NCG-MS180DMotion Detector

5015 B.U. Bowman Drive Buford, GA 30518 USA Voice: 770-831-8048 Fax: 770-831-8598 Certification Exhibit FCC ID: NCG-MS180D FCC Rule Part: 15.245 ACS Project Number: 11-0249 Manufacturer: Cooper Lighting, LLC Manual Instruction Manual/Instrucciones Questions?/¿Preguntas? 1-800-334-6871 [email protected] 1 CAUTION • Connect fixture to a 120 volt, 60 Hz power source. Any other connection voids the warranty. • Fixture must be mounted to a grounded recessed junction box marked for use in wet locations. • Suitable for wall mount or eave mount only. NOT suitable for ground mount installation. • Do not allow sensor head to touch light housing – maintain at least 1 inch space between fixture and sensor. • Keep away from flammable objects. Do not position fixture within 2 inches of any combustible materials. • For proper operation and protection against damage, the motion sensor head adjustment knobs must be facing the ground. • MINIMUM 90° C SUPPLY CONDUCTORS. • Do not use this apparatus near water. • Clean only with a dry cloth. • Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. • Do not install near any heat sources such as radiators, heat registers, stoves or other apparatus (including amplifiers) that produce heat. • Only use attachments/accessories specified by the manufacturer. • This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Under Part 15 of the FCC Rules, any changes or modifications to the motion detector described in this instruction sheet that are not expressly approved by Cooper Lighting, LLC could void the user’s authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. WARNING: FCC Regulations state that any unauthorized changes or modifications to this equipment not expressly approved by the manufacturer could void the user’s authorization to operate this equipment. PACKAGING CONTENTS/CONTENIDO DEL PAQUETE ITEMS REQUIRED (Purchase separately) • Phillips screwdriver • Outdoor weatherproof silicone caulking • (2) 100 watt (MAX) PAR 38 floodlight bulbs NOTE: This fixture was designed to work with up to 150 watt maximum PAR halogen flood bulbs. For improved energy efficiency, lower wattage PAR halogen flood bulbs may be used. Compact Fluorescent (CFL) bulbs contain electronics which may interfere with the motion sensing function of your fixture and are not recommended. To meet ENERGY STAR ® requirements, maximum total lamp wattage can not exceed 250 watts. HOW IT WORKS PIR does a good job of detecting lateral motion across the 180° range of detection. Precision Plus Doppler Radar™ does an excellent job detecting motion towards and away from the unit. Both systems combined provide enhanced accuracy and complete coverage within the detection range. Motion from any direction will trigger your floodlight—even during hot or cold temperature extremes. IMPORTANT SAFETY INSTRUCTIONS When using product, basic precautions should always be followed, including the following: • Read and follow these instructions. • Heed all warnings, including below warnings AND those included on product. • Save these instructions and warnings. • For outdoor use only. • cETLus LISTED for wet location. • Suitable for wall mount or eave mount only. NOT suitable for ground mount installation. • Disassembling your fixture will void the warranty. • Your fixture is prewired and preassembled for easy installation. • Bulb gets HOT quickly! • The bulb and fixture get extremely hot during use. Disconnect power and allow fixture to cool before changing bulb or handling fixture. • Fixture should be installed by persons with experience in household wiring or by a qualified electrician. The electrical system, and the method of electrically connecting the fixture to it, must be in accordance with the National Electrical Code and local building codes. • Always replace bulb with the same wattage or lower wattage than marked. Installing a bulb of a higher wattage could create a fire hazard. Use of a higher wattage bulb will void the warranty. (Maximum 150 watt PAR halogen bulb.) CMS185D (Bronze) CMS185DW (White) A. Motion detector and light fixture Detector de movimiento y artefacto de luz ENGLISH Up to 70 feet 180 degrees D. (2) #6 and (2) #8 mounting screws (use the size that fits your junction box) (2) Tornillos #6 y (2) tornillos #8 de montaje (utilice el tamaño que mejor se adecue a su caja de conexión) B. Coverplate gasket Junta de la placa de cubierta E. (3) Wire nuts (3) Conectores de cable C. (2) Lampholder gaskets (2) Juntas obturadoras del receptáculo F. Color-matched center hole plug Tapón para agujero central de color coincidente G. Mounting plate screw Tornillo para la placa de montaje H. Moun…

Text truncated - open the document above for the full version.

Customer First Center 1121 Highway 74 South Peachtree City, GA 30269 Main Number: 770-486-4800 July 25, 2011 Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 Dear Sir or Madam: I hereby appoint Sam Wismer at Advanced Compliance Solutions, Inc. to act as our agent in the preparation of an application for equipment authorization of FCC ID: NCG-MS180D to the FCC Rules and Regulations. I certify that all exhibits contained within this filing properly describe the device or system for which authorization is sought. I further certify that appropriate arrangements have been made to assure that production units of this equipment bearing the name and FCC IDENTIFIER listed in this application will continue to comply with the Commission's requirements. I further certify by signature below that no party (per 47 CFR 1.2002(b)) to the application is subject to a denial of Federal benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). This appointment also includes the authority to complete FCC Form 731 on our behalf and sign the application as an authorized agent. Sincerely, Name: Scott Formel Title: Engineering Director

Advanced Compliance Solutions – 5015 B.U. Bowman Drive, Buford, GA 30518 Phone: (770) 831-8048 Fax: (770) 831-8598 August 10, 2011 Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 Gentlemen: Cooper Lighting, LLC respectfully requests confidentiality of certain materials provided with the submission of the MS180D and its model variants under FCC ID: NCG-MS180D in accordance with FCC Regulations 0.459. The confidentiality request applies to the following exhibits: 11-0249 – Schematics.pdf 11-0249 – System Block Diagram.pdf 11-0249 – Theory of Operation.pdf The MS180D series has been developed at considerable effort and expense by Cooper Lighting, LLC. These items are considered as Trade Secrets and therefore public access to the proprietary material could possibly result in duplication of equipment that could severely damage the company’s business advantage. I appreciate your assistance in this matter. Sincerely, Sam Wismer Vice President, Technology Agent

5015 B. U. Bowman Dr. Buford, GA 30518 August 15, 2011 ACS TCB 5015 B.U. Bowman Drive Buford, GA 30518 Re: FCC ID: NCG-MS180D To Whom It May Concern: The following application is submitted on behalf of our client, Cooper Lighting, LLC, for evaluation of FCC ID: NCG-MS180D for certification under FCC Part 15.245. FCC ID: NCG-MS180D is a motion detecting sensor head that is to be installed in conjunction with an outdoor light. The models listed in this filing are electrically identical and differ only in the lighting option / load and device color. FCC ID: NCG-MS180D was tested to the above referenced standards and found to be in compliance. Sincerely, Sam Wismer Vice President, Technology Advanced Compliance Solutions, Inc.

5015 B.U. Bowman Drive Buford, GA 30518 USA Voice: 770-831-8048 Fax: 770-831-8598 Certification Exhibit FCC ID: NCG-MS180D FCC Rule Part: 15.245 ACS Project Number: 11-0249 Manufacturer: Cooper Lighting, LLC External Photos FCC ID: NCG-MS180D ACS Project: 11-0249 Advanced Compliance Solutions Page 2 Figure 1: Bottom FCC ID: NCG-MS180D ACS Project: 11-0249 Advanced Compliance Solutions Page 3 Figure 2: Bottom FCC ID: NCG-MS180D ACS Project: 11-0249 Advanced Compliance Solutions Page 4 Figure 3: Front and Top FCC ID: NCG-MS180D ACS Project: 11-0249 Advanced Compliance Solutions Page 5 Figure 4: Front and Side

5015 B.U. Bowman Drive Buford, GA 30518 USA Voice: 770-831-8048 Fax: 770-831-8598 Certification Exhibit FCC ID: NCG-MS180D FCC Rule Part: 15.245 ACS Project Number: 11-0249 Manufacturer: Cooper Lighting, LLC Label Information FCC ID: NCG-MS180D ACS Project: 11-0249 Advanced Compliance Solutions Page 2 Figure 1: Label Location FCC ID: NCG-MS180D ACS Project: 11-0249 Advanced Compliance Solutions Page 3 Figure 2: Sample Label for Model: MS-180DW FCC ID: NCG-MS180D ACS Project: 11-0249 Advanced Compliance Solutions Page 4 Figure 3: Sample Label for Model: MS-185D FCC ID: NCG-MS180D ACS Project: 11-0249 Advanced Compliance Solutions Page 5 Figure 4: Sample Label for Model: MS-185DW FCC ID: NCG-MS180D ACS Project: 11-0249 Advanced Compliance Solutions Page 6 Figure 5: Sample Label for Model: MS-187D FCC ID: NCG-MS180D ACS Project: 11-0249 Advanced Compliance Solutions Page 7 Figure 6: Sample Label for Model: MS-187DW FCC ID: NCG-MS180D ACS Project: 11-0249 Advanced Compliance Solutions Page 8 Figure 7: Sample Label for Model: MS-180D

5015 B.U. Bowman Drive Buford, GA 30518 USA Voice: 770-831-8048 Fax: 770-831-8598 Certification Exhibit FCC ID: NCG-MS180D FCC Rule Part: 15.245 ACS Project Number: 11-0249 Manufacturer: Cooper Lighting, LLC Internal Photos FCC ID: NCG-MS180D ACS Project: 11-0249 Advanced Compliance Solutions Page 2 Figure 1: Internal Photos - Assembled FCC ID: NCG-MS180D ACS Project: 11-0249 Advanced Compliance Solutions Page 3 Figure 2: Internal Photos - Assembled FCC ID: NCG-MS180D ACS Project: 11-0249 Advanced Compliance Solutions Page 4 Figure 3: Internal Photos FCC ID: NCG-MS180D ACS Project: 11-0249 Advanced Compliance Solutions Page 5 Figure 4: Internal Photos FCC ID: NCG-MS180D ACS Project: 11-0249 Advanced Compliance Solutions Page 6 Figure 5: Internal Photos FCC ID: NCG-MS180D ACS Project: 11-0249 Advanced Compliance Solutions Page 7 Figure 6: Internal Photos FCC ID: NCG-MS180D ACS Project: 11-0249 Advanced Compliance Solutions Page 8 Figure 7: Internal Photos FCC ID: NCG-MS180D ACS Project: 11-0249 Advanced Compliance Solutions Page 9 Figure 8: Internal Photos FCC ID: NCG-MS180D ACS Project: 11-0249 Advanced Compliance Solutions Page 10 Figure 9: Internal Photos

5015 B.U. Bowman Drive Buford, GA 30518 USA Voice: 770-831-8048 Fax: 770-831-8598 Certification Test Report FCC ID: NCG-MS180D FCC Rule Part: 15.245 ACS Report Number: 11-0249.W03.11.A Manufacturer: Cooper Lighting, LLC Test Begin Date: July 5, 2011 Test End Date: July 10, 2011 Report Issue Date: July 12, 2011 FOR THE SCOPE OF ACCREDITATION UNDER LAB Code 200612-0 This report must not be used by the client to claim product certification, approval, or endorsement by NVLAP, NIST, or any agency of the Federal Government. Reviewed by: Kirby Munroe Director, Wireless Certifications ACS, Inc. This test report shall not be reproduced except in full. This report may be reproduced in part with prior written consent of ACS, Inc. The results contained in this report are representative of the sample(s) submitted for evaluation. This report contains 17 pages 5015 B.U. Bowman Drive Buford, GA 30518 USA Voice: 770-831-8048 Fax: 770-831-8598 TABLE OF CONTENTS 1 GENERAL ............................................................................................................................................ 3 1.1 PURPOSE .......................................................................................................................................... 3 1.2 GENERAL ......................................................................................................................................... 3 1.3 TEST METHODOLOGY AND CONSIDERATIONS ................................................................................. 3 2 TEST FACILITIES .............................................................................................................................. 4 2.1 LOCATION ....................................................................................................................................... 4 2.2 LABORATORY ACCREDITATIONS/RECOGNITIONS/CERTIFICATIONS (ACS) ..................................... 4 2.3 RADIATED EMISSIONS TEST SITE DESCRIPTION (ACS) ................................................................... 5 2.3.1 Semi-Anechoic Chamber Test Site .......................................................................................... 5 2.3.2 Open Area Tests Site (OATS) ................................................................................................. 6 2.4 CONDUCTED EMISSIONS TEST SITE DESCRIPTION (ACS) ................................................................ 7 3 APPLICABLE STANDARD REFERENCES .................................................................................... 7 4 LIST OF TEST EQUIPMENT ............................................................................................................ 8 5 SUPPORT EQUIPMENT .................................................................................................................... 9 6 EQUIPMENT UNDER TEST SETUP BLOCK DIAGRAM ........................................................... 9 7 SUMMARY OF TESTS ..................................................................................................................... 10 7.1 ANTENNA REQUIREMENT – FCC: SECTION 15.203 ....................................................................... 10 7.2 POWER LINE CONDUCTED EMISSIONS – FCC: SECTION 15.207 IC: RSS-GEN 7.2.4 ...................... 10 7.2.1 Measurement Procedure ....................................................................................................... 10 7.2.2 Measurement Results ............................................................................................................ 10 7.3 20DB / 99% BANDWIDTH – FCC: SECTION 15.215, IC: RSS-GEN 4.6.1 ........................................ 12 7.3.1 Measurement Procedure ....................................................................................................... 12 7.3.2 Measurement Results ............................................................................................................ 12 7.4 FUNDAMENTAL FIELD STRENGTH – FCC: SECTION 15.245(B) IC: RSS-210 ANNEX 7 .................. 14 7.4.1 Measurement Procedure ....................................................................................................... 14 7.4.2 Measurement Results ............................................................................................................ 14 7.5 RADIATED SPURIOUS EMISSIONS - FCC: SECTION 15.245(B); IC:RSS-210 ANNEX 7 ................... 15 7.5.1 Measurement Procedure ....................................................................................................... 15 7.5.2 Duty Cycle Correction .......................................................................................................... 15 7.5.3 Measurement Results ............................................................................................................ 16 7.5.4 Sample Calculation: ............................................................................................................. 17 8 CONCLUSION ................................................................................................................................... 17 FCC ID: NCG-MS180D ACS Report: 11-0249.W03.11.A Advanced Compliance Solutions Page 3 1 GENERAL 1.1 Purpose The purpose of this report is to demonstrate compliance with Part 15 Subpart C of the FCC’s Code of Federal Regulations and Industry Canada’s Radio Standards Specification RSS-210. 1.2 General The EUT is a motion detecting head that is to be installed in conjunction with an outdoor light. It utilizes infrared, photometric and Doppler detecting devices to automatically turn on and off a light fixture. Technical Information: Band of Operation: 10,500MHz – 10,550MHz Number of Channels: 1 Modulation Format: Pulsed CW Antenna Type: Integral PCB Operating Voltage: 120VAC / 60Hz Model Variants: Model # Floodlight Description Max. Total Wattage Color MS-180D N/A - Sensor only300Bronze MS-180DW N/A - Sensor only300White MS-185D Twin PAR lamp holders300Bronze…

Text truncated - open the document above for the full version.

5015 B.U. Bowman Drive Buford, GA 30518 USA Voice: 770-831-8048 Fax: 770-831-8598 Certification Exhibit FCC ID: NCG-MS180D FCC Rule Part: 15.245 ACS Project Number: 11-0249 Manufacturer: Cooper Lighting, LLC Test Setup Photos FCC ID: NCG-MS180D ACS Project: 11-0249 Advanced Compliance Solutions Page 2 Figure 1: Conducted Emissions Figure 2: Conducted Emissions FCC ID: NCG-MS180D ACS Project: 11-0249 Advanced Compliance Solutions Page 3 Figure 3: Conducted Emissions Figure 4: Radiated Emissions FCC ID: NCG-MS180D ACS Project: 11-0249 Advanced Compliance Solutions Page 4 Figure 5: Radiated Emissions Figure 6: Radiated Emissions FCC ID: NCG-MS180D ACS Project: 11-0249 Advanced Compliance Solutions Page 5 Figure 7: Radiated Emissions Figure 8: Radiated Emissions
