reaches the maximum count up time to 23:59:59, it will stop counting at 0:00 and starts beeping for 20 seconds to alert the user. To stop the alert sound, press the [START/STOP] button. How to use the count down timer 1. With the unit in Timer mode and the timer is stop running, press [CLEAR] button to reset the timer to 0:00. 2. Press [HR/▲] and [MIN/▼] button to enter desired count down time. 3. Press [START/STOP] button to start counting down, the icon ‘ ’ will flash in 1Hz. Press [START/STOP] button again to temporarily stop the counting. 4. While the count down time reaches 0:00, the unit will beep for 20 seconds to alert the user. Meanwhile, the timer will automatically switch to count up timer. The icon ‘’ and ‘’ will blink together to prompt the user that the count down timer is times up and start counting the elapsed time. Page 4 of 10 Thermometer mode Pre-programmed Temperature Alert In Thermometer mode, this device will alert user when the probe temperature reached the pre-determined selective setting. The user firstly selects a meat type (e.g. Beef) and a taste level (e.g. WELL DONE). The pre-set temperature of 170ºF display automatically. MEAT TASTE Type English French WELL DONE MEDIUM MEDIUM RARE RARE Beef BEEF BOEUF 170ºF 160ºF 145ºF 140ºF Veal VEAL VEAU 170ºF 160ºF 145ºF N/A Lamb LAMB AGNEA 170ºF 160ºF 145ºF N/A Pork PORK PORC 170ºF 160ºF N/A N/A Chicken, whole CHICK POUL 185ºF N/A N/A N/A Turkey, whole TURKY DINDE 185ºF N/A N/A N/A Ham pre-cooked HAM JAMBO 140ºF N/A N/A N/A Low battery indicator for receiver Low battery indicator for transmitter Meat type Taste level Page 5 of 10 Pre-Alert When the probe temperature is within 10°F (5°C) of the pre-set temperature, the device unit will beep once every 2 seconds and last for 1 minute. Reach Alert When the probe temperature reaches the pre-set temperature, the device unit will beep in pattern of bi-bi-bi/sec for 5 second, then silent for 7 second. This beeping pattern will repeat and last for 10 minutes. Note: To stop the alert sound, press the [START/STOP] button. Page 6 of 10 Manual temperature setting The user can use [▲] and [▼] button to enter a manual temperature other than the above pre-programmed temperature. When manual temperature is in use, the ‘PRE-SET’ icon change to ‘MANUAL’. RF loss link indication The receiver unit normally works well in the 30 m / 98 ft. range (at sign) with the Transmitter unit. However, if the receiver unit is taken outside the wireless reception range or there is severe external radio interference, the receiver may not able to receive the temperature signal from the Wireless sensor probe. If this loss link condition persist…
Text truncated - open the document above for the full version.
External Photos
PHOTOGRAPH OF THE PRODUCT FRONT VIEW OF THE PRODUCT PHOTOGRAPH OF THE PRODUCT REAR VIEW OF THE PRODUCT
Operational Description
FCC ID: N9ZTPX303 Circuit Description The 433 MHz crystal oscillator drives the base of Q2 the final/buffer amplifier. The modulation provided by IC. The output of Q3 has the matching network consisting of L1, L2 and C23, C24 that limit the harmonic content and effect the proper coupling of the antenna to the output stage. Antenna, Ground and Power Source The antenna consists of a 5.5 cm long Metal antenna. There is no external ground connection. The ground is only that of the printed circuit board. Electric current is supplied by a 3 Volt (“AAA” size battery x 2) primary battery Operation Descriptions The transmitter is a weather station operating at 433MHz band. The transmitter is powered by a 3V battery (“AAA” size battery x 2) and the transmitting frequency is crystal controlled. The transmitting data is controlled by 2 sensors. The operation is achieved by different combinations of form pulse modulating signal on the 433 MHz carrier frequency. Remarks: The transmitter is a periodic transmitter. Modulation by IC; and type is Pulse modulation.
Parts List/Tune Up Info
Bom List Report Of All Bom#890-TPX30300-001-901Description: LevelPartNumDescriptionQPA 1.892-02340300-003-9MODEL TPX303(023403) CASING1.000000 1.1.893-02340300-001-9 MODEL TPX303 (023403) PCBA1.000000 1.1.1.894-02340300-003-9 MODEL TPX303 (023403) COB2 (BONDING2)1.000000 1.1.1.1.895-02340300-005-9 MODEL TPX303 (023403) COB1 (SMT1)1.000000 1.1.1.1.1.200-02340000-002-9 0234,PCB MAIN,TPX301,FR4,1.0mm,D/S,GP+SM+CL,V1,RoHS1.000000 1.1.1.1.2.302-76612720-001-9XC61CN2702M 2.7V 2% SOT23 ROHS1.000000 1.1.1.1.3.303-10170031-000-9ROHS,FR RF/BFS17,FT=1.0G,F=800MHz1.000000 1.1.1.1.4.303-10947022-000-9ROHS,TRANSISTOR,NPN,PHILIPS,UHF WIDEBAND,PRF947,SOT-3231.000000 1.1.1.1.5.305-10000300-007-9 ROHS,RESISTOR CHIP,0ohm,+/-5%,1/16W,06034 [305-10000300-002-9] 1.1.1.1.6.305-11006100-006-9ROHS,CHIP RESISTOR,10Kohm,+/-1%,1/16W,06032.000000 1.1.1.1.7.305-11007100-002-9 ROHS,RESISTOR CHIP,100K,+/-1%,1/16W,06032 1.1.1.1.8.305-11008300-004-9 ROHS,RESISTOR CHIP,1Mohm,+/-5%,1/16W,06032.000000 1.1.1.1.9.305-11204300-001-9ROHS,RESISTOR CHIP,120ohm,+/-5%,1/16W,06031.000000 1.1.1.1.10.305-12006100-002-9 ROHS,RESISTOR CHIP,20Kohm,+/-1%,1/16W,06031.000000 1.1.1.1.11.305-12705300-001-9 ROHS,RESISTOR CHIP,2.7Kohm,+/-5%,1/16W,06031.000000 1.1.1.1.12.305-13003300-000-9ROHS,RESISTOR CHIP,30ohm,+/-5%,1/16W,06031.000000 1.1.1.1.13.305-13304100-001-9ROHS,RESISTOR CHIP,330ohm,+/-1%,1/16W,06031.000000 1.1.1.1.14.305-13905100-003-9ROHS,RESISTOR CHIP,3.9K,+/-1%,1/16W,06031.000000 [305-13905100-004-9] 1.1.1.1.16.305-14708300-001-9 ROHS,RESISTOR CHIP,4.7Mohm,+/-5%,1/16W,06033.000000 1.1.1.1.17.305-15606100-003-9 ROHS,RESISTOR CHIP,56Kohm,+/-1%,1/16W,06031.000000 1.1.1.1.18.306-61064000-000-9ROHS,TANTAL CAP 10uF,+/-10%,6.3V,AVX,CASEA1.000000 [306-61065000-003-9] 1.1.1.1.19.306-81003000-002-9ROHS,CAP CHIP,10pF,+/-5%,50V,0603,NPO1.000000 [306-81003000-003-9] 1.1.1.1.20.306-81048000-005-9 ROHS,CAP CHIP,0.1uF,+80/-20%,25V,060311.000000 1.1.1.1.21.306-81503000-005-9ROHS,CAP CHIP,15PF,+/-5%,0603,(MURATAGRM1885C1H1)1.000000 [306-81503000-004-9] [306-81503000-002-9] 1.1.1.1.22.306-82003000-002-9 ROHS,CAP CHIP,20pF,+/-5%,50V,0603,NPO2.000000 1.1.1.1.23.306-82093000-002-9ROHS,CAP CHIP,2pF,+/-0.25pF,50V,06032.000000 1.1.1.1.24.306-82258000-004-9RoHS,CAP CHIP,2.2uF,+80/-20%,25V,06031.000000 [306-82254000-005-9] 1.1.1.1.25.306-82703000-001-9 ROHS,CAP CHIP,27pF,+/-5%,50V,0603 NPO2.000000 1.1.1.1.26.306-86093000-000-9ROHS,CAP CHIP,6pF,+/-0.25pF,50V,0603,NP1.000000 1.1.1.1.27.313-08220400-000-9ROHS,INDUCTOR CHIP,2.2nH,SHL160808H,06031.000000 [313-08220400-001-9] 1.1.1.1.28.313-08471400-000-9ROHS,INDUCTOR CHIP,47nH,+/-5%,DCR MAX1OHM,06032.000000 1.1.1.2.302-11541000-002-9 RoHS,IC,CMOS,WINBOND W541C260-7652H,DICEFORM1.000000 1.1.2.200-02347000-001-9 0234,PCB JACK,TPX301,FR4,1.0mm,D/S,GP+SM+CL,V1,RoHS1.000000 1.1.3.221-10011000-000-9 ROHS,JACK,EJ-2511,D2.5mm1.000000 1.1.4.249-22217002-000-9 2P2T PUSH SWITCH PS-22E70L1.000000 1.1.5.251-30500045-002-9 ROHS,WIRE RAINBOW,2PIN,L45mm(3+39+3),#30,TIN=3mm1.000000 1.1.6.251-30500060-000-9 RoHS,RAINBOW CABLE,3PIN,L60mm(3+54+3),#30,TIN 3mm1.000000 1.1.7.310-13276101-000-9 ROHS,RESONATOR CRYSTAL,KDS,DT-26,32.768KHZ,20PPM,12.5pF,D2x6mm1.000000 1.1.8.310-21000306-001-9 ROHS,RESONATOR CERAMIC 1MHZ,+/-0.5%1.000000 1.1.9.310-44339505-000-9 ROHS,RESONATOR SAW,HR433C-F11,PORTF=433.921.000000 [310-44339505-001-9] 1.1.10.311-43400214-000-9 ROHS,LED RED,D3.0mm,H4.5mm,(3R4HDY)1.000000 1.1.11.313-04100100-000-9 ROHS,SPRING COILS 0.4mm WIRE,INSIDE 2.3mm,10T1.000000 1.1.12.313-04300000-001-9 ROHS,SPRING COILS 0.4mm WIRE,INSIDE 2.3mm,3T1.000000 1.1.13.313-04800000-000-9 ROHS,COIL SPRING,WIRE 0.4mm,INSIDE D2.3mm,8T1.000000 [313-04800000-001-9] 1.1.14.532-36000200-000-9ANTENNA PURE COPPER NI-PLATED EWIG PCS ROHS1.000000 1.2.898-02340300-000-9 MODEL TPX303 INSERT MOLDING,170-00000000-004-9+892-02340300-002-91.000000 1.2.1.175-00000000-004-9 PLASTIC GRAIN,PVC80°,DCYTA-8,NATURAL WHITE,KG,RoHS0.005000 1.2.2.892-02340300-002-9MODEL TPX303 (023403) CASING1.2.11.000000 1.2.2.1.168-00000000-000-9 RoHS,GREASE,THERMAL CONDUCTIVE 910-500.001000 1.2.2.2.221-00110000-000-9 RoHS,PLUG,D2.5*L26.0mm1.000000 1.2.2.3.250-05900000-006-9 ROHS,TUBE HIGH TEMP 200DEC INSULATION,2.5KV,ID1.0/+0.20-0.00mm,T0.18mm0.000350 1.2.2.4.250-09100000-001-9 RoHS,TUBE HEAT SHRINKABLE,D2.5mm,200m/ROLL0.035000 1.2.2.5.250-09100000-004-9 ROHS,TUBE HEAT SHRINKABLE,D2.00mm,L200m/ROLL0.000180 1.2.2.6.251-00401200-007-9 RoHS,WIRE HIGH TEMPERATURE,L1200mm,ONECORE1.000000 1.2.2.7.309-02000200-000-9 RoHS,THERMISTOR,ISHIZUKA/204CT-4-3P,200Kohm,25DEG.C P+1-3% B+1-2%1.000000 1.2.2.8.532-26000000-000-9 ROHS,TUBE STEEL,S/S,ID3.2xOD4.0mm,L202mm1.000000 1.2.2.9.532-46000000-004-9 ROHS,HEADER PROBE1.000000 1.2.2.10.532-48000101-000-9 RoHS,TERMINAL COPPER,R2121BS-0,25K PCS/ROLL2.000000 1.3.045-02341610-999-9 DUMMY,DOOR BATTERY,046-02341610-000-1,ABS,0234,1,PCS,RoHS1.000000 1.4.045-02341710-999-9 DUMMY,BUTTON POWER,046-02341710-000-1,ABS,0234,1,PCS,RoHS1.000000 1.5.045-02341810-999-9 DUMMY,BUTTON BOTTOM 1,046-02341810-000-1,ABS,0234,1,PCS,RoHS1.000000 1.6.045-02342010-999-9 DUMMY,CAB BOTTOM-A,046-02342010-000-1,ABS,0234,1,PCS,RoHS1.000000 1.7.045-02342110-999-9 DUMMY,CAB TOP,046-02342110-000-1,ABS,0234,1,PCS,RoHS1.000000 1.8.238-07110010-000-9 ROHS,KEY RUBBER,SINGLE,U-126,ANY COLOR1.000000 1.9.238-80700010-000-9 ROHS,FOOT RUBBER,NO COLOR,D6.0x2.0mm4.000000 1.10.532-01000800-001-9 RoHS,SPRING BATTERY,+VE,D0.6mm,NI WIRE1.000000 1.11.532-02000800-002-9 RoHS,SPRING BATTERY,-VE,D0.6mm,NI WIRE1.000000 1.12.532-03000800-009-9 RoHS,PLATE BATTERY,+/-VE,C-STEEL,NI-PLATED1.000000 1.13.533-17050009-002-9 ROHS,SCREW,D1.7x5mm,PB8.000000 1.14.533-20070000-000-9 ROHS,SCREW,D2x7mm,PB,STD CROSS TYPE,ALLOY4.000000 1.15.056-07500009-000-9ROHS,CABLE TIE,L75mm,BLACK1.000000 1.16.044-02340003-000-9FILM,0234,PET,L52.0xW20.8xH1.0mm,BLACK,RoHS1.000000
Schematics
FCC ID: N9ZTPX303 Circuit Description The 433 MHz crystal oscillator drives the base of Q2 the final/buffer amplifier. The modulation provided by IC. The output of Q3 has the matching network consisting of L1, L2 and C23, C24 that limit the harmonic content and effect the proper coupling of the antenna to the output stage. Antenna, Ground and Power Source The antenna consists of a 5.5 cm long Metal antenna. There is no external ground connection. The ground is only that of the printed circuit board. Electric current is supplied by a 3 Volt (“AAA” size battery x 2) primary battery Operation Descriptions The transmitter is a weather station operating at 433MHz band. The transmitter is powered by a 3V battery (“AAA” size battery x 2) and the transmitting frequency is crystal controlled. The transmitting data is controlled by 2 sensors. The operation is achieved by different combinations of form pulse modulating signal on the 433 MHz carrier frequency. Remarks: The transmitter is a periodic transmitter. Modulation by IC; and type is Pulse modulation.
Test Report
STC Test Report Date : 2008-06-26 Page 1 of 18 No. : HM161833 The Hong Kong Standards and Testing Centre Ltd. 10 Dai Wang Street, Taipo Industrial Estate, N.T., Hong Kong Tel: (852) 2666 1888 Fax: (852) 2664 4353 Homepage: www.hkstc.org E-mail: [email protected] This report shall not be reproduced unless with prior written approval from the Hong Kong Standards and Testing Centre Ltd. For full text of “Conditions of Issuance of Test Report”, please refer to overleaf or refer to the website of Homepage. Applicant (EWI002): Ewig Industries Macao Commercial Offshore Limited. Rua de Pequim Macau Finance Centre 10E, Macau Description of Samples: Model Name: 433MHz RF Wireless Cooking Thermo Brand Name: Accu-Temp Model Number: TPX303 FCC ID: N9ZTPX303 Date Samples Received: 2008-06-06 Date Tested: 2008-06-13 Investigation Requested: FCC Part 15 Subpart C Conclusions: The submitted product was deemed to have COMPLIED with the requirements of Federal Communications Commission [FCC] Rules and Regulations Part 15. The tests were performed in accordance with the standards described above and on Section 2.2 in this Test Report. Remarks: ---- Dr. LEE Kam Chuen, ElectroMagnetic Compatibility Department For and on behalf of The Hong Kong Standards and Testing Centre Ltd. STC Test Report Date : 2008-06-26 Page 2 of 18 No. : HM161833 The Hong Kong Standards and Testing Centre Ltd. 10 Dai Wang Street, Taipo Industrial Estate, N.T., Hong Kong Tel: (852) 2666 1888 Fax: (852) 2664 4353 Homepage: www.hkstc.org E-mail: [email protected] This report shall not be reproduced unless with prior written approval from The Hong Kong Standards and Testing Centre Ltd. For Conditions of Issuance of this test report, please refer to the overleaf or Homepage CONTENT: Cover Page 1 of 18 Content Page 2-3 of 18 1.0 General Details 1.1 Test Laboratory Page 4 of 18 1.2 Applicant Details Page 4 of 18 Applicant Manufacturer 1.3 Equipment Under Test [EUT] Page 5 of 18 Description of EUT operation 1.4 Date of Order Page 5 of 18 1.5 Submitted Samples Page 5 of 18 1.6 Test Duration Page 5 of 18 1.7 Country of Origin Page 5 of 18 2.0 Technical Details 2.1 Investigations Requested Page 6 of 18 2.2 Test Standards and Results Summary Page 6 of 18 3.0 Test Results 3.1 Emission Page 7-10 of 18 3.2 Bandwidth Measurement Page 11-12 of 18 STC Test Report Date : 2008-06-26 Page 3 of 18 No. : HM161833 The Hong Kong Standards and Testing Centre Ltd. 10 Dai Wang Street, Taipo Industrial Estate, N.T., Hong Kong Tel: (852) 2666 1888 Fax: (852) 2664 4353 Homepage: www.hkstc.org E-mail: [email protected] This report shall not be reproduced unless with prior written approval from The Hong Kong Standards and Testing Centre Ltd. For Conditions of Issuance of this test report, please refer to the overleaf or Homepage Appendix A List of Measurement Equipment Page 13 of 18 Appendix B Duty Cycle Correction During 100 msec Page 14-15 of 18 Appendix C Periodic Operation Page 16 of 18 Appendix D Photographs Page 17-18 of 18 STC Test Report Date : 2008-06-26 Page 4 of 18 No. : HM161833 The Hong Kong Standards and Testing Centre Ltd. 10 Dai Wang Street, Taipo Industrial Estate, N.T., Hong Kong Tel: (852) 2666 1888 Fax: (852) 2664 4353 Homepage: www.hkstc.org E-mail: [email protected] This report shall not be reproduced unless with prior written approval from The Hong Kong Standards and Testing Centre Ltd. For Conditions of Issuance of this test report, please refer to the overleaf or Homepage 1.0 General Details 1.1 Test Laboratory The Hong Kong Standards and Testing Centre Ltd. EMC Laboratory 10 Dai Wang Street, Taipo Industrial Estate New Territories, Hong Kong Telephone: 852 2666 1888 Fax: 852 2664 4353 1.2 Applicant Details Applicant Ewig Industries Macao Commercial Offshore Limited. Rua de Pequim Macau Finance Centre 10E, Macau HKSTC Code Number for Applicant Manufacturer Q & S Manufacturing Co., Ltd. Yin Shan District, Fu Gang Village, Xiang Mang West Road, Qing Xi Town, Dong Guan, China STC Test Report Date : 2008-06-26 Page 5 of 18 No. : HM161833 The Hong Kong Standards and Testing Centre Ltd. 10 Dai Wang Street, Taipo Industrial Estate, N.T., Hong Kong Tel: (852) 2666 1888 Fax: (852) 2664 4353 Homepage: www.hkstc.org E-mail: [email protected] This report shall not be reproduced unless with prior written approval from The Hong Kong Standards and Testing Centre Ltd. For Conditions of Issuance of this test report, please refer to the overleaf or Homepage 1.3 Equipment Under Test [EUT] Description of Sample Product: 433MHz RF Wireless Cooking Thermo Manufacturer: Q & S Manufacturing Co., Ltd. Brand Name: Accu-Temp Model Number: TPX303 Rating: 3Vd.c (“AAA” size battery x 2) 1.3.1 Description of EUT Operation The Equipment Under Test (EUT) is a Ewig Industries Macao Commercial Offshore Limited., 433MHz RF Wireless Cooking Thermo. The transmitter is a period transmitter, modulation by IC; and type is pulse modulation. 1.4 Date of Order 2008-06-06 1.5 Submitted Sample(s): 2 Samples 1.6 Test Duration 2008-06-13 1.7 Country of Origin China STC Test Report Date : 2008-06-26 Page 6 of 18 No. : HM161833 The Hong Kong Standards and Testing Centre Ltd. 10 Dai Wang Street, Taipo Industrial Estate, N.T., Hong Kong Tel: (852) 2666 1888 Fax: (852) 2664 4353 Homepage: www.hkstc.org E-mail: [email protected] This report shall not be reproduced unless with prior written approval from The Hong Kong Standards and Testing Centre Ltd. For Conditions of Issuance of this test report, please refer to the overleaf or Homepage 2.0 Technical Details 2.1 Investigations Requested Perform ElectroMagnetic Interference measurement in accordance with FCC 47CFR [Codes of Federal Regulations] Part 15: 2007 and ANSI C63.4:2003 for FCC Certification. 2.2 Test Standards and Results Summary Tables EMISSION Results Summary Test Condition Test Requirement Test Method Class / Test Result Severity Pass Failed Field Strength of Fundamental Emissions & Spurious Emissions FCC 47CFR 15.231e ANSI C63.4:2003 N/A Radiat…
Text truncated - open the document above for the full version.
Contact Information
Applicant
Liu Binkky(Electronic Supervisor)
Test Firm
Hong Kong Standards and Testing CenterWison Wong
Technical Specifications
| # | Rule Parts | Frequency Range | Power Output |
|---|---|---|---|
| 1 | 15.231(e) | 433.8 MHz - 433.8 MHz | - |
