FCCID: NEX-9405-49RX 1. Operation Description The equipment under test ( EUT) is a RC toy car operating at 49.860MHz. The forward, backward, left and right movement are controlled by the associated transmitter. 2. Circuit Description 1) Q1 and the associated circuit act as a RF-receiver. 2) IC1 and the associated circuit act an AF amplifier. 3) Q2-Q7 and the associated circuit act as a power amplifier for DC motor.

TÜV Rheinland Product Safety GmbH Am Grauen Stein D - 51105 Köln Appendix 5 Prüfbericht - Nr.: Test Report No. 14005578 002 Seite 2 von 4 Page 2 of 4

TÜV Rheinland Product Safety GmbH Am Grauen Stein D - 51105 Köln Prüfbericht - Nr.: Test Report No. 14005578 002 Seite 6 von 11 Page 6 of 11 3 General Product Information 3.1 Product Function and Intended Use The equipment under test ( EUT) is a RC toy car operating at 49.860MHz. The forward, backward, left and right movement are controlled by the associated transmitter. After construction checking and declaration from the manufacturer, it is deemed that that 9389, 9406, 9407 and 9408 are same in circuit design and PCB layout as 9405, they only differ in the cosmetic design. Hence, all testing was conducted on the representative model: 9405. FCCID: NEX-9405-49RX Model Product description 9389 3” R/C Smart 9405 Micro Subaru 9406 Micro Mitsubishi 9407 3” R/C Roadster 9408 Micro Citroen 3.2 Circuit Description 1) Q1 and the associated circuit act as a RF-receiver. 2) IC1 and the associated circuit act an AF amplifier. 3) Q2-Q7 and the associated circuit act as a power amplifier for DC motor. 3.3 Ratings and System Details Receiver Frequency range : 49.860MHz Number of channels : 1 Type of antenna : Permanently attached receiving antenna. Power supply : Rechargeable battery 2.4V. Ports : none Protection Class : III
