NC3BEACON-100Beacon-100

Tracker100 andBeacon100 Installation andOperationGuide January2022 2|InstallationandOperationGuide:attentifusionTracker100andBeacon100 Version Comments Author Date 1.0 Initialreleaseversion. SteveGraniewitz 04January2022 Informationinthisdocumentationissubjecttochangewithoutnoticeanddoesnotrepresentacommitmenton part of Attenti Electronic Monitoring. The software described in this document is subject to the license agreement that is included with the product, which specifies the permitted and prohibited uses of the product. Any unauthorized duplication or use of this documentation, in whole or in part, in print, or in any other storage or retrieval system is prohibited. No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language in any form by any means for any purpose other than the purchaser’s personal use without the permission of Attenti Electronic Monitoring. © 1995-2022AttentiElectronicMonitoring.Allrightsreserved. Unlessotherwisenoted,allnamesofcompanies,products,streetaddresses,andpersonscontained hereinarepartof a completely fictitious scenario and are designed solely to document the use of an Attenti Electronic Monitoringproduct. ContactInfo: CorporateHeadquarters: Attenti Electronic Monitoring, 2 Ha-Barzel St., P.O. Box 13236, 61132 Tel Aviv, Israel. T:+972-3-7671800//F:+972-3-7671801//U.S.ACustomers,call1-800-313-1483 Visitusat:attentigroup.com InstallationandOperationGuide:attentifusionTracker100andBeacon100|3 WARNING Avoidplacingadevicenexttoanimplantedelectronicdevice(e.g.,don’tcarrythedeviceinashirtorjacketpocketdirectlynear an implanted device). Toreducethe risksassociatedwithfireor explosion:  Donotintentionallyopenor damagethedevice.  Ensurestoragetemperatureofdeviceiswithintherangeasspecifiedindevicemanual.  Donotattempttoaccessorreplacebattery.Batteryisnotuser- replaceable.ThedeviceshallbeopenedbyAttentiauthorized service only.  Donotusedeviceoutsideofthespecifiedoperationtemperaturerange. WARNING Toreducethe risks associatedwithhazardous voltage:  Donotmodify,decorate,orattempttoservicethedevice.ReturntoAttentiauthorizedpersonnelorlocationforrepairorservice. There are no user serviceable parts.  If thedeviceorpowercordbecomesdamaged, contacttheagencyrepresentative fromwhichyou aremonitored. SafetyInformation Pleaseread,understand,andfollowallsafetyinformationcontainedintheseinstructionspriortotheuseofthisAttentiElectronicMonitoringdevice. Retain these instructions for future reference. IntendedUse ThisAttentiElectronicMonitoringdeviceispartofanelectronicmonitoringsystem,whichperformsdatatransferusingcellularnetworktoamonitoring platform.Thisdevicehasnotbeentestedforandisnotintendedforuseonairplanes,inhazardousenvironments,inhealthcarefacilities, or where cellular phones or other intentional transmitters are restricted. ThefunctionaloperatingtemperatureoftheTracker100is-20°Cto+55°C.TheoperatingtemperatureoftheBeacon100is-20°Cto+55°C.Thestorage temperature of the Tracker 100is -40°C to +70°C. The storage temperature of the Beacon 100 is -40°Cto+70°C. ExplanationofSignalWord Consequences WARNING Indicatesahazardoussituationwhich, ifnotavoided, couldresultinseriousinjuryordeath. CAUTION Indicatesahazardoussituationwhich,ifnotavoided,couldresultinminorormoderateinjuryand/orpropertydamag e. NOTICE: Indicatesasituationwhich,ifnot avoided,couldresultinpropertydamage. Safetyinformationfor:  Rechargeablehand-held/wearabledevices  Non-rechargeable hand-held/wearable devices  Cradles/receivers/base units 4|InstallationandOperationGuide:attentifusionTracker100andBeacon100 WARNING Toreducethe risks associatedwithhazardous voltage:         Donot modifyAC/DCpower adapter plug. Donotforcethepowerplugintoanoutletwhereitdoesnotfit. UseonlyanAttentiprovidedAC/DCpoweradaptertorechargeorpowerthedevice.Useonl yaSafetycertifiedLPSAC/DCplug-inadapter withoutputrating5VDC,2A.DonotunplugAC/DCadapterbypowercord.Handletheadapt erbythebodyonly. Donotattempt tocharge the deviceusinganoutdooroutlet.Onlyuse the AC/DCadapterindoors. Donotexposepoweradaptertorain,steamorwetconditions. Donotsubmergethedevice,orholdthedeviceunderrunningwater,whileitischarging. CAUTION Toreduce the risks associatedwithhot surfaces:  Donottouchthermalpadsondeviceorchargerifchargingisinterrupted.  Inambienttemperaturesof40°C,thewearabledevice’stouch-temperaturemayreach43°C.  Donotchargethedeviceintemperaturesabove45°C. WARNING Toreducethe risksassociatedwithfireor explosion:  Donot enter areas with potentially explosive atmosphere. Potentially explosive areas are often, but not always, clearlymarked. Safetyinformationfor:  Rechargeablehand-held/wearabledevices  Cradles/receivers/base units Safetyinformationonly for:  RechargeableHand-held/wearableDevices  Non-rechargeable Hand-held/wearableDevices NOTICE:  Only authorizedpersonnelcanturnofforremovethedevice. InstallationandOperationGuide:attentifusionTracker100andBeacon100|5 WARNING Toreducetherisks associatedwithhazardousvoltage:  Donotsubmergethedeviceorholdthedeviceunderrunningwater. Safetyinformationonly for:  Cradles/receivers/baseunits WEEE ThissymbolaccordingtotheEuropeanDirectiveindicatesthattheWasteofElectricalandElectronicEquipment(WEEE)mustn ot bedisposedofasunsortedmunicipal wasteandmustbecollectedseparately.Pleasecontactan authorizedrepresentativeofthemanufactureroranauthorizedwastemanagement companyfor informationconcerningthedecommissioning of your equipment. CAUTION  Avoidinstallingtheelectronicmonitoringdeviceinthepresenceofulcers,openwounds,blisters,swellingorskininfectionover the expected area of contact with the electronic monitoring device.  Iftheuserreportspain,numbnessorothersymptomovertheexpectedareaofcontactwiththeelectronicmonitoringdevice, a medical opinion is recommended prior to installation.  Iftheuserreportsconcernsaboutanunderlyingmedicalconditionthatcouldbeexacerbatedbyuseoftheelectronicmonitor ing device, a medical opinion is …

Text truncated - open the document above for the full version.

DATE : 2024-01-10 Federal Communications Commission Authorization & Evaluation Division 7345 Oakland Mills Road Columbia, Maryland 21046 Authority to Act as Agent On our behalf, I appoint Jason Wu of Global United Te chnology Services Co., Ltd.and No. 123-128, Tower A, Jinyuan Business Build ing, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China to act as our agent in the p reparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is s ought. I also certify that each unit manufactured, imported or marketed, as defined in the F ederal Communications Commission's regulations will have affixed to it a label identical to t hat submitted for approval with this application. F or instances where our authorized agent signs the application for certification on our b ehalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, still resides with Allied Universal Electronic Monitoring US, Inc. and 1838 Gunn Hi ghway, Odessa, Florida 33556, United States Signatur�Sllfi-- Name: Daniel Williamson Title: Electronics/RF Engineer Tech Company: Allied Universal Electronic Monitoring US, Inc.

Allied Universal Electronic Monitoring US, Inc. DATE : 2024-01-10 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: NC3BEACON-100 Product Name: Beacon-100 Request for Confidentiality To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Operational Description In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); External Photos Test Setup Photos Internal Photos User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuantto KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Signature: Name: Daniel Williamson Title: Electronics/RF Engineer Tech Company: Allied Universal Electronic Monitoring US, Inc.

Page 1 of 3 Test Model No.: BCN‐100‐0‐9‐00 Page 2 of 3 Page 3 of 3

ADHESIVE OPPOSITE OF PRINT SIDE 64.60 19.50 R2.70 TYP R1.20 x2 R8.95 QR CODE YYYYYYYYYYY=Country Of Origin FONT:Centry Gothic Regular 6 TYP. MATERIAL: GLOSS WHITE POLYESTER - 518 ADHESIVE: PERMANENT - ACRYLIC BASED please notice: QR code content : - 1st line : S/N - 2nd line : Top P/N and revison For QR content and S/N format, Refer to Attenti SI-075 Document ! REVISIONS ECOREV.DESCRIPTIONDATEAPPROVED 010271A00Initial Release11/19/2023Andrew Moonin D C B A A B C D 1 2 3 4 5 6 7 8 8 7 6 5 4 3 2 1 DIMENSIONS ARE IN MILLIMETERS THIS DOCUMENT IS COPYRIGHTED PROPERTY OF ATTENTI COMPANY AND MAY NOT BE REPRODUCED WITHOUT ATTENTI WRITTEN PERMISSION OR USED OR DISCLOSED FOR OTHER THAN ATTENTI AUTHORIZED PURPOSES. TOLERANCES (UNLESS OTHERWISE SPECIFIED) 0.5 TO 6 0.1 > 6 TO 30 0.2 > 30 TO 120 0.3 >120 TO 400 0.5 ANGULAR: .5 REVISION ITEM NUMBER (PARTS LIST) INSPECTION DIMENSION CORRESPONDING NOTE SYMBOL KEY: PROJECTION: A00 42110382 PART. NO. INPERPRET PER ASME Y14.5M-1994 SHEET 1 OF 1 WEIGHT (gr): REV DOC. NO. A3 SIZE TITLE: NAMEDATE CHECKED DRAWN SEE NOTES FINISH MATERIAL Beacon Housing Label Andrew Moonin 11/19/2023 SCALE 42110382 2:1 Andrew Moonin11/19/2023 Released

Label location

Page 1 of 2 Test Model No.: BCN‐100‐0‐9‐00 Page 2 of 2

FCC ID: NC3BEACON-100 RF Exposure evaluation According to 447498 D04 Interim General RF Exposure Guidance v01 eirp = pt x gt = (EXd) 2 /30 where: pt = transmitter output power in watts, gt = numeric gain of the transmitting antenna (unitless), E = electric field strength in V/m, --- 10 ((dBuV/m)/20) /10 6 d = measurement distance in meters (m)---3m Sopt = (EXd) 2 /30 x gt Frequency(MHz) Field Strength (dBuv/m) antenna gain(dBi) numeric gain calc. Pt (mW) erp(mW) limit (mW) min. distance (cm) 915 90.54 1.7 1.48 0.34 0.31 8.13 0.50 WORSE CASE 0.31mW<8.13mW Then SAR evaluation is not required

Product Specification A10340H-PS-1.0 Page 1 Antennas for Wireless Applications 1. Features  GSM/UMTS antenna supporting up to five frequency bands  High efficiency  Easy to Integrate  Intended for SMD mounting  Supplied in Tape and reel Calvus support the following communication standards: 2. Description Calvus uses a ground plane to radiate efficiently, but the ground plane must not be present underneath the antenna itself. The antenna uses a matching circuit to achieve optimized results for the specific frequency bands that are required. This product specification shows the performance of the antenna when optimized to cover a typical penta-band reception: GSM850/900/1800/1900 and WCDMA. If the antenna is used for fewer than five bands, higher efficiencies are possible. 3. Applications  Femto / Pico base stations  Vehicle tracking  Machine to machine communication  Remote monitoring  Remote security  Vending machines Calvus Penta-band SMD Antenna Part No. A10340H gigaNOVA ® Product Specification Product Specification A10340H-PS-1. Antennas for Wireless Applications tennas for Wireless Applications 4. Part Number Calvus: A10340H 5. General Data Product name Calvus Part Number A10340H Frequency 824 – 960MHz 1710 – 2170 MHz Polarization Linear Operating temperature -40°C to140°C Environmental condition test ISO 16750-4.5.1.1.1/5.1.2.1/5.3.2 Impedance with matching 50 Ω Weight 2.0 g Antenna type SMD Dimensions 27.0 x 8.0 x 3.2 (mm) Minimum Distance to GND ≥ 5.6mm Calvus Part No. A10340H Antennas for Wireless Applications Antennas for Wireless Applications Product Specification A10340H-PS-1.0 Page 3 6. RF Characteristics 824 – 960 MHz 1710 - 2170 MHz Peak gain 1.70dBi 3.0dBi Average gain (Linear) -1.80dBi -1.60dBi Average efficiency >65% >65% Maximum return loss -6dB -6dB Maximum VSWR 3.2:1 3.0:1 All data measured on Antenova’s evaluation PCB Part No. A10340H-EVB-1 Calvus Part No. A10340H Antennas for Wireless Applications Antennas for Wireless Applications Product Specification A10340H-PS-1.0 Page 4 7. RF Performance 7.1 Return Loss 7.2 VSWR Calvus Part No. A10340H Antennas for Wireless Applications Antennas for Wireless Applications Product Specification A10340H-PS-1.0 Page 5 7.3 Antenna pattern 7.3.1 824 MHz – 960 MHz 3D pattern at 880 MHz Drag to rotate pattern and PCB by using Adobe Reader (Click to Activate) Calvus Part No. A10340H Antennas for Wireless Applications Antennas for Wireless Applications Product Specification A10340H-PS-1.0 Page 6 7.3.2 1710 MHz – 2170 MHz 3D pattern at 1930 MHz Drag to rotate pattern and PCB by using Adobe Reader (Click to Activate) Calvus Part No. A10340H Antennas for Wireless Applications Antennas for Wireless Applications Product Specification A10340H-PS-1.0 Page 7 8. Antenna Dimensions Top side Bottom Side All Dimensions in (mm) Calvus Part No. A10340H Antennas for Wireless Applications Antennas for Wireless Applications Product Specification A10340H-PS-1.0 Page 8 9. Schematic symbol and Pin definition The circuit symbol for the antenna is shown below. The antenna has five pins with only two as functional. All other pins are for mechanical strength. 10. Antenna footprint The recommended host PCB footprint is below. 4 copper pads all 1.5 x 1.5 (mm) 1 copper pad (feed) 2.5 x 1.0 (mm) Pin Description 1 Feed 2,3,4,5 Not used (Mechanical only) Calvus Part No. A10340H Antennas for Wireless Applications Antennas for Wireless Applications Product Specification A10340H-PS-1.0 Page 9 11. Electrical Interface 11.1 Transmission Line All transmission lines should be designed to have a characteristic impedance of 50Ω. • The length of the transmission lines should be kept to a minimum • Any other parts of the RF system like transceivers, power amplifiers, etc, should also be designed to have an impedance of 50 Ω Once the material for the PCB has been chosen (PCB thickness and dielectric constant), a coplanar transmission line can easily be designed using any of the commercial software packages for transmission line design. For the chosen PCB thickness, copper thickness and substrate dielectric constant, the program will calculate the appropriate transmission line width and gaps on either side of the track so the characteristic impedance of the co-planar transmission is 50 Ω. 11.2 Matching Circuit The antenna requires a matching circuit that must be optimized for each product. The matching circuit will require up to six components and the following circuit should be designed into the host PCB. Not all components may be required but should be included as a precaution. The matching network must be placed close to the antenna feed to ensure it is more effective in tuning the antenna. Calvus Part No. A10340H Antennas for Wireless Applications Antennas for Wireless Applications Product Specification A10340H-PS-1.0 Page 10 12. Antenna Integration Guide 12.1 Antenna Placement Calvus should be fitted to the device so that power from the antenna can radiate into free space. Antenova recommends fitting the antenna close to the corner of the PCB with few components or metal objects nearby. Ground can be placed at the side of the antenna closest to the feed, and it is recommended that any ground either side of the antenna should be at least 15mm away. The area directly above and below should be free from components or conducting objects. Antenova offers a full range of development support to ensure efficient implementation of the antenna into the specific design. To overcome RF design issues, matching circuits, transmission lines, layout and other components, please contact Antenova ([email protected]) for design and placement recommendations. Two recommended configurations are shown below, but other layouts are possible. In both the distance to the antenna from the GND plane is 5.6mm. Recommended PCB layouts: antenna mounted straight (left) and at 45 degrees (right). Calvus Part No. A10340H Antennas for Wireless Applications Antennas for Wireless Applications Produc…

Text truncated - open the document above for the full version.

Global United Technology Services Co., Ltd. Report No.: GTS2023120253F01 Authorized Signature: Robinson Luo Laboratory Manager This results shown in this test report refer only to the sample(s) tested, this test report cannot be reproduced, except in full, without prior written permission of the company. The report would be invalid without specific stamp of test institute and the signatures of compiler and approver. Page 1 of 21 TEST REPORT Applicant: Allied Universal Electronic Monitoring US, Inc. Address of Applicant: 1838 Gunn Highway, Odessa, Florida 33556, United States Manufacturer: Allied Universal Electronic Monitoring US, Inc. Address of Manufacturer: 1838 Gunn Highway, Odessa, Florida 33556, United States Equipment Under Test (EUT) Product Name: Beacon-100 Model No.: BCN-100-0-9-00 FCC ID: NC3BEACON-100 Applicable standards: FCC CFR Title 47 Part 15 Subpart C Section 15.249 Date of sample receipt: December 21, 2023 Date of Test: December 22, 2023-January 10, 2024 Date of report issued: January 10, 2024 Test Result : PASS * * In the configuration tested, the EUT complied with the standards specified above. Report No.: GTS2023120253F01 Page 2 of 21 2 Version Version No. Date Description 00 January 10, 2024 Original Prepared By: Date: January 10, 2024 Project Engineer Check By: Date: January 10, 2024 Reviewer Report No.: GTS2023120253F01 Page 3 of 21 3 Contents Page 1 COVER PAGE ............................................................................................................................................ 1 2 VERSION .................................................................................................................................................. 2 3 CONTENTS .............................................................................................................................................. 3 4 TEST SUMMARY ..................................................................................................................................... 4 4.1 MEASUREMENT UNCERTAINTY ............................................................................................................ 4 5 GENERAL INFORMATION ...................................................................................................................... 5 5.1 GENERAL DESCRIPTION OF EUT ......................................................................................................... 5 5.2 TEST MODE ........................................................................................................................................ 6 5.3 DESCRIPTION OF SUPPORT UNITS ....................................................................................................... 6 5.4 DEVIATION FROM STANDARDS ............................................................................................................. 6 5.5 ABNORMALITIES FROM STANDARD CONDITIONS ................................................................................... 6 5.6 TEST FACILITY .................................................................................................................................... 6 5.7 TEST LOCATION ................................................................................................................................. 6 5.8 ADDITIONAL INSTRUCTIONS ................................................................................................................. 6 6 TEST INSTRUMENTS LIST ..................................................................................................................... 7 7 TEST RESULTS AND MEASUREMENT DATA ...................................................................................... 9 7.1 ANTENNA REQUIREMENT ..................................................................................................................... 9 7.2 CONDUCTED EMISSIONS ................................................................................................................... 10 7.3 RADIATED EMISSION METHOD ........................................................................................................... 13 7.3.1 Field Strength of The Fundamental Signal ................................................................................ 15 7.3.2 Spurious emissions and Band Edge .......................................................................................... 16 7.4 20DB OCCUPY BANDWIDTH .............................................................................................................. 20 8 TEST SETUP PHOTO ............................................................................................................................ 21 9 EUT CONSTRUCTIONAL DETAILS ..................................................................................................... 21 Report No.: GTS2023120253F01 Page 4 of 21 4 Test Summary Test Item Section in CFR 47 Result Antenna requirement 15.203 Pass AC Power Line Conducted Emission 15.207 Pass Field strength of the fundamental signal 15.249 (a) Pass Spurious emissions 15.249 (a) (d)/15.209 Pass Band edge 15.249 (d)/15.205 Pass 20dB Occupied Bandwidth 15.215 (c) Pass Remarks: 1. Test according to ANSI C63.10: 2013. 2. Pass: The EUT complies with the essential requirements in the standard. 3. N/A: Not applicable. 4.1 Measurement Uncertainty Test Item Frequency Range Measurement Uncertainty Notes Radiated Emission 30MHz-200MHz 3.8039dB (1) Radiated Emission 200MHz-1GHz 3.9679dB (1) Radiated Emission 1GHz-18GHz 4.29dB (1) Radiated Emission 18GHz-40GHz 3.30dB (1) AC Power Line Conducted Emission 0.15MHz ~ 30MHz 3.44dB (1) Note (1): The measurement uncertainty is for coverage factor of k=2 and a level of confidence of 95%. Report No.: GTS2023120253F01 Page 5 of 21 5 General Information 5.1 General Description of EUT Product Name: Beacon-100 Model No.: BCN-100-0-9-00 Serial No.: BCN1009A04200226230019 Test sample(s) ID: GTS2023120253-1 Sample(s) Status Engineered sample Operation Fre…

Text truncated - open the document above for the full version.

Page 1 of 2 Test Model No.: BCN‐100‐0‐9‐00 Radiated Emission Page 2 of 2 Conducted Emission
