NBF-9X30-1-1Mobile Computer

User’s Manual PT-90 Series Mobile Computer PT-9130-1-1,PT-9230-1-1 (Contains WiFi/Bluetooth/GPRS/ GPS) PT-9132-0-0,PT-9232-0-0 (Contains WiFi/Bluetooth/RFID) (WinCE 6.0 version) DOC NO. UM-P9005-01 Dec. 2012 Version 2.0 Em p ower the Bar Code User’s Manual II NOTICE: This user’s manual may be revised or withdrawn at any time without prior notice. Copyright 2009, Argox Information Co., Ltd. All rights reserved. This manual may not, in whole or in part, be copied, photocopied, reproduced, translated or converted to any electronic or machine readable form without the prior written consent of Argox. Limited warranty and disclaimers By opening the package of this product you agree to become bound by the liability and warranty conditions as described below. Under all circumstances this manual should be read attentively before installing and or using the product. In no event, will Argox be liable for any direct, indirect, consequential or incidental damages arising out of use or inability to use both the hardware and software, even if Argox has been informed about the possibility of such damages. A serial number appears on all Argox products. This official registration number is strictly related to the device purchased. Make sure that the serial number appearing on your Argox device has not been removed. Servicing by our service department can only be carried out under warranty. All Argox products are warranted for the legal warranty period after purchase, covering defects in material and workmanship. Argox will repair or, at its opinion, replace products that prove to be defective in material or workmanship under proper use during the warranty period. Argox will not be liable in case modifications are made by the customer. In such case the standard repair charge will be applicable. The standard charge for repair will also be applicable in case no defect is found at all. These rules also apply for products that are still under warranty. Therefore, you are advised to have the product specifications always at hand. Trademarks used are property of their respective owners. User’s Manual III FEDERAL COMMUNICATIONS COMMISSION INTERFERENCE STATEMENT This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: --Reorient or relocate the receiving antenna. --Increase the separation between the equipment and receiver. --Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. --Consult the dealer or an experienced radio/TV technician for help. CAUTION: Any changes or modifications not expressly approved by the grantee of this device could void the user's authority to operate the equipment. Labeling requirements This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. RF exposure warning This equipment must be installed and operated in accordance with provided instructions and must not be co-located or operating in conjunction with any other antenna or transmitter. End-users and installers must be providing with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. Maximum SAR value: 0.793 W/kg (For M/N: PT-9130-1-1, PT-9230-1-1) 0.561 W/kg (For M/N: PT-9132-0-0, PT-9232-0-0) User’s Manual I Table of Contents 1. INTRODUCTION............................................................................................................. 1 1.1 ABOUT THIS MANUAL................................................................................................ 1 1.2 USER AND PRODUCT SAFETY..................................................................................... 2 1.3 SPECIFICATIONS......................................................................................................... 4 2. GETTING STARTED ...................................................................................................... 6 2.1 CHECK THE PACKAGE................................................................................................ 6 2.1.1 Compact Package ........................................................................................... 6 2.1.2 Cadle & Pistol grip Package (Optional)......................................................... 7 2.2 DETAILED VIEW......................................................................................................... 8 2.2.1 PT-90 Mobile Computer ................................................................................. 8 2.2.2 Cradle ............................................................................................................. 9 2.3 INSTALLING, REPLACING AND CHARGING BATTERIES.......................................... 10 2.3.1 Installing / Replacing the Battery Pack......................................................... 12 2.3.2 Charging the Battery Pack with a Power Adapter ........................................ 12 2.3.3 Charging the Battery Pack with Cradle ........................................................ 13 2.4 INSTALLING IN A SYSTEM............................................................…

Text truncated - open the document above for the full version.

Report No.: 12C330R-HPUSP07V01 Page : 1 of 19 Attachment 2 : EUT Detailed Photographs (1) EUT Photo (2) EUT Photo Report No.: 12C330R-HPUSP07V01 Page : 2 of 19 (3) EUT Photo (4) EUT Photo

Argox Information Co.,Ltd. FCC ID.: NBF-9X30-1-1 7F., No.126, Ln. 235, Baociao Rd., Sindian Dist., New Taipei City 231, Taiwan (R.O.C.) Tel : 886-2-8912-1121 The FCC ID will be placed on the equipment as shown in the photograph below.

Argox Information Co.,Ltd. FCC ID.: NBF-9X30-1-1 7F., No.126, Ln. 235, Baociao Rd., Sindian Dist., New Taipei City 231, Taiwan (R.O.C.) Tel : 886-2-8912-1121 FCC ID Label

Report No.: 12C330R-HPUSP07V01 Page : 3 of 19 (5) EUT Photo (6) EUT Photo Report No.: 12C330R-HPUSP07V01 Page : 4 of 19 (7) EUT Photo (8) EUT Photo Report No.: 12C330R-HPUSP07V01 Page : 5 of 19 (9) EUT Photo (10) EUT Photo Report No.: 12C330R-HPUSP07V01 Page : 6 of 19 (11) EUT Photo_(PT-9230-1-1, Scan Tech: 2D ) (12) EUT Photo_(PT-9130-1-1, Scan Tech: Laser ) Report No.: 12C330R-HPUSP07V01 Page : 7 of 19 (13) EUT Photo (14) EUT Photo Report No.: 12C330R-HPUSP07V01 Page : 8 of 19 (15) EUT Photo (16) EUT Photo Report No.: 12C330R-HPUSP07V01 Page : 9 of 19 (17) EUT Photo (18) EUT Photo Report No.: 12C330R-HPUSP07V01 Page : 10 of 19 (19) EUT Photo (20) EUT Photo Report No.: 12C330R-HPUSP07V01 Page : 11 of 19 (21) EUT Photo (22) EUT Photo Report No.: 12C330R-HPUSP07V01 Page : 12 of 19 (23) EUT Photo (24) EUT Photo Report No.: 12C330R-HPUSP07V01 Page : 13 of 19 (25) EUT Photo (26) EUT Photo Report No.: 12C330R-HPUSP07V01 Page : 14 of 19 (27) EUT Photo (28) EUT Photo Report No.: 12C330R-HPUSP07V01 Page : 15 of 19 (29) EUT Photo (30) EUT Photo Report No.: 12C330R-HPUSP07V01 Page : 16 of 19 (31) EUT Photo (32) EUT Photo Report No.: 12C330R-HPUSP07V01 Page : 17 of 19 (33) EUT Photo (34) EUT Photo Report No.: 12C330R-HPUSP07V01 Page : 18 of 19 (35) EUT Photo (36) EUT Photo Report No.: 12C330R-HPUSP07V01 Page : 19 of 19 (37) EUT Photo (38) EUT Photo

Report No. 12C330R-RFUSP43V01 Page: 1 of 74 FCC Test Report Product Name Mobile Computer Model No. PT-9130-1-1, PT-9230-1-1 FCC ID. NBF-9X30-1-1 Applicant Argox Information Co.,Ltd. Address 7F., No.126, Ln. 235, Baociao Rd., Sindian Dist., New Taipei City 231, Taiwan (R.O.C.) Date of Receipt Dec. 20, 2012 Issued Date Mar. 20, 2013 Report No. 12C330R-RFUSP43V01 Report Version V1.0 The Test Results relate only to the samples tested. The test report shall not be reproduced except in full without the written approval of QuieTek Corporation. This report must not be used to claim product endorsement by NVLAP any agency of the U.S. Government Report No. 12C330R-RFUSP43V01 Page: 2 of 74 Test Report Certification Issued Date: Mar. 20, 2013 Report No.: 12C330R-RFUSP43V01 Product Name Mobile Computer Applicant Argox Information Co.,Ltd. Address 7F., No.126, Ln. 235, Baociao Rd., Sindian Dist., New Taipei City 231, Taiwan (R.O.C.) Manufacturer Argox Information Co.,Ltd. Model No. PT-9130-1-1, PT-9230-1-1 FCC ID. NBF-9X30-1-1 EUT Rated Voltage AC 100-240V, 50-60Hz EUT Test Voltage AC 120V/ 60Hz Trade Name ARGOX Applicable Standard FCC CFR Title 47 Part 15 Subpart C: 2012 ANSI C63.4: 2003, ANSI C63.10: 2009 Test Result Complied The Test Results relate only to the samples tested. The test report shall not be reproduced except in full without the written approval of QuieTek Corporation. This report must not be used to claim product endorsement by NVLAP any agency of the U.S. Government Documented By : ( Senior Adm. Specialist / Genie Chang ) Tested By : ( Assistant Engineer / Alan Chen ) Approved By : ( Manager / Vincent Lin ) Report No. 12C330R-RFUSP43V01 Page: 3 of 74 TABLE OF CONTENTS Description Page 1. GENERAL INFORMATION ...............................................................................................................5 1.1. EUT Description......................................................................................................................................5 1.2. Operational Description...........................................................................................................................7 1.3. Tested System Details..............................................................................................................................8 1.4. Configuration of Tested System ..............................................................................................................8 1.5. EUT Exercise Software ...........................................................................................................................8 1.6. Test Facility .............................................................................................................................................9 2. CONDUCTED EMISSION ................................................................................................................10 2.1. Test Equipment ......................................................................................................................................10 2.2. Test Setup ..............................................................................................................................................10 2.3. Limits.....................................................................................................................................................11 2.4. Test Procedure .......................................................................................................................................11 2.5. Uncertainty ............................................................................................................................................11 2.6. Test Result of Conducted Emission .......................................................................................................12 3. PEAK POWER OUTPUT ..................................................................................................................14 3.1. Test Equipment ......................................................................................................................................14 3.2. Test Setup ..............................................................................................................................................14 3.3. Limit .....................................................................................................................................................14 3.4. Test Procedure .......................................................................................................................................14 3.5. Uncertainty ............................................................................................................................................14 3.6. Test Result of Peak Power Output .........................................................................................................15 4. RADIATED EMISSION .....................................................................................................................17 4.1. Test Equipment ......................................................................................................................................17 4.2. Test Setup ..............................................................................................................................................17 4.3. Limits.....................................................................................................................................................18 4.4. Test Procedure .......................................................................................................................................19 4.5. Uncertainty ............................................................................................................................................19 4.6. Test Result of Radiated Emission ...............................................................................…

Text truncated - open the document above for the full version.

Report No. 12C330R-RFUSP43V01 Page: 52 of 74 7. Channel Number 7.1. Test Equipment Equipment Manufacturer Model No./Serial No. Last Cal. Spectrum Analyzer R&S FSP40 / 100170 Jun, 2012 Spectrum Analyzer Agilent E4407B / US39440758 Jun, 2012 X Spectrum Analyzer Agilent N9010A / MY48030495 Apr., 2012 Note: 1. All equipments are calibrated every one year. 2. The test instruments marked by “X” are used to measure the final test results. 7.2. Test Setup 7.3. Limit Frequency hopping systems operating in the 2400-2483.5 MHz bands shall use at least 75 hopping frequencies. 7.4. Test Procedure The EUT was setup to ANSI C63.10: 2009; tested to FHSS test procedure of FCC Public Notice DA 00-705 for compliance to FCC 47CFR 15.247 requirements. 7.5. Uncertainty N/A SMA Connecter EUT Spectrum Analyzer RF Cable Report No. 12C330R-RFUSP43V01 Page: 53 of 74 7.6. Test Result of Channel Number Product : Mobile Computer Test Item : Channel Number Test Site : No.3 OATS Test Mode : Mode 1: Transmit - 1Mbps (GFSK) Frequency Range (MHz) Measurement (Hopping Channel) Required Limit (Hopping Channel) Result 2402 ~ 2480 79 >75 Pass 2402-2421MHz 2422-2441MHz 2442-2461MHz 2462-2480MHz Report No. 12C330R-RFUSP43V01 Page: 54 of 74 Product : Mobile Computer Test Item : Channel Number Test Site : No.3 OATS Test Mode : Mode 2: Transmit - 3Mbps (8DPSK) Frequency Range (MHz) Measurement (Hopping Channel) Required Limit (Hopping Channel) Result 2402 ~ 2480 79 >75 Pass 2402-2421MHz 2422-2441MHz 2442-2461MHz 2462-2480MHz Report No. 12C330R-RFUSP43V01 Page: 55 of 74 8. Channel Separation 8.1. Test Equipment Equipment Manufacturer Model No./Serial No. Last Cal. Spectrum Analyzer R&S FSP40 / 100170 Jun, 2012 Spectrum Analyzer Agilent E4407B / US39440758 Jun, 2012 X Spectrum Analyzer Agilent N9010A / MY48030495 Apr., 2012 Note: 1. All equipments are calibrated every one year. 2. The test instruments mark by “X” are used to measure the final test results. 8.2. Test Setup 8.3. Limit Frequency hopping systems shall have hopping channel carrier frequencies separated by a minimum of 25 kHz or the 20 dB bandwidth of the hopping channel, whichever is greater. 8.4. Test Procedure The EUT was setup to ANSI C63.10: 2009; tested to FHSS test procedure of FCC Public Notice DA 00-705 for compliance to FCC 47CFR 15.247 requirements. 8.5. Uncertainty ± 150Hz SMA Connecter EUT Spectrum Analyzer RF Cable Report No. 12C330R-RFUSP43V01 Page: 56 of 74 8.6. Test Result of Channel Separation Limit Limit of (2/3)*20dB Channel No. Frequency (MHz) Measurement Level (kHz) (kHz) Bandwidth (kHz) Result 00 2402 1080 >25 kHz 746.7 Pass 39 2441 1160 >25 kHz 746.7 Pass 78 2480 1060 >25 kHz 746.7 Pass NOTE: The 20dB Bandwidth is refer to section 10. Channel 00 2402MHz Product : Mobile Computer Test Item : Channel Separation Test Site : No.3 OATS Test Mode : Mode 1: Transmit - 1Mbps (GFSK) Report No. 12C330R-RFUSP43V01 Page: 57 of 74 Channel 39 2441MHz Channel 78 2480 MHz Report No. 12C330R-RFUSP43V01 Page: 58 of 74 Limit Limit of (2/3)*20dB Channel No. Frequency (MHz) Measurement Level (kHz) (kHz) Bandwidth (kHz) Result 00 2402 1140 >25 kHz 940.0 Pass 39 2441 1340 >25 kHz 946.7 Pass 78 2480 1000 >25 kHz 940.0 Pass NOTE: The 20dB Bandwidth is refer to section 10. Channel 00 2402MHz Product : Mobile Computer Test Item : Channel Separation Test Site : No.3 OATS Test Mode : Mode 2: Transmit - 3Mbps (8DPSK) Report No. 12C330R-RFUSP43V01 Page: 59 of 74 Channel 39 2441MHz Channel 78 2480 MHz Report No. 12C330R-RFUSP43V01 Page: 60 of 74 9. Dwell Time 9.1. Test Equipment Equipment Manufacturer Model No./Serial No. Last Cal. Spectrum Analyzer R&S FSP40 / 100170 Jun, 2012 Spectrum Analyzer Agilent E4407B / US39440758 Jun, 2012 X Spectrum Analyzer Agilent N9010A / MY48030495 Apr., 2012 Note: 1. All equipments are calibrated every one year. 2. The test instruments marked by “X” are used to measure the final test results. 9.2. Test Setup 9.3. Limit The dwell time shall be the average time of occupancy on any frequency shall not be greater than 0.4 seconds within a 30 second period. 9.4. Test Procedure The EUT was setup to ANSI C63.10: 2009; tested to FHSS test procedure of FCC Public Notice DA 00-705 for compliance to FCC 47CFR 15.247 requirements. 9.5. Uncertainty ± 25msec SMA Connecter EUT Spectrum Analyzer RF Cable Report No. 12C330R-RFUSP43V01 Page: 61 of 74 9.6. Test Result of Dwell Time Product : Mobile Computer Test Item : Dwell Time Test Site : No.3 OATS Test Mode : Mode 1: Transmit - 1Mbps (GFSK) (Channel 00,39,78 –DH5) Frequency (MHz) Time slot length (ms) Hopping of Number Sweep time (ms) Duty cycle Dwell Time (Sec) Limit (Sec) Result 2402 2.900 13 50 0.75 0.302 0.4 Pass 2441 2.900 13 50 0.75 0.302 0.4 Pass 2480 2.900 13 50 0.75 0.302 0.4 Pass Duty cycle =((Time slot length(ms)*Hopping of Number) / Sweep time (ms) Dwell time = (Duty cycle /79) * (79*0.4) CH 00 Time Interval between hops CH 00 Transmission Time CH39 Time Interval between hops CH 39Transmission Time Report No. 12C330R-RFUSP43V01 Page: 62 of 74 CH 78 Time Interval between hops CH 78 Transmission Time Note: The dwell times of the packet type of DH1, DH3, and DH5 are tested. Only the worst case is shown on the report. Report No. 12C330R-RFUSP43V01 Page: 63 of 74 Product : Mobile Computer Test Item : Dwell Time Test Site : No.3 OATS Test Mode : Mode 2: Transmit - 3Mbps (8DPSK) (Channel 00,39,78 –DH5) Frequency (MHz) Time slot length (ms) Hopping of Number Sweep time (ms) Duty cycle Dwell Time (Sec) Limit (Sec) Result 2402 2.890 13 50 0.75 0.301 0.4 Pass 2441 2.900 13 50 0.75 0.302 0.4 Pass 2480 2.910 13 50 0.76 0.303 0.4 Pass Duty cycle =((Time slot length(ms)*Hopping of Number) / Sweep time (ms) Dwell time = (Duty cycle /79) * (79*0.4) CH 00 Time Interval between hops CH 00 Transmission Time CH39 Time Interval between hops CH 39Transmission Time Report No. 12C330R-RFUSP43V01 Page: 64 of 74 CH 78 Time Interval between hops CH 78 Transmission Time Note: The dwell times of the packet type of DH1, DH3, and D…

Text truncated - open the document above for the full version.

Report No.: 12C330R-RFUSP43V01 Page : 1 of 3 Attachment 1: EUT Test Setup Photographs Front View of Conducted Test Back View of Conducted Test Report No.: 12C330R-RFUSP43V01 Page : 2 of 3 Front View of Radiated Test Back View of Radiated Test Report No.: 12C330R-RFUSP43V01 Page : 3 of 3 Front View of Radiated Test (Horn) Back View of Radiated Test (Horn)

Report No：12C330R-HPUSP09V01 Page: 1 of 23 Appendix C. Test Setup Photographs & EUT Photographs Test Setup Photographs EUT Back EUT Front Distance 1cm Distance 1cm Report No：12C330R-HPUSP09V01 Page: 2 of 23 EUT R-Side EUT Top Distance 1cm Distance 1cm Report No：12C330R-HPUSP09V01 Page: 3 of 23 Depth of the liquid in the phantom-Zoom In Note: The positions used in the measurements were according to IEEE 1528-2003.
