NEX-9304S-27TXRadio Control Toy Transmitter

www.tuv.com Appendix 5 Prüfbericht - Nr.: Test Report No. 14010718 002 Seite 5 von 5 Page 5 of 5 The applicant declared that this user manual is of models 9456/9457/9485/9344/9356/9376/9462/9463/9409/9396/9404/9403 which consist of the transmitter 9304S.

www.tuv.com Appendix 3 Prüfbericht - Nr.: Test Report No. 14010718 002 Seite 1 von 2 Page 1 of 2 www.tuv.com Appendix 3 Prüfbericht - Nr.: Test Report No. 14010718 002 Seite 2 von 2 Page 2 of 2

www.tuv.com Appendix 5 Prüfbericht - Nr.: Test Report No. 14010718 002 Seite 4 von 5 Page 4 of 5 Label location

www.tuv.com Appendix 4 Prüfbericht - Nr.: Test Report No. 14010718 002 Seite 1 von 2 Page 1 of 2 www.tuv.com Appendix 4 Prüfbericht - Nr.: Test Report No. 14010718 002 Seite 2 von 2 Page 2 of 2

www.tuv.com Test Report No.: 14010718 002 Date: 03.01.2006 Page 2 of 12 Test Summary Radiated Emission of Carrier Frequency Result: Pass Spurious Radiated Emissions Result: Pass Bandwidth Measurement Result: Pass www.tuv.com Test Report No.: 14010718 002 Date: 03.01.2006 Page 3 of 12 Contents List of Test and Measurement Instruments.........................................................4 General Product Information ................................................................................5 Product Function and Intended Use.............................................................................................5 Circuit Description .........................................................................................................................5 Ratings and System Details ..........................................................................................................5 Independent Operation Modes......................................................................................................6 Submitted Documents ...................................................................................................................6 Related Submittal(s) Grants ..........................................................................................................6 Test Set-up and Operation Mode..........................................................................7 Principle of Configuration Selection ............................................................................................7 Test Operation and Test Software ................................................................................................7 Special Accessories and Auxiliary Equipment ...........................................................................7 Countermeasures to achieve EMC Compliance..........................................................................7 Test Methodology ..................................................................................................8 Radiated Emission .........................................................................................................................8 Field Strength Calculation .............................................................................................................8 Test Results ...........................................................................................................9 Radiated Emission of Carrier Frequency Subclause 15.227(a).........................................9 Spurious Radiated Emissions Subclause 15.227(b).......................................10 Bandwidth Measurement Subclause 15.227(b).......................................12 Appendix 1: Test Results Appendix 2: Test Setup Appendix 3: EUT External Photo Appendix 4: EUT Internal Photo Appendix 5: FCCID Label, Block Diagram, Schematics and User manual. www.tuv.com Test Report No.: 14010718 002 Date: 03.01.2006 Page 4 of 12 List of Test and Measurement Instruments Kind of Equipment Manufacturer Type S/N Test Receiver Rohde & Schwarz ESVS30 842807/009 Biconical Antenna Rohde & Schwarz HK116 841489/015 Log.-Periodic Antenna Rohde & Schwarz HL223 841516/017 Double Ridge Horn Antenna EMCO 3115 9002-3347 Spectrum Analyzer Rohde & Schwarz FSP30 1093.4495K30 www.tuv.com Test Report No.: 14010718 002 Date: 03.01.2006 Page 5 of 12 General Product Information Product Function and Intended Use The equipment under test (EUT) is a transmitter for a RC toy car operating at 27.145 MHz. The EUT has two control rods for commanding the forward, backward, left and right movement of the associated receiver. FCCID: NEX-9304S-27TX Model Product description 9304S Radio Control Toy Transmitter Circuit Description IC1 and the associated circuit act as AF-modulator. Q2 and the associated circuit act as a RF-Transmitter. Q1, XTAL and the associated circuit act as an oscillator. The EUT is using surface mount technology (SMT) electronic components on the PCB circuit. Ratings and System Details Transmitter Frequency range : 27.145MHz Number of channels : 1 Type of antenna : External wire antenna Power supply : Battery operated 9V Ports : none Protection Class : III www.tuv.com Test Report No.: 14010718 002 Date: 03.01.2006 Page 6 of 12 Independent Operation Modes The basic operation modes are: - Remote Control: On and Off For further information refer to User Manual Submitted Documents The submitted documents are listed as follow: - Circuit diagram - Block diagram - User manual - Label artwork Related Submittal(s) Grants This is a single application for certification of the transmitter. www.tuv.com Test Report No.: 14010718 002 Date: 03.01.2006 Page 7 of 12 Test Set-up and Operation Mode Principle of Configuration Selection Emission: The equipment under test (EUT) was configured to measure its highest possible radiation level. The test modes were adapted accordingly in reference to the instructions for use. Test Operation and Test Software Test operation should refer to test methodology. - There was no special software to exercise the device. Special Accessories and Auxiliary Equipment The product has been tested together with the following additional accessories: - none Countermeasures to achieve EMC Compliance The test sample, which has been tested, contained the noise suppression parts as described in the Circuit Diagram or the Technical Construction File. No additional measures were employed to achieve compliance. www.tuv.com Test Report No.: 14010718 002 Date: 03.01.2006 Page 8 of 12 Test Methodology Radiated Emission The radiated emission measurements were performed according to the procedures in ANSI C63.4-2003. The equipment under test (EUT) was placed at the middle of the 80 cm height turntable, and the turntable is 3 meters far from the measuring antenna. During the testing, the EUT was operated standalone and arranged for maximum emissions. The EUT was tested in three orthogonal planes. The investigation is performed with …

Text truncated - open the document above for the full version.

www.tuv.com Appendix 1 Prüfbericht - Nr.: Test Report No. 14010718 001 Seite 1 von 1 Page 1 of 1 136.96 kHz limit reachedAtt 20 dB 136.96 kHz A 136.96 kHz 136.96 kHz 32 kHz/ 136.96 kHz Start 26.96 MHz 136.96 kHz Stop 27.28 MHz 136.96 kHz RBW 10 kHz 136.96 kHz VBW 30 kHz 136.96 kHz SWT 5 ms 136.96 kHz 1 PK 136.96 kHz MAXH 136.96 kHz 136.96 kHz 136.96 kHz 136.96 kHz 136.96 kHz 136.96 kHz 136.96 kHz 136.96 kHz 136.96 kHz 136.96 kHz -100 -90 -80 -70 -60 -50 -40 -30 -20 -10 0 136.96 kHz Delta 2 [T1] -32.88 dB -183.040000000 kHz Marker 1 [T1] -34.41 dBm 27.143040000 MHz Delta 3 [T1] -31.21 dB 136.960000000 kHz 2 1 3 DELTA MARKER 3 136.96 kHz limit reached Date: 30.NOV.2005 17:44:03

www.tuv.com Appendix 2 Prüfbericht - Nr.: Test Report No. 14010718 002 Seite 1 von 1 Page 1 of 1 Set-up for Radiation Emission (Transmitter)
