NC3-24074AVLGPS Tracking System (RTC)

Allied Universal Electronic Monitoring US, Inc.

Click to zoom

Application Details

Equipment Class: DSR - Part 15 Remote Control/Security Device Transceiver
Date of Grant: Jul 22, 2021
Application Purpose: Original Equipment
Date of Application: Jul 22, 2021
Equipment Note: GPS Tracking System (RTC)
Frequency Range: 433.92000000 - 433.92000000
Company: Allied Universal Electronic Monitoring US, Inc.
Country: United States

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Attenti Two-Piece Real-Time Communication Device (RTC) User Guide 2-Piece (RTC - Voice) User Guide 2 Attenti Two-Piece Real-Time Communication (RTC) User Guide July 6, 2021 2-Piece (RTC - Voice) User Guide 3 Copyright ©2019 Attenti. All rights reserved. No part of this publication may be reproduced, stored in a retrieval system, or transmitted, in any form or by any means, electronic, mechanical, photocopying, recording, or otherwise, without the prior written permission of Attenti. The information in this document is subject to change without notice. The software mentioned in this document is furnished under license and may only be used or copied in accordance with the terms of such license. Contact software manufacturers directly for terms of software licenses for any software mentioned in this document not originating from Attenti. All brand or product names are the trademarks or registered trademarks of their respective holders. 2-Piece (RTC - Voice) User Guide 4 Accessing the Offender Menu To access the Offender Menu, use the Acknowledge (center) button. Messages: Displays messages sent to the device. Vibrate/Beep: Changes 2 Piece (RTC) alert mode. ID Numbers: Displays ID numbers of assigned hardware. Alarm Set: Accesses alarm clock function. Call List: Displays the officer-defined phone numbers that the 2 Piece (RTC) can dial. Icon Glossary: Displays the icons that will appear with each alarm. 2-Piece (RTC - Voice) User Guide 5 RF Exposure Statement Attenti Offender tracking device, Model 24014VL, has been evaluated under FCC Bulletin OET 65C and found to be compliant with FCC RF radiation exposure limits set forth for an uncontrolled environment. This device is to be used solely by law enforcement agencies for tracking purposes. The antenna(s) used for this transmitter must not be co- located or operating in conjunction with any other antenna or transmitter except in accordance with FCC multi- transmitter product procedures. The use of accessories not approved by Attenti, including but not limited to batteries, antennas, wall adapters, chargers and belt clips may cause the device to malfunction or in the case of unapproved electrical accessories may lead to hazardous conditions, cause the device to exceed RF energy exposure guidelines, and/or damage the device. FCC Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: —Reorient or relocate the receiving antenna —Increase the separation between the equipment and receiver —Connect the equipment into an outlet on a circuit different from that to which the receiver is connected —Consult the dealer or an experienced radio/TV technician for help. 2-Piece (RTC - Voice) User Guide 6 Canada Note: CAN ICES-3 B/NMB-3 B This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Cet appareil est conforme avec la norme RSS-210 d'Industrie Canada exempte de licence. Son fonctionnement est soumis aux deux conditions suivantes: (1) cet appareil peut causer des interférences, et (2) cet appareil doit accepter toute interférence, y compris celles pouvant provoquer un fonctionnement indésirable de l'appareil. Note: Modifications to this device shall not be made without the written consent of Attenti. Unauthorized modifications may void the authority granted under Federal Communication Rules and Industry Canada Rules permitting the operation of this device.

Cover Letter(s)

Attenti US, Inc. 1838 Gunn Hwy. Odessa, FL 33556 813 749 5454 Office 888 677 6278 Office 813 749 5474 Fax www.attentigroup.com July 07, 2021 Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 Confidentiality Request FCC ID: NC3-24074AVL Pursuant to Sections 0.457(d)(1)(ii) and 0.459 of the Commission’s Rules, Attenti US, Inc. hereby requests permanent confidential treatment of information accompanying this application as outlined below:  Schematics  Bill of Materials/Parts List  Block Diagrams  Operation Description  Tune Up Procedure  All unsigned TUV SUD Correspondence/Attenti Responses Attenti US, Inc. also hereby requests short-term confidential treatment of information accompanying this application as outlined below for a period of period of 180 days:  Internal Photos In addition to this product being a safety/security device, the above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. This device is to be used solely by law enforcement agencies for offender tracking & monitoring purposes and will not be available to the public. The device is sealed in a molded plastic enclosure which is not accessible to the users at any time. The Applicant understands that pursuant to Rule 0.457(d)(1)(ii), disclosure of this Application and all accompanying materials will not be made before the date of the Grant for this Application. Respectfully, FCC & ISED Contact for Attenti US, Inc. Stan DuPont |Electronics Engineer 1838 Gunn Hwy., Odessa, FL 33556, USA www.attentigroup.com

Cover Letter(s)

Attenti US, Inc. 1838 Gunn Hwy. Odessa, FL 33556 813 749 5454 Office 888 677 6278 Office 813 749 5474 Fax www.attentigroup.com July 07, 2021 TUV SUD America Inc. 10 Centennial Drive Peabody, MA 01960, USA Dear Madam or Sir, We, Attenti USA, Inc of 1838 Gunn Highway, Odessa, FL 33556, USA hereby authorize Marlene Sealey of TUV SUD America, 10040 Mesa Rim Road, San Diego, CA, 92121 to act as our agent in matters relating exclusively to the RTC FCC & IC applications for equipment authorization specified below, including the signing of documents relating these Applications:  NC3-24074AVL Requested ID for FCC Application  23669-24074AVL Requested ID for ISED Application Respectfully, FCC & ISED Contact for Attenti US, Inc. Stan DuPont |Electronics Engineer 1838 Gunn Hwy., Odessa, FL 33556, USA www.attentigroup.com

External Photos

NC3-24074AVL External Photos Applies to all 4 Models RTCAT2, RTCVZ3, RTCAV2, And RTCCS2 See Label Location on 2 nd Page

ID Label/Location Info

MODEL: RTCAT2 MODEL: RTCAV2 MODEL: RTCVZ3 MODEL: RTCCS2

Internal Photos

NC3-24074AVL Internal Photos Rev 1.0 Applies to all 4 Models RTCAT2, RTCVZ3, RTCAV2, And RTCCS2

RF Exposure Info

© 2021 RF Exposure Lab, LLC This report shall not be reproduced except in full without the written approval of RF Exposure Lab, LLC. 802 N. Twin Oaks Valley Road, Suite 105 • San Marcos, CA 92069 • U.S.A. TEL (760) 471-2100 • FAX (760) 471-2121 http://www.rfexposurelab.com CERTIFICATE OF COMPLIANCE SAR EVALUATION Attenti Group Dates of Test: June 3-11, 2021 1838 Gunn Hwy. Test Report Number: SAR.20210606 Odessa, FL 33556 This wireless mobile and/or portable device has been shown to be compliant for localized specific absorption rate (SAR) for uncontrolled environment/general exposure limits specified in ANSI/IEEE Std. C95.1-1992 and had been tested in accordance with the measurement procedures specified in IEEE 1528-2013 and IEC 62209-2:2010 (See test report). I attest to the accuracy of the data. All measurements were performed by myself or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. RF Exposure Lab, LLC certifies that no party to this application has been denied FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). Jay M. Moulton Vice President Testing Cert. # 2387.01 FCC ID: NC3-24074AVL IC Certificate: 23669-24074AVL Model(s): RTCVZ3 Test Sample: Engineering Unit Same as Production Serial No.: 36090012 Equipment Type: Tracking Phone Classification: Portable Transmitter Next to Head and Body TX Frequency Range: 699 – 716 MHz; 777 – 787 MHz; 824 – 849 MHz; 1710 – 1755 MHz; 1850 – 1910 MHz, 2412 – 2462 MHz Frequency Tolerance: ± 2.5 ppm Maximum RF Output: 750 MHz (LTE) – 24.0 dBm, 835 MHz (LTE) – 24.0 dBm, 1750 MHz (LTE) – 24.0 dBm, 1900 MHz (LTE) – 24.0 dBm, 2450 MHz (WiFi) – 18.3 dBm Conducted Signal Modulation: QPSK, 16QAM, DSSS, OFDM Antenna Type: Internal Antenna Application Type: Certification FCC Rule Parts: Part 2, 22, 24, 27 KDB Test Methodology: KDB 447498 D01 v06, KDB 941225 D05 v02r05, KDB 865664 D01 v01r04, KDB 865664 D02 v01r02, KDB 648474 D04 v01r03 Industry Canada: RSS-102 Issue 5, Safety Code 6 Max. Stand Alone SAR Value: 1.23 W/kg Reported Head; 1.50 W/kg Reported Body Max. Simultaneous SAR Value: 1.36 W/kg Reported Head; 1.58 W/kg Reported Body Separation Distance: 0 mm Report Number: SAR.20210606 © 2021 RF Exposure Lab, LLC Page 2 of 164 This report shall not be reproduced except in full without the written approval of RF Exposure Lab, LLC. Table of Contents 1. Introduction ........................................................................................................................ 4 SAR Definition [5] ................................................................................................................... 5 2. SAR Measurement Setup ................................................................................................... 6 Robotic System ...................................................................................................................... 6 System Hardware ................................................................................................................... 6 System Electronics ................................................................................................................. 7 Probe Measurement System .................................................................................................. 7 3. Definition of Reference Points ...........................................................................................15 Ear Reference Point ..............................................................................................................15 Device Reference Points .......................................................................................................15 4. Test Configuration Positions ..............................................................................................16 Positioning for Cheek/Touch [5] ............................................................................................16 Positioning for Ear / 15 ̊ Tilt [5] ..............................................................................................17 Body Worn Configurations ....................................................................................................18 5. Probe and Dipole Calibration .............................................................................................19 6. Phantom & Simulating Tissue Specifications .....................................................................20 Head & Body Simulating Mixture Characterization ................................................................20 7. ANSI/IEEE C95.1 – 1999 RF Exposure Limits [2] ..............................................................21 Uncontrolled Environment .....................................................................................................21 Controlled Environment .........................................................................................................21 8. Measurement Uncertainty .................................................................................................22 9. System Validation..............................................................................................................23 Tissue Verification .................................................................................................................23 Test System Verification ........................................................................................................23 10. LTE Document Checklist ...............................................................................................24 11. SAR Test Data Summary ..............................................................................................29 Procedures Used To Establish Test Signal ........................................................................…

Text truncated - open the document above for the full version.

Test Report

TÜV SÜD America 5610 West Sligh Ave., Suite 100 Tampa, FL 33634 Phone: 813-284-2715 www.tuv-sud-america.com TÜV SÜD Certification Exhibit FCC ID: NC3-24074AVL IC: 23669-24074AVL FCC Rule Part: 15.231 ISED Canada’s Radio Standards Specification: RSS-210 Project: 72169129 Manufacturer: Attenti US, Inc Model: 24074AVL Test Setup Photos Model: 24074AVL FCC ID: NC3-24074AVL IC: 23669-24074AVL Project: 72169129 TÜV SÜD America, Inc. Page 2 Figure 1: Radiated Emissions – Front View – Below 30 MHz – EUT Flat Model: 24074AVL FCC ID: NC3-24074AVL IC: 23669-24074AVL Project: 72169129 TÜV SÜD America, Inc. Page 3 Figure 2: Radiated Emissions – Back View – Below 30 MHz – EUT Flat Model: 24074AVL FCC ID: NC3-24074AVL IC: 23669-24074AVL Project: 72169129 TÜV SÜD America, Inc. Page 4 Figure 3: Radiated Emissions – Front View – 30 MHz - 1 GHz – EUT Flat Model: 24074AVL FCC ID: NC3-24074AVL IC: 23669-24074AVL Project: 72169129 TÜV SÜD America, Inc. Page 5 Figure 4: Radiated Emissions – Back View – 30 MHz – 1 GHz – EUT Flat Model: 24074AVL FCC ID: NC3-24074AVL IC: 23669-24074AVL Project: 72169129 TÜV SÜD America, Inc. Page 6 Figure 5: Radiated Emissions – Front View – Above 1 GHz – EUT Flat Model: 24074AVL FCC ID: NC3-24074AVL IC: 23669-24074AVL Project: 72169129 TÜV SÜD America, Inc. Page 7 Figure 6: Radiated Emissions – Back View – Above 1 GHz – EUT Flat Model: 24074AVL FCC ID: NC3-24074AVL IC: 23669-24074AVL Project: 72169129 TÜV SÜD America, Inc. Page 8 Figure 7: Radiated Emissions – Front View – Below 30 MHz – EUT on Side Model: 24074AVL FCC ID: NC3-24074AVL IC: 23669-24074AVL Project: 72169129 TÜV SÜD America, Inc. Page 9 Figure 8: Radiated Emissions – Back View – Below 30 MHz – EUT on Side Model: 24074AVL FCC ID: NC3-24074AVL IC: 23669-24074AVL Project: 72169129 TÜV SÜD America, Inc. Page 10 Figure 9: Radiated Emissions – Front View – 30 MHz - 1 GHz – EUT on Side Model: 24074AVL FCC ID: NC3-24074AVL IC: 23669-24074AVL Project: 72169129 TÜV SÜD America, Inc. Page 11 Figure 10: Radiated Emissions – Back View – 30 MHz – 1 GHz – EUT on Side Model: 24074AVL FCC ID: NC3-24074AVL IC: 23669-24074AVL Project: 72169129 TÜV SÜD America, Inc. Page 12 Figure 11: Radiated Emissions – Front View – Above 1 GHz – EUT on Side Model: 24074AVL FCC ID: NC3-24074AVL IC: 23669-24074AVL Project: 72169129 TÜV SÜD America, Inc. Page 13 Figure 12: Radiated Emissions – Back View – Above 1 GHz – EUT on Side Model: 24074AVL FCC ID: NC3-24074AVL IC: 23669-24074AVL Project: 72169129 TÜV SÜD America, Inc. Page 14 Figure 13: Radiated Emissions – Front View – Below 30 MHz – EUT Upright Model: 24074AVL FCC ID: NC3-24074AVL IC: 23669-24074AVL Project: 72169129 TÜV SÜD America, Inc. Page 15 Figure 14: Radiated Emissions – Back View – Below 30 MHz – EUT Upright Model: 24074AVL FCC ID: NC3-24074AVL IC: 23669-24074AVL Project: 72169129 TÜV SÜD America, Inc. Page 16 Figure 15: Radiated Emissions – Front View – 30 MHz - 1 GHz – EUT Upright Model: 24074AVL FCC ID: NC3-24074AVL IC: 23669-24074AVL Project: 72169129 TÜV SÜD America, Inc. Page 17 Figure 16: Radiated Emissions – Back View – 30 MHz – 1 GHz – EUT Upright Model: 24074AVL FCC ID: NC3-24074AVL IC: 23669-24074AVL Project: 72169129 TÜV SÜD America, Inc. Page 18 Figure 17: Radiated Emissions – Front View – Above 1 GHz – EUT Upright Model: 24074AVL FCC ID: NC3-24074AVL IC: 23669-24074AVL Project: 72169129 TÜV SÜD America, Inc. Page 19 Figure 18: Radiated Emissions – Back View – Above 1 GHz – EUT Upright Model: 24074AVL FCC ID: NC3-24074AVL IC: 23669-24074AVL Project: 72169129 TÜV SÜD America, Inc. Page 20 Figure 19: RF Conducted Emissions Model: 24074AVL FCC ID: NC3-24074AVL IC: 23669-24074AVL Project: 72169129 TÜV SÜD America, Inc. Page 21 Figure 20: Power Line Conducted Emissions – Front View Model: 24074AVL FCC ID: NC3-24074AVL IC: 23669-24074AVL Project: 72169129 TÜV SÜD America, Inc. Page 22 Figure 21: Power Line Conducted Emissions – Rear View

Test Setup Photos
