NHS-R9P136Surge Protective Devices

GREEN POWERLINK On-Line Energy Management Solution User Manual © Copyright 2012 The information contained herein is subject to change without notice. This document contains proprietary information, which is protected by copyright. No part of this document may be photocopied, reproduced, or translated into another language without the prior written consent. Feb. 2012 All Versions TABLE OF CONTENTS INTRODUCTION...................................................................... 2 HARDWARE FEATURES ......................................................... 3 INSTALLATION....................................................................... 5 Wireless Setup Range.......................................................................... 5 Install Smart Socket............................................................................ 5 Install Smart Power Strip ................................................................... 6 Install CT Smart Meter in the circuit breaker panel............................ 7 Prepare the electrical circuit breaker................................................................... 7 Connect the CT clamps & voltage wires to the curren & voltage input terminals..................................................................................... 8 Wiring Diagram .................................................................................................... 9 ENERGY MANAGEMENT GATEWAY INITIAL SETUP.............. 11 Browse and access Gateway within intranet network ...................... 11 Energy Gateway and Smart Metering Devices pairing instructions... 18 Change User ID and Password ......................................................... 22 Network Setup ................................................................................. 22 Electricity Cost and CO2 Emission Setup.......................................... 23 Outgoing Server Setup...................................................................... 24 Reset the Energy Gateway to Factory Default................................... 24 Reset to factory default from energy gateway web server................ 25 Browse and access Gateway from internet....................................... 25 GREEN POWERLINK On-Line Energy Management Solution V1.0 1 INTRODUCTION Thank you for purchasing the GREEN POWERLINK online energy management solution, an innovative product which is designed to manage home electricity usage efficiently and reduce home electricity bill. In an effort to reduce your electricity bills, why not first check out what appliance uses most energy in your home. The GREEN POWERLINK online energy management allows you to take control of home electricity usage while saving you money in the process. With GREEN POWERLINK, you can see how much electricity you are using and with greater awareness you’ll become more energy efficient. Fully educated with the critical energy information, you are naturally motivated to adopt new energy saving habits and reduce harmful carbon emission for our environment. The GREEN POWERLINK is the total solution for green inspiration, energy conservation, and surge protection for your everyday life. GREEN POWERLINK On-Line Energy Management Solution V1.0 2 GREEN POWERLINK On-Line Energy Management Solution V1.0 3 HARDWARE FEATURES ZigBee Tracking Smart SocketZigBee Tracking Smart Strip Surge Protected Outlet 180J Surge Protection ZigBee Link: 2.4GHz (IEEE 802.15.4) Transmission Time: 6 seconds Wireless Range: 100 ft in open area ZigBee Function: Router ZigBee Profile: Smart Energy 1.0 ZigBee Cluster: Simple Metering Green Surge Protected LED Indicator Manual ON/OFF Button w/ Green LED Indicator Security: AES 128 bits (Optional) Meet IEC 62053‐21 class I standard (1~1.5%) 6 Surge Protected Outlets 540J Surge Protection Red Grounded Fault LED Indicator R9P136A600R9P624NI00 ZigBee Tracking Smart SocketZigBee Tracking Smart Strip Transmission Time: 6 seconds ZigBee Function: Router ZigBee Cluster: Simple Metering Installation type: 1‐phase & 3‐wire CT Meter Input Voltage:100~240V CT Meter Input Current: 60A CT Meter Frequency: 50/60Hz CT Meter Accuracy: <1% at PF=1 Power Supply: Power acquired from electrical meter ZigBee Link: 2.4GHz (IEEE 802.15.4) Wireless Range: 100 ft in open area ZigBee Profile: Smart Energy 1.0 Security: AES 128 bits (Optional) Link up to 9 PowerLink energy tracking devices ZigBee Function: Coordinator Proprietary remote outlet on/off control Remote web browsing management & power on/off control Remote real time Cost, KWH, CO2 usage information display RJ45 Ethernet Port Connection Power Supply: AC/DC adaptor (included) GREEN POWERLINK On-Line Energy Management Solution V1.0 4 GREEN POWERLINK On-Line Energy Management Solution V1.0 5 INSTALLATION Wireless Setup Range The energy gateway and smart socket/strip/CT meter communicate with wireless technology. To ensure the communication with no interruption, please locate and setup energy gateway, smart socket/strip/CT meter within 100 Ft of range. Install Smart Socket The single outlet smart socket allows the user to track electricity consumption of individual home appliance and protect it against surge and voltage spikes. 1. Plug in the smart socket to a powered AC outlet. 2. Plug in the appliance into the smart socket outlet. 3. The outlet power can be manually turned ON/OFF by pressing the “Manual ON/OFF” button on the smart socket. You may also control the outlet power remotely by using the energy monitor (see the operation instruction). 4. Perform initial energy monitor and smart socket pair up (see the operation instruction). PROTECTED LED LIGHT This LED light illuminates to indicate that the surge protection is active and protecting equipments from power surges. Manual ON/OFF” button M9PC020000M9PG040000 Install Smart Power Strip The smart power strip allows the user to track electricity consumption of group home appliances in the same area and protect it against surge and voltage spikes. 1…

Text truncated - open the document above for the full version.

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 3.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (current) 2.0 3.0 Jan-31-2012 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 3.0 Aug. 15, 2012 To: SIEMIC, INC. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Project and Product Certification Representative Authorization Letter We, Powertech Industrial Co Ltd. hereby authorize SIEMIC, INC. to act as a Certification Body for certifying for the following project(s): Product Name: Surge Protective Devices Model Name: R9P136A600 We affirm that between SIEMIC and Powertech Industrial Co Ltd., any difference in understanding, including test plan, measurement methods, applicable standards and relevant procedures and processes have been resolved prior to commencement of testing activities. Sincerely, George Lee / Director Powertech Industrial Co Ltd. 10F, No. 407, Chung Shan Rd., Sec 2 Chung Ho City, Taipei Hsien, 235 Taiwan

SCS-F19: Confidentiality Request Letter Page 1 of 2 Rev 3.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (current) 2.0 3.0 Jan-31-2012 SCS-F19: Confidentiality Request Letter Page 2 of 2 Rev 3.0 Aug. 15, 2012 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: NHS-R9P136 We hereby request confidential treatment of information accompanying this application as outlined below: - Block Diagram - Schematics - Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, George Lee / Director Powertech Industrial Co Ltd. 10F, No. 407, Chung Shan Rd., Sec 2 Chung Ho City, Taipei Hsien, 235 Taiwan

Powertech Industrial Co Ltd Surge Protective Devices FCC ID : NHS-R9P136 EUT External Photos Photo 1 General Appearance (Front View) Photo 2 General Appearance (Back View) Powertech Industrial Co Ltd Surge Protective Devices FCC ID : NHS-R9P136 Photo 3 General Appearance (Side View) Photo 4 General Appearance (Side View)
