NEX-9343-49-RXRC Car

INTERTEK TESTING SERVICES Ophoto1 Ophoto2

INTERTEK TESTING SERVICES Iphoto1 Iphoto2 INTERTEK TESTING SERVICES Iphoto3 Iphoto4 INTERTEK TESTING SERVICES Iphoto5

FCC ID: NEX-9343-49-RX Technical Description : The brief circuit description is listed as follows : - Q1 and associated circuit act as Super-regenerative Receiver. - Q2 & Q3 and associated circuit act as Baseband Signal Amplifier. - IC and associated circuit act as Decoder. - Q4 & Q5 and associated circuit act as Power Amplifier. - Q6 and associated circuit act as Switch for Lamp. - Q7 and associated circuit act as Audio Amplifier. - Q8 ∼ Q9 and associated circuit act as Motor Driver. Antenna Used : A permanent wire antenna has been used.

•The test results reported in this report shall refer only to the sample actually tested and shall not refer or be deemed to refer to bulk from which such a sample may be said to have been obtained. •This report shall not be reproduced except in full without prior authorization from Intertek Testing Services Hong Kong Limited •The evaluation data of the report will be kept for 3 years from the date of issuance. FCC ID : NEX-9343-49-RX Lucky Plastic Factory Limited Application For Certification (FCC ID: NEX-9343-49-RX) Superregenerative Receiver Model : 9343 WO# 0213638 WN/at November 12, 2002 INTERTEK TESTING SERVICES FCC ID: NEX-9343-49-RX i LIST OF EXHIBITS INTRODUCTION EXHIBIT 1:General Description EXHIBIT 2:System Test Configuration EXHIBIT 3:Emission Results EXHIBIT 4:Equipment Photographs EXHIBIT 5:Product Labelling EXHIBIT 6:Technical Specifications EXHIBIT 7:Instruction Manual EXHIBIT 8:Miscellaneous Information INTERTEK TESTING SERVICES FCC ID: NEX-9343-49-RX ii MEASUREMENT/TECHNICAL REPORT Lucky Plastic Factory Limited - MODEL: 9343 FCC ID: NEX-9343-49-RX November 12, 2002 This report concerns (check one:)Original Grant X Class II Change Equipment Type: Superregenerative Receiver (example: computer, printer, modem, etc.) Deferred grant requested per 47 CFR 0.457(d)(1)(ii)?Yes No X If yes, defer until: date Company Name agrees to notify the Commission by: date of the intended date of announcement of the product so that the grant can be issued on that date. Transition Rules Request per 15.37?Yes No X If no, assumed Part 15, Subpart B for intentional radiator Report prepared by:Wilbur Ng Intertek Testing Services 2/F., Garment Center, 576, Castle Peak Road, HONG KONG Phone:852-2173-8502 Fax:852-2742-9149 INTERTEK TESTING SERVICES FCC ID: NEX-9343-49-RX iii Table of Contents 1.0 General Description......................................................................................................................2 1.1 Product Description..................................................................................................................2 1.2 Related Submittal(s) Grants.....................................................................................................2 1.3 Test Methodology.....................................................................................................................3 1.4 Test Facility...............................................................................................................................3 2.0 System Test Configuration..........................................................................................................5 2.1 Justification...............................................................................................................................5 2.2 EUT Exercising Software.........................................................................................................5 2.3 Support Equipment List and Description................................................................................5 2.4 Equipment Modification..........................................................................................................6 2.5 Special Accessories...................................................................................................................6 3.0 Emission Results...........................................................................................................................8 3.1 Field Strength Calculation........................................................................................................9 3.2 Radiated Emission Configuration Photograph.....................................................................10 3.3 Radiated Emission Data.........................................................................................................11 4.0 Equipment Photographs............................................................................................................15 5.0 Product Labelling.......................................................................................................................17 6.0 Technical Specifications.............................................................................................................19 7.0 Instruction Manual.....................................................................................................................21 8.0 Miscellaneous Information........................................................................................................23 8.1Stabilization Waveform..........................................................................................................24 8.2 Emissions Test Procedures.....................................................................................................25 8.2 Emissions Test Procedures (cont'd).......................................................................................26 INTERTEK TESTING SERVICES FCC ID: NEX-9343-49-RX iv List of attached file Exhibit typeFile Descriptionfilename Test ReportTest Reportreport.pdf Operation DescriptionTechnical Descriptiondescri.pdf Test Setup PhotoRadiated Emissionradiated photos.pdf Test ReportBandwidth Plotbw.pdf External PhotoExternal Photoexternal photos.pdf Internal PhotoInternal Photointernal photos.pdf Block DiagramBlock Diagramblock.pdf SchematicsCircuit Diagramcircuit.pdf ID Label/LocationLabel Artwork and Locationlabel.pdf User ManualUser Manualmanual.pdf INTERTEK TESTING SERVICES FCC ID: NEX-9343-49-RX 1 EXHIBIT 1 GENERAL DESCRIPTION INTERTEK TESTING SERVICES FCC ID: NEX-9343-49-RX 2 1.0General Description 1.1Product Description The equipment under test (EUT) is a receiver for a RC Car operating at 49.860 MHz. The EUT is powered by four AA batteries. The EUT has an ON/OFF switch to control the power on or off. The EUT can be controlled to move forward or backward, to turn left or right, to switch the light on or off and to generate sound by the controller…

Text truncated - open the document above for the full version.

INTERTEK TESTING SERVICES Front View Back View
